- Page 1 DataDirect Networks, Inc StorageScaler 6000 Drive Enclosure User Guide 96-00189-001 Rev B March, 2010...
- Page 2 Networks accept no liability for any errors that may arise. No part of this document may be transmitted or copied in any form, or by any means, for any purpose, without the written permission of DataDirect Networks. March, 2010 96-00189-001 Rev B...
-
Page 3: Table Of Contents
Computer Doesn’t Recognize the Storage Scaler 6000 Subsystem ....... 20 4.3 LEDs ............................20 4.3.1 HDD (Hard Disk Drive) ..................... 20 4.3.2 PCM (Power Cooling Module) ..................21 4.3.3 DEM (Drive Expander Module) ..................21 DataDirect Networks StorageScaler 6000 User Guide Rev B... - Page 4 Power Cooling Modules ....................26 4.6.2 I/O Module ........................28 4.6.3 Replacing the Drive Carrier Module ................. 29 4.7 Replacing the DEM ........................30 Appendix A Tier Mapping ........................31 Appendix B Rack Mounting ....................... 37 DataDirect Networks StorageScaler 6000 User Guide Rev B...
-
Page 5: European Regulations
What is in this guide This user guide gives you step-by-step instructions on how to install, configure, and connect the StorageScaler 6000 storage subsystem to your host computer system, as well as to use and maintain the system. Who should use this guide This user guide assumes that you have a working knowledge of the Serial Attached SCSI (SAS) protocol environments into which you are installing the StorageScaler 6000 system. -
Page 6: Qualified Personnel
• Remove drives to minimize weight. • Do not try to lift the enclosure by yourself. • Do not lift the StorageScaler 6000 by the handles on the power cooling module (PCM); they are not designed to support the weight of the populated enclosure. - Page 7 Preface • The StorageScaler 6000 unit must only be operated from a power supply input voltage range of 200 V AC to 240 V AC. • The plug on the power supply cord is used as the main disconnect device. Ensure that the socket outlets are located near the equipment and are easily accessible.
-
Page 8: Rack System Precautions
The rack will require labelling with “HIGH LEAKAGE CURRENT. Earth connection essential before connecting supply.” • The rack when configured with the units must meet the safety requirements of UL 60950 and IEC 60950. DataDirect Networks StorageScaler 6000 User Guide Rev B... -
Page 9: Esd Precautions
Caution It is recommended that you fit and check a suitable anti-static wrist or ankle strap and observe all conventional ESD precautions when handling StorageScaler 6000 plug-in modules and components. Avoid contact with backplane components and module connectors, etc. Data Security •... - Page 10 Preface • Ensure that all disk drives are removed from the enclosure before attempting to move the rack installation. • Do not abandon your backup routines. No system is completely foolproof. DataDirect Networks StorageScaler 6000 User Guide Rev B...
-
Page 11: Introduction
Introduction Chapter 1 Introduction 1.1 The StorageScaler 6000 System The StorageScaler 6000 storage system is an ultra dense 4U 60 disk drive enclosure based on 3.5 inch SAS or SATA Hard Disk Drives (HDDs). Figure 1–1 Figure 1–2 show front and rear views of a StorageScaler 6000 enclosure respectively. -
Page 12: Enclosure Core Product
StorageScaler 6000 User Guide (96-00189-001 Rev B) 1.2 Enclosure Core Product The StorageScaler 6000 design concept is based on a subsystem together with a set of plug-in modules and (as supplied) comprises: • Enclosure Chassis with integral Front Panel Drive Status Indicator (Figure 1–10). -
Page 13: The Plug-In Modules
Figure 1–4 Power Cooling Module (1) The StorageScaler 6000 must always be operated with two (2) Power Cooling Modules fitted (2 PCMs). Module replacement should only take a few minutes to perform but must be completed within 10 minutes from removal of the failed module. Four (4) LEDs mounted on the PCM (Figure 1–5... -
Page 14: Input/Output (I/O) Module
Backplane, PCM, and Display Panel in order to monitor internal functions. The plug-in I/O modules have been designed for integration into a StorageScaler 6000 storage subsystem, providing external SAS cable interfacing with up to 60 SAS or SATA disk drives. -
Page 15: Drive Carrier Module And Status Indicator
• The handle assembly also incorporates a Drive Status LED (Figure 1–7). Note The enclosure system design allows for drive bays to be left empty without the need for fitting dummy drive carriers. DataDirect Networks StorageScaler 6000 User Guide Rev B... -
Page 16: Dem Card
1.3.3.1 SATA Interposer Card The StorageScaler 6000 enclosure supports a SATA interposer card which allows simultaneous access to the SATA HDD from both IO modules installed in the enclosure as well as the power cycling of a single HDD through SES commands. -
Page 17: Front Panel Indicators
The Front Panel Indicators show the aggregated status of all the modules and drive activity. This panel and its associated LEDs are shown in Figure 1–10. The Front Panel LEDs are defined in Table 1–4. Figure 1–10 Front Panel Indicators DataDirect Networks StorageScaler 6000 User Guide Rev B... -
Page 18: Environment
Note 3: not currently implemented 1.5 Environment The enclosure and all of its sub-components are compliant to the European Union RoHS (Restriction of Hazardous Substances) Directive (Directive 2002/95/EC) with no exceptions or exemptions. DataDirect Networks StorageScaler 6000 User Guide Rev B... -
Page 19: Storagescaler 6000 Technical Specification
50A @ 230VAC, 25 C, 5 msec max Minimum Efficiency measured at 30% and 50% load and nominal line (208 VAC) Maximum Average Output Power 1750 W Maximum Peak Output Power, 1 second 1922W DataDirect Networks StorageScaler 6000 User Guide Rev B... -
Page 20: Dc Input Pcm
Cord Type SV or SVT, 18 AWG minimum, 3 conductor Plug 250V, 10A Socket IEC 320 C-14, 250V, 15A Note Power cord is not included in the standard StorageScaler 6000 enclosure package. DataDirect Networks StorageScaler 6000 User Guide Rev B... -
Page 21: Getting Started
Chapter 2 Getting Started 2.1 Planning Your Installation Before you begin installation you should become familiar with the configuration requirements of your StorageScaler 6000 system and the correct positions of each of the optional plug-in modules (Table 2–1). Table 2–1... -
Page 22: Enclosure Bay Numbering Convention
ESSENTIAL that all (rear) apertures are filled before operating the unit. The StorageScaler 6000 subsystem is housed in a 60-drive bay enclosure, arranged in four (4) groups. Each group comprises two banks of 15 bays, that is, (as viewed from the front): 12 bays across the enclosure by 5 bays deep. - Page 23 Getting Started Figure 2–2 1X60 Drive Numbering Table. Figure 2–3 2x30 Drive Numbering Table DataDirect Networks StorageScaler 6000 User Guide Rev B...
-
Page 24: Enclosure Installation Procedures
2.2 Enclosure Installation Procedures Warning The StorageScaler 6000 Enclosure with all its component parts installed is too heavy for a single person to easily install into a Rack cabinet. Caution Ensure that you have fitted and checked a suitable anti-static wrist or ankle strap and observe all conventional ESD precautions when handling StorageScaler 6000 modules and components. -
Page 25: Dem
Getting Started 2.4 DEM The StorageScaler 6000 enclosure contains eight (8) top-loadable, hot swappable DEMs. The DEMs provide the SAS connectivity between the I/O module and the HDDs located within the enclosure. Each DEM connects to a single port of the HDD based on the location within the enclosure in which it is installed. - Page 26 This page is intentionally blank. DataDirect Networks StorageScaler 6000 User Guide Rev B...
-
Page 27: Operation
To power the enclosure down, switch off the PCMs installed in the Enclosure. 3.2.1 PCM LEDs The PCM incorporates 4 LEDs, located above the On/Off switch. Please refer to Figure 1–4 Figure 1–5. DataDirect Networks StorageScaler 6000 User Guide Rev B... -
Page 28: I/O Panel Leds
Expansion Port 2 I/O Module Green •properly booted and functioning correctly internal fault I/O Module Amber •No Faults present Fault I/O Fault I/O Module Blue •Receiving SES Command Identify Not receiving SES Command DataDirect Networks StorageScaler 6000 User Guide Rev B... -
Page 29: Troubleshooting And Problem Solving
The Audible Alarm sounds anytime the top cover is open. The alarm mutes automatically once the cover is closed. 4.2.3 Green “Signal Good” LED on I/O Module Not Lit Check to ensure that the cables have not been reversed during installation. DataDirect Networks StorageScaler 6000 User Guide Rev B... -
Page 30: Computer Doesn't Recognize The Storage Scaler 6000 Subsystem
HDD LEDs Location Color Identifier Behavior Enclosure front Amber Enclosure fault This LED is ON with a drive fault Enclosure front Amber Drive fault This LED is ON with a drive fault DataDirect Networks StorageScaler 6000 User Guide Rev B... -
Page 31: Pcm (Power Cooling Module)
OFF when the expander internal processor is NOT booted or ready. Internal (DEM) BLUE DEM identify ON indicates that this DEM is being sent Enclosure an identify command by the SEP. DataDirect Networks StorageScaler 6000 User Guide Rev B... -
Page 32: I/O Module
Amber SAS Link Fault ON when a fault is present on any of the 4 links of the 4-wide port. OFF when none of the 4 links of the 4- wide port have a fault. DataDirect Networks StorageScaler 6000 User Guide Rev B... -
Page 33: Front Panel Drive Activity Indicators
ON-at least one DEM has failed; implemented service action required Drive Fault AMBER Drive fault ON-one or more HDDs are faulted. SES must determine Currently not exact HDD. implemented OFF-no detectable drive faults DataDirect Networks StorageScaler 6000 User Guide Rev B... -
Page 34: Troubleshooting
PCMs fitted. 4 Check that all Blank modules are in place. 5 Reduce the ambient temperature. DataDirect Networks StorageScaler 6000 User Guide Rev B... -
Page 35: Thermal Alarm
4.4.3 Thermal Shutdown Important An Enclosure will shut down when a critical temperature threshold is exceeded in order to prevent permanent damage to the disk drives. DataDirect Networks StorageScaler 6000 User Guide Rev B... -
Page 36: Dealing With Hardware Faults
As there should always be two PCMs installed, you can continue working while replacing the faulty module. Make sure you identify the faulty PCM correctly from the two modules installed. Lift latch which secures the power supply cord. Switch off and disconnect the power supply cord. DataDirect Networks StorageScaler 6000 User Guide Rev B... - Page 37 Secure the two thumbscrews on the left and right sides of the unit. Connect the power supply cord to the power source; secure latch, and switch the power supply ON. Note The alarm will sound until the new PCM is operating correctly. DataDirect Networks StorageScaler 6000 User Guide Rev B...
-
Page 38: I/O Module
With the latches in the open position, slide the EBOD module into the enclosure until the latch engages automatically. Cam the module home by manually closing the latches. A click should be heard as the latch engages. DataDirect Networks StorageScaler 6000 User Guide Rev B... -
Page 39: Replacing The Drive Carrier Module
Cam the drive carrier home. The camming foot on the base of the carrier will engage into a slot in the enclosure. When the carrier is fully home, close the handle. You should hear a click as the latch engages and holds the handle closed. Close the enclosure. DataDirect Networks StorageScaler 6000 User Guide Rev B... -
Page 40: Replacing The Dem
Grip the top latch, rotate it until you reach the limit of rotation, and then pull up to remove the DEM. Insert the replacement DEM. Press on the latch to rotate it down to lock it into place. DataDirect Networks StorageScaler 6000 User Guide Rev B... -
Page 41: Appendix A Tier Mapping
Drive Enclosure Addressing Background This sections explains the drive enclosure addressing of the disk enclosures for the StorageScaler 6000 Drive Enclosure. There are three drive numbering options: • 1 x 60 (one set of drives 1 through 60); (Figure A–1, use Figure A–4, and Figure A–5 for cabling). - Page 42 D r i v e A d d r e s s i n g M a p p i n g Figure A–3 4 x 15 Drive Layout Configuration DataDirect Networks StorageScaler 6000 User Guide Rev B...
- Page 43 D r i v e A d d r e s s i n g Figure A–4 StorageScaler 6000 - 1x60 Configuration DataDirect Networks StorageScaler 6000 User Guide Rev B...
- Page 44 D r i v e A d d r e s s i n g M a p p i n g Figure A–5 StorageScaler 6000 - Daisy Chain Configuration for 2 Rack 20 Drawer DataDirect Networks StorageScaler 6000 User Guide Rev B...
- Page 45 D r i v e A d d r e s s i n g Figure A–6 StorageScaler 6000 - 2x30 Configuration DataDirect Networks StorageScaler 6000 User Guide Rev B...
- Page 46 D r i v e A d d r e s s i n g M a p p i n g Figure A–7 StorageScaler 6000 - 4 x 15 Configuration DataDirect Networks StorageScaler 6000 User Guide Rev B...
-
Page 47: Appendix B Rack Mounting
Appendix B. Rack-Mounting the StorageScaler 6000 The Storage Scaler 6000 is designed to fit within a 4U rack space. Follow these steps to mount the system in your rack: 1. Using eight (8) 32 × 0.188" Phillips panhead screws for each slider, attach the four (4) inner sliders to the chassis... - Page 48 2. Loosen the nine (9) screws on the rail kit and set the length to fit the depth of your rack Figure B-2. Tighten all the screws once the rail kit is set to the desired length. Repeat for the other rail kit. 3.
- Page 49 5. Using two (2) 10-32 ×0.50" (100d) Phillips flathead screws for each CMA, attach the CMA to the CMA brackets Figure B-3. If the depth of your rack is 25.5 inches (647 mm) or less, attach the CMA directly to the rack, above the rail kits.
