- Page 1 Model PD6120D User Guide Plasma Monitor...
-
Page 2: Important Information
Moreover, there is a serious risk of electric shock. 7. Do not attempt to service or repair the unit. Marantz is not liable for any bodily harm or damage caused if unqualified persons attempt service or open the back cover. - Page 3 4. Protect the inside of the unit from liquids and small metal objects. In case of accident, unplug the unit and have it serviced by an authorized Marantz Service Center. 5. Do not hit or scratch the panel surface as this causes flaws on the surface of the screen.
-
Page 4: Doc Avis De Conformation
Précautions Veuillez lire ce manuel avec attention avant d’utiliser votre moniteur Plasma Monitor Marantz et conserver ce manuel à portée de la main pour une consultation ultérieure. ATTENTION RISQUE D’ELECTROCUTION NE PAS OUVRIR MISE EN GARDE: AFIN DE REDUIRE LES RISQUES D’ELECTRO- CUTION, NE PAS DEPOSER LE COUVERCLE, IL N’Y... - Page 5 Pour protéger votre investissement dans ce moniteur Plasma Marantz, veuillez suivre les directives et les recommandations suivantes pour minimiser l’occurence de brûlure d’image : • Assurez-vous de mettre en marche et d’utliser Connecteur l’économisateur d’écran chaque fois que c’est possible...
-
Page 6: Before Requesting Service
To get warranty service: Repair must be performed by an authorized service center. If you do not know of a Marantz authorized Plasma Television service center, contact your dealer. If your dealer is an authorized service center, they will arrange for repair. -
Page 7: Table Of Contents
Contents How to Attach Options to the Plasma Monitor ... 1 Introduction ... 2 Introduction to the Plasma Monitor ... 2 The features you’ll enjoy include: ... 2 Contents of the Package ... 2 Options ... 2 Part Names and Function ... 3 Front View ... -
Page 8: How To Attach Options To The Plasma Monitor
(Wall mount unit, Stand, etc.) * See page 2. • For correct installation and mounting it is strongly recommended to use a trained, authorized Marantz dealer. Failure to follow correct mounting procedures could result in damage to the equipment or injury to the installer. -
Page 9: Introduction
PCs to DVD players- into art. And weighing only 134.5 lbs/ 61 kg, it actually can be hung almost anywhere. Marantz has made sure that a host of multimedia resources can be easily connected and displayed as brilliantly as intended on the Plasma Monitor. -
Page 10: Part Names And Function
Part Names and Function Front View VOLUME PROCEED DOWN qPROCEED Sets the On-Screen Menu (OSM) mode and displays the main menu. w VOLUME DOWN and UP Adjusts the volume. Functions as the CURSOR (L/ M) buttons in the On-Screen Menu (OSM) mode. e LEFT/–... -
Page 11: Rear View/ Terminal Board
Rear View/ Terminal Board AC IN RIGHT AC IN RIGHT A AC IN Connect the included power cord here. B EXT SPEAKER L and R Connect speakers here. Maintain the correct polarity. C EXTERNAL CONTROL This terminal is used when power ON/OFF, input selection and AUDIO MUTE and other controls are operated externally (by external control). -
Page 12: Remote Control
Remote Control q POWER ON/OFF Switches Power ON/OFF. (This does not operate when POWER/STANDBY indicator of the main unit is off.) w RGB/PC Press this button to select RGB/PC as the source. RGB/PC1 RGB/PC2 RGB/PC3 RGB/PC can also be selected using the INPUT SELECT button on the monitor. -
Page 13: Battery Installation And Replacement
!3 DISPLAY Displays the source settings on the screen. !4 OFF TIMER Activates the off timer for the unit. !5 MULTI Press this button to select a screen mode from among single mode, side by side, and picture in picture. !6 SELECT Press this button to select the active picture in a multi screen mode. -
Page 14: Operating Range
Operating Range * Use the remote control within a distance of about 7 m/ 23ft. from the front of the monitor’s remote control sensor and at horizontal and vertical angles of up to approximately 30°. * The remote control operation may not function if the monitor’s remote control sensor is exposed to direct sunlight or strong artificial light, or if there is an obstacle between the sensor and the remote control. -
Page 15: Installation
Installation To video inputs on the plasma monitor VIDEO 1 VIDEO 2 VIDEO 3 L ( MONO ) L ( MONO ) RGB 1 G / Y L ( MONO ) Signal cable To Mini D-Sub 15 pin connector on the plasma monitor RGB 3 (Digital RGB) Personal computer with a... -
Page 16: Connecting Your Pc Or Macintosh Computer
Connecting Your PC or Macintosh Computer Connecting your PC or Macintosh computer to your plasma monitor will enable you to display your computer’s screen image for an impressive presentation. The plasma monitor supports the signals described on page 47. To connect a PC, Macintosh or compatible graphics adapter, simply: 1. -
Page 17: External Speaker Connections
External Speaker Connections External speakers may be connected to the plasma monitor to reproduce sound from VIDEO, DVD or RGB signal sources. External speakers may be connected directly to the SPEAKERS terminals or indirectly by connecting a stereo system amplifier to the audio outputs. CAUTION: Unplug the plasma monitor and all connected components before connecting external speakers. -
Page 18: Pin Assignments And Signal Levels For 15 Pin Rgb (Analog)
Pin Assignments and Signal Levels for 15 pin RGB (Analog) 10 9 15 14 13 12 11 Pin Configuration and Signal of the RGB 3 IN Connector (DVI Connector) The unit is equipped with a type of connector commonly used for both analog and digital. (Functionally, this cannot be used for an analog input.) (TMDS can be used for one link only.) -
Page 19: Basic Operations
Basic Operations POWER To turn the unit ON and OFF: 1. Plug the power cord into an active AC power outlet. 2. Press the POWER ON button (on the remote control) to turn on the unit. The monitor’s POWER/STANDBY indicator will light up (green) when the unit is on. -
Page 20: Off Timer
OFF TIMER To set the off timer: The off timer can be set to turn the power off after 30, 60, 90 or 120 minutes. 1. Press the OFF TIMER button to start the timer at 30 minutes. 2. Press the OFF TIMER button to the desired time. 3. -
Page 21: Wide Operations
WIDE Operations Watching with a wide screen With this function, you can select one of four screen sizes. When watching videos or digital video discs 1. Press the WIDE button on the remote control. 2. Within 3 seconds ... Press the WIDE button again. The screen size switches as follows: ZOOM NORMAL... -
Page 22: Watching Computer Images With A Wide Screen
Watching computer images with a wide screen Switch to the wide screen mode to expand the 4 : 3 image to fill the entire screen. 1. Press the WIDE button on the remote control. 2. Within 3 seconds ... Press the WIDE button again. The screen size switches as follows: NORMAL FULL... -
Page 23: Multi Screen Operations
MULTI SCREEN Operations Showing a couple of pictures on the screen at the same time * An RGB-input picture may not be displayed in these modes, depending on the input signal specifications. 1. Press the MULTI button to select a screen mode from among single mode, side by side, and picture in picture. -
Page 24: Osm Controls
(On Screen Menu) Menu Operations The OSM window is displayed with respect to the screen as shown on the diagram. * Depending on the screen’s mode, the OSM may be displayed differently. In the explanation, the OSM section is shown close up. M A I N M E N U PICTURE SOUND... - Page 25 Main menu Sub menu PICTURE CONTRAST BRIGHTNESS SHARPNESS COLOR TINT PICTURE MODE COLOR TEMP Main menu Sub menu SOUND BASS TREBLE BALANCE Main menu Sub menu SCREEN V-POSITION H-POSITION V-HEIGHT H-WIDTH AUTO PICTURE FINE PICTURE PICTURE ADJ. Main menu Sub menu FUNCTION OSM ADJ.
-
Page 26: Picture Settings Menu
Picture Settings Menu Adjusting the picture The contrast, brightness, sharpness, color and tint can be adjusted as desired. Example: Adjusting the contrast Press the PROCEED button on the remote control to display the MAIN MENU on the screen, then... 1. Use the L and M buttons to select “PICTURE”, then press the PROCEED button. -
Page 27: Setting The Picture Mode According To The Brightness Of The Room
Setting the picture mode according to the brightness of the room There are four picture modes that can be used effectively according to the environment in which you are viewing the display. Example: Setting the “THEATER” mode Press the PROCEED button on the remote control to display the MAIN MENU on the screen, then... -
Page 28: Setting The Color Temperature
Setting the color temperature Use this procedure to set color tone produced by the plasma display. Example: Setting “1” Press the PROCEED button on the remote control to display the MAIN MENU on the screen, then... 1. Use the L and M buttons to select “PICTURE”, then press the PROCEED button. -
Page 29: Adjusting The Color To The Desired Quality
Adjusting the color to the desired quality Use this procedure to adjust the white balance for bright pictures and dark pictures to achieve the desired color quality. Example: Adjusting the “WHITE BALANCE” Press the PROCEED button on the remote control to display the MAIN MENU on the screen, then... -
Page 30: Reducing Noise In The Picture
Reducing noise in the picture Use these settings if the picture has noise due to poor reception or when playing video tapes on which the picture quality is poor. Example: Setting “NR-3” Press the PROCEED button on the remote control to display the MAIN MENU on the screen, then... -
Page 31: Sound Settings Menu
Sound Settings Menu Adjusting the treble, bass and left/right balance The treble, bass and left/right balance can be adjusted to suit your tastes. Example: Adjusting the bass Press the PROCEED button on the remote control to display the MAIN MENU on the screen, then... 1. -
Page 32: Adjusting The Position, Size, Fine Picture, Picture Adj
Screen Settings Menu Adjusting the Position, Size, Fine Picture, Picture Adj The position of the image can be adjusted and flickering of the image can be corrected. Example: Adjusting the vertical position in the normal mode Press the PROCEED button on the remote control to display the MAIN MENU on the screen, then... -
Page 33: Function Settings Menu
Information Adjusting the Auto Picture ON ... The Picture ADJ and Fine Picture adjustments are made automatically. OFF ... The Picture ADJ and Fine Picture adjustments are made manually. Adjusting the position of the image V-POSITION ... Adjusts the vertical position of the image. -
Page 34: Adjusting The Position Of The Menu Display
Adjusting the position of the menu display Use these operations to adjust the position of the menus that appear on the screen. Example: Adjusting the position of the menu display Press the PROCEED button on the remote control to display the MAIN MENU on the screen, then... 1. -
Page 35: Setting The Power Management For Computer Images
Setting the power management for computer images This energy-saving (power management) function automatically reduces the monitor’s power consumption if no operation is performed for a certain amount of time. Example: Turning the power management function on Press the PROCEED button on the remote control to display the MAIN MENU on the screen, then... -
Page 36: Power/Standby Indicator
POWER/STANDBY indicator Power management POWER/STANDBY Power management mode indicator operating status Green Not activated. Standby Orange Activated. Suspend Activated. Activated. Description Horizontal and vertical synchronizing signals are present from the computer. No horizontal synchronizing signals are sent from the computer. No vertical synchronizing signals are sent from the computer. -
Page 37: Setting The Gray Level For The Sides Of The Screen
Setting the gray level for the sides of the screen Use this procedure to set the gray level for the parts on the screen on which nothing is displayed when the screen is set to the 4:3 size. Example: Adjusting the “GRAY LEVEL” Press the PROCEED button on the remote control to display the MAIN MENU on the screen, then... -
Page 38: Setting Rgb3 Adj
Setting RGB3 ADJ. When the picture input from the RGB3 input terminal is distorted, select the most appropriate setting from among “1”, “2”, and “3”. Example: Setting “2” Press the PROCEED button on the remote control to display MAIN MENU on the screen, then... 1. -
Page 39: Resetting To The Default Values
Information AUTO ... The brightness of the screen is adjusted automatically to suit the picture quality. LOCK ... The brightness level is set to minimum. ORBITER ON ... The picture moves around the screen intermittently. OFF ... Orbiter mode does not function. INVERSE ON ... -
Page 40: Option Settings Menu
Option Settings Menu Setting the allocation of the audio connectors Setting the AUDIO 1, 2, and 3 connectors to the desired input. Example: Setting “AUDIO 1” to “VIDEO 2” Press the PROCEED button on the remote control to display the MAIN MENU on the screen, then... 1. -
Page 41: Setting A Computer Image To The Correct Rgb Select Screen
Information BNC SELECT RGB ... Uses the 5BNC terminal for RGB input. COMP..Use the 3BNC terminal for component input. Restoring the factory default settings Select “RESET” under the function menu. Note that this also restores other settings to the factory defaults. Setting a computer image to the correct RGB select screen With the computer image, select the RGB Select mode... -
Page 42: Setting High Definition Images To The Suitable Screen Size
Information RGB SELECT modes One of these 6 modes must be selected in order to display the following signals correctly. AUTO ... Select the suitable mode for the specifications of input signals as listed in the table “Computer input signals supported by this system” on page 47. -
Page 43: Setting The Picture Size For Rgb Input Signals
Setting the picture size for RGB input signals Use this procedure to switch the setting to “ON” or “OFF”. Example: Setting the “ON” mode to “OFF” Press the PROCEED button on the remote control to display the MAIN MENU on the screen, then... 1. -
Page 44: Setting The Language For The Menus
Setting the language for the menus The menu display can be set to one of seven languages: Japanese, English, German, French, Swedish, Italian or Spanish. Example: Setting the menu display to “DEUTSCH” Press the PROCEED button on the remote control to display the MAIN MENU on the screen, then... - Page 45 4. Once the setting is completed ... Press the EXIT button to return to the main menu. To delete the main menu, press the EXIT button once more. The color system is set to “3.58 NTSC”. Information Video signal formats Different countries use different formats for video signals.
-
Page 46: External Control
External Control Application These specifications cover the communications control of the plasma monitor by external equipment. Connections Connections are made as described below. External equipment plasma monitor e.g., Personal computer 1) Connector on the plasma monitor side: EXTERNAL CONTROL connector. Type of connector: D-Sub 9-pin male Pin Name No Connection... -
Page 47: Communication Format
Communication Format 8 bit 8 bit 8 bit 8 bit 8 bit 8 bit Command 1 Unit ID 1 Unit ID 2 Command 2 Data length Data Check sum Command 1 Command 1, along with command 2, is a number used to distinguish each command. -
Page 48: Command Reference List
Command Reference List CMD1 CMD2 LEN 01. Power ON 02. Power OFF 03. Input Switch Change 04. VOLUME Gain Data 05. SCREEN MODE Select 06. AUDIO Mute On 07. AUDIO Mute Off 08. OSM Select 09. Color Gain Data 10. TINT Gain Data 11. -
Page 49: Color Gain Data
06. AUDIO Mute On Function The external control equipment switches on AUDIO Mute of the plasma monitor. Transmission Data 07. AUDIO Mute Off Function The external control equipment switches off AUDIO Mute of the plasma monitor. Transmission Data 08. OSM Select Function The external control equipment switches on or off the on-screen menu (OSM) of the plasma monitor. -
Page 50: Sharpness Gain Data
11. SHARPNESS Gain Data Function The external control equipment changes the SHARPNESS gain data of the plasma monitor. Transmission Data DFH 80H DATA00 DATA01 DATA02 CKS DATA00: USER PICTURE Gain Flag DATA01: SHARPNESS Gain Flag DATA02: SHARPNESS Gain F0H: -16 FFH: -01 00H: 0 01H: +01... -
Page 51: Multi Screen Select
17. RED Gain Data Function The external control equipment changes the RED Gain Data of the plasma monitor. Transmission Data DFH 80H DATA00 to DATA03 DATA00: USER PICTURE Gain Flag DATA01: RED Gain Flag DATA02: RED Gain 1 (Bias) D8H: -40 FFH: -1 00H: 0 IEH: +30... -
Page 52: Video Adj Request
21. VIDEO ADJ Request Function The display returns the video adjustments information by the external control equipment’ s request. Transmission Data 0CH DATA00 to DATA0B CKS DATA00: RED Gain(Bias) D8H: -40 FFH: -1 00H: 0 IEH: +30 DATA01: GREEN Gain(Bias) D8H: -40 FFH: -1 00H: 0... -
Page 53: Failure Mode Request
22. Audio Select Set Function The external control equipment sets combinations of audio and video inputs for the plasma monitor. Transmission Data DFH 80H DATA00 DATA01 CKS DATA00: AUDIO INPUT 01H: AUDIO 1 02H: AUDIO 2 03H: AUDIO 3 DATA01: VISUAL INPUT 01H: Video 1 02H:... -
Page 54: Table Of Signals Supported
Table of Signals Supported Supported resolution • When the screen mode is NORMAL, each signal is converted to a 1024 dots 768 lines signal. (Except for * • When the screen mode is TRUE, the picture is displayed in the original resolution. •... - Page 55 *1 Only when using a graphic accelerator board that is capable of displaying 852 480. *2 This signal is converted to a 1228 dots *3 The picture is displayed in the original resolution. *4 The aspect ratio is 5:4. This signal is converted to a 960 dot 768 line signal. *5 Normally the RGB select mode suite for the input signals is set automatically.
-
Page 56: Troubleshooting
60 minutes. If the problem persists, contact your Marantz dealer for service. *2 In the following case, power off the monitor immediately and contact your dealer or authorized Marantz Service Center. The monitor turns off 5 seconds after powering on and then the POWER/STANDBY indicator blinks. It indicates that the power supply circuit or, one or more fans have been damaged. -
Page 57: Specifications
Specifications Product Name SLIM SERIES Plasma Monitor Product Code PD6120D Screen Size 53.2"(H) 29.9"(V) inches 1351(H) 760(V) mm diagonal 61" Aspect Ratio 16 : 9 Resolution 1365(H) 768(V) pixels Pixel Pitch 0.039"(H) 0.039"(V) inches 0.987(H) 0.987(V) mm Color Reproduction 256 levels, 16,770,000 colors... - Page 60 P.O. Box 685, Bell Village, Port Louis, Mauritius PO BOX 1280, Sandhausen 69200, Germany A division of Marantz Europe B.V., Building SFF2, P.O. Box 80002, 5600 JB Eindhoven, The Netherlands 14 Malvern Road, Mt. Albert, Auckland, New Zealand Sandkerveien 64, Oslo 0483, Norway P.O.
