3. IC INFORMATIONS .................................................................................................................................... 3
8. IDLING CURRENT AND DC OFFSET VOLTAGE ALIGNMENT ............. 34 9. ELECTRICAL PARTS LIST ........................35 Please use this service manual with referring to the user guide (D.F.U) without fail. - PM7000 / PM8000 - 276W855010 ACT 3120 785 22011...
Page 2
MARANTZ Parts for your equipment are generally available to our National Marantz Subsidiary or Agent. ORDERING PARTS : Parts can be ordered either by mail or by Fax.. In both cases, the correct part number has to be specified.
All manuals and user guides at all-guides.com 1. SPECIFICATIONS Power output (class AB operation) RMS 8ohms (20 Hz - 20 kHz) ........95W DIN 8 ohms ..............105W THD at 8 ohms RMS rated output ....... 0.03% Damping factor ..............150 Power out put (PM8000 classA operation) RMS 8 ohms (20 Hz - 20 kHz) ........
All manuals and user guides at all-guides.com 2.TEST EQUIPMENT REQUIRED FOR SERVICING Item Distortion Analyzer Distortion measurements Audio Oscillator Sinewave and squarewave signal source AC VTVM Voltage measurements (AC) Oscilloscope Waveform analysis and trouble shooting and ASO alignment DC VTVM Voltage measurements (DC) AC Wattmeter Monitors primary power to amplifier...
All manuals and user guides at all-guides.com 3. IC INFORMATIONS MICROPROCESSOR TMP47C200BM BLOCK DIAGRAM LARGE CURRENT OUTPUT PORT SDIP42-P-600 POWER GND. FLAG H RESISTER L RESISTER PROGRAM DATA MEMORY ACCUMLATOR RAM ADDRESS BUFFER COUNTER (RAM) STACK PROGRAM MEMORY (ROM) HOLD INPUT HOLD INTERRUPT INTERRUPT HOLD OPERATION MODE CONTROL...
Page 6
All manuals and user guides at all-guides.com TA7317P (Position NO.7290) NJM2068 (Position NO.7501,7502,7503) NJM2068 TA7317P A OUTPUT A -INPUT B OUTPUT A +INPUT B-INPUT B+INPUT NJM2068 -INPUT +INPUT OUTPUT DETECT PC817 (Position NO.7269,7270) MUTING REGULATOR (POWER ON/OFF) PC817 RELAY SCHMITT DETECT DRIVE (OVER CURRENT)
All manuals and user guides at all-guides.com 4. BLOCK DIAGRAM PHONO EQ PHONO SYSTEM 1 POWER AMP SYSTEM 2 TUNER SOURCE DIRECT AUX 1 VOLUME AUX 2 HEADPHONES SOURCE SELECTOR TAPE CD-R/MD FLAT AMP TAPE BALANCE CD-R/MD VOLUME SOURCE TAPE CD-R CD-R TAPE...
All manuals and user guides at all-guides.com 6. SCHEMATIC DIAGRAM AND PARTS LOCATION (PARTS SIDE) FUNCTION & TAPE IN/OUT CIRCUIT 1257 H13 5604 J 5 1551 B 3 5605 H 8 1601 F 3 5606 H10 1602 G 2 5607 I10 1604 D13 5608 I11 7551...
Page 10
1232 J 3 1233 J 3 1234 K 3 BLACK 1401 L13 2201 G 2 2202 E 3 1206 From 2204 F14 PM7000 ONLY YKE31-0092 VOLTAGE FUSE HOLDER 2205 F15 2206 G15 9201 2207 H15 2208 I15 9202 2209 I15...
Page 11
All manuals and user guides at all-guides.com FRONT CIRCUIT 1401 B6 3487 F3 1402 B6 3488 F2 1403 H3 3489 G3 1405 A13 3490 G2 1406 B13 3491 H3 1407 D1 3492 H2 1408 G12 3493 H3 2401 B12 3494 H2 DIPMATE 2403 B6 3495 C11...
Page 15
All manuals and user guides at all-guides.com VOLUME CONTROL CIRCUIT (PM7000) 1651 B1 1655 D1 2654 D3 2658 C4 2662 D6 2666 C6 2670 C4 3653 A2 3657 B3 3661 A3 3665 B4 3669 B5 3673 B6 3681-A C2 7651 B3...
Page 16
All manuals and user guides at all-guides.com VOLUME CONTROL CIRCUIT (PM8000) 1651 C1 7655-A D5 1652 B8 7655-B B5 1653 A8 T117 C1 1654 E1 T118 C1 1655 E1 T119 C1 2651 B1 T120 C1 EH-B 2652 D2 T121 A8 1653 2653 B2 T122 A8...
Page 17
All manuals and user guides at all-guides.com FUNCTION & TAPE IN / OUT & POWER BOARD 1257 B 6 3562 C 3 9624 B 3 1232 A 8 3139 118 85360 - ... 3357p3 dd wk922 pm68/pwpanel-p3-970903-1 mech pm68/pwpanel-p3-970903-1 spcs 1551 C 1 3563 C 4 9625 B 3...
Page 18
All manuals and user guides at all-guides.com TONE BOARD (PM7000) TONE BOARD (PM8000) This assembly drawing shows a summary of all possible versions. For components used in a specific version see schematic diagram and respective This assembly drawing shows a summary of all possible versions. For components used in a specific version see schematic diagram and respective parts list.
Page 19
All manuals and user guides at all-guides.com VOLUME BOARD (PM7000) MAIN & SP PROTECT BOARD 1251 A 3 3304 D 2 6281 D 2 9256 B 2 PM68/mainpanel-p2-970507-1 mech PM68/mainpanel-p2-970507-1 spcs 3139 113 33542 3139 113 33542 1252 A 3...
All manuals and user guides at all-guides.com 7. EXPLODED VIEW AND PARTS LIST EXPLODED VIEW PM8000 Only 3139 119 31970 dd wk921...
Page 21
All manuals and user guides at all-guides.com POS. VERS. PART NO. DESCRIPTION COLOR (PCS) PM7000 BLK 3139 117 88070 FRONT PANEL BLACK PM8000 BLK 3139 117 88080 FRONT PANEL BLACK PM7000 GLD 3139 117 88050 FRONT PANEL GOLD PM8000 GLD...
All manuals and user guides at all-guides.com 8. IDLING CURRENT AND DC OFFSET VOLTAGE ALIGNMENT 8.1 Quiescent Current Adjustment for Class AB -Set to CD mode with no input, minimum volume position & mains supply at 230 V ±5 %. -Power up the unit, adjust SLOWLY 3299 (L) &...
All manuals and user guides at all-guides.com 9. ELECTRICAL PARTS LIST NOTE ON SAFETY FOR FUSIBLE RESISTOR : ASSIGNMENT OF COMMON PARTS CODES. RESISTORS : 1) GD05 x x x 140, Carbon film fixed resistor, ±5% 1/4W The suppliers and their type numbers of fusible resistors are as : 2) GD05 x x x 160, Carbon film fixed resistor, ±5% 1/6W follows ;...
Page 29
All manuals and user guides at all-guides.com POS. VERS. PART NO. POS. VERS. PART NO. DESCRIPTION DESCRIPTION COLOR (PCS) COLOR (PCS) SPK PROTECT CIRCUIT BOARD CAPACITORS 2277 4822 121 51387 FILM 10NF 20% 16V 2278 4822 124 40433 ELECT 47 F 20% 25V 2279 4822 124 40433 ELECT 47 F 20% 25V...
