- Page 1 6G SAS NAS System Hardware Manual Revision 1.0...
-
Page 2: Table Of Contents
NAS System Table of Contents Preface ..........................3 Before You Begin ......................4 Chapter 1 Introduction ....................5 1.1 Key Features ................................5 Technical Specifications ............................6 1.3 RAID Concepts ................................ 7 Array Definition ..............................10 1.4.1 Drive Group .............................. -
Page 3: Preface
NAS System Preface About this manual his manual provides information regarding the hardware features, installation and configuration of the SAS NAS System. Information contained in the manual has been reviewed for accuracy, but not for product warranty because of the various environment/OS/settings. Information and specifications will be changed without further notice. -
Page 4: Before You Begin
NAS System Before You Begin efore going through with this manual, you should read and focus on the following safety guidelines. Information about the NAS system’s packaging and delivery are also included. To provide reasonable protection against any harm on the part of the user and to obtain maximum performance, user is advised to be aware of the following safety guidelines particularly in handling hardware components: Upon receiving of the product:... -
Page 5: Chapter 1 Introduction
NAS System Chapter 1 Introduction The NAS System 1.1 Key Features - Configurable to 19" rack-mountable 2U chassis - Intel Sandy Bridge / Ivy Bridge inside - Supports up to Twelve (12) 2.5" and 3.5'' hot-swappable 6G SAS/SATA hard drives - Supports RAID levels 0, 1, 5, 6, 10, 50, 60 - Support three Gigabit Ethernet port for NAS file-sharing application - Supports Tape/DAT backup/restore (Option) -
Page 6: Technical Specifications
NAS System 1.2 Technical Specifications Hardware Platform Intel Quad Core Xeon 3.1GHz processor System Memory：4GB DDR3 SDRAM up to 32GB Three Gigabit Ethernet ports (option for 10Gigabit Ethernet) Up to Twelve (12) 2.5" and 3.5” hot-swappable 6Gb SAS/SATA hard drives Real time drive activity and status indicators Environmental monitoring unit Two(2) 460W 80plus hot-swap power supplies with PFC... -
Page 7: Raid Concepts
NAS System 1.3 RAID Concepts RAID Fundamentals The basic idea of RAID (Redundant Array of Independent Disks) is to combine multiple inexpensive disk drives into an array of disk drives to obtain performance, capacity and reliability that exceeds that of a single large drive. The array of drives appears to the host computer as a single logical drive. - Page 8 NAS System Definition of RAID Levels RAID 0 is typically defined as a group of striped disk drives without parity or data redundancy. RAID 0 arrays can be configured with large stripes for multi-user environments or small stripes for single-user systems that access long sequential records. RAID 0 arrays deliver the best data storage efficiency and performance of any array type.
- Page 9 NAS System Under RAID 5 parity information is distributed across all the drives. Since there is no dedicated parity drive, all drives contain data and read operations can be overlapped on every drive in the array. Write operations will typically access one data drive and one parity drive.
-
Page 10: Array Definition
NAS System In summary: RAID 0 is the fastest and most efficient array type but offers no fault-tolerance. RAID 0 requires a minimum of one drive. RAID 1 is the best choice for performance-critical, fault-tolerant environments. RAID 1 is the only choice for fault-tolerance if no more than two drives are used. RAID 5 combines efficient, fault-tolerant data storage with good performance ... -
Page 11: Chapter 2 Getting Started
NAS System Chapter 2 Getting Started 2.1 Packaging, Shipment and Delivery Before removing the subsystem from the shipping carton, you should visually inspect the physical condition of the shipping carton. Unpack and verify that the contents of the shipping carton are complete and in good condition. -
Page 12: Identifying Parts Of The Nas System
NAS System 2.3 Identifying Parts of the NAS System The illustrations below identify the various parts of the subsystem. 2.3.1 Front View User’s Manual... -
Page 13: Lcd Front Panel
NAS System 2.3.1.1 LCD Front Panel Front Panel The LCD front panel is an option to setup some system settings. To start using the LCD panel, press the Select button to login and configure the system. See the LCD menu diagram in the next section. Parts Function Press this button to return to the previous... - Page 14 NAS System Menu Diagram MODEL xxx.xxx.xxx.xxx VERSION 3.x.xx CHANGE NEW PASSWORD SUBMIT PASSWORD PASSWORD 00000000 SETTING(YES/NO) BEEPER SETTING SUBMIT BEEPER SETTING MUTE / ALARM SETTING(YES/NO) NORMAL NORMAL DISK NORMAL POWER NORMAL TEMP NORMAL RAID NORMAL DISK INFORMATION DISK_1 *O* TEMP 35C DISK_12 *O* TEMP 35C RAID ARRAY NAME...
-
Page 15: Rear View
NAS System 2.3.2 Rear View NOTE: For maximum performance, we recommend that you select the second PCIe bus(x8 connector) for installing other HBA (10G LAN, SAS, FC). Refer to the motherboard documentation to obtain a block diagram of all available PCI buses. This diagram will help you determine which connectors belong to which buses. -
Page 16: Drive Carrier Module
NAS System 2.4 Drive Carrier Module The Drive Carrier Module houses a 3.5 inch hard disk drive. It is designed for maximum airflow and incorporates a carrier locking mechanism to prevent unauthorized access to the HDD. 2.4.1 Disk Drive Status Indicators Every Drive Carrier has 2 status indicator lights. -
Page 17: Installing Hard Drives
NAS System Drive Carrier is Unlocked Drive Carrier is locked 2.5 Installing Hard Drives This section describes the physical locations of the hard drives supported by the NAS system and give instructions on installing a hard drive. The system supports hot-swapping allowing you to install or replace a hard drive while the NAS system is running. -
Page 18: Preparing The System
NAS System 2.6 Preparing the System 1. Attach network cable to Ethernet port LAN0. Connect the other end to your network switch. You may also connect the other Ethernet LAN port if needed. 2. Connect monitor to the VGA port. 3. -
Page 19: Chapter 3 Raid Configuration And Management
NAS System Chapter 3 RAID Configuration and Management Before using the NAS system, a RAID configuration must be created. At least one virtual drive is required to be used in the NAS. You may create more than one Virtual Drive if needed. -
Page 20: Webbios Cu Main Screen Options
NAS System 3.1.2 WebBIOS CU Main Screen Options The figure below shows the screen when you start the WebBIOS CU and select an adapter. In the lower right panel, the logical view part of the screen displays all of the virtual drives that are configured on this controller. - Page 21 NAS System The toolbar at the top of the WebBIOS CU has the following buttons: Table 3.1.2 WebBIOS CU Toolbar Icons Icon Description Click this icon to return to the main screen from any other WebBIOS CU screen. Click this icon to return to the previous screen that you were viewing.
-
Page 22: Configuring Raid Drive Groups And Virtual Drives
NAS System 3.2 Configuring RAID Drive Groups and Virtual Drives NOTE: This section describes the steps to create two RAID Level 5 Virtual Drives to be used in the NAS system. For additional information about the LSI MegaRAID 9260-4i RAID Configuration and Management, please visit the LSI web site: http://www.lsi.com/DistributionSystem/AssetDocument/files/d ocs/techdocs/storage_stand_prod/sas/mr_sas_sw_ug.pdf... - Page 23 NAS System 3. To create a new configuration, select New Configuration. Click Next. A dialog box will warn that you will lose data if you select Clear Configuration or New Configuration. NOTE: You only select New Configuration the first time you create the drive group and virtual drives.
-
Page 24: Using Auto Configuration
NAS System 3.2.1 Using Auto Configuration If you select one of the Auto Configuration options, either with or without redundancy, the following are the steps to configure RAID: 1. When WebBIOS displays the proposed new configuration, review the information on the screen, and click Accept to accept it. (Or click Back to go back and change the configuration.) ... -
Page 25: Using Manual Configuration: Creating Raid 5 Virtual Drives
NAS System 3.2.2 Using Manual Configuration: Creating RAID 5 Virtual Drives When you select Custom Configuration and click Next, the Drive Group Definition screen appears. You use this screen to select drives to create drive groups. 1. Hold <Ctrl> while you select at least three ready drives in the Physical Drives panel on the left. - Page 26 NAS System 4. Click Next. 5. The Span Definition screen appears. Drive Group 0 is shown in the Array With Free Space list. Click Add to SPAN. 6. Drive Group 0 is listed in the Span panel. Click Next. User’s Manual...
- Page 27 NAS System 7. The Virtual Drive Definition screen appears. You use this screen to select the RAID level, stripe size, read policy and other attributes for the new virtual drives. Virtual Drive Parameters and Descriptions Parameter Description The drop-down menu lists the possible RAID levels for the virtual RAID Level drive.
- Page 28 NAS System Write Back with BBU: Select this mode if you want the controller to use Writeback mode but the controller has no BBU or the BBU is bad. If you do not choose this option, the controller firmware automatically switches to Writethrough mode if it detects a bad or missing BBU.
- Page 29 NAS System To create Virtual Drive 0, select RAID 5 as RAID Level, and enter the size in Select Size. Click Accept then Next. NOTE: The Virtual Drive can use all of the capacity of the Drive Group. You may create several Virtual Drives depending on your usage and requirement.
- Page 30 NAS System 8. VD 0 is created. To create the second Virtual Drive, click Back. The Span Definition will be displayed. Click Add to SPAN and Yes. 9. The Virtual Disk Definition screen appears. To create Virtual Drive 1, select RAID 5 as RAID Level.
- Page 31 NAS System 10. Virtual Drive 1 is created. Click Next. 11. The Configuration Preview screen is shown. Click Accept to save the configuration. User’s Manual...
- Page 32 NAS System 12. A Confirmation Page will be displayed. Select Yes to confirm. 13. Another Confirmation Page is displayed. Select Yes to initialize the Virtual Drives. 14. The two Virtual Drives will be initialized in the background. Click Home to return to the main screen of WebBIOS CU.
-
Page 33: Creating Global Hot Spare
NAS System 3.3 Creating Global Hot Spare A global hot spare can be used to replace a failed physical disk in any redundant array as long as the capacity of the global hot spare is equal to or larger than the coerced capacity of the failed physical disk. - Page 34 NAS System 3. Choose the Make Global HSP option and click Go. 4. Click Go. User’s Manual...
-
Page 35: Restarting The Controller
NAS System 5. The global hot spare drive is created. 3.4 Restarting the Controller 1. Verify the status of Virtual Drives. User’s Manual... - Page 36 NAS System 2. Click Exit. 3. A confirmation screen will be displayed. Select Yes. 4. A message “Please Reboot your system.” Will be displayed. Reboot your system by pressing CTRL+ALT+DEL keys. 5. The system will reboot. 6. The NAS system will be started. Please refer to Part 2 for the proNAS system configuration.
