SD161BT
Type SD.118.0000.0X
Sigmann DELTA GmbH
Hauptstraße 53
D-74928 Hüffenhardt
UstIDNr: DE257944309
Operating Instructions
Bluetooth Handheld Scanner
ex
Date: 11.02.2020
Tel. 06268-92899-73
Fax 06268-92899-74
info@sigmann-delta.de
http://www.sigmann-delta.de
SD261BT
3rd
ex
Type SD.11B.000.00
Handelsregister
Mannheim HRB 703603
Geschäftsführer
Joachim Kraus

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SD161BTex and is the answer not in the manual?

Questions and answers

Related Manuals for Sigmann DELTA SD161BTex

Summary of Contents for Sigmann DELTA SD161BTex

  • Page 1 Operating Instructions Bluetooth Handheld Scanner SD161BT SD261BT Type SD.118.0000.0X Type SD.11B.000.00 Date: 11.02.2020 Sigmann DELTA GmbH Tel. 06268-92899-73 Handelsregister Hauptstraße 53 Fax 06268-92899-74 Mannheim HRB 703603 D-74928 Hüffenhardt info@sigmann-delta.de Geschäftsführer UstIDNr: DE257944309 http://www.sigmann-delta.de Joachim Kraus...
  • Page 2 SD160BTex_BA_en_008.docx...

  • Page 3: Table Of Contents

    Table of contents Product range Bluetooth Scanner Zone 1 Scanner overview Compatible Scanner and Base station overview Important Notes on the Operating Instructions 4.1. Safety Information ................... 6 Notes on the Operating Instructions ................... 7 General Notes of Caution ................... 8 Product Information SD161BT Explosion Protection ..................
  • Page 4 System Assembly - 2D Scanner SD261BT System assembly 1 – Explosion-protected base charging station ........ 21 System assembly 2 – Non-explosion-protected base charging station ........ 21 Cable range in system assembly Cable range in system assembly 1 .......... 22 Cable range in system assembly 2 ..........
  • Page 5 1 Product range Bluetooth scanner Zone 1 SD160BTex_BA_en_008.docx...

  • Page 6: Scanner Overview

    2 Scanner overview Wired Bluetooth SD160      SD160      SD260      SD161BT      SD161BT      SD261BT     ...

  • Page 7: Compatible Scanner And Base Station Overview

    3 Compatible Scanner and Base station overview Typenumber Typenumber Scanner Power supply Base station/ SDVM125ex Scanner Charging station SD.119.0000.00 / SD161BT SD.118.0000.0X SD.11C.0000.00 with USB-Connection: SD.211.X111.00 with RS232-Connection: SD.211.X011.00 SD.211.X001.00 SD.119.0000.00 / SD261BT SD.11B.0000.0X SD.11C.0000.00 SD161BT SD.118.0000.0X SD.Z10.0035.00 With USB-Connection: PC USB-Interface Wtih RS232-Connection: only 5V-non hazardous...

  • Page 8: Important Notes On The Operating Instructions

    4 Important notes on the Operating Instructions 4.1 Safety information Warnings are highlighted by a special symbol and a different font colour: Non-compliance may result in life-threatening situations. This warning must be heeded. Danger This type of warning concerns dangerous situations that may result in minor injuries. Warning Important and helpful notes and information.

  • Page 9: Notes On The Operating Instructions

    The notes contained in this manual are important for starting up and operating the product. These instructions may be updated at any time. Sigmann DELTA GmbH reserves the right to make changes to this document.

  • Page 10: General Notes Of Caution

    4.3 General notes of caution Caution / Notes The devices may only be operated when fully assembled. In hazardous areas the devices must not be wiped or cleaned with a dry cloth. The device must be switched off immediately if it is likely that as a consequence of damaging impact or general peculiarities the device can no longer be safely operated.
  • Page 11 Caution Devices fitted with laser fall under standards US 21 CFR 1040.10 and on laser devices EN 60825-1. The laser's classification is stated on a plate affixed to the device. Class 1 lasers are deemed inherently safe during normal use, but users must not look directly into the light source.

  • Page 12: Product Information Sd161Bt

    II 2D Ex ib IIIC T135C II 2D Ex ib IIIC T135C Db Certification IBExU 12 ATEX 1162 IECEx IBE 15.0017 Manufacturer Sigmann DELTA GmbH Hauptstraße 53 74928 Hüffenhardt Germany 5.2 Technical data With Battery type SD.Z10.0017.00 3,6 V; 1500 mAh With Battery type SD.Z10.0018.00...

  • Page 13: Technical Data Base Charging Station Sdx61Bt Ex Basis

    5.3 Technical data Base charging station SDX61BT Basis for SD161BT Ambient temperature -20°C to +50°C Base charging station Bluetooth Bluetooth V 2.1 EDR, Class 2 Base charging station 2,4 ... 2,4835 GHz (ISM Band) Terminal assignment USB-Cable RS 232-Cable (Base charging station) USB/D+ green RS 232-TXD white USB/D- white...

  • Page 14: Ex Basis 3Rd

    5.4 Technische Daten Base charging station SDX61BT Basis 3rd for SD161BT Ambient temperature -20°C to +50°C Base charging station Bluetooth 1D Bluetooth V2.1 EDR, Klasse 2 Base charging station Up to 30m radius 2D Bluetooth V4.0 EDR, Klasse 1 Up to 100m radius (2,402 ...

  • Page 15: Type Numbers - 1D Scanner Sd161Bt

    5.5 Type numbers - 1D Scanner SD161BT SD.118.0000.00 Standard 1D SD.118.0000.01 Standard 1D, Stacked PDF Both are for use with accu SD.Z10.0018.00 and a base charging station of your choice (see below) Explosion-protected connection cable USB SD.Z10.0011.0X / RS232 SD.Z10.0010.0X or a non-explosion-protected connection cable USB SD.Z10.0013.0X / RS232 SD.Z10.0012.0X and a power supply SDVM125...

  • Page 16: System Assembly - 1D Scanner Sd161Bt

    6 System assembly - 1D Scanner SD161BT 6.1 System assembly 1 Overview of the complete system assembly 1, Bluetooth handheld scanner SD161BT Assembly with base charging sta- tion and power supply in hazard- ous area Description: The Bluetooth handheld SD161BT scanner (SD.118.0000.0x) was designed for use in hazardous areas.

  • Page 17: System Assembly 2 - Non-Explosion-Protected Base Charging Station

    6.2 System Assembly 2 Overview of the complete system assembly 2, Bluetooth handheld scanner SD161BT Assembly with base charging sta- tion in non-hazardous areas Description: The Bluetooth handheld SD161BT scanner (SD.118.0000.0X) can also be used separately in the hazardous area. The base charging station (SD.Z10.0035.00) is then operated in the non-hazardous area.

  • Page 18: Product Information Sd261Bt

    II 2D Ex ib op is IIIC T135C II 2D Ex ib op is IIIC T135C Db Certification IBExU 12 ATEX 1162 IECEx IBE 15.0017 Manufacturer Sigmann DELTA GmbH Hauptstraße 53 74928 Hüffenhardt Germany 7.2 Technical data With Battery Type SD.Z10.0017.00 3,6 V; 1500 mAh With Battery Type SD.Z10.0018.00 3,6 V;...
  • Page 19 7.3 Technical data Base charging station SDX61BT Basis for SD261BT Ambient temperature -20°C to +50°C Base charging station Bluetooth V 2.1 EDR, Class 2 Bluetooth Base charging station 2,4 ... 2,4835 GHz (ISM Band) Terminal assignment USB-Cable RS 232-Cable (Base charging station) USB/D+ green RS 232-TXD white USB/D- white...

  • Page 20: Ex Basis

    7.4 Technische Daten Base charging station SDX61BT Basis 3 for SD261BT Ambient temperature -20°C to +50°C Base charging station Bluetooth 1D Bluetooth V2.1 EDR, Klasse 2 Base charging station Up to 30m radius 2D Bluetooth V4.0 EDR, Klasse 1 Up to 100m radius (2,402 ...

  • Page 21: Type Numbers - 2D Scanner Sd261Bt

    7.5 Type numbers - 2D Scanner SD261BT SD 116.0000.00 Standard 1D, Stacked PDF, 2D Scanner for use with accu SD.Z10.0018.00 and a base charging station of your choice (see below) Explosion-protected connection cable USB SD.Z10.0011.0x / RS232 SD.Z10.0010.0x or a non-explosion-protected connection cable USB SD.Z10.0013.0x / RS232 SD.Z10.0012.0x and a power supply SDVM125 , depending on voltage and interface...

  • Page 22: System Assembly - 2D Scanner Sd261Bt Ex 3 Rd

    8 System assembly - 2D Scanner SD261BT 8.1 System assembly 1 Overview of the complete system assembly 1, Bluetooth handheld scanner SD261BT Assembly with base charging sta- tion and power supply in hazard- ous area Discription: The Bluetooth handheld SD161BT scanner (SD.11B.0000.00) was designed for use in hazardous areas.

  • Page 23: System Assembly 1 - Explosion-Protected Base Charging Station

    8.2 System Assembly 2 Overview of the complete system assembly 2, Bluetooth handheld scanner SD261BT Assembly with base charging sta- tion in non-hazardous areas Description: The Bluetooth handheld SD261BT scanner (SD.11B.0000.00) can also be used separately in the hazardous area. The base charging station (SD.Z10.0035.00) is then operated in the non-hazardous area.

  • Page 24: Cable Range In System Assembly

    9 Cable range in system assembly 9.1 Cable range in system assembly 1 SDX61BT Basis 3 1,8 or 3,8m SDX61BT Basis RS232 optional with 6m SDVM125 Up to 20m Host Base charching extension station SDX61BT Basis 3 SDX61BT Basis 1,8 or 3,8 m SDVM125 Up to 5m Host...

  • Page 25: Step-By-Step Guide On Installation And Operation

    10 Step-by-step guide on installation and operation 10.1 Preparation handheld scanner for system assembly 1 and 2 Do not replace accu in hazardous areas. Incorrect handling may result in the termination of the operating permit. The accu compartment is located at the bottom of the Bluetooth handheld scanner.

  • Page 26: Preparation Sd161Bt 10.2 Using Base Charging Station For System 1

    10.2 Using the base charging station SDX61BT Basis (SD.119.0000.00) and SDX61BT Basis 3 (SD.11C.0000.00) (Use the base charging station in hazardous area - System assembly 1) The device has been closed ex-factory. Incorrect handling may result in the termination of the operating permit.

  • Page 27: Using Base Charging Station For System 2

    10.3 Using the base charging station SDX61BT Basis (SD.Z10.0035.00) and SDX61BT Basis (SD.Z10.0034.00) (Use base charging station in non hazardous area - System assembly 2) Charge the handheld scanner in non hazardous area with a non- explosion-protected base charging station Use a non hazardous area power supply for supply o the base charg- ing station.

  • Page 28: Pin Assignment Power Supply Sdvm125

    10.4 Pin assignment power supply SDVM125 with RS232 interface (SD.211.X0X1.00) Supply of the base charging station according to system assembly 1 with plug connection The pin assignment is located underneath the removable cover at the front of the power supply. Caution! Do not open enclosure in the hazardous area! Before operating the device in a hazardous area you have to ensure...

  • Page 29: Ex Rs232

    Direct connection of the base charging station without plug connection to the power supply SDVM125 with RS232 interface (SD.211.X0X1.00), Connection of base charging station RS232 SD.Z10.0010.0X - Connection with cable end sleevs RJ 45 Pin Base charging station RS232 Wire colours Definition Assignment assignment...

  • Page 30: Pin Assignment Power Supply Sdvm125

    10.5 Pin assignment power supply SDVM125 with USB interface (SD.211.X1X1.00) Supply of the base charging station according to system assembly 1 - with plug connection The terminal assignment is located underneath the removable cover at the front of the power supply. Caution! Do not open enclosure in the hazardous area! Before operating the device in a hazardous area you have to ensure...

  • Page 31: Ex Usb

    Direct connection of the base charging station without plug connection to the SDVM125 power supply with USB interface (SD.211.X1X1.00), Connection base charging station USB SD.Z10.0011.0X - Connection with cable end sleevs RJ 45 Pin Base charging station USB Wire colours Definition Assignment assignment...

  • Page 32: Attachment

    11 Attachment 11.1 EC type examination certificate: SD160BT and SD160BT base charging station SD160BTex_BA_en_008.docx...
  • Page 33 SD160BTex_BA_en_008.docx...
  • Page 34 SD160BTex_BA_en_008.docx...
  • Page 35 SD160BTex_BA_en_008.docx...
  • Page 36 SD160BTex_BA_en_008.docx...

  • Page 37: Certificate Of Conformity Sd161Bt

    11.2 Certificate of Conformity SD160BTex and SD160BTex base charging station SD160BTex_BA_en_008.docx...
  • Page 38 SD160BTex_BA_en_008.docx...
  • Page 39 SD160BTex_BA_en_008.docx...
  • Page 40 SD160BTex_BA_en_008.docx...
  • Page 41 SD160BTex_BA_en_008.docx...
  • Page 42 SD160BTex_BA_en_008.docx...

  • Page 43: Eg-Type Examination Certificate Sdvm125 Ex

    11.3 EC type examination certificate: Power supply SDVM125 SD160BTex_BA_en_008.docx...
  • Page 44 SD160BTex_BA_en_008.docx...
  • Page 45 SD160BTex_BA_en_008.docx...
  • Page 46 SD160BTex_BA_en_008.docx...

  • Page 47: Certificate Of Conformity Sdvm125 Ex

    11.4 Certificate of Conformity Power supply SDVM125 SD160BTex_BA_en_008.docx...
  • Page 48 SD160BTex_BA_en_008.docx...
  • Page 49 SD160BTex_BA_en_008.docx...
  • Page 50 SD160BTex_BA_en_008.docx...
  • Page 51 SD160BTex_BA_en_008.docx...
  • Page 52 SD160BTex_BA_en_008.docx...

  • Page 53: Contact

    12 Contact Sigmann DELTA GmbH Hauptstraße 53 D-74928 Hüffenhardt Tel. +49 (0) 6268 / 92899 - 73 Fax +49 (0) 6268 / 92899 - 74 info@sigmann-delta.de SD160BTex_BA_en_008.docx...
