Vecow PE-3004 User Manual

Pe-3000 series pci express x4/ 4-channel gigabit lan, ieee 802.3at compliant intel i350 poe+/lan bypass expansion card
Hide thumbs
Table of Contents

Advertisement

Quick Links

IEEE 802.3at Compliant Intel
PE-3000
PCI Express x4/ 4-channel Gigabit LAN,
®
I350 PoE
+
/LAN Bypass Expansion Card
USER
USER
Manual
Manual
1.0.0 Edition 20180525

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PE-3004 and is the answer not in the manual?

Questions and answers

Related Manuals for Vecow PE-3004

Summary of Contents for Vecow PE-3004

  • Page 1 USER USER PE-3000 Manual Manual PCI Express x4/ 4-channel Gigabit LAN, IEEE 802.3at Compliant Intel ® I350 PoE /LAN Bypass Expansion Card 1.0.0 Edition 20180525...
  • Page 2 Record of Revision Version Date Page Description Remark 05/25/2018 Official Release...

  • Page 3: Declaration Of Conformity

    This manual is released by Vecow Co., Ltd. for reference purpose only. All product offerings and specifications are subject to change without prior notice. It does not represent commitment of Vecow Co., Ltd. Vecow shall not be liable for direct, indirect, special, incidental, or consequential damages arising out of the use of the product or documentation or any infringements upon the rights of third parties, which may result from such use.
  • Page 4 Part Number Description ® PE-3004 Intel I350 4-Channel PCI Express Card with PoE ® PE-3014 Intel I350 4-CH PCI Express Card with advanced 2-pair LAN Bypass...

  • Page 5: Table Of Contents

    CHAPTER 2 GETTING TO KNOW YOUR PE-3000 2.1 Packing List 2.2 PE-3004(M) I/O and Indication 2.3 PE-3014(M) I/O and Indication CHAPTER 3 GETTING START 3.1 Installing PE-3004/ PE-3014 APPENDIX A : PoE Guide (PE-3004/3004M only) APPENDIX B : Software Functions...

  • Page 6: Chapter 1 General Introduction

    IEEE 802.3az Energy Efficient Ethernet (EEE) and DMA Coalescing (DMAC) Power Management functions. Just simply by RJ45 or optional rugged M12 connections, Vecow PE-3000 is enabled to provide up to 1000Mbps data rate each port with teaming functions, link aggregation (LAG), 9.7K Jumbo Frame, IEEE 1588 Precision Time Protocol (PTP),...

  • Page 7: Product Specification

    1.3 Product Specification 1.3.1 Specifications of Vecow PE-3004/3004M Ethernet Interface PCI Express x4 ® Chipset 1 Intel Ethernet Controller I350 Data Rate 10/100/1000 Mbps Jumbo Frame Up to 9728 byte Link Aggregation (LAG) Present Connector • 8-pin RJ45 • A-coded M12 (Optional) PoE Standard IEEE 802.3at compliant...

  • Page 8: Specifications Of Vecow Pe-3014/3014M

    1.3.2 Specifications of Vecow PE-3014/3014M Ethernet Interface PCI Express x4 ® Chipset 1 Intel Ethernet Controller I350 Data Rate 10/100/1000 Mbps Jumbo Frame Up to 9728 byte Link Aggregation (LAG) Present Connector • 8-pin RJ45 • A-coded M12 (Optional) Environment Operating Temperature -25°C to 70°C (-13°F to 158°F)

  • Page 9: Mechanical Dimension

    167.6 (6.60”) 8.5 (0.33”) 6.5 (0.25”) Ø3.2 (0.13”) 111.1 (4.38”) 101.2 (3.98”) 95.6 (3.76”) 81.1 (3.19”) 62.0 (2.44”) 43.0 (1.69”) 23.9 (0.94”) 9.6 (0.38”) 4.5 (0.18”) 0.0 (0.00”) 10.8 3.7 (0.15”) (0.43”) Unit: mm (inch) ©Vecow PE-3000 User Manual GENERAL INTRODUCTION...

  • Page 10: Chapter 2 Getting To Know Your Pe-3000

    PE-3000, PCI Express x4 PoE /LAN Bypass, 4-Channel, ® GigE, IEEE 802.3at Compliant Intel I350 PCI Express Expansion Card (It is based on the configuration you ordered.) • Accessory box, which contains Vecow Drivers & Utilities DVD GETTING TO KNOW YOUR PE-3000...

  • Page 11: Pe-3004(M) I/O And Indication

    LAN 2 LAN 4 LAN 4 LAN 3 LAN 2 LAN 1 PoE Power LED PE-3004 is equipped with 4 IEEE 802.3at PoE ports for transmitting power as much as 25.5W / 48V per port and 1000BASE-T gigabit data signals over standard Ethernet CAT-5/CAT-6 cable.
  • Page 12 2.2.2 Power Input CN 3 The PE-3004 is also equipped with one 4-pin power plug (12V, 6A max) for additional power supply. For most cases, the power obtained from PCIe bus is sufficient for the PoE devices, and you do not need to supply extra power to the card.
  • Page 13 LAN 3 Ground Ground Ground Ground SPD1_0 LAN 2 SPD3_0 LAN 4 SPD1_1 LAN 2 SPD3_1 LAN 4 SPD1_2 LAN 2 SPD3_2 LAN 4 SPD1_3 LAN 2 SPD3_3 LAN 4 Ground Ground ©Vecow PE-3000 User Manual GETTING TO KNOW YOUR PE-3000...
  • Page 14 2.2.4 PoE Power On/Off SW 1 PE-3004 controls LTC4266 PoE Power ON/OFF via SMBUS. LTC4266 Address Setting as below: SW 1 Address 0x40 1-ON 2-ON 3-ON 4-ON 0x42 (Default) 1-OFF 2-ON 3-ON 4-ON 0x44 1-ON 2-OFF 3-ON 4-ON 0x46 1-OFF...

  • Page 15: Pe-3014(M) I/O And Indication

    There are four 8-pin RJ-45 jacks supporting 10/100/1000 Mbps Ethernet connections in PE-3014. Pin No. 10/ 100 Mbps 1000 Mbps E_TX+ MDI0_P E_TX- MDI0_N E_RX+ MDI1_P ---- MDI2_P ----- MDI2_N E_RX- MDI1_N ----- MDI3_P ------ MDI3_N ©Vecow PE-3000 User Manual GETTING TO KNOW YOUR PE-3000...
  • Page 16 2.3.3 IEEE 1588 CN 1 Intel i350 supports a header for IEEE 1588 related applications. Pin No. Description LAN Port Pin No. Description LAN Port Ground Ground SPD0_0 LAN 1 SPD2_0 LAN 3 SPD0_1 LAN 1 SPD2_1 LAN 3 SPD0_2 LAN 1 SPD2_2 LAN 3...
  • Page 17 JP1/JP2 controls LAN bypass enabling and disabling. Jumper Setting: Jumper Setting Description *LAN1 LAN2 LAN bypass Enable LAN1 LAN2 LAN bypass Disable Jumper Setting Description *LAN3 LAN4 LAN bypass Enable LAN3 LAN4 LAN bypass Disable ©Vecow PE-3000 User Manual GETTING TO KNOW YOUR PE-3000...

  • Page 18: Chapter 3 Getting Start

    GETTING START 3.1 Installing PE-3004/ PE-3014 Step 1. Insert PE-3000 golden finger and PCI bracket into PCIe socket carefully. Step 2. Make sure golden finger and PCI bracket are inserted smoothly. GETTING START...
  • Page 19 Step 3. Make sure the bracket aligns screw hole. Step 4. Fasten the M3 screw. ©Vecow PE-3000 User Manual GETTING START...

  • Page 20: Appendix A : Poe Guide (Pe-3004/3004M Only)

    APPENDIX A : PoE Guide (PE-3004/3004M only) A.1 Function Description The PE-3000 offers a 4-port PoE or 2-pair LAN Bypass. Pin No. Definition Pin No. Definition LAN1 POE 0 LAN3 POE 2 LAN2 POE 1 LAN4 POE 3 Appendix A...
  • Page 21 5. UE-1000: USB (IDUE-1000 = IDPE-3000 >> 1 & 3 | IDPE-3000 << 2 & 4) PoE ON/OFF vs Slave address setting as below: SW 1 Slave Address 0x40 0x42 (Default) 0x44 0x46 0x48 0x4A 0x4C 0x4E 0x50 0x52 0x54 0x56 0x58 0x5A 0x5C 0x5E Appendix A ©Vecow IVH-9000 User Manual...
  • Page 22 A.2 Software Package Contain Distribution folder include x32 and x64 versions, use batch file for installation. There are included as fallowed: Win7_32.bat: Installation for 32-bit driver Win7_64.bat: Windows update package which driver required (need to restart), and Installation for 64-bit driver Win8_32.bat, Win8_64.bat: Installation for driver, and guideline to Framework 3.5 distribution for sample...
  • Page 23 User setting, POE port writable of POE configuration. Use for Write button activate. POE port mode texts (port 4 ~ port 1): User setting, POE port mode of POE configuration. Use for Write button activate. Appendix A ©Vecow IVH-9000 User Manual...

  • Page 24: Appendix B : Software Functions

    APPENDIX B : Software Functions B.1 Driver API Guide In Runtime folder, on PE3K.h: _DLL_IMPORT_ definition is used on LoadLibrary API for PE3K.dll. PE3K_EXPORTS definition is used on PE3K.dll building. Otherwise, that is used to compile with PE3K.lib BOOL Initial(BYTE Scan, BYTE ID) Initial card for POE Scan: POE ID scan type 2: Auto scan;...
  • Page 25 ID ([3:0]): POE ID POE ([3:0]): POE state, pin setting by hexadecimal bitmask 1: On; 0: Off Return: TRUE (1): Success; FALSE (0): Fail (Initial error, or out of range error, or hardware problem) Appendix B ©Vecow IVH-9000 User Manual...
  • Page 26 No part of this publication may be reproduced in any form or by any means, electric, photocopying, or recording, without prior authorization from the publisher. The rights of all the brand names, product names, and trademarks belong to their respective owners. © Vecow Co., Ltd. 2018. All rights reserved.

This manual is also suitable for:

Pe-3014
