1.1 INTRODUCTION
This operating handbook contains the necessary information for a sure and efficient
employment of the aircraft FLYSYNTHESIS STORCH S LSA ROTAX 912 UL 80 HP and
STORCH S JABIRU 2200 85 HP. Unless indicated, all descriptive data are valid for both
engine versions. The POH has been prepared to comply with the requirements of CS-VLA
and where relevant the ASTM standard.
The Pilot Operating Handbook is valid only for the particular aircraft identified on page 2,
the identification page.
1.2 WARNINGS, SUGGESTIONS AND NOTES
The observance of this manual is compulsory for the aircraft's use.
FLYSYNTHESIS S.r.l. declines every responsibility for any damage to person and thing
derived by a missed or partial observance of the prescriptions contained in this manual.
FLYSYNTHESIS S.r.l. reserves it, to terms of law, the exclusive ownership of this manual
and also forbids the partial or integral reproduction of it and however to communicate it to
competing firms without a preventive written authorization.
1.3 DESCRIPTIVES AIRCRAFTS DATA
TYPE OF AIRCRAFT
Storch S is ultra light aircraft with airframe, wing and control surfaces in composite materials.
The tail beam is made of aeronautical aluminum alloy, fixed on composite structure. The
retangular shape high wing utilizes a laminar flow airfoil section. The ailerons are differential
whilst the flaps are electrically operated plain type. The vertical tail control surface is
composed by a fixed fin and by a mobile rudder, the horizontal tail control surface is
completely mobile, hinged in the central part with integrated trim. The tricycle type landing
gear is fixed, with dampened nose wheel and with main legs made of either spring steel or
ERGAL aeronautical aluminum alloy.
The Storch S aircraft is approved for Day VFR only. Flight into bad weather with IFR
conditions by VFR pilots and aircraft is extremely dangerous. As the owner and operator of
an aircraft you are responsible for the safety of your passenger and yourself.
DIMENSIONS (valid for Rotax 912 UL and Jabiru 2200 engines)
General
Wing span:
Length:
Height:
Wing
Surface:
Wing chord:
Wing load:
Flap
Surface:
Pilot Operating Handbook and
Training Manual
FLY SYNTHESIS
STORCH S 500 LSA
(for Rotax 912 UL and
Jabiru 2200 engines versions
9.300 m
5.950 m
2.150 m
10.250 m2
1.100 m
44.500 kg/m2
0.620 m2
