Input
Tuner
Output
CD player
R SYSTEM 2 L
R SYSTEM 1 L
Processor
Output
PROCESSOR
IN IN
CD-R/MD
OUT OUT
AUX2 IN
TAPE
AUX1 OUT
TUNER R L
CD
R L
PHONO
NOTE:
Turn the knobs on the speaker terminals by hand.
(Do not use a tool to turn the knobs.)
Loosen the terminal
Figure 1
77
Tape Deck
Output
SPEAKER SYSTEMS
SYSTEM 1 :
SYSTEM 2 :
SYSTEM 1+2 :
SYSTEM 2
R
R SYSTEM 1
Turntable
5 mm
Insert the core
Connecttion of speaker cable
Input
8 - 16 OHMS
8 - 16 OHMS
16 OHMS
L
L
Tighten the terminal
