Page 1: Installation Manual
The energy you need Installation manual Envirosorb Envirosorb... -
Page 2: Table Of Contents
Observe maintenance intervals ......19 Preparing maintenance .......... 19 Pre-maintenance instructions ........ 19 Annual Maintenance ..........19 Draining ............... 19 Checking the appliance status codes ...... 19 Checking the electrical installation ......20 Start-up after maintenance ........20 0020154078_00 - 02/13 - Glow-worm... -
Page 3: Safety
∙ Use only R410A refrigerant. ∙ The tools used for charging, for measuring pressure, for creating a vacuum and for the recovery of the fl uid must be compatible with and employed solely for R410A. 0020154078_00 - 02/13 - Glow-worm... -
Page 4: Intended Use
Installers are required to carry out installation, commissioning and servicing work in accordance with the Benchmark Code of Practice which is available from the Heating and Hotwater Industry Council who manage and promote the Scheme. ∙ Visit www.centralheating.co.uk for more information. 0020154078_00 - 02/13 - Glow-worm... - Page 5 The adhesives and sealants used in this appliance are cured and give no known hazard in this state. The refrigerant used in this appliance is R410a the use of which is strictly controlled by F Gas regulation EN842/2006. 0020154078_00 - 02/13 - Glow-worm...
-
Page 6: Notes On The Documentation
Four way valve Ventilating fan limit. This value varies depending on the evaporation and Compressor condensation temperatures. - The appliance is equipped with a measuring device that checks the water fl ow rate at start-up. 0020154078_00 - 02/13 - Glow-worm... - Page 7 Domestic hot water operating limits Water temperature Air temperature 3.2.4 Permitted hydraulic confi gurations 3.2.4.1 Direct connection to the installation heating circuit 3.2.4.2 Indirect connection with a hydraulic module For detailed configurations please refer to the system manual. 0020154078_00 - 02/13 - Glow-worm...
-
Page 8: Structure Of The Appliance
26 Gas buff er 12 Plate to plate heat exchanger 13 Temperature sensor after plate to plate heat exchanger Heat pump return 14 High-pressure circuit maintenance valve Heat pump fl ow 15 Refrigerant pressure switch 0020154078_00 - 02/13 - Glow-worm... -
Page 9: Type Designation And Serial Number
EER (Axx/Wx) temperature of xx°C and cooling fl ow temperature of xx°C The refrigerating power for an air temperature of (Axx/Wx) xx°C and cooling fl ow temperature of xx°C See chapter "CE label" Transport strap 0020154078_00 - 02/13 - Glow-worm... - Page 10 (E). ∙ Remove the bag of documents (B) and the accessory box (A). ∙ Detach the transport strap (C). ∙ Carefully remove the packaging and protections without damaging the parts of the appliance (D). 0020154078_00 - 02/13 - Glow-worm...
- Page 11 ∙ Provide a condensate drain either into a bed of pebbles or pump: connected to a drain with installation of a siphon. - prevailing winds, - the noise generated by the fan and the compressor - the visual impact on the surrounding neighbourhood. 0020154078_00 - 02/13 - Glow-worm...
-
Page 12: Mounting The Appliance
Max. length of the hydraulic circuit DN 28 In the case of the installation of a module 30 m without an expansion tank ∙ Install the appliance level so that the condensates drain correctly. 0020154078_00 - 02/13 - Glow-worm... - Page 13 ∙ In the case of an installation with a swimming pool option, the waste water piping. take into account the water volume up to the swimming pool kit for proper sizing of the installation (e.g.: expansion tanks...). 0020154078_00 - 02/13 - Glow-worm...
-
Page 14: Electrical Installation
III. X7 FLOOR H EBUS eBUS connection to the heat pump (comply with the polarity ±) Connect the fl oor heating protection device to the heat pump e-BUS connection terminal on the control box 0020154078_00 - 02/13 - Glow-worm... - Page 15 ∙ Use a drill of the same diameter as the cable and drill through the cable gland seal (B). ∙ Pass the cable through the cable gland provided for this purpose (C) ∙ Set the cable gland with 2 fl at spanners (D) to get it tight. 0020154078_00 - 02/13 - Glow-worm...
- Page 16 Heat pump return temperature sensor 21 Installer interface Air outside temperature sensor 22 Overheating safety 10 Electronic expansion valve 23 Rotary compressor 11 Main PCB 24 Inverter box 12 Product coding resistor 25 Fin exchanger 0020154078_00 - 02/13 - Glow-worm...
-
Page 17: Start-Up
∙ Using a fl at wrench, open the tap a ¼ turn (B) in order to remove the air present in the glycol circuit, then close it quickly (in order to avoid emptying the circuit). 0020154078_00 - 02/13 - Glow-worm... -
Page 18: Installation Of Side Panel
• Avoid any contact with the skin or eyes. 1000 1500 2000 Envirosorb3 8 (with the water circuit at 20 ° C) Envirosorb3 11 (with the water circuit at 20 ° C Available pressure (kPa) circuit fl ow rate (l/h) 0020154078_00 - 02/13 - Glow-worm... -
Page 19: Maintenance
Note: if necessary, the heating installation can be drained via ∙ Check that the fan rotates freely. this bleed valve by opening the shutoff valves located at the rear of the heat pump. ∙ Check the pressure of the expansion vessel. 0020154078_00 - 02/13 - Glow-worm... -
Page 20: Checking The Appliance Status Codes
The error codes are described in a table in the appendix (see section 11.2). In the case of a fault, the fault code number is displayed on the control unit. ∙ Carry out any necessary repairs. ∙ Switch ON/OFF the appliance using heat pump circuit breaker. 0020154078_00 - 02/13 - Glow-worm... -
Page 21: Decommissioning
“Click” is heard. Decommissioning ∙ Switch off the product. ∙ Isolate the product from the power mains. ∙ Drain the appliance (see chapter 6.5). ∙ Recycle or dispose the product and its components (see chapter 9). 0020154078_00 - 02/13 - Glow-worm... -
Page 22: Refrigerant Fl Uid
Polyvinylether (PVE) oil. Type of regulator Electronic 41.5 41.5 Maximum relative operating pressure (PS) 41.5 x 10 41.5 x 10 Heat pump circuit Min. fi lling pressure. 1 x 10 1 x 10 0020154078_00 - 02/13 - Glow-worm... - Page 23 Fan rotation speed Coeffi cient Of Performance (according to EN 14511) Energy Effi ciency Ratio (according to EN 14511) Fluorinated greenhouse gases as identified in the Kyoto protocol, are contained within a fully sealed system. 0020154078_00 - 02/13 - Glow-worm...
-
Page 24: Appendix
Product coding resistor The circuit board or inverter driver error. Spare part The resistance value is outside used as a replacement part does identifi cation error. the authorised limits. not correspond to the product. 0020154078_00 - 02/13 - Glow-worm... - Page 25 The 4-way valve is defective. The electronic expansion valve’s motor is defective or the connection is defective. The sensor is defective or not Cooling circuit pressure correctly connected to the main sensor fault. circuit board. 0020154078_00 - 02/13 - Glow-worm...
