EP-2126-SS
SCSI to SCSI
RAID Subsystem
User Manual
Revision 1.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EP-2126-SS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Proware EP-2126-SS

Summary of Contents for Proware EP-2126-SS

  • Page 1 EP-2126-SS SCSI to SCSI RAID Subsystem User Manual Revision 1.1...

  • Page 2: Preface

    About this manual This manual provides information regarding the quick installation and hardware features of the EP-2126-SS RAID subsystem. This document also describes how to use the storage management software. Information contained in the manual has been reviewed for accuracy, but not for product warranty because of the various environment/OS/settings.

  • Page 3: Table Of Contents

    Before You Begin ..................6 Safety Guidelines ................................6 Controller Configuration..............................6 Packaging, Shipment and Delivery..........................6 Unpacking the Subsystem ............................7 Chapter 1 Product Introduction..............8 Identifying Parts of the EP-2126-SS........................9 1.1.1 Front View .................................9 1.1.2 Rear View................................9 Enclosure Chassis ..............................10 Technical Specifications............................. 11 1.3.1...
  • Page 4 SCSI to SCSI RAID Subsystem 2.6 Rackmount Slide Rail Installation........................31 Chapter 3 Getting Started with the System..........35 Connecting the RAID Subsystem to the Host..................35 SCSI Termination............................. 36 Chapter 4 RAID Concepts ................ 38 4.1 RAID Fundamentals............................. 38 SCSI Concepts ...............................
  • Page 5 SCSI to SCSI RAID Subsystem Channel Manager..............................79 Modify Password..............................81 Upgrade Firmware ............................... 82 Restart..................................84 Chapter 9 Event Log ................85 Event Log................................. 85 Export Log................................86 Chapter 10 Information................87 10.1 Disk Information ..............................87 10.2 RAID Information............................... 88 10.3 System Information ............................

  • Page 6: Before You Begin

    SCSI to SCSI RAID Subsystem Before You Begin Before going through with this manual, you should read and focus on the following safety guidelines. Notes about the subsystem’s controller configuration and the product packaging and delivery are also included. Safety Guidelines To provide reasonable protection against any harm on the part of the user and to obtain maximum performance, user is advised to be aware of the following safety guidelines particularly in handling hardware components:...

  • Page 7: Unpacking The Subsystem

    SCSI to SCSI RAID Subsystem Unpacking the Subsystem The package contains the following items: • RAID subsystem unit • Two power cords • One external serial cable • One external UPS cable • One RJ-45 Ethernet cable • Two external SCSI cables •...

  • Page 8: Chapter 1 Product Introduction

    SCSI to SCSI RAID Subsystem Chapter 1 Product Introduction The EP-2126-SS RAID Subsystem Features Intel 80331 64 bit I/O processor Supports RAID levels 0, 1, 0+1, 3, 5, 6, 30, 50, NRAID and JBOD Dual SCSI Ultra320 host channels support clustering technology...

  • Page 9: Identifying Parts Of The Ep-2126-Ss

    SCSI to SCSI RAID Subsystem 1.1 Identifying Parts of the EP-2126-SS The illustrations below identify the various parts of the subsystem. Each part will be discussed in details in the following sections of this manual. 1.1.1 Front View The front section consists of the Drive Carriers and the Smart LCD Panel.

  • Page 10: Enclosure Chassis

    SCSI to SCSI RAID Subsystem 1.2 Enclosure Chassis The EP-2126-SS is a redundant system with hot swappable disks, cooling fans and power supplies. The chassis assembly contains 12 drive bays at the front. These drive carriers are arranged in 4 columns of 3 drives. Each drive carrier is lockable and has a lock indicator.

  • Page 11: Technical Specifications

    SCSI to SCSI RAID Subsystem 1.3 Technical Specifications RAID Controller U320 SCSI-to-SCSI Host Bus Interface Ultra 320 SCSI Drive Bus Interface Ultra 320 SCSI Data Transfer Rate Up to 320MB/Sec Cache Memory 256MB ~ 2GB ECC DDR SDRAM RAID Processor Intel 80331 64 bit RISC Remote Management R-Link Port...

  • Page 12: Environmental

    SCSI to SCSI RAID Subsystem 1.3.3 Environmental Relative Humidity 10% ~ 85% Non-condensing ◦ ◦ ◦ ◦ Operating Temperature C ~ 40 C (50 F ~ 104 Weight 14 kg/30.8Lbs (without drives) Physical Dimensions 88(H) x 482(W) x 550 (L) mm User Manual...

  • Page 13: Chapter 2 Physical Components

    SCSI to SCSI RAID Subsystem Chapter 2 Physical Components 2.1 Controller Module The EP-2126-SS includes a U320 SCSI-to-SCSI Controller Module. 2.1.1 Controller Module Panel The Controller Module has 6 major parts: Host Channel, UPS Port, RS-232 Port, Ethernet Port, Alarm Mute Button, and a Hard Contact Relay. These parts are described as follows: 1.
  • Page 14 SCSI to SCSI RAID Subsystem 3. RS-232 Port The subsystem is equipped with a serial monitor port allowing you to connect to a PC or terminal. Below are the RS-232 settings. Settings Baud Rate 115200 Data Bits Parity None Stop Bits Flow Control None R-Link Port : Remote Link through RJ-45 Ethernet for remote...

  • Page 15: Controller Module Installation

    SCSI to SCSI RAID Subsystem 2.1.2 Controller Module Installation In this section, you will be shown how to install the Controller Module. a. Check for damage, especially to the connectors at the rear of the Controller Module. CAUTION! Handle the module with care and avoid damaging the connectors.

  • Page 16: Controller Board Replacement

    SCSI to SCSI RAID Subsystem 2.1.3 Controller Board Replacement NOTE: It is necessary to use ESD anti-static device when handling sensitive parts of the controller module. 1. Loosen the thumb screws. Raise the controller handle and pull out the controller module until it moves out of the slot. 2.
  • Page 17 SCSI to SCSI RAID Subsystem 5. Remove the controller board from the module case. 6. Remove the four hex screws. 7. Replace the controller board. User Manual...

  • Page 18: Power Supply / Fan Module

    SCSI to SCSI RAID Subsystem 2.2 Power Supply / Fan Module Every EP-2126-SS contains two 300W Power Supply / Fan Modules. All PSFMs are inserted into the rear of the chassis. Each PSFM delivers Full-Range (90 – 254V) AC voltage of electricity. The EP-2126- SS normally operates with two PSFMs running.

  • Page 19: Power Supply Module Led

    SCSI to SCSI RAID Subsystem 2.2.2 Power Supply Module LED When the power cord connected from main power source is inserted to the AC Power Inlet, the power status LED becomes RED. When the switch of the PSFM is turned on, the LED will turn GREEN. When the Power On/Fail LED is GREEN, the PSFM is functioning normally.

  • Page 20: Power Supply Installation

    SCSI to SCSI RAID Subsystem 2.2.4 Power Supply Installation In this section, you will be shown how to install the Power Supply. a. Check for damage, especially to the PCB Golden Fingers at the rear of the Power Supply. CAUTION! Handle the module with care and avoid damaging the Golden Fingers.

  • Page 21: Fan Replacement

    SCSI to SCSI RAID Subsystem 2.2.5 Fan Replacement 1. Remove the Power Supply Fan Module from the enclosure. 2. Unscrew 6 screws; 2 from left side, 2 from right side and 2 from top cover. Right Side Screws Top Cover Screws Left Side Screws 3.
  • Page 22 SCSI to SCSI RAID Subsystem 5. Unscrew the 4 screws of the power supply fan. Then remove the metal brace. 6. Remove the fan and replace. User Manual...

  • Page 23: Terminal Module

    SCSI to SCSI RAID Subsystem 2.3 Terminal Module Terminators must be attached to both Disk Channel ports of the Terminal Module in order for the SCSI disk drives to work properly. 2.3.1 Terminal Module Panel User Manual...

  • Page 24: Terminal Module Installation

    SCSI to SCSI RAID Subsystem 2.3.2 Terminal Module Installation In this section, you will be shown how to install the Terminal Module. a. Check for damage, especially to the connectors at the rear of the Terminal Module. CAUTION: Handle the module with care and avoid damaging the connectors.

  • Page 25: Terminal Module Board Replacement

    SCSI to SCSI RAID Subsystem 2.3.3 Terminal Module Board Replacement 1. Remove the Terminal Module from the enclosure. 2. Remove the four (4) lock nut screws. 3. Remove the six (6) hex screws from the terminal board. 4. Carefully remove the terminal board and pull away from the case. 5.

  • Page 26: Drive Carrier Module

    SCSI to SCSI RAID Subsystem 2.4 Drive Carrier Module The Drive Carrier Module houses a 3.5 inch hard disk drive. It is designed for maximum airflow and incorporates a carrier locking mechanism to prevent unauthorized access to the HDD. 2.4.1 Disk Drive Status Indicators Every Drive Carrier has 2 status indicator lights.

  • Page 27: Lock Indicator

    SCSI to SCSI RAID Subsystem 2.4.2 Lock Indicator Every Drive Carrier is lockable and is fitted with a lock indicator to indicate whether or not the carrier is locked into the chassis or not. Each carrier is also fitted with an ergonomic handle for easy carrier removal.
  • Page 28 SCSI to SCSI RAID Subsystem c. Place the hard drive in the disk tray. Make sure the holes of the disk tray align with the holes of the hard drive. d. Install the mounting screws on the bottom part to secure the drive in the disk tray.

  • Page 29: Lcd Display Panel

    SCSI to SCSI RAID Subsystem 2.5 LCD Display Panel 2.5.1 LCD Display Panel LEDs Environmental Status Parts Function Power LED Green indicates power is ON. If one of the redundant power supply unit Power Fail LED fail, this LED will turn to RED and alarm will sound.

  • Page 30: Lcd Front Panel Function Keys

    SCSI to SCSI RAID Subsystem 2.5.2 LCD Front Panel Function Keys Parts Functions Use the Up or Down arrow keys to go through the information on the LCD Up and Down screen. This is also used to move between Arrow buttons each menu when you configure the subsystem.

  • Page 31: Rackmount Slide Rail Installation

    SCSI to SCSI RAID Subsystem 2.6 Rackmount Slide Rail Installation An optional Rail box can be purchased and included in the package. Verify if the content of the Rail Box is complete. 2 x Rack Rails 2 x Inner Brackets 4 x M5*P0.8 L=25mm Long Screws 8 x M5*0.8 L=8.0mm...
  • Page 32 SCSI to SCSI RAID Subsystem 2. Place one inner bracket to the side of the chassis. Align the holes on the front side of the inner rail to the holes on the RAID system ear. Tighten the screw that was removed in Step1. 3.
  • Page 33 SCSI to SCSI RAID Subsystem 6. Place the right side rack rail on the rack cabinet. Use four M5 round head screws to fix the rack rail to the rack post (Front Right and Rear Right). NOTE: In the Front Right part of the rack rail, the M5 screws must be placed in holes 1 and 3.
  • Page 34 SCSI to SCSI RAID Subsystem 8. Carefully insert the RAID system into the cabinet. Make sure the inner brackets align with the center opening of the rack rails. Front View Rear View 9. Use two M5 long screws to fix the RAID system in the cabinet. 10.

  • Page 35: Chapter 3 Getting Started With The System

    Chapter 3 Getting Started with the System 3.1 Connecting the RAID Subsystem to the Host This section describes how to connect the EP-2126-SS to your host system. The subsystem supports Ultra 320 SCSI LVD interface which provides fast 320MB/s data transfer rates using a 16-bit SCSI bus. Installation of the disk array is very similar to the installation of a standard SCSI drive.

  • Page 36: Scsi Termination

    SCSI to SCSI RAID Subsystem 7. Attach a SCSI terminator to the other SCSI Host Channel connector (Host Channel A Out port). Make sure to tighten the lock screws of the SCSI terminator. 8. If you want to configure subsystem into multi-host attachment, connect another host system using the other external SCSI cable to the other SCSI Host Channel (B).
  • Page 37 SCSI to SCSI RAID Subsystem Correct SCSI termination procedures require that the last device on the SCSI bus be terminated. If the last device is not terminated or if devices other than the last are terminated, erratic SCSI bus performance may occur. Typically, the system or host adapter (SCSI card inside the host computer) is the first device and is already terminated.

  • Page 38: Chapter 4 Raid Concepts

    SCSI to SCSI RAID Subsystem Chapter 4 RAID Concepts 4.1 RAID Fundamentals The basic idea of RAID (Redundant Array of Independent Disks) is to combine multiple inexpensive disk drives into an array of disk drives to obtain performance, capacity and reliability that exceeds that of a single large drive.
  • Page 39 SCSI to SCSI RAID Subsystem Definition of RAID Levels RAID 0 is typically defined as a group of striped disk drives without parity or data redundancy. RAID 0 arrays can be configured with large stripes for multi-user environments or small stripes for single-user systems that access long sequential records. RAID 0 arrays deliver the best data storage efficiency and performance of any array type.
  • Page 40 SCSI to SCSI RAID Subsystem RAID 3 sector-stripes data across groups of drives, but one drive in the group is dedicated to storing parity information. RAID 3 relies on the embedded ECC in each sector for error detection. In the case of drive failure, data recovery is accomplished by calculating the exclusive OR (XOR) of the information recorded on the remaining drives.
  • Page 41 SCSI to SCSI RAID Subsystem RAID 6 is similar to RAID 5 in that data protection is achieved by writing parity information to the physical drives in the array. With RAID 6, however, two sets of parity data are used. These two sets are different, and each set occupies a capacity equivalent to that of one of the constituent drives.

  • Page 42: Raid Management

    SCSI to SCSI RAID Subsystem RAID Management The subsystem can implement several different levels of RAID technology. RAID levels supported by the subsystem are shown below. RAID Description Level Drives Linear is similar to RAID 0 in that it combines the capacity of all member drives.

  • Page 43: Scsi Concepts

    SCSI to SCSI RAID Subsystem 4.2 SCSI Concepts Before configuring the subsystem, you must first understand some basic SCSI concepts so that the subsystem and SCSI devices will function properly. 4.2.1 Multiple SCSI Format Support The subsystem support the SCSI interface standards listed below. Note that the data bit and cable length restrictions must be followed.

  • Page 44: Disk Drive Organization

    SCSI to SCSI RAID Subsystem 4.3 Disk Drive Organization The subsystem arranges the SCSI drives connected to it as a physical drive group and logical unit (LUN). 4.3.1 Physical Drive Groups The subsystem has up to a maximum of twelve (12) individual disk drives which can be used to form a physical drive group.

  • Page 45: Chapter 5 Configuration Utility Options

    SCSI to SCSI RAID Subsystem Chapter 5 Configuration Utility Options The subsystem has a built-in setup configuration utility containing important information about the configuration as well as settings for various optional functions in the subsystem. This chapter explains how to use and make changes to the setup utility. Configuration Methods There are three methods of configuring the subsystem: •...
  • Page 46 SCSI to SCSI RAID Subsystem 4. The default setting of the monitor port is 115200 baud rate, 8 data bit, non-parity, 1 stop bit and no flow control. User Manual...
  • Page 47 SCSI to SCSI RAID Subsystem 5. After connecting and powering on the terminal. Press “l” key to enter password screen. The preset password is 8 zeroes. Type “00000000”. 6. Then press <Enter> to enter screen. The Main Menu will appear. Keyboard Function Key Definitions “...
  • Page 48 SCSI to SCSI RAID Subsystem VT100 terminal configuration Utility Main Menu Options Select an option and the related information or submenu items display beneath it. The submenus for each item are explained as below. User Manual...
  • Page 49 SCSI to SCSI RAID Subsystem The configuration utility main menu options are: Menu Option Description Quick Setup Quickly create a single Array and Volume Create single or multiple Arrays and Volumes with RAID Management custom parameters. Set SCSI parameters such as SCSI ID, speed and SCSI Configuration Tag Queue.

  • Page 50: Upgrading Firmware Through Vt-100 Terminal Emulation

    SCSI to SCSI RAID Subsystem 5.1.1 Upgrading Firmware through VT-100 Terminal Emulation The RAID controller’s firmware can be upgraded through a terminal. To upgrade the firmware, follow these steps: 1. Shut down the host computer system, if a host computer is connected. 2.
  • Page 51 SCSI to SCSI RAID Subsystem 6. Click Browse. Locate where the Firmware file has been saved, select the file and click Open. 7. Select “Ymodem” under Protocol. YMODEM is the file transfer protocol used by the terminal emulation software. 8. Click “Send” to send the Firmware file to the RAID controller. 9.

  • Page 52: Configuring The Subsystem Using The Lcd Panel

    SCSI to SCSI RAID Subsystem 5.2 Configuring the Subsystem Using the LCD Panel All configurations can be performed through the LCD Display front panel function keys, except for the “Firmware update”. The LCD provides a system of screens with areas for information, status indication, or menus.
  • Page 53 SCSI to SCSI RAID Subsystem To view system information, hardware monitor information, array information, and other related information, press the Down Arrow button. Model-Name RAID READY IOP-80331 FW1.30 RAM:256MB HD#12 Temperature System:40 C S 1:34C S 2:31C S 3:33C S 4:32C S 5:33C S 6:29C S 7:29C S 8:31C S 9:32C S106:31C...

  • Page 54: Configuration Using The Proraid Manager Gui

    SCSI to SCSI RAID Subsystem 5.3 Configuration using the proRAID Manager GUI The RAID subsystem can be managed through the controller’s Ethernet connection. Any PC on the network to which the RAID subsystem is connected can manage the subsystem using proRAID Manager. proRAID Manager is web browser-based Graphical User Interface (GUI) that is supported on many OS platforms.

  • Page 55: The Proraid Manager Main Menu

    SCSI to SCSI RAID Subsystem 5.3.2 The ProRAID Manager Main Menu After login, the Main Screen will be displayed. There are several menu items shown on the upper part of the screen. The menu items are grouped according to their functionality.
  • Page 56 SCSI to SCSI RAID Subsystem User Manual...
  • Page 57 SCSI to SCSI RAID Subsystem Mount or Detach RAID Subsystem To login to another RAID Subsystem, click the Mount button and enter the Subsystem Name (you can use any name to identify the subsystem you are going to manage), the IP Address, and the subsystem Password.

  • Page 58: Proraid Manager Menu Hierarchy

    SCSI to SCSI RAID Subsystem 5.3.3 ProRAID Manager Menu Hierarchy Below is the summary of the menu and functions available in proRAID Manager GUI. Quick Setup Create Array Modify Array RAID Delete Array Create Volume Modify Volume Delete Volume Network Setting SNMP Setting Network SMTP Setting...

  • Page 59: Chapter 6 Raid Management

    SCSI to SCSI RAID Subsystem Chapter 6 RAID Management This chapter describes the available RAID Management tasks; these tasks may be selected using the RAID menu icon in the upper part of the screen or in the left side menu of the ProRAID Manager screen. There are seven functions: Quick Setup, Create Array, Modify Array, Delete Array, Create Volume, Modify Volume, and Delete Volume.
  • Page 60 SCSI to SCSI RAID Subsystem Enter Array Name, Volume Name, select the disk drives to be included in the Array, and select RAID Level, Stripe Size, and Block Size. Click “Submit” when done. Option Description The name of the array you want to assign to the Array Name Array.
  • Page 61 SCSI to SCSI RAID Subsystem The Array and Volume will be created. NOTE: Quick Setup can only be used if there’s no existing Array. NOTE: In Quick Setup, the Array will be created in background initialization mode, which means the Volume will be available immediately while initializing in the background.

  • Page 62: Create Array

    SCSI to SCSI RAID Subsystem 6.2 Create Array NOTE: The RAID subsystem supports up to 16 Arrays. To create a new Array: 1. In RAID menu, click “Create Array”. 2. Enter the Array Name, change the Re-Mapped BS count as necessary, select the disks drives to be included in the Array, and set the RAID Level, Stripe Size, Block Size, and Task Priority.
  • Page 63 SCSI to SCSI RAID Subsystem Option Description The name of the array you want to assign to the Array Name Array. Maximum is 20 characters. Capacity The total capacity of the Array in GB. Set the maximum number of bad sector count to be Re-Mapped BS count remapped.
  • Page 64 SCSI to SCSI RAID Subsystem 3. The Array will be initialized. 4. The next step is to create a Volume. When Array has completed its initialization in Foreground mode, or still initializing in Background mode, a Volume can created. NOTE: Any FREE or un-used hard disk will automatically become Global Hot Spare disk, which means it can replace any failed disk in any Array, as long as the capacity is the same or greater than the capacity of the smallest disk size in the Array.

  • Page 65: Modify Array

    SCSI to SCSI RAID Subsystem 6.3 Modify Array Use this function to modify settings of an existing Array To modify Array: In RAID menu, click “Modify Array”. Change the settings of the Array as necessary. NOTE: Some settings are read-only and cannot be modified. Click “Submit”...

  • Page 66: Delete Array

    SCSI to SCSI RAID Subsystem 6.4 Delete Array 1. To delete an Array, select “Delete Array” from RAID menu. 2. Select the Array to be deleted from the list of Arrays displayed on the left side. 3. Click “Submit” when done. A warning message will be displayed. Click “OK” to proceed with deletion.

  • Page 67: Create Volume

    SCSI to SCSI RAID Subsystem 6.5 Create Volume A Volume is seen by the host system as a single logical device. Multiple Volumes can be created in an Array as long as there is free capacity in the Array. Up to 32 Volumes can be mapped to a LUN in each Host Channel (LUN ID 0 to 31 for Host A and for Host B).
  • Page 68 SCSI to SCSI RAID Subsystem 3. Enter the Volume Name, the Volume Size, and change the Read Ahead option if necessary. Map the Volume to a LUN by enabling the Activate option and selecting the LUN ID in the Host Channel. Option Description The name you want to assign to the Volume.
  • Page 69 SCSI to SCSI RAID Subsystem 4. Click “Submit” when done. The Volume will be created. IMPORTANT: Once a LUN number is already assigned to a Volume, it cannot be used again. User Manual...

  • Page 70: Modify Volume

    SCSI to SCSI RAID Subsystem 6.6 Modify Volume The Volume attributes can be modified using the “Modify Volume” function in RAID menu. To modify a Volume: 1. Select “Modify Volume” from RAID menu. Select the Array name from the Array List, and then select the Volume to be modified.

  • Page 71: Delete Volume

    SCSI to SCSI RAID Subsystem 6.7 Delete Volume To delete a Volume: 1. Select “Delete Volume” from RAID menu. From the Array List, select the Array name which contains the Volume to be deleted. Then select the Volume to be deleted.

  • Page 72: Chapter 7 Network Management

    SCSI to SCSI RAID Subsystem Chapter 7 Network Management 7.1 Network Settings To setup the R-Link Ethernet port: 1. Select “Network Settings” from Network menu. 2. Set the following options: Option Description Enter the IP address you want to assign to the RAID IP Address subsystem.

  • Page 73: Snmp Setting

    SCSI to SCSI RAID Subsystem 7.2 SNMP Setting The SNMP gives users independence from the proprietary network management schemes of some manufacturers. SNMP is supported by many WAN and LAN manufacturers enabling true LAN/ WAN management integration. To set the SNMP function: 1.

  • Page 74: Smtp Setting

    SCSI to SCSI RAID Subsystem 7.3 SMTP Setting To set the Mail Notification function: 1. Select “SMTP Setting” from Network menu. 2. Tick the “Enable Mail Notification” option. Then setup the necessary options. Option Description SMTP Server Enter the SMTP Server IP address. Use Secure To use secure authentication in SMTP server, enable this Authentication...

  • Page 75: Ntp Setting

    SCSI to SCSI RAID Subsystem 7.4 NTP Setting NTP (Network Time Protocol) is an Internet standard protocol used to synchronize the clocks of computers to some time reference. By default, “Use Local Time Setting” is selected. This means the RAID subsystem will get time information from local computer.

  • Page 76: Sync Rtc

    SCSI to SCSI RAID Subsystem 7.5 Sync RTC When time setting is not configured to get time from an NTP server (“Use Local Time Setting” option is selected in NTP Setting), the “Sync RTC” function must be used whenever the RAID subsystem is started or restarted. RTC Stands for Real Time Clock and is used to set the time on the RAID controller.

  • Page 77: Chapter 8 System Management

    SCSI to SCSI RAID Subsystem Chapter 8 System Management 8.1 System Setting Some RAID subsystem System settings can be configured to the user’s preference to match certain application. The following can be set using “System Setting” function in System menu: Alarm Beeper: The Alarm Beeper function item is used to Disable or Enable the RAID subsystem alarm tone generator.
  • Page 78 SCSI to SCSI RAID Subsystem Notification Level: Events are classified to 5 levels (Critical, Error, Warning, Notice, Info). Event Log Level Slot inserted Notice Slot removed Notice Temperature back to normal Notice Voltage back to normal Notice PSU back to normal Notice Fan back to normal Notice...

  • Page 79: Channel Manager

    SCSI to SCSI RAID Subsystem 8.2 Channel Manager The Channel Manager can be used to configure the SCSI Host Channels A and B options to the preferred settings. Select “Channel Manager” function in System menu. For each Host Channel, the SCSI ID, Wide, Speed Setting, Current Speed, and Tag Queue can be set.
  • Page 80 SCSI to SCSI RAID Subsystem After setting the preferred option, click “Update” to save the changes. To see the current settings, click “Refresh”. User Manual...

  • Page 81: Modify Password

    SCSI to SCSI RAID Subsystem 8.3 Modify Password To set or change the login password of RAID subsystem, click “Modify Password” function in System menu. Enter the old password in the Old Password field, and the new password in the New Password and Confirm New Password fields. Click “Submit”...

  • Page 82: Upgrade Firmware

    SCSI to SCSI RAID Subsystem 8.4 Upgrade Firmware The RAID controller’s firmware can be upgraded when new firmware version is available. Select “Upgrade Firmware” function in System menu then click “Upload”. Select the firmware file. Click “Open” to start updating. User Manual...
  • Page 83 SCSI to SCSI RAID Subsystem The firmware file will be uploaded to the RAID controller. Then the upgraded process will be started. After the upgrade is completed, the subsystem will automatically restart. User needs to login again to proRAID Manager GUI after subsystem has restarted. User Manual...

  • Page 84: Restart

    SCSI to SCSI RAID Subsystem 8.5 Restart The RAID subsystem can be restarted using the “Restart” function in System menu. Click the “Submit” button to restart the RAID subsystem. User Manual...

  • Page 85: Chapter 9 Event Log

    SCSI to SCSI RAID Subsystem Chapter 9 Event Log 9.1 Event Log The RAID subsystem’s event log information can be displayed by selecting “Event Log” function in Event Log menu. To update the current displayed event logs, click “Refresh”. User Manual...

  • Page 86: Export Log

    SCSI to SCSI RAID Subsystem 9.2 Export Log The RAID subsystem’s event log information can be saved to local destination by selecting “Export Log” function in Event Log menu. Click “Submit” to save the event log. The file type of the exported event log will be in XML.

  • Page 87: Chapter 10 Information

    SCSI to SCSI RAID Subsystem Chapter 10 Information 10.1 Disk Information To view detailed information about the disk drives in the RAID subsystem, select “Disk Info” function in Info menu. The Slot ID (Disk#), the disk vendor, model, capacity, number of remapped bad sectors, firmware version, and state are shown. When disks are already member of an Array, the State will show USED.

  • Page 88: Raid Information

    SCSI to SCSI RAID Subsystem 10.2 RAID Information To view information about existing Array and Volume in the RAID subsystem, select “RAID” function in Info menu. Then select the Array name from the list of Arrays. The Array Info and Logical Volume Details will be displayed. The logical volume details can be shown in grid view using “Grid View”...

  • Page 89: System Information

    SCSI to SCSI RAID Subsystem 10.3 System Information Use the “System Info” function in Info menu to view the RAID subsystem information. The Vendor Name, Serial No., Product ID, CPU Name, CPU Speed, Memory Size, Memory Speed, BBM Module installed or not, ECC DRAM support, Subsystem Model, Controller Model, Firmware Version, Disk Channel Type, Number of Host Channels, Host Channel Type, Host Channel Sync Speed, Number of Slots, Number of Backplane Slots, Baud Rate, Cache Type, Cache Ratio, Beeper enabled or not, Log Level, proSES enabled or not,...

  • Page 90: Hardware Monitor

    SCSI to SCSI RAID Subsystem 10.4 Hardware Monitor To view RAID subsystem’s hardware information, select “Hardware Monitor” in Info menu. The Hardware Monitor information provides the power supply status, fan speed, temperature, and voltage levels of the RAID subsystem. All items are also unchangeable. The warning messages will indicate through the LCD, LED and alarm buzzer.

  • Page 91: Chapter 11 Raid Task

    SCSI to SCSI RAID Subsystem Chapter 11 Raid Task 11.1 Raid Status To view the RAID status of an Array, select “Raid Status” in Raid Task menu. The List of Arrays, and the RAID Level, Capacity, Member Disks and Status are displayed. The states available are: Ready Need to Rebuild...
  • Page 92 SCSI to SCSI RAID Subsystem A Parity Check function is available for existing Arrays with parity, such as those configured with RAID level 3, 5, 6, 30, or 50, to check the consistency of parity blocks, i.e. verify that parity information matches the stored data. Click “Check Parity”...
