- Page 1 USER USER PE-2000 Manual Manual PCI Express x4, 2-channel/ 4-channel Gigabit LAN, IEEE 802.3at Compliant Intel ® I210 PoE Expansion Card 1.0.0 Edition 20150713...
- Page 2 Record of Revision Version Date Page Description Remark 07/13/2015 Official Release...
-
Page 3: Declaration Of Conformity
This manual is released by Vecow Co., Ltd. for reference purpose only. All product offerings and specifications are subject to change without prior notice. It does not represent commitment of Vecow Co., Ltd. Vecow shall not be liable for direct, indirect, special, incidental, or consequential damages arising out of the use of the product or documentation, nor for any infringements upon the rights of third parties, which may result from such use. -
Page 4: Order Information
Order Information Part Number Description ® PE-2002 Intel I210 2-CH PCI Express PoE Expansion Card ® PE-2004 Intel I210 4-CH PCI Express PoE Expansion Card... -
Page 5: Table Of Contents
1.3.1 Specifications of Vecow PE-2002 1.3.2 Specifications of Vecow PE-2004 1.4 Mechanical Dimension 1.4.1 PE-2002 1.4.2 PE-2004 CHAPTER 2 GETTING TO KNOW YOUR PE-2000 2.1 Packing List 2.2 I/O and Indication 2.2.1 LED1 CN3 CN4 CN5 CN6 2.2.2 CN1 2.2.3 CN2 CHAPTER 3 GETTING START 3.1 Installing PE-2002/ PE-2004... -
Page 6: Chapter 1 General Introduction
GENERAL INTRODUCTION 1.1 Overview PE-2000 is a series of gigabit Ethernet (GigE) card, up to 4 independent channels, and compatible with IEEE 802.3at PoE for power sourcing equipment (PSE) devices. Just simply by RJ45 connection, Vecow PE- 2000 is enabled to provide not only 10/ 100/ 1000 Mbps gigabit data rate but also up to 25.5W at 48V DC power delivery. -
Page 7: Product Specification
1.3 Product Specification 1.3.1 Specifications of Vecow PE-2002 Ethernet Interface PCI Express x4 ® Chipset 2 Intel I210 Gigabit LAN Data Rate 10/ 100/ 1000 Mbps (Vary by attached Ethernet device) Jumbo Frame 9.5KB Link Aggregation (LAG) Present Connector 8-pin RJ45 PoE Standard IEEE 802.3at compliant... -
Page 8: Specifications Of Vecow Pe-2004
1.3.2 Specifications of Vecow PE-2004 Ethernet Interface PCI Express x4 ® Chipset 4 Intel I210 Gigabit LAN Data Rate 10/ 100/ 1000 Mbps (Vary by attached Ethernet device) Jumbo Frame 9.5KB Link Aggregation (LAG) Present Connector 8-pin RJ45 PoE Standard IEEE 802.3at compliant... -
Page 9: Mechanical Dimension
1.4 Mechanical Dimension 1.4.1 PE-2002 168 (6,6”) 21 (0,8”) 98 (3,9”) 111 (4,4”) 121 (4,8”) Unit: mm (inch) 1.4.2 PE-2004 168 (6,6”) 21 (0,8”) 98 (3,9”) 111 (4,4”) 121 (4,8”) Unit: mm (inch) ©Vecow PE-2000 User Manual GENERAL INTRODUCTION... -
Page 10: Chapter 2 Getting To Know Your Pe-2000
GETTING TO KNOW YOUR PE-2000 2.1 Packing List Item Description PE-2000, PCI Express x4 PoE , 2-Channel/ 4-Channel, ® Gigabit, IEEE 802.3at Compliant Intel I210 PCI Express Expansion Card (According to the configuration you order.) • Accessory box, which contains •... -
Page 11: I/O And Indication
LAN 3 LAN 4 LAN 4 LAN 3 LAN 2 LAN 1 PoE Power LED PE-2000 equipped with 4 IEEE 802.3at PoE ports for transmitting power as much as 25.5W / 48V per port and 1000BASE-T gigabit data signals over standard Ethernet CAT-5/CAT-6 cable. Every PoE port ®... -
Page 12: Cn1
2.2.2 CN1 The PE-2000 offers a 16-bit Isolated DIO (8-DI / 8-DO) connector. Each bit of DI and DO equipped with a photo-coupler for protection. A power buffer device TPD2007F integrated in 8-DO circuit for industrial applications. Pin No. Definition Pin No. -
Page 13: Cn2
1 Pin +12V CN 2 The PE-2000 also equipped with one 4-pin power plug (12V, 6A max) for additional power supply. For most cases, the power obtained from PCIe bus is sufficient for the PoE devices, and you do not need to supply extra power to the card. -
Page 14: Chapter 3 Getting Start
GETTING START 3.1 Installing PE-2002/ PE-2004 Step 1. Insert PE-2000 golden finger and PCI bracket into PCIe socket carefully. Step 2. Make sure golden finger and PCI bracket was inserted smoothly. GETTING START... - Page 15 Step 3. Make sure the bracket aligns screw hole. Step 4. Fasten the M3 screw. ©Vecow PE-2000 User Manual GETTING START...
-
Page 16: Chapter 4 Driver Installation And Setting
DRIVER INSTALLATION AND SETTING 4.1 Driver Installation This section describes: How to install drivers for PE-2002/ PE-2004 PoE Card. System OS: Windows XP, Windows 7 32-bit, Windows 7 64-bit, Windows 8. Step 1. Execute Intel_i210_PROWin64.exe and then go "Next" step. DRIVER INSTALLATION AND SETTING... - Page 17 Step 2. Select "Modify" and then go to "Next" step. Step 3. Select program features. DRIVER INSTALLATION AND SETTING ©Vecow PE-2000 User Manual...
- Page 18 Step 4. Click the "Install" icon to begin the installation. Step 5. Install wizard completed. DRIVER INSTALLATION AND SETTING...
-
Page 19: Jumbo Frame
After installing the driver for Intel I210 GbE controller, you can get the enhance function that called jumbo frame, please find more instruction as below. Step 1. Open the "Control Panel → Device Manager → Network adapters". DRIVER INSTALLATION AND SETTING ©Vecow PE-2000 User Manual... - Page 20 ® Step 2. Select anyone "Intel I210 Gigabit Network Connection #xx", right Click and select "Properties", a property dialog appears and Click on the Advanced page. DRIVER INSTALLATION AND SETTING...
- Page 21 Step 3. Select the "Jumbo Packet", settings, and select the expected jumbo frame size. DRIVER INSTALLATION AND SETTING ©Vecow PE-2000 User Manual...
-
Page 22: Link Aggregation
4.3 Link Aggregation Step 1. Here shows another enhance network function "Teaming". DRIVER INSTALLATION AND SETTING... - Page 23 Step 2. You could multi-select network device to get a high performance net DRIVER INSTALLATION AND SETTING ©Vecow PE-2000 User Manual...
- Page 24 DRIVER INSTALLATION AND SETTING...
- Page 25 No part of this publication may be reproduced in any form or by any means, electric, photocopying, recording or otherwise, without prior authorization of the publisher. The rights of all the brand names, product names and trademarks belong to their respective owners. © Vecow Co., Ltd. 2015. All rights reserved.
