Sigmann DELTA SD160ex Operating Instructions Manual

Wired handheld scanner sd.112.0000.0x sd.115.0000.00
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Sigmann DELTA GmbH
Hauptstraße 53
D-74928 Hüffenhardt
UstIDNr: DE257944309

Operating Instructions

Wired handheld scanner
SD160
Type SD.112.0000.0X
ex
SD260
Type SD.115.0000.00
ex
Date: 03.12.2015
Tel. 06268-92899-73
Fax 06268-92899-74
info@sigmann-delta.de
http://www.sigmann-delta.de
Handelsregister
Mannheim HRB 703603
Geschäftsführer
Joachim Kraus
Volksbank Kraichgau
BLZ 672 922 00 Konto 55258007
S.W.I.F.T.-Code GENO DE 61SSH
IBAN DE31 6729 2200 0055 2580 07

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SD160ex and is the answer not in the manual?

Questions and answers

Related Manuals for Sigmann DELTA SD160ex

Summary of Contents for Sigmann DELTA SD160ex

  • Page 1: Operating Instructions

    Operating Instructions Wired handheld scanner SD160 Type SD.112.0000.0X SD260 Type SD.115.0000.00 Date: 03.12.2015 Sigmann DELTA GmbH Tel. 06268-92899-73 Handelsregister Volksbank Kraichgau Hauptstraße 53 Fax 06268-92899-74 Mannheim HRB 703603 BLZ 672 922 00 Konto 55258007 D-74928 Hüffenhardt info@sigmann-delta.de Geschäftsführer S.W.I.F.T.-Code GENO DE 61SSH UstIDNr: DE257944309 http://www.sigmann-delta.de...
  • Page 2 SD160 _BA_en_004...

  • Page 3: Table Of Contents

    Table of contents Product range wired handheld scanner Zone 1 Scanner overview Important Notes on Operating Instructions 3.1. Safety Information ....................4 Notes on Operating Instructions ....................5 General Notes of Caution ....................6 Product Information - SD160 Explosion Protection ........................8 Technical Data ........................

  • Page 4: Product Range Wired Handheld Scanner Zone

    Step-by-step Guide on Installation and Operation Connection Handheld Scanner SD160 / SD260 ..........17 Connection power supply SDVM125 RS232 ..........18 Direct Connection SD160 / SD260 to SDVM125 RS232 ..........19 Connection power supply SDVM125 ..........20 Direct Connection SD160 to SDVM125 ..........
  • Page 5 1 Product range wired handheld scanner Zone 1 SD160 _BA_en_004...

  • Page 6: Scanner Overview

    2 Scanner overview Wired Bluetooth SD160      SD160      SD260      SD160BT      SD160BT      SD161BT     ...

  • Page 7: Important Notes On Operating Instructions

    3 Important Notes on Operation Instructions 3.1 Safety information Warnings are highlighted by a special symbol and a different font colour: Non-compliance may result in life-threatening situations. This warning must be heeded. Danger This type of warning concerns dangerous situations that may result in minor injuries.

  • Page 8: Notes On Operating Instructions

    The notes contained in this manual are important for starting up and operating the product. These instructions may be updated at any time. Sigmann DELTA GmbH reserves the right to make changes to this document.

  • Page 9: General Notes Of Caution

    3.3 General Notes of Caution Caution / Notes The devices may only be operated when fully assembled. In hazardous areas the devices must not be wiped or cleaned with a dry cloth! The device must be switched off immediately if it is likely that as a consequence of damaging impact or general peculiarities the device can no longer be safely operated.
  • Page 10 Caution Devices fitted with laser fall under standards US 21 CFR 1040.10 and EN on laser devices 60825-1. The laser's classification is stated on a plate affixed to the device. Class 1 lasers are deemed inherently safe during normal use, but users must not look directly into the light source.

  • Page 11: Product Information - Sd160

    II 2D Ex ib IIIC T135C II 2D Ex ib IIIC T135C Db Certification IBExU 12 ATEX 1120 IECEx IBE 15.0016 Manufacturer Sigmann DELTA GmbH Hauptstraße 53 74928 Hüffenhardt Germany 4.2 Technical Data Type SD.112.0000.0X - RS232 5,6V (with connection cable SD.Z10.0007.XX)
  • Page 12 Typ SD.112.0000.0X - USB (with connection cable SD.Z10.0009.XX) maximum input voltage 4,9 V maximum input current 480 mA maximum input power 1,25 W maximum internal inductance negligible maximum internal capacitance 112,4 µF Technical data Light source: Visible red light, 630nm (Scan engine) LED safety: LED classification acc.

  • Page 13: Type Numbers

    4.3 Typenumbers - 1D Scanner SD160 SD.112.0000.00 Standard 1D RS232/RS422-5,6V-Version, used with connection cable SD.Z10.0007.XX and only for connection to 5.6V power supply SD.211.X001.XX SD.112.0000.00 Standard 1D RS232/RS422-4,9V-Version, used with connection cable SD.Z10.0008.XX and only for connection to power supply SD.211.X011.XX. SD.112.0000.00 Standard 1D USB-Version, used with connection cable SD.Z10.0009.XX...

  • Page 14: System Assembly - 1D Sanner

    5 System Assembly - 1D Scanner SD160 Overview of the complete system assembly, wire handheld scanner SD160 5.1 Description: The wired handheld scanner SD160 (SD.112.0000.0X) was designed for use in hazardous areas. Normal opera- tion requires an power supply SDVM125 (SD.211.XX11.00) a connection cable between power supply and scanner (SD.Z10.000X.XX) and a connection cable between power supply and a PC.

  • Page 15: Product Information - Sd260

    II 2D Ex ib IIIC T135C II 2D Ex ib IIIC T135C Db Certification IBExU 12 ATEX 1120 IECEx IBE 15.0016 Manufacturer Sigmann DELTA GmbH Hauptstraße 53 74928 Hüffenhardt Germany 6.2 Technical data Typ SD.115.0000.00 - RS232 4,9V (connection cable SD.Z10.0008.XX)
  • Page 16 Technical data Light source: Lighting-LEDs: Visible red light, 630nm (Scan engine) Laser: Visible red light 630nm LED safety: LED classification acc. to IEC62471 Laser safety Laser classification acc. to IEC60825-1 Class 1 Scan rate: 60 scans per second Reader distance: 35mm to 90 mm (0,13mm) Dimensions 104 x 76 x 185 mm (length x width x height)

  • Page 17: Type Numbers

    6.3 Type numbers - 2D Scanner SD260 SD.115.0000.00 Standard 1D, Stacked PDF, 2D RS232/RS422-5,6V-Version, used with connection cable SD.Z10.000X.XX 6.4 Serial numbers Serial key: year of manufactur serial number 2 numbers 4 numbers Example: 130001 6.5 Application The scanner is a handheld device. Its purpose is portable capture and direct transfer of data in hazardous areas.

  • Page 18: System Assembly - 2D Scanner

    7 System Assembly - 2D Scanner SD260 Overview of the complete system assembly, wire handheld scanner SD260 7.1 Description: The wired handheld scanner SD260 (SD.115.0000.00) was designed for use in hazardous areas. Normal opera- tion requires an power supply SDVM125 (SD.211.XX21.00), a connection cable between power supply and scanner (SD.Z10.000X.XX) and a connection cable between power supply and a PC.

  • Page 19: Cable Range In System Assembly For 1D And 2D Scanner

    8 Cable range in System Assembly with SD160 and SD260 1,8m or 3,8m SD160 or optional with RS232 SD125 Up to 20m Host SD260 4,5m or 6m extension SD160 1,8m or 3,8m SD125 Up to 5m Host SD160 _BA_en_004...
  • Page 20 9 Step-by-step guide on installation and operation 9.1 General connection of handheld scanner SD160 and SD260 Insert the RJ45 plug of the cable (SD.Z10.0008.XX, SD.Z10.0009.XX) at the bottom of the scanner to connect the handheld scanner with the power supply. Make sure the plug has engaged fully.
  • Page 21 9.2 Connection of power supply SDVM125 RS232 (SD.211.X0X1.00) The terminal assignment is located underneath the removable cover at the front of the power supply. Caution! Do not open enclosure in the hazardous area! Before operating the device in a hazardous area you have to ensure that the enclosure has been closed fully and all screws have been tightened.
  • Page 22 9.3 Direct connection of the handheld scanner SD160 (SD. 112.0000.0X) or handheld scanner SD260 (SD.115.0000.00) without plug connection to the SDVM125 power supply with RS232 interface (SD.211.X0X1.00) - connection with cable end sleeve Pin assignment RS232 connection cable Wired handheld scanner Power supply (SD.Z10.0008.0X) SD160...
  • Page 23 9.4 Connection of power supply SDVM125 USB (SD.211.X1X1.00) Only for handheld scanner SD160 The terminal assignment is located underneath the removable cover at the front of the power supply. Caution! Do not open enclosure in the hazardous area! Before operating the device in a hazardous area you have to ensure that the enclosure has been closed fully and all screws have been tightened.
  • Page 24 9.5 Direct connection of the handheld scanner SD160 (SD.112.0000.0X) without plug connection to the power supply SDVM125 with USB interface (SD.211.X1X1.00) - Connection with cable end sleeve Pin assignment UBS connection cable Power supply Wired handheld scanner SD160 (SD.Z10.0009.0X) RJ45 pin Connection Wire assign-...
  • Page 25 10 Attachment 10.1 EC type examination certificate: SD160 SD160 _BA_en_004...
  • Page 26 SD160 _BA_en_004...
  • Page 27 SD160 _BA_en_004...
  • Page 28 SD160 _BA_en_004...
  • Page 29 10.2 Certificate of Conformity SD160 SD160 _BA_en_004...
  • Page 30 SD160 _BA_en_004...
  • Page 31 SD160 _BA_en_004...
  • Page 32 10.3 EC type examination certificate: SDVM125 SD160 _BA_en_004...
  • Page 33 SD160 _BA_en_004...
  • Page 34 SD160 _BA_en_004...
  • Page 35 SD160 _BA_en_004...
  • Page 36 SD160 _BA_en_004...
  • Page 37 SD160 _BA_en_004...
  • Page 38 10.4 Certificate of Conformity SDVM125 SD160 _BA_en_004...
  • Page 39 SD160 _BA_en_004...
  • Page 40 SD160 _BA_en_004...
  • Page 41 SD160 _BA_en_004...
  • Page 42 SD160 _BA_en_004...
  • Page 43 SD160 _BA_en_004...
  • Page 44 SD160 _BA_en_004...
  • Page 45 11 Contact Sigmann DELTA GmbH Hauptstraße 53 D-74928 Hüffenhardt Tel. +49 (0) 6268 / 92899 - 73 Fax +49 (0) 6268 / 92899 - 74 info@sigmann-delta.de www.sigmann-DELTA.de SD160 _BA_en_004...
