RS-232C Control Specification
Category
Document Version
Author(s)
Date
Number of Page
All rights are reserved. Reproduction in whole or in part is prohibited without the written consent of copyright.
All specifications might be subject to change without notice.
PDxx01
:
Plasma Display
:
1.0
:
Marantz America, Inc.
:
2006/12/07
:
49
Marantz America, Inc. 2006
PDxx01 RS-232C Control
Specification : Rev.1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PDxx01 and is the answer not in the manual?

Questions and answers

Related Manuals for Marantz PDxx01

Summary of Contents for Marantz PDxx01

  • Page 1 Document Version Author(s) Date Number of Page Marantz America, Inc. 2006 All rights are reserved. Reproduction in whole or in part is prohibited without the written consent of copyright. All specifications might be subject to change without notice. PDxx01 Plasma Display Marantz America, Inc.

  • Page 2: Table Of Contents

    PDxx01 Table of Contents Application... 4 Connections... 4 2-1. Connector on the plasma monitor side: EXTERNAL CONTROL connector..4 2-2. Connector on the external equipment side: Serial port (RS-232C) connector..4 2-3. Wiring... 4 2-4. Communication Parameters ... 4 Communication Format...
  • Page 3 PDxx01 5-38. HD Select... 26 5-39. LANGUAGE Select... 26 5-40. COLOR SYSTEM Select ... 27 5-41. FREQUENCY Request (SIGNAL INFORMATION) ... 27 5-42. Input MODE Request ... 29 5-43. VIDEO ADJ. Request ... 29 5-44. Audio Select Request ... 31 5-45.

  • Page 4: Application

    PDxx01 1. Application These specifications are applicable to plasma monitors and communications control from external equipment. "Please also support the command of VP series and refer to the manual of the conventional model about specification." 2. Connections Connections should be made as described below.

  • Page 5: Communication Format

    PDxx01 3. Communication Format 8bit 8bit Command 1 Unit ID 1 Unit ID 2 Command 2 Data length Data Check sum 3-1. Command1 Command 1, along with command 2, is a number used to distinguish each command. Bit1, Bit0: 11B or 10B :Usually, a form In the case of ACK, when the lower order 4 bits is FH (as in 3FH and 7FH), this indicates that the commands and data of the supported equipment have been received.

  • Page 6: Command Reference List

    PDxx01 4. Command Reference List Power ON Power OFF Input Switch Change VOLUME Gain Data AUDIO Mute ON AUDIO Mute OFF CONTRAST Gain Data BRIGHT Gain Data SHARPNESS Gain Data Color Gain Data TINT Gain Data PICTURE MODE Select COLOR TEMP SELECT...
  • Page 7 PDxx01 PICTURE FREEZE PAUSE COMMAND OSM CONTRAST CLOSED CAPTION CAPTION CONTRAST PICTURE MEMORY Select PICTURE MEMORY Set PICTURE MEMORY NOTE WRITE SET UP LEVEL BACK GROUND PDP SAVER AUTO select Audio HDMI Request POWER ON MODE (INPUT) POWER ON MODE (VOLUME)

  • Page 8: Command

    PDxx01 5. Command 5-1. Power ON Function The external control equipment switches on the power of the plasma monitor. Transmission Data 9FH 80H 60H 4EH 00H CKS The plasma monitor returns the following ACK when the power is switched on.

  • Page 9: Volume Gain Data

    PDxx01 5-4. VOLUME Gain Data Function The external control equipment changes the VOLUME gain data of the plasma monitor. Transmission Data DFH 80H 60H 7FH 03H DATA00 DATA01 DATA02 CKS DATA00: USER SOUND Gain Flag DATA01: VOLUME Gain Flag DATA02: VOLUME Gain...

  • Page 10: Contrast Gain Data

    PDxx01 5-7. CONTRAST Gain Data Function The external control equipment changes the CONTRAST gain data of the plasma monitor. Transmission Data DFH 80H 60H 7FH 03H DATA00 DATA01 DATA02 CKS DATA00: USER PICTURE Gain Flag DATA01: CONTRAST Gain Flag DATA02: CONTRAST Gain...

  • Page 11: Sharpness Gain Data

    PDxx01 5-9. SHARPNESS Gain Data Function The external control equipment changes the SHARPNESS gain data of the plasma monitor. Transmission Data DFH 80H 60H 7FH 03H DATA00 DATA01 DATA02 CKS DATA00: USER PICTURE Gain Flag DATA01: SHARPNESS Gain Flag DATA02: SHARPNESS Gain...

  • Page 12: Tint Gain Data

    PDxx01 5-11. TINT Gain Data Function The external control equipment changes the TINT gain data of the plasma monitor. Transmission Data DFH 80H 60H 7FH 03H DATA00 DATA01 DATA02 CKS DATA00: USER PICTURE Gain Flag DATA01: TINT Gain Flag DATA02: TINT Gain * TINT Gain is from -22 (EAH) to +22 (16H) only during video.

  • Page 13: Color Temp Select

    PDxx01 5-13. COLOR TEMP SELECT Function The external control equipment changes the COLOR TEMP of the plasma monitor. Transmission Data DFH 80H 60H 00H 01H DATA00 CKS DATA00: 00H: low 01H: middle 02H: high 03H: middle low 7FH 60H 80H 00H 01H DATA00 CKS...

  • Page 14: Green Gain Data

    PDxx01 5-15. GREEN Gain Data Function The external control equipment changes the GREEN Gain Data of the plasma monitor. Transmission Data DFH 80H 60H 7FH 04H DATA00 to DATA03 CKS DATA00: USER PICTURE Gain Flag DATA01: GREEN Gain Flag DATA02: GREEN Gain1 (Bias)

  • Page 15: Nr Mode Set

    PDxx01 5-17. NR MODE Set Function The external control equipment sets the NR (Noise Reduction) mode of the plasma monitor. Transmission Data DFH 80H 60H C0H 01H DATA00 CKS DATA00: 01H: NR OFF 02H: NR-1 03H: NR-2 04H: NR-3 7FH 60H 80H C0H 01H DATA00 CKS...

  • Page 16: Treble Gain Data

    PDxx01 5-19. TREBLE Gain Data Function The external control equipment changes the TREBLE gain data of the plasma monitor. Transmission Data DFH 80H 60H 7FH 03H DATA00 DATA01 DATA0 CKS DATA00: USER PICTURE Gain Flag DATA01: TREBLE Gain Flag DATA02: TREBLE Gain...

  • Page 17: Screen Mode Select

    PDxx01 5-21. SCREEN MODE Select Function The external control equipment switches the screen mode of the plasma monitor. Transmission Data DFH 80H 60H 51H 01H DATA00 CKS DATA00 02H: STADIUM 03H: ZOOM 04H: NORMAL 05H: ANAMORHIC (FULL) 06H: REAL 08H: UNDERSCAN 09H: 14:9 0AH: 2.35:1...

  • Page 18: Position Gain Data

    PDxx01 5-23. H. POSITION Gain Data Function The external control equipment changes the H. POSITION gain data of the plasma monitor. Transmission Data DFH 80H 60H 7FH 03H DATA00 DATA01 DATA02 CKS DATA00: USER PICTURE Gain Flag DATA01: H.POSITION Gain Flag DATA02: H.POSITION Gain...

  • Page 19: Auto Picture Select

    PDxx01 5-26. AUTO PICTURE Select Function The external control equipment switches on or off the AUTO PICTURE of the plasma monitor. Transmission Data DFH 80H 60H 7FH 03H DATA00 DATA01 DATA02 CKS DATA00: USER PICTURE Gain Flag DATA01: AUTO PICTURE Select Flag...

  • Page 20: Clock (Picture Adjust) Gain Data

    PDxx01 5-28. CLOCK (PICTURE ADJUST) Gain Data Function The external control equipment changes the CLOCK gain data (ratio of frequency division) of the plasma monitor. Transmission Data DFH 80H 60H 7FH 03H DATA00 DATA01 DATA02 CKS DATA00: USER PICTURE Gain Flag...

  • Page 21: Gray Level Set

    PDxx01 5-31. GRAY LEVEL Set Function The external control equipment sets the GRAY LEVEL of the plasma monitor. Transmission Data DFH 80H 60H C6H 01H DATA00 CKS DATA00: GRAY LEVEL 7FH 60H 80H C6H 01H DATA00 CKS DATA00: GRAY LEVEL 5-32.

  • Page 22: Screen Wiper Set

    PDxx01 5-34. SCREEN WIPER Set Function The external control equipment sets the SCREEN WIPER of the plasma monitor. Transmission Data DFH 80H 60H C8H 04H DATA00 to DATA03 CKS DATA00: SCREEN WIPER DATA01: DATA02: DATA03: 3FH 60H 80H C8H 00H CKS 5-35.

  • Page 23: Audio Select Set

    PDxx01 5-36. Audio Select Set Function The external control equipment sets combinations of audio and video inputs for the plasma monitor. Transmission Data DFH 80H 60H 70H 02H DATA00 DATA01 CKS DATA00: AUDIO INPUT DATA01: VISUAL INPUT The plasma monitor returns the following ACK when the input is switched.

  • Page 24: Rgb Select

    PDxx01 5-37. RGB Select Function The external control equipment sets the RGB SELECT of the plasma monitor. Transmission Data DFH 80H 60H 8BH 01H DATA00 CKS DATA00 01H: AUTO 11H: type1 12H: type2 13H: type3 14H: type4 15H: type5 16H: type6...
  • Page 25 PDxx01 Type1 Type2 H mode:3 848x480 640x480 V mode:5 H mode:4 768×576 1920×1080 V mode:5 H mode:4 640×480 852×480 V mode:6 @60_1 H mode:4 720×400 720×350 V mode:7 1920×1035 (1035I) 1920×1080 H mode:5 800×600 V mode:6 (1080A) 1920×1080 (1080B) H mode:7 1280×768@5...

  • Page 26: Hd Select

    PDxx01 5-38. HD Select Function The external control equipment sets the HD SELECT of the plasma monitor. Transmission Data DFH 80H 60H 8AH 01H DATA00 CKS DATA00 01H: 1035I 02H: 540P (1080A) 03H: 1080I (1080B) 7FH 60H 80H 8AH 01H DATA00 CKS...

  • Page 27: Color System Select

    PDxx01 5-40. COLOR SYSTEM Select Function The external control equipment sets the COLOR SYSTEM of the plasma monitor. Transmission Data DFH 80H 60H 5CH 01H DATA00 CKS DATA00: 01H: 3.58NTSC 02H: 4.43NTSC 03H: PAL 04H: SECAM 0AH: AUTO 0BH: PAL60...
  • Page 28 PDxx01 Horizontal sync polarity DATA04 00H: - 01H: Positive 02H: Negative Vertical sync polarity DATA05 00H: - 01H: Positive 02H: Negative MODE DATA06 No signal 01H to 80H RGB signal Video signal A0H : HD/DVD/DTV signal A2H : A3H :...

  • Page 29: Input Mode Request

    PDxx01 5-42. Input MODE Request Function The display returns the current input information by the external control equipment’s request. Transmission Data 1FH 80H 60H 41H 00H CKS 7FH 60H 80H 41H 01H DATA00 CKS DATA00: Input Select 5-43. VIDEO ADJ. Request Function The display returns the video adjustments information by the external control equipment’s request.
  • Page 30 PDxx01 DATA03: COLOR Gain DATA04: TINT Gain DATA05: SHARPNESS Gain DATA06: CONTRAST Gain DATA07: BRIGHT Gain DATA08: RED Gain (Drive) RS-232C Control Specification E0H: -32 FFH: -01 00H: 0 01H: +01 20H: +32 E0H: -32 FFH: -01 00H: 0 01H: +01...

  • Page 31: Audio Select Request

    PDxx01 DATA09: GREEN Gain (Drive) DATA0A: BLUE Gain (Drive) DATA0B: COLOR TEMP SELECT 5-44. Audio Select Request Function The external control equipment inquires the current combinations of audio and video inputs for the plasma monitor. Transmission Data 1FH 80H 60H 6FH 00H CKS...

  • Page 32: Failure Mode Request

    PDxx01 5-45. Failure Mode Request Function The external control equipment inquires the detection of failures of the plasma monitor. Transmission Data 1FH 80H 60H 3FH 00H CKS The plasma monitor returns the following ACK: 7FH 60H 80H 3FH 02H DATA00 DATA01 CKS...

  • Page 33: Model Name Request

    PDxx01 5-46. MODEL NAME Request Function The external control equipment inquires the product code of the plasma monitor. Transmission Data 1FH 80H 60H 17H 00H CKS The plasma monitor returns the following ACK: 7FH 60H 80H 17H 0CH DATA00 to DATA11 CKS...

  • Page 34: Low Tone (50Inch Only)

    PDxx01 5-47. LOW TONE (50inch only) Function The external control equipment sets the Low toned of the plasma monitor. Transmission Data DFH 80H 60H 0CH 01H DATA00 CKS DATA00: 01H: Mode1 02H: Mode2 7FH 60H 80H 0CH 01H DATA00 CKS...

  • Page 35: Gamma Gain Data

    PDxx01 DATA06: RESET 00H: OFF 01H: ON 7FH 60H 80H 0DH 00H CKS 5-49. GAMMA GAIN Data Function External control apparatus changes Gamma of a plasma monitor. Transmission Data DFH 80H 60H 13H 02H DATA00 DATA01 CKS DATA00: GAMMA FLAG...

  • Page 36: Osm Orbiter

    PDxx01 5-51. OSM ORBITER Function In order to decrease printing of a screen by OSM display, whenever it displays OSM, shift operation of the OSM is carried out. Transmission Data DFH 80H 60H 5FH 01H DATA00 CKS DATA00 01H: ORBITER ON...

  • Page 37: S1/S2 Select

    PDxx01 5-54. S1/S2 SELECT Function External control apparatus sets up the S1/S2 detection of a plasma monitor. Transmission Data DFH 80H 60H 89H 01H DATA00 CKS DATA00 01H: AUTO 02H: OFF 7FH 60H 80H 89H 01H DATA00 CKS DATA00 01H: AUTO 02H: OFF 5-55.

  • Page 38: Multi (Sprit) Screen Select

    PDxx01 5-57. MULTI (SPRIT) SCREEN Select Function selects a screen mode from alternatives mentioned below, such as single mode, side by side, External control apparatus picture in picture, etc., of Plasma Monitor. Transmission Data DFH 80H 60H 07H 01H DATA00 CKS...

  • Page 39: Sub Picture Detect Select

    PDxx01 7FH 60H 80H 07H 01H DATA00 CKS DATA00: 00H: Single Screen 01H: Side by Side 1 (Same Size Screen) 02H: Side by Side 2R (Left Screen smaller) 03H: Picture in Picture 1 (sub screen Bottom Left) with size1 04H: Picturein Picture 2(sub screen Bottom Right) with size1...

  • Page 40: Zoom Navigation Select

    PDxx01 5-59. ZOOM NAVIGATION SELECT Function External control apparatus selects digital zoom display of a plasma monitor, from the alternatives mentioned below; Transmission Data DFH 80H 60H 7BH 01H DATA00 CKS DATA00 01H: OFF (single screen) 02H: Side By Side (Left Screen smaller)

  • Page 41: Picture Freeze (Pause) Command

    PDxx01 5-61. PICTURE FREEZE (Pause) Command Function External control apparatus sets picture freeze or remove picture freeze of a plasma monitor. Transmission Data DFH 80H 60H 7DH 01H DATA00 CKS DATA00 01H: FREEZE 02H: FREEZE OFF 7FH 60H 80H 7DH 01H DATA00 CKS...

  • Page 42: Cc (Closed Caption) Contrast Select

    PDxx01 7FH 60H 80H 3CH 01H DATA00 CKS DATA00 00H: OFF 01H: CC1 (closed caption1) 02H: CC2 (closed caption2) 03H: CC3 (closed caption3) 04H: CC4 (closed caption4) 05H: TEXT1 06H: TEXT2 07H: TEXT3 08H: TEXT4 5-64. CC (Closed caption) CONTRAST SELECT Function External control apparatus selects the Closed Caption Contrast function of a plasma monitor.

  • Page 43: Picture Memory Set

    PDxx01 5-66. PICTURE MEMORY Set Function The external control equipment ser and reset the Picture Memory function of a plasma monitor. Transmission Data DFH 80H 60H 25H 02H DATA00 DATA01 CKS DATA00: 01H: SET 02H: RESET DATA01: MEMORY select 00H: OFF...

  • Page 44: Set Up Level Select

    PDxx01 Corresponding character Received data (H) Corresponding character Received data (H) Corresponding character Received data (H) 3FH 60H 80H 2DH 00H CKS NOTE) Please select the memory you like to write by “68.PICTURE MEMORY Select” before setting “PICTURE MEMORY NOTE WRITE”...

  • Page 45: Pdp Saver Auto Select

    PDxx01 5-70. PDP SAVER AUTO Select Function External control apparatus selects automatic or manual of the PDP saver function of a plasma monitor. Transmission Data DFH 80H 60H 2CH 01H DATA00 CKS DATA00 01H: MANUAL 02H: AUTO 7FH 60H 80H 2CH 01H DATA00 CKS...

  • Page 46: Power On Mode (Volume)

    PDxx01 5-73. POWER ON MODE (VOLUME) Function Power-on modes (Volume) are set up. Transmission Data DFH 80H 60H 0FH 01H DATA00 CKS DATA00: Power ON mode (VOLUME) 7FH 60H 80H 0FH 00H CKS 5-74. 74. SUB PICTURE RATE set Function Sub screen rate of PIP are set up.

  • Page 47: Multi (Sprit) Screen Power On Mode Set

    PDxx01 5-75. MULTI (SPRIT) SCREEN POWER ON MODE SET Function Power-on modes (Input) for sprit screen are set up. Transmission Data DFH 80H 60H 33H 04H DATA00 to DATA03 CKS DATA00 POWER ON MODE 01H: LAST 02H: MULTI DATA01 MULTI MODE...

  • Page 48: Remote Code Setting

    PDxx01 5-76. REMOTE CODE SETTING Function Remotecontroler codes are set. Transmission Data DFH 80H 60H 2BH 01H DATA00 CKS DATA00 00H: ALL 01H: CODE1 02H: CODE2 03H: CODE3 04H: CODE4 7FH 60H 80H 2BH 01H DATA00 CKS DATA00 00H: ALL...

  • Page 49: Revision History

    PDxx01 Revision history Rev. Date Owner 1.0 12/06/06 Marantz America, Inc. RS-232C Control Specification Change description Issued Revision1.0 Company Restricted Page: 49 / 49 Document Version [1.0]...
