Christ Elektronik Touch-it XPC Operating Instructions Manual

Touch-panel

Advertisement

Quick Links

Document No.
Revision
Date
Address
Telephone
Fax
E-Mail
Internet
Copyright
Technical changes
Trademarks
Touch-it XPC
E461201
00
18.03.2010
Christ-Elektronik GmbH
Alpenstraße 34
DE-87700 Memmingen
+49 (0)8331 8371 – 0
+49 (0)8331 8371 – 99
info@christ-elektronik.de
http://www.christ-elektronik.de
No part of this documentation may in any form whatsoever be repro-
duced, nor used, copied or distributed by means of electronic systems
without previous written permission by Christ-Elektronik GmbH. The
translation into another language also requires a written permission. This
documentation may be exclusively entrusted to the owner of the installa-
tion or to the employees of Christ-Elektronik GmbH.
Christ-Elektronik GmbH reserves the right to change specifications, exe-
cutions and technical data held within this document without prior notice.
Brand and product names are trademarks or registered trademarks of
their respective owners.
Operating Instructions
Touch-Panel

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Touch-it XPC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Christ Elektronik Touch-it XPC

  • Page 1 Operating Instructions Touch-Panel Touch-it XPC Document No. E461201 Revision Date 18.03.2010 Address Christ-Elektronik GmbH Alpenstraße 34 DE-87700 Memmingen Telephone +49 (0)8331 8371 – 0 +49 (0)8331 8371 – 99 E-Mail info@christ-elektronik.de Internet http://www.christ-elektronik.de Copyright No part of this documentation may in any form whatsoever be repro- duced, nor used, copied or distributed by means of electronic systems without previous written permission by Christ-Elektronik GmbH.
  • Page 2: Table Of Contents

    Table of contents Page Pointers........................2 1.1. Used symbols......................2 1.2. General pointers......................2 1.3. Safety pointers ......................2 General........................4 Housing Types.......................5 3.1. VESA housing ......................5 3.2. Switchgear cabinet housing ..................5 3.3. In wall housing......................6 3.4. Open frame ......................6 Commissioning .....................7 4.1. Equipment .......................7 4.1.1.
  • Page 3: Pointers

    Pointers 1.1. Used symbols Symbols The following symbols are used in this instruction manual: DANGER! Denotes a direct threat of danger. Not observing this pointer may be life threatening or lead to serious injuries. CAUTION! Denotes a possibly dangerous situation. Not observing this pointer can cause minor injuries or lead to material damages.
  • Page 4 DANGER! Only the qualified staffs are allowed to carry out the repairs. The incorrect repair may lead to serious danger for the user. Avoid any penetration of liquid or dust. Do not expose the device to humidity for a long time! CAUTION! If the device is used for other purposes or incorrectly operated, Christ Elektronik GmbH will not hold damages liable.
  • Page 5: General

    1,6 GHz 6. Memory 2 GB, DDRII 7. Storage Compact Flash 8 GB, 133x Hard Disk Drive 120 GB, 2,5”, SATA 8. Operation Foil touch Table 1: overview Touch-it XPC Please refer to the order number for further information. E461201...
  • Page 6: Housing Types

    Housing Types In order to mount the touch panel, the following variants are available: 3.1. VESA housing Picture 1: VESA mounting mounting variants front view desk stand surface mounting individual holder-system 3.2. Switchgear cabinet housing Picture 2: switchgear cabinet housing mounting front view with fan...
  • Page 7: In Wall Housing

    3.3. In wall housing Picture 3: wall mounting housing front view built-in housing in the wall 3.4. Open frame Picture 4: open frame (with front USB) front view reverse view E461201...
  • Page 8: Commissioning

    VESA Housing VESA Housing VESA Housing VESA Housing Picture 5: power supply The Touch-it XPC VESA housing needs a power supply with Hirose connector (see chapter 4.3). A 24VDC power supply is included in the delivery. 4.1.2. 4.1.2. 4.1.2.
  • Page 9: Supply Voltage Application

    Picture 8: wiring diagram Touch-it XPC wall / cabinet housing Ethernet COM1 EIA-232 The interfaces are described in the chapter 7. 4.3. Supply voltage application Picture 9: connection supply voltage VESA housing Pin 1: 24 V DC nominal Pin 2: PE...
  • Page 10: Software

    Software 5.1. System Test and Initialization These routines test and initialize board hardware. If the routines encounter an error during the tests, you will either hear a few short beeps or see an error message on the screen. There are two kinds of errors: fatal and non-fatal.
  • Page 11: Changing Display Resolution

    Integrated Peripherals Use this menu to specify your settings for integrated peripherals. (Primary slave, secondary slave, keyboard, mouse etc.) Power Management Setup Use this menu to specify your settings for power management. (HDD power down, power on by ring, KB wake up, etc.) 5.3.1.
  • Page 12: Touch Panel Driver

    Touch Panel Driver 1. Click on [Start] [All Programs] [Pen Mount Universal Driver] [Pen Mount Control Panel] 2. Click on [Pen Mount 6000 USB] E461201...
  • Page 13 3. Click on [Standard Calibration] 4. Pressing the [Standard Calibration] button on the main window activates the calibration screen to carry out calibration of the Touch Panel. Briefly touch the center of the red square splayed on the screen in order as they appear. Once calibration is carried out, the calibrated value is saved.
  • Page 14: Interfaces

    Connection of the supply voltage, see chapter 4.3. 7.1. USB connection The Touch-it XPC offers two USB ports. The USB connections are pro- vided for the connection of storage media as well as peripheral equip- ment (USB Mouse or Keyboard).
  • Page 15: Ethernet (Lan)

    6: D2- pin 3: D2+ pin 7: D4+ pin 4: D3+ pin 8: D4- The Touch-it XPC offers two Ethernet network interfaces. 7.3. COM1 (EIA-232 interface) Picture 14: pin assignment EIA-232 interface (DB9 male socket) COM1 pin 1: DCD...
  • Page 16: Maintenance And Servicing

    Maintenance and servicing 8.1. Maintenance plan INFORMATION! Only the manufacturer (Christ-Elektronik GmbH) is allowed to replace the internal lithium battery. The calibration of the touch may be required from time to time. 8.2. Repairs DANGER! Only the qualified staffs are allowed to carry out the repairs. The incorrect repair may lead to serious danger for the user.
  • Page 17: Error Treatment And Disturbance Removal

    Error treatment and Disturbance removal Error Cause Remedy Wrong voltage supply Use adequate power supply unit Touch-Panel does not 24 V DC function Application download Voltage failure during a Send the Touch-Panel for check not possible anymore download. This could damage to Christ-Elektronik the bootloader.
  • Page 18: Technical Specifications

    Technical Specifications Touch-it XPC Display Screen Size 7” (17,8 cm) 10,4“ (26,4 cm) 15” (38,1 cm) Display Dimensions [mm] 155 x 94 215 x 162 304 x 228 800 x 480 800 x 600 1024 x 768 Native Resolution (Pixel)
  • Page 19 Touch-it XPC Material Front anodised aluminium Chassis (wall, cabinet) galvanised metal Chassis VESA anodised aluminium Weight [kg] User Environment Operating Temperature 0 to +50 ° C Storage Temperature -10 to +70 ° C Humidity 5% to 80% (non condensing) Degree of Protection (Front)
  • Page 20: Scale Drawing

    Scale Drawing 11.1. VESA Housing Picture 16: dimensions Touch-it XPC 7” E461201...
  • Page 21 Picture 17: dimensions Touch-it XPC 10,4” E461201...
  • Page 22 Picture 18: dimensions Touch-it XPC 15” E461201...
  • Page 23: 11.2. Switchgear Cabinet Housing

    11.2. Switchgear Cabinet Housing Picture 19: dimensions Touch-it XPC 10,4” with fan E461201...
  • Page 24 Picture 20: dimensions Touch-it XPC 10,4” fanless E461201...
  • Page 25 Picture 21: dimensions Touch-it XPC 15” with fan E461201...
  • Page 26 Picture 22: dimensions Touch-it XPC 15” fanless E461201...
  • Page 27: 11.3. In Wall Housing

    11.3. In Wall Housing Picture 23: dimensions Touch-it XPC 10,4” E461201...
  • Page 28 Picture 24: dimensions built-in housing for Touch-it XPC 10,4” E461201...
  • Page 29 Picture 25: dimensions Touch-it XPC 15” E461201...
  • Page 30 Picture 26: dimensions built-in housing for Touch-it XPC 15” E461201...
  • Page 31: Open Frame

    11.4. Open Frame with Front-USB Picture 27: dimensions Touch-it XPC 10,4” E461201...
