1. Manuals
  2. Brands
  3. Fly Synthesis Manuals
  4. Aircrafts
  5. Texan top class 580 ISR
  6. Maintenance manual

Fly Synthesis Texan top class 580 ISR Maintenance Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

FLY SYNTHESIS
TEXAN TOP CLASS

MAINTENANCE MANUAL

02
15/02/11
01
20/12/10 Propeller auto pitch contr.
00
18/11/10
Num.
Date
REVISION
FlySynthesis s.r.l. Reserves in terms of law the exclusive ownership of this manual and also forbids the whole or partial reproduction of it.
(For Rotax 912 ULS)
Placard updated
New manual issue
Description
580 ISR
C. Cosatto
C. Cosatto
C. Cosatto
C. Cosatto
C. Cosatto
C. Cosatto
Issued
Verified
C. Cosatto
C. Cosatto
C. Cosatto
Approved

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Texan top class 580 ISR and is the answer not in the manual?

Questions and answers

Related Manuals for Fly Synthesis Texan top class 580 ISR

Summary of Contents for Fly Synthesis Texan top class 580 ISR

  • Page 1: Maintenance Manual

    FLY SYNTHESIS TEXAN TOP CLASS 580 ISR MAINTENANCE MANUAL (For Rotax 912 ULS) 15/02/11 Placard updated C. Cosatto C. Cosatto C. Cosatto 20/12/10 Propeller auto pitch contr. C. Cosatto C. Cosatto C. Cosatto 18/11/10 New manual issue C. Cosatto C. Cosatto C.

  • Page 2: Mortegliano (Ud) – Italy

    This manual may be revised in the future and pages/or sections re-issued in part or whole. Revisions will be available on the Fly Synthesis website www.flysynthesis.com. Any revisions and/or sections should be printed and replaced in the manual at the earliest possible time for flight safety.
  • Page 3 Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 3 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...
  • Page 4 Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 4 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...

  • Page 5: Table Of Contents

    Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 5 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...
  • Page 6 Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 6 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...

  • Page 7: General Safety Information

    Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 7 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...
  • Page 8 1.2 OWNER MAINTENACE The Texan Top Class 580 ISR has been designed as a simple aircraft that can be maintained by owners. Fly Synthesis allows normal maintenance up to 100 hourly servicing to be carried out by the owner.
  • Page 9 Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 9 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...
  • Page 10 Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 10 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...
  • Page 11 Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 11 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...

  • Page 12: Provincial Road N.78 Km 12.150

    Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 12 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...

  • Page 13: List Of Disposable Replacement Parts

    Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 13 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...

  • Page 14: Engine Specifications

    Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 14 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...
  • Page 15 Placard update 3.1 ENGINE SPECIFICATION The approved power plant installations for the TEXAN TOP CLASS 580 ISR is the ROTAX 912 ULS. For full detail of engine construction see ROTAX manuals. 3.2 ROTAX 912 S/ULS Version Performance Torque Max.RPM...
  • Page 16 Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 16 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...
  • Page 17 Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 17 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...

  • Page 18: Weight And Balance

    Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 18 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...
  • Page 19 Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 19 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...
  • Page 20 Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 20 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...
  • Page 21 Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 21 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...

  • Page 22: Tire Inflation Pressure

    Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 22 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...

  • Page 23: Changing The Tire And Tube Replacement

    Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 23 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...

  • Page 24: Approved Oils, Fuel And Quantity

    Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 24 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...
  • Page 25 Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 25 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...

  • Page 26: Fastener Torque Values

    Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 26 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...

  • Page 27: Recommended Fastener Torque Values

    Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 27 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...
  • Page 28 Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 28 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...
  • Page 29 Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 29 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...
  • Page 30 Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 30 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...

  • Page 31: Reporting Possible Safety Of Flight Concerns

    Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 31 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...

  • Page 32: Reporting Instructions

    FlySynthesis Srl in the following way. If your concern relates to engine internals you should notify the engine manufacturer. 8.2 FEED BACK FORM EXAMPLE ONLY Model Aircraft Texan Top Class 580 ISR Registration No 4X- XXXX Registration No Engine type and...

  • Page 33: Inspection Proceedures

    Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 33 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...
  • Page 34 Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 34 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...
  • Page 35 Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 35 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...
  • Page 36 Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 36 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...
  • Page 37 Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 37 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...
  • Page 38 Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 38 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...
  • Page 39 Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 39 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...
  • Page 40 Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 40 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...
  • Page 41 Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 41 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...
  • Page 42 Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 42 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...
  • Page 43 Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 43 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...
  • Page 44 Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 44 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...

  • Page 45: Landing Gear

    Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 45 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...
  • Page 46 Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 46 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...

  • Page 47: Fuel System

    Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 47 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...
  • Page 48 Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 48 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...
  • Page 49 Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 49 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...
  • Page 50 Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 50 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...
  • Page 51 Do not run engine with propeller disconnected or engine damage will result For a list of approved propellers see Appendix C of the supplementary approved optional equipment or consult the Technical dept of Fly Synthesis SRL directly. Written permission is required from the manufacturer prior to installing any non-listed...

  • Page 52: Instruments And Avionics

    Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 52 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...
  • Page 53 Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 53 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...
  • Page 54 Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 54 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...

  • Page 55: Electrical System

    Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 55 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...
  • Page 56 Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 56 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...
  • Page 57 Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 57 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...
  • Page 58 Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 58 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...
  • Page 59 Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 59 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...
  • Page 60 Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 60 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...
  • Page 61 Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 61 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...
  • Page 62 Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 62 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...
  • Page 63 Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 63 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...
  • Page 64 Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 64 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...
  • Page 65 Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 65 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...
  • Page 66 Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 66 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...
  • Page 67 Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 67 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...
  • Page 68 Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 68 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...
  • Page 69 Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 69 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...
  • Page 70 Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 70 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...
  • Page 71 Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 71 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...
  • Page 72 Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 72 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...
  • Page 73 Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 73 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...
  • Page 74 Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 74 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...
  • Page 75 Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 75 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...
  • Page 76 Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 76 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...
  • Page 77 Identification: MM_TC_580_Rev.2 Maintenance Manual Page: 77 of 77 Date: 15/02/11 FLY SYNTHESIS TEXAN Provincial Road n.78 Km 12.150 Issued: C. Cosatto 33050 Mortegliano (UD) – Italy Verified: C. Cosatto TOP CLASS 580 ISR Tel. +39.(0)432.992482 – +39.(0)432.993557 Approved: C. Cosatto Fax +39.(0)432.931280...

Table of Contents

Save PDF
