Vecow UE-1000 User Manual

Pci express x4, 8 ports/ 4 ports usb 3.0 expansion card
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
UE-1000
PCI Express x4, 8 Ports/ 4 Ports USB 3.0 Expansion Card
USER
USER
Manual
Manual
1.0.0 Edition 20150213

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UE-1000 and is the answer not in the manual?

Questions and answers

Related Manuals for Vecow UE-1000

Summary of Contents for Vecow UE-1000

  • Page 1 USER USER UE-1000 Manual Manual PCI Express x4, 8 Ports/ 4 Ports USB 3.0 Expansion Card 1.0.0 Edition 20150213...
  • Page 2 Record of Revision Version Date Page Description Remark 01/20/2015 Preliminary Release 02/13/2015 Offical Release...

  • Page 3: Declaration Of Conformity

    Declaimer This manual is released by Vecow Co., Ltd. for reference purpose only. All product offerings and specifications are subject to change without prior notice. It does not represent commitment of Vecow Co., Ltd. Vecow shall not be liable for direct, indirect,...

  • Page 4: Order Information

    Order Information Part Number Description UE-1004 PCI Express x4, 4 Ports USB 3.0 Expansion Card UE-1008 PCI Express x4, 8 Ports USB 3.0 Expansion Card...

  • Page 5: Table Of Contents

    1.3.1 Specifications of Vecow UE-1004 1.3.2 Specifications of Vecow UE-1008 1.4 Mechanical Dimension 1.4.1 UE-1004 1.4.2 UE-1008 2 GETTING TO KNOW YOUR UE-1000 CHAPTER 2.1 Packing List 2.2 I/O and Indication 2.3 Jumper Setting for Current Limit 3 GETTING START CHAPTER 3.1 Installing UE-1004/ UE-1008...

  • Page 6: General Introduction

    GENERAL INTRODUCTION 1.1 Overview UE-1000 is a series of USB 3.0 expansion cards which is powered by independent USB 3.0 host chips. With the latest USB 3.0 technology, UE-1000 series USB 3.0 expansion card delivers 10-times data transfer rate, up to 5Gbps, to make performance driven plug-and-...

  • Page 7: Product Specification

    1.3 Product Specification 1.3.1 Specifications of Vecow UE-1004 Interface PCI Express x4 Chipset 4 Renesas μPD720202 Host Controllers Compliant with Universal Serial Bus 3.0 specification Revision 1.0 ® Compliant with Intel xHCI specification Revision 1.0 Connector 4 USB 3.0 Type-A Connectors...

  • Page 8: Mechanical Dimension

    1.4 Mechanical Dimension 1.4.1 UE-1004 180.44 (7.1”) 21.1 (0.83”) 167.65 (6.6”) 9.5 (0.37”) 98.4 (3.87”) 19 (0.75”) 121 (4.76”) Unit: mm (inch) 1.4.2 UE-1008 180.44 (7.1”) 21.1 (0.83”) 167.65 (6.6”) 9.5 (0.37”) 98.4 (3.87”) 121 (4.76”) Unit: mm (inch) GENERAL INTRODUCTION...

  • Page 9: Chapter 2 Getting To Know Your Ue-1000

    Vecow Drivers & Utilities DVD 2.2 I/O and Indication 2.2.1 USB Connectors The UE-1000 comes with 8 USB 3.0. These USB 3.0 ports allow data transfers up to 5 Gbps. The controller supports SuperSpeed (SS), High-Speed (HS), Full-Speed (FS) and Low-Speed (LS) traffic on the bus.

  • Page 10: Jumper Setting For Current Limit

    2.3 Jumper Setting for Current Limit 2.3.1 Current limit jumpers User-configurable 900mA and 1500mA current limit. Jumper Pin 900 mA 1-2 (Default) 1500 mA GETTING TO KNOW YOUR UE-1000...

  • Page 11: Getting Start

    GETTING START 3.1 Installing UE-1004/ UE-1008 Step 1. Insert UE-1004/ UE-1008 golden finger and PCI bracket into PCIe socket carefully. Step 2. Make sure golden finger and PCI bracket was inserted smoothly. ©Vecow UE-1000 User Manual GETTING START...
  • Page 12 Step 3. Make sure the bracket aligns screw hole. Step 4. Fasten the M3 screw. GETTING START...

  • Page 13: Driver Installation And Setting

    DRIVER INSTALLATION AND SETTING 4.1 Driver Installation System OS: Windows You can install the Windows driver for Vecow UE-1004 / UE-1008 manually by following the steps listed below : Step 1. Execute RENESAS-USB3-Host-Driver-30230-setup.exe and then go “Next” step. DRIVER INSTALLATION AND SETTING...
  • Page 14 Step 2. Accept the terms of the license agreement and then go “Next” step. Step 3. Click “Install” to begin installation. DRIVER INSTALLATION AND SETTING...
  • Page 15 Step 4. Waiting for driver installation. Step 5. Click into “Control Panel” “Device Manager”. Check Vecow UE-1004/UE-1008 driver setup success. DRIVER INSTALLATION AND SETTING ©Vecow UE-1000 User Manual...

  • Page 16: Power On/ Off Control

    4.2 Power On/ Off Control UE-1000 series include USB port power ON/OFF function and help to maintain on field operation. Step 1. Every power source of USB port are independent, we could ON/OFF directly thought SW thread. The device control Line is SMbus that connect to all SMbus devices on the PCB.
  • Page 17 Step 3. SMbus IO Address Mapping table DRIVER INSTALLATION AND SETTING ©Vecow UE-1000 User Manual...
  • Page 18 Step 4. To Access SMBus register , below shows standard Read/Write scenarios. You refer to demo code that follow SMbus protocol to complete the process. void smbwrite(Data_BYTE device_id, Data_BYTE reg_no, unsigned char data) Data_BYTE err_no; WriteAByte(SMBus_Host_Status, 0xFF); Delay_T(1); err_no = Check_SMBus_Ready(); if (err_no != 0) return;...
  • Page 19 = Check_SMBus_Ready(); if (err_no != 0) return err_no; WriteAByte(SMBus_Trans_Addr, device_id+1); WriteAByte(SMBus_Host_Command, reg_no); WriteAByte(SMBus_Host_Control, 0x48); Delay_T(20); err_no = Check_SMBus_Ready(); if (err_no != 0) return err_no; *dat = ReadAByte(SMBus_Host_Data0); return (err_no); //Data 0 DRIVER INSTALLATION AND SETTING ©Vecow UE-1000 User Manual...
  • Page 20 USB port ON/OFF register = 0x02 Reg.0x20 Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 PE-1008 PE-1004 * If more help is needed, please contact Vecow Technical Support DRIVER INSTALLATION AND SETTING...
  • Page 21 No part of this publication may be reproduced in any form or by any means, electric, photocopying, recording or otherwise, without prior authorization of the publisher. The rights of all the brand names, product names and trademarks belong to their respective owners. © Vecow Co., Ltd. 2015. All rights reserved.
