Service Manual
AV-14F3PX
AV-14F3PX
SCHEMATIC DIAGRAMS
COLOR TELEVISION
AV-14F3PX
(PH)
−
+
No. 56083
COPYRIGHT © 2000 VICTOR COMPANY OF JAPAN, LTD.
Sep. 2000
No. 56083
2-1
Advertisement
Table of Contents
Related Manuals for JVC AV-14F3PX
Summary of Contents for JVC AV-14F3PX
- Page 1 AV-14F3PX AV-14F3PX SCHEMATIC DIAGRAMS COLOR TELEVISION AV-14F3PX (PH) − No. 56083 COPYRIGHT © 2000 VICTOR COMPANY OF JAPAN, LTD. Sep. 2000 No. 56083...
- Page 2 AV-14F3PX No. 56083...
- Page 3 AV-14F3PX STANDARD CIRCUIT DIAGRAM NOTE ON USING CIRCUIT DIAGRAMS Type No indication : Ceramic capacitor 1. SAFETY : Mylar capacitor The components identified by the ! ! ! ! ! symbol and shading are : Metalized mylar capacitor critical for safety. For continued safety replace safety critical : Polypropylene capacitor components only with manufactures recommended parts.
- Page 4 AV-14F3PX CONTENTS SEMICONDUCTOR SHAPES ............2-4 BLOCK DIAGRAM ................2-5 CIRCUIT DIAGRAMS MAIN PWB CIRCUIT DIAGRAM (Including CRT SOCKET PWB) ......... 2-7 PATTERN DIAGRAMS MAIN PWB PATTERN ......................2-11 CRT SOCKET PWB PATTERN ....................2-13 SEMICONDUCTOR SHAPES TRANSISTOR FRONT VIEW...
- Page 5 AV-14F3PX AV-14F3PX BLOCK DIAGRAM MAIN PWB SP02 VIF IN Q101 SF101 CF161 Q161 TUNER SIF OUT IF AMP SAW FILTER 4.5MHz FILTER SIF AMP VIF IN IC601 AUDIO AMP SP01 RF AGC SIF IN HEADPHONE Q131 CF131 TV.V V OUT BUFFER 4.5MHz TRAP...
- Page 6 AV-14F3PX AV-14F3PX CIRCUIT DIAGRAMS MAIN PWB CIRCUIT DIAGRAM (1/2) MAIN PWB ASS'Y SGA-1051A-H2 (AV-14F3PX-PH) No. 56083 No. 56083...
- Page 7 AV-14F3PX AV-14F3PX MAIN PWB CIRCUIT DIAGRAM (2/2) CRT SOCKET CRT SOCKET PWB (WITHIN MAIN PWB) MAIN PWB ASS'Y SGA-1051A-H2 (AV-14F3PX-PH) No. 56083 2-10 No. 56083...
- Page 8 AV-14F3PX AV-14F3PX PATTERN DIAGRAMS MAIN PWB PATTERN FRONT TP-E TP-91 (B1) 2-11 2-12 No. 56083 No. 56083...
- Page 9 AV-14F3PX CRT SOCKET PWB PATTERN No. 56083 2-13...
- Page 10 AV-21FT VICTOR COMPANY OF JAPAN, LIMITED TELEVISION RECEIVER DIVISION 1106 Heta, Iwai-city, Ibaraki-prefecture, 306-0698, Japan Printed in Japan CTH 0009 2-14 No. 56083...
