Bluetooth Handheld Scanner SD160BT
Sigmann DELTA GmbH
Hauptstraße 53
D-74928 Hüffenhardt
UstIDNr: DE257944309
Operating Instructions
Type SD.113.000.0x
Date: 10.10.2013
Tel. 06268-92899-73
Fax 06268-92899-74
info@sigmann-delta.de
http://www.sigmann-delta.de
Commercial Register
Mannheim HRB 703603
Manager
Joachim Kraus
ex
Volksbank Kraichgau
BLZ 672 922 00 Konto 55258007
S.W.I.F.T.-Code GENO DE 61SSH
IBAN DE31 6729 2200 0055 2580 07
Advertisement
Table of Contents
Related Manuals for Sigmann DELTA SD160BTex
Summary of Contents for Sigmann DELTA SD160BTex
-
Page 1: Operating Instructions
Operating Instructions Bluetooth Handheld Scanner SD160BT Type SD.113.000.0x Date: 10.10.2013 Sigmann DELTA GmbH Tel. 06268-92899-73 Commercial Register Volksbank Kraichgau Hauptstraße 53 Fax 06268-92899-74 Mannheim HRB 703603 BLZ 672 922 00 Konto 55258007 D-74928 Hüffenhardt info@sigmann-delta.de Manager S.W.I.F.T.-Code GENO DE 61SSH UstIDNr: DE257944309 http://www.sigmann-delta.de... - Page 2 Operating Instructions_SD160BT _002...
-
Page 3: Table Of Contents
Table of contents Important Notes on the Operating Instructions 1.1. Safety Information ..................2 Notes on the Operating Instructions ..................3 General Notes of Caution ..................4 Product Information Manufacturer ..................6 Explosion Protection ..................6 Technical Data Handheld Scanner .................. -
Page 4: Important Notes On The Operating Instructions
1 Important notes on the Operating Instructions 1.1 Safety information Warnings are highlighted by a special symbol and a different font colour: Non-compliance may result in life-threatening situations. This warning must be heeded. Danger This type of warning concerns dangerous situations that may result in minor injuries. Warning Important and helpful notes and information. -
Page 5: Notes On The Operating Instructions
The notes contained in this manual are important for starting up and operating the product. These instructions may be updated at any time. Sigmann DELTA GmbH reserves the right to make changes to this document. -
Page 6: General Notes Of Caution
1.3 General notes of caution Caution / Notes The devices may only be operated when fully assembled. In hazardous areas the devices must not be wiped or cleaned with a dry cloth. The device must be switched off immediately if it is likely that as a consequence of damaging impact or general peculiarities the device can no longer be safely operated. - Page 7 Caution Devices fitted with laser fall under standards US 21 CFR 1040.10 and EN on laser devices 60825-1. The laser's classification is stated on a plate affixed to the device. Class 1 lasers are deemed inherently safe during normal use, but users must not look directly into the light source.
-
Page 8: Product Information
2 Product information 2.1 Manufacturer Sigmann DELTA GmbH Hauptstraße 53 74928 Hüffenhardt Germany Device SD160BT type: SD.113.0000.0x 2.2 Explosion II 2G Ex ib IIC T4 protection II 2G Ex ib IIC T4 Gb II 2D Ex ib IIIC T135C II 2D Ex ib IIIC T135C Db... -
Page 9: Technical Data Base Charging Station
2.4 Technical Data Base charging station Ambient temperature -20°C to +50°C Base charging station Bluetooth Bluetooth V 2.1 EDR, Class 2 Base charging station 2.4 ... 2.4835 GHz (ISM band) Terminal assignment USB cable RS 232 cable (Base charging station) USB/D+ green RS 232-TXD white USB/D- white... -
Page 10: Type Numbers
2.5 Type numbers SD.113.0000.00 Standard version SD 113.0000.01 Stacked PDF version Both are for use with accu SD.Z10.0018.00 and a base charging station of your choice (see below) Explosion-protected connection cable USB SD.Z10.0011.0x / RS232 SD.Z10.0010.0x or a non-explosion-protected connection cable USB SD.Z10.0013.0x / RS232 SD.Z10.0012.0x and a power supply SDVM125 , depending on voltage and interface... -
Page 11: System Assembly
3 System assembly 3.1 System assembly 1 Overview of the complete system assembly 1, Bluetooth handheld scanner SD160BT Assembly with base charging sta- tion and power supply in hazard- ous area Description: The Bluetooth handheld SD160BT scanner (SD.113.0000.0x) was designed for use in hazardous areas. Normal operation requires a base charging station (SD.114.0000.00), a connection cable between the base charging station and the SDVM125 power supply (SD.211.xx11.00) and a connection cable between the power supply... - Page 12 3.2 System Assembly 2 Overview of the complete system assembly 2, Bluetooth handheld scanner SD160BT Assembly with base charging sta- tion in non-hazardous areas Description: The Bluetooth handheld SD160BT scanner (SD.113.0000.0x) can also be used separately in the hazardous area. The base charging station (SD.Z10.0015.00) is then operated in the non-hazardous area.
-
Page 13: Cable Range In System Assembly 1
3.3 Cable range in system assembly 1 1,8 or 3,8m SD160BT optional with 4,5m RS232 Base charging SDVM125 Up to 20m Host or 6m station extension SD160BT Base charging 1,8 or 3,8 m SDVM125 Up to 5m Host station 3.4 Cable range in system assembly 2 SD160BT 1,8 or 3,8m Non hazardous... -
Page 14: Step-By-Step Guide On Installation And Operation
4 Step-by-step guide on installation and operation 4.1 Preparation handheld SD160BT scanner for system assembly 1 and 2 Do not replace accu in hazardous areas. Incorrect handling may result in the termination of the operating permit. The accu compartment is located at the bottom of the Bluetooth handheld SD160BT scanner. - Page 15 4.2 Using the base charging station for system assembly 1 (Use the base charging station in hazardous area) The device has been closed ex-factory. Incorrect handling may result in the termination of the operating permit. The cable connecting the base charging station to the power supply is: SDZ10.0011.00 for USB or SD.Z10.0010.00 for RS232.
- Page 16 4.3 Using the base charging station for system assembly 2 (Use base charging station in non hazardous area) Use power supply SDZ10.0016.00 to load the scanner with a non- explosion-protected base charging station in a non-hazardous area. This connection is closed ex-factory for a base charging station for hazardous areas.
-
Page 17: Power Supply
4.4 Pin assignment SDVM125 power supply with RS232 interface (SD.211.x011.00) Supply of the base charging station according to system assembly 1 with plug connection The pin assignment is located underneath the removable cover at the front of the power supply. Caution! Do not open enclosure in the hazardous area! Before operating the device in a hazardous area you have to ensure... -
Page 18: Ex Rs232
Direct connection of the base charging station (SD.114.0000.00) without plug connection to the power supply SDVM125 with RS232 interface (SD.211.x011.00) Connection of base charging station RS232 SD.Z10.0010.0x - Connection with cable end sleevs RJ 45 Base charging station SD160BT RS232 Pin assign- Wire colours Definition... - Page 19 4.5 Pin assignment SDVM125 power supply with USB interface (SD.211.x111.00) Supply of the base charging station according to system assembly 1 - with plug connection The terminal assignment is located underneath the removable cover at the front of the power supply. Caution! Do not open enclosure in the hazardous area! Before operating the device in a hazardous area you have to ensure...
-
Page 20: Ex Usb
Direct connection of the base charging station (SD.114.0000.00) without plug connection to the SDVM125 power supply with USB interface (SD.211.x111.00) Connection base charging station USB SD.Z10.0011.0x - Connection with cable end sleevs RJ 45 Base charging station SD160 Pin assign- Wire colours Definition Assignment... -
Page 21: Attachment
5 Attachment 5.1 EC type examination certificate: SD160BT and SD160BT base charging station Operating Instructions_SD160BT _002... - Page 22 Operating Instructions_SD160BT _002...
- Page 23 5.2 EC type examination certificate: Power supply SDVM125 Operating Instructions_SD160BT _002...
- Page 24 Operating Instructions_SD160BT _002...
- Page 25 Operating Instructions_SD160BT _002...
- Page 26 Operating Instructions_SD160BT _002...
- Page 27 6 Contact Sigmann DELTA GmbH Hauptstraße 53 D-74928 Hüffenhardt Tel. +49 (0) 6268 / 92899 - 73 Fax +49 (0) 6268 / 92899 - 74 info@sigmann-delta.de Operating Instructions_SD160BT _002...
