- Page 1 NAS System User Manual Revision 1.0...
-
Page 2: Table Of Contents
NAS System Table of Contents Preface ............................. 3 Before You Begin ........................4 Safety Guidelines.................................... 4 Packaging, Shipment and Delivery ............................4 Chapter 1 Introduction ...................... 5 Key Features ..................................5 Technical Specifications ..............................6 RAID Levels .................................... 7 Chapter 2 Installation ......................8 Unpacking the NAS System ............................ -
Page 3: Preface
NAS System Preface About this manual This manual provides information regarding the quick installation and hardware features of the NAS System. This document also describes how to use the storage management software. Information contained in the manual has been reviewed for accuracy, but not for product warranty because of the various environment/OS/settings. -
Page 4: Before You Begin
NAS System Before You Begin Before going through with this manual, you should read and focus to the following safety guidelines. Notes about the subsystem product packaging and delivery are also included. Safety Guidelines To provide reasonable protection against any harm on the part of the user and to obtain maximum performance, user is advised to be aware of the following safety guidelines particularly in handling hardware components: Upon receiving of the product:... -
Page 5: Chapter 1 Introduction
NAS System Chapter 1 Introduction The NAS System 1.1 Key Features - Supports up to four (4) hot-swappable 6Gb/s SATA3 hard drives - Supports RAID levels 0, 1, 5, 6, 10 - Support Smart-functional LCD panel - Support drive hot spare and automatic hot rebuild - Centralization of Data and Storage Management - Real-time drive activity and status indicators - Environmental monitoring unit... -
Page 6: Technical Specifications
NAS System 1.2 Technical Specifications Hardware Platform Intel Celeron 2.8GHz or above Cache memory : 8GB DDR4 SDRAM up to 32GB Four USB3.0 and two USB2.0 ports Two Gigabit Ethernet ports Up to four(4) 2.5"/3.5” hot-swappable 6Gb/s SATA3 hard drives Real-time drive activity and status indicators Environmental monitoring unit 250W power supply with PFC... -
Page 7: Raid Levels
NAS System 1.3 RAID Levels Below is the list of RAID Levels available for configuration in the NAS. No. of Minimum RAID Allowed Required Description Level Failed Number Drives of Drives Block striping is provided and yields higher None performance than with individual drives. There is no redundancy. -
Page 8: Chapter 2 Installation
NAS System Chapter 2 Installation 2.1 Unpacking the NAS System The package contains the following items: NAS System Unit One (1) power cord Two (2) Ethernet LAN cables Installation Reference Guide NOTE: If any of these items are missing or damaged, please contact your dealer or sales representative for assistance. -
Page 9: Identifying Parts Of The Nas System
NAS System 2.2 Identifying Parts of the NAS System The illustrations below identify the various parts of the NAS System. 2.2.1 Front View User Manual... -
Page 10: Rear View
NAS System 2.2.2 Rear View 1. USB 2.0 ports – Two USB 2.0 ports are located at the rear of the system. 2. Power Supply – The NAS System has one power supply. 3. AC Power Input Socket - Use this to connect the power cords connected from power source. -
Page 11: Disk Tray
NAS System 2.2.3 Disk Tray The NAS System houses a 2.5/3.5 inch hard disk drive. It is designed for maximum airflow and incorporates a carrier locking mechanism to prevent unauthorized access to the HDD. 2.2.3.1 Disk Drive Status Indicator Every Disk Tray has 2 status indicator lights. The Disk Status Indicator light is for Power On/Error status. -
Page 12: Lock Indicator
NAS System 2.2.3.2 Lock Indicator Every Disk Tray is lockable and is fitted with a lock indicator to indicate whether or not the disk tray is locked into the chassis. Each tray is also fitted with an ergonomic handle for easy carrier removal. 2.2.4 LCD Panel Parts Function... - Page 13 NAS System Menu Diagram MODEL xxx.xxx.xxx.xxx VERSION 3.x.xx CHANGE NEW PASSWORD SUBMIT PASSWORD PASSWORD 00000000 SETTING(YES/NO) BEEPER SETTING SUBMIT BEEPER SETTING MUTE / ALARM SETTING(YES/NO) NORMAL NORMAL DISK NORMAL POWER NORMAL TEMP NORMAL RAID NORMAL DISK INFORMATION DISK_1 *O* TEMP 35C DISK_4 *O* TEMP 35C RAID ARRAY NAME...
-
Page 14: Chapter 3 Getting Started With The Nas System
NAS System Chapter 3 Getting Started with the NAS System 3.1 Preparing the Subsystem and Powering On Here are the basic steps to prepare the NAS System for use. 1. Attach network cable to LAN0 Ethernet port. Connect the other end of network cable to your network hub or switch. - Page 15 NAS System c. Place the hard drive in the disk tray. d. Install the mounting screws on the bottom part to secure the drive in the disk tray. Tray Hole A e. Slide the tray into a slot. Close the lever handle until you hear the latch click into place. User Manual...
-
Page 16: Installing 2.5" Disk In A Disk Tray
NAS System 3.2.2 Installing 2.5” Disk in a Disk Tray a. Make sure the lock indicator is in unlocked position. To pull out a disk tray, press the tray open button. Tray Open Button b. Pull out an empty disk tray. Pull the lever handle outwards to remove the carrier from the enclosure.
