P8
P.6
CB34VWP
SUPER LONG RANGE IR CAMERA
INSTRUCTION MANUAL
1.FEATURES:
◎ Sony 1/3" Color Exview™ CCD 700TVL Effio-S 960H.
◎ High Sensitivity、True Color reproduced in Day time
◎ Built in 12 Super Output and 6 high output LEDs Automatically and
Precisely Switch to ON/OFF through Micro Proessor
◎ IR Range: More than 200 Meters/ 656 Ft.
◎ Mechanical IR Cut Filter Buit in for longer IR range.
◎ Lens External Adjustment through Side Hinged Lid
◎ Multi-Language OSD setup menu
◎ ATR(Dgital Wide Dynamic Range), Motion Detection,
Y; C; YC Noise Reduction, High Light Compensation, Privacy
◎ Multiple PCBs Design, Reliable Circuitry & Safety
◎ Weather Proof IP-65 Rated
When connectting the power on IR-illuminator it will
turn on to detect for a few seconds and then turn off
automatically.
4. OPERATION GUIDE:
Zoom / Focus / OSD adjustment
5. SYSTEM CONNECTION
AC24V input
P.1
P.3
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for NST CB34VWP
Summary of Contents for NST CB34VWP
- Page 1 CB34VWP SUPER LONG RANGE IR CAMERA INSTRUCTION MANUAL 1.FEATURES: ◎ Sony 1/3” Color Exview™ CCD 700TVL Effio-S 960H. ◎ High Sensitivity、True Color reproduced in Day time ◎ Built in 12 Super Output and 6 high output LEDs Automatically and Precisely Switch to ON/OFF through Micro Proessor ◎...
-
Page 2: System Components
2.CAUTIONS: 1、Before attempting to connect this product,please read this manual completely. 2、Ensure the supply voltage is correct as specified for the particular variant of the camera before operation. 3、Never face the camera toward the sun directly. 4、Do not attempt to service this unit yourself unless you are authorized to do so.Opening or removing cover may expose you to dangerous or other hazardous materials.
