Inner Range 3000 Installation Manual

Weatherproof terminal module
Hide thumbs Also See for 3000:

Advertisement

Quick Links

Revision 1.0 March 2006.
Model
Model
Model
Model 3OOO / Access 4OOO
Model
Weatherproof Terminal Module.
Overview
The Weatherproof Terminal Module currently provides the following operations:
1. Single Door PIN code Access control including the "auto area off" and REX/REN button options.
Note: A Wiegand Reader can also be connected in parallel with the keypad to provide "PIN or Card" operation.
2. Control and status indication of a single "Associated Area" assigned to the Module, or a User's "Extra Area".
The Weatherproof Terminal supports all Concept 3000/4000 1 to 8 digit PIN codes.
The keypad features a CODE lamp (green), an ARMED lamp (red), two general purpose yellow lamps, numeric keys 0 to 9, an OK
key and an ON/OFF key. Beeper feedback is provided for each key press and the beeper can also be controlled by an Auxiliary
output.
Two methods of keypad tamper protection are provided:
-A built-in optical device detects removal of the keypad from its mounting surface.
-Presence of the keypad connections is monitored via the data inputs on the PCB.
In addition to this, a Tamper switch input is also provided on the PCB for cabinet tamper monitoring.
IMPORTANT NOTES:
1) Control Module Firmware must be V5.60 or later.
2) The Weatherproof Terminal is enrolled on the LAN and programmed as a Reader Module. (MENU, 7, 2, 4) When programming;
options relating to "2nd Door / 2nd Lift", "2 Door Mode", "Reader 2..." and "Backup Cards" should not be programmed.
3) Separate Inputs are provided for Exit & Entry buttons. Regardless of whether these inputs are used for Exit or Entry buttons, they
must be programmed for Exit button operation. i.e. Select the "B"utton option in the "Exit Options" of the Access Group
assigned to the Door. Note that Review will therefore always record the direction for the button operation as "Exit".
4) Zones Rnn:Z02 to Z05, Z07 and Z08 do not exist on the Weatherproof Terminal Module and therefore must not be programmed.
5) Auxiliaries Rnn:X07 and X08 do not physically exist on the Weatherproof Terminal Module and therefore can only be used as
phantom Auxiliaries.
Installing the Weatherproof Terminal.
Weatherproof Terminal Parts List
- Weatherproof Terminal Module PCB assembly.
- Inner Range Weatherproof keypad with 1 metre connection cable.
- Installation Manual. (This document)
- Installation Kit in Plastic bag containing:
-
1 x 3 Way Plug on Screw Terminal.
-
3 x 6 Way Plug on Screw Terminals.
-
1 x 5 Way Plug on Screw Terminal.
-
1 x 6.3mm Quick Connect.
-
1 x 500mA Amp Fuse. (Spare)
-
2 x Jumper Link 0.1".
-
5 x 2k2 End-of-line resistors. (red-red-black-brown-brown)
-
5 x 6k8 End-of-line resistors. (blue-grey-black-brown-brown)
-
1 x 1N4004 protection diodes. (For connecting across lock strike)
3OOO / Access 4OOO
3OOO / Access 4OOO
3OOO / Access 4OOO
3OOO / Access 4OOO
P/N: 995010
INSTALLATION MANUAL
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the 3000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Inner Range 3000

  • Page 1 2. Control and status indication of a single “Associated Area” assigned to the Module, or a User’s “Extra Area”. The Weatherproof Terminal supports all Concept 3000/4000 1 to 8 digit PIN codes. The keypad features a CODE lamp (green), an ARMED lamp (red), two general purpose yellow lamps, numeric keys 0 to 9, an OK key and an ON/OFF key.
  • Page 2 W W W W W eatherproof T eatherproof T eatherproof T eatherproof T eatherproof Terminal Module. erminal Module. erminal Module. erminal Module. erminal Module. Installation Manual. Keypad layout and functions. Lamp 1 Lamp 2 Lamp 3 Lamp 4 Green Yellow Yellow Mounting hole Numeric keys...
  • Page 3: Installation

    Revision 1.0 March 2006. Installation Installation environment. Module PCB: 0º to 40º Celsius and 15% to 85% Relative humidity (non-condensing) Keypad: -20º to 70º Celsius. Moisture and Dust rating = IP68. Dimensions. PCB dimensions: Length: 96mm Width: 96mm Keypad dimensions: Height: 130mm Width:...
  • Page 4 W W W W W eatherproof T eatherproof T eatherproof T eatherproof T eatherproof Terminal Module. erminal Module. erminal Module. erminal Module. erminal Module. Installation Manual. Cabling. LAN and Power Supply Wiring MODULE POWERED FROM EXTERNAL SUPPLY (Recommended) Heavy duty Fig. 8 cable (24/0.20 or 14/0.20) recommended for Ext.
  • Page 5 Revision 1.0 March 2006. Reader Wiring. A Wiegand Reader may be wired in parallel with the keypad to provide “PIN or Card” Door access operation. The Reader supply (+VRD) is fixed at 12V. i.e. A 5V Reader supply is not available and any Wiegand Reader connected must be able to accept a 12V supply. Readers with Clock and Data output (e.g.
  • Page 6 W W W W W eatherproof T eatherproof T eatherproof T eatherproof T eatherproof Terminal Module. erminal Module. erminal Module. erminal Module. erminal Module. Installation Manual. Module Numbering The Single Door Access Module is enrolled on the LAN as a Reader Module (R). The Module number is set using DIPswitches 1 to 7.
  • Page 7: Fault Diagnosis

    Revision 1.0 March 2006. THE WEATHERPROOF TERMINAL MODULE PCB 1. Earth. Connect to building earth or electrical earth. 8. L1 (RX). LAN Data Transmit & FAULT DIAGNOSIS 2. LK1. TERM. Fitted only if this unit is one of the two L2 (TX).
  • Page 8: Specifications

    Keypad dimensions: Height: 130mm Width: 81mm Depth: 21mm Distance between mounting hole centres: 82.2mm Mounting hole diameter: 4.15mm Due to on-going product development this manual is subject to change without notice. © Inner Range Pty Ltd. 2006. Part No: 635010...
