- Page 1 EVGA Z170 STINGER (111-SS-E172) User Guide EVGA Z170 STINGER Specs and Initial Installation - 1 -...
-
Page 2: Table Of Contents
EVGA Z170 STINGER (111-SS-E172) Table of Contents Before you Begin………………………………………………………………………4 Parts Not in the kit…………………………………………………………………….5 Intentions of the kit……………………………………………………………………5 Motherboard Specifications……………………………………………………………6 Unpacking and Parts Descriptions……………………………………………………..8 Equipment……………………………………………………………………………..8 Component legend………..………………………………………………………..…10 PCI-E Slot Breakdown………………………………………………………………..11 Rear I/O Panel legend………………………………………………………………..12 Preparing the Motherboard…………………………………………………………...13 Installing the CPU…………………………………………………………………….13 Installing the Cooling Device……………………………………….…………...…….14... - Page 3 EVGA Z170 STINGER (111-SS-E172) Clear CMOS Button…………………………………………………………………..29 Reset and Power button……………………………………………………………..29 Post Debug LED and LED Status Indicators………..………………………………..30 Post Port Debug LED………………………………………………………………..30 LED Status Indicators………………………………………………………………...30 Installing Drivers and Software……………………………………………………….31 Windows 10/8/7 Driver Installation………………………………………………….31 POST Codes…………………………………….…………...……………….……..32 AMI POST Codes……………...…………………..…..…………………………..32 Glossary of Terms….………………………………………………………………..36 Compliance Information….…………………………………………………………..39...
-
Page 4: Before You Begin
GUI BIOS/UEFI that is focused on functionality, high quality components and next generation dual channel DDR4 memory. With these features and more, it is clear that the EVGA Z170 motherboards are engineered to set the new standard for the mainstream chipset motherboard. -
Page 5: Parts Not In The Kit
Keyboard / Mouse Monitor (Optional) Optical Drive Operating System EVGA assumes you have purchased all the necessary parts needed to allow for proper system functionality. For a full list of supported CPUs on this motherboard, please visit www.evga.com/support/motherboard Intentions of the Kit This kit provides you with the motherboard and all connecting cables necessary to install the motherboard into a PC case. -
Page 6: Motherboard Specifications
EVGA Z170 STINGER (111-SS-E172) Motherboard Motherboard Specifications Size: mITX form factor of 6.7 (170.18mm) inches x 6.7 inches (170.18mm) Microprocessor support: Intel Socket 1151 Processor Operating Systems: Supports Windows 10 / 8 / 7 -For Windows 7 users, please remember drivers are REQUIRED for USB3 and above support. - Page 7 EVGA Z170 STINGER (111-SS-E172) Onboard Audio: Realtek HD Audio (ALC1150) Supports 8-channel (7.1) audio Supports Optical Output Power Functions: Supports ACPI (Advanced Configuration and Power Interface) Supports S0 (normal), S3 (suspend to RAM), S4 (Suspend to disk - depends on OS), and S5 (soft - off) Expansion Slots: 1x PCI-E 3.0 1x16 slot...
-
Page 8: Unpacking And Parts Descriptions
EVGA Z170 STINGER (111-SS-E172) Unpacking and Parts Descriptions Equipment The following accessories are included with the EVGA Z170 STINGER Motherboard: - 8 -... - Page 9 EVGA Z170 STINGER (111-SS-E172) - 9 -...
-
Page 10: Component Legend
EVGA Z170 STINGER (111-SS-E172) Component Legend Intel Z170 STINGER Motherboard The EVGA Z170 STINGER Motherboard with the Intel Z170 and PCH Chipset. Figure 1 shows the motherboard and Figure 2 shows the back panel connectors FIGURE 1. Z170 STINGER Motherboard Layout... -
Page 11: Pci-E Slot Breakdown
EVGA Z170 STINGER (111-SS-E172) Wh ^ & < > Wh d & Wh & DK^ /K^ & WtD Z D /DD ^ W^ & W/ ^ PCI-E Slot Breakdown PCI-E Lane Distribution PE1 – x16, from CPU This motherboard does not have lane replication via PLX;... -
Page 12: Rear I/O Panel Legend
EVGA Z170 STINGER (111-SS-E172) Figure 2. Chassis Rear Panel Connectors /K^ DK^ Z ,D/ > > > & & & & & & - 12 -... -
Page 13: Preparing The Motherboard
EVGA Z170 STINGER (111-SS-E172) Preparing the Motherboard Installing the CPU Be very careful when handling the CPU. Hold the processor only by the edges and do not touch the bottom of the processor. Note: Use extreme caution when working with the CPU,... -
Page 14: Installing The Cooling Device
EVGA Z170 STINGER (111-SS-E172) Align the notches on the CPU to the notches in the socket. Lower the processor straight down into the socket. Note: Make sure the CPU is fully seated and level in the socket. Lower the load plate so it is resting on the CPU. -
Page 15: Installing System Memory (Dimms)
EVGA Z170 STINGER (111-SS-E172) Installing System Memory (DIMMs) Your Z170 Classified has 2 (288-pin) slots for DDR4 memory. These slots support 4GB, 8GB and 16GB DDR4 DIMMs. There must be at least one memory slot populated to ensure normal operation. -
Page 16: Installing The Motherboard
EVGA Z170 STINGER (111-SS-E172) Installing the Motherboard The sequence of installing the motherboard into a system case depends on the chassis you are using and if you are replacing an existing motherboard or working with an empty system case. Determine if it would be easier to make all the connections prior to this step or to secure the motherboard and then make all the connections. -
Page 17: Securing The Motherboard To The Case
EVGA Z170 STINGER (111-SS-E172) Securing the Motherboard into a System Case Most system cases have a base with mounting holes you thread standoffs onto to allow the motherboard to be secured to the chassis and help to prevent short circuits. If there are studs that do not align with a mounting hole on the motherboard, it is recommended that you remove that standoff to prevent the possibility of a short circuit. - Page 18 EVGA Z170 STINGER (111-SS-E172) Above, all locations safe to secure the board to a standoff with are circled in red, and the upper left side of that picture is a zoomed in view of the hole. Keep in mind that when the screws are installed but not fully tightened, the motherboard should have 1-2mm of movement;...
-
Page 19: Connecting Cables
EVGA Z170 STINGER (111-SS-E172) Connecting Cables This section takes you through all the necessary connections on the motherboard. This will include: Power Connections 24pin ATX power ( EPS 8pin 12V power Internal Headers Front Panel connectors (power/reset/LED’s) Fan Headers (PWM for CPU and DC/PWM for case fans ) USB 3.0 Header... -
Page 20: Pin Atx Power
EVGA Z170 STINGER (111-SS-E172) 24-pin ATX Power (ATX_PWR_24P) is the main power supply connector located along the lower ATX_PWR_24p right edge of the board. Make sure that the power supply cable and pins are properly aligned with the connector on the motherboard. Firmly plug the power supply cable into the connector and make sure it is secure. -
Page 21: Connecting Internal Headers
EVGA Z170 STINGER (111-SS-E172) Connecting Internal Headers Front Panel Header The front panel header on this motherboard is used to connect the following four cables. PWRLED Attach the front panel power LED cable to these two pins of the connector. -
Page 22: Fan Header
EVGA Z170 STINGER (111-SS-E172) Fan Header This motherboard line only has 4pin fan headers, which are backwards compatible with 3 pin, can be controlled by PWM or DC controls and has an absolute safe power limit of 1 Amp @ 12 Volts (12 Watts). These plugs are for your CPU heatsink and chassis cooling fans. -
Page 23: Usb Headers
EVGA Z170 STINGER (111-SS-E172) USB Headers This motherboard contains USB 3.1, 3.0, and 2.0 ports that are exposed on the rear panel of the chassis. The motherboard also contains 19-pin internal header connectors onboard that can be used to connect an optional external bracket containing up to (2) USB 3.0 ports. -
Page 24: Front Panel Audio
EVGA Z170 STINGER (111-SS-E172) Front Panel Audio The audio connector supports HD audio standard and provides two kinds of audio output choices: the Front Audio and the Rear Audio. S/PDIF Header The S/PDIF (Sony/Philips Digital Interface Format) is used for specific Audio- Out applications, typically for using an audio pass-through device. -
Page 25: Thunderbolt Gpio
EVGA Z170 STINGER (111-SS-E172) Thunderbolt GPIO Thunderbolt technology is a transformational high-speed, dual protocol, PC I/O delivering performance, simplicity and flexibility. Thunderbolt I/O technology lets you move data between your devices and your computer with 2 channels of 20Gbps flowing both ways (upstream and downstream) at the same time. -
Page 26: Probe It
EVGA Z170 STINGER (111-SS-E172) Probe IT The Probe IT offers a means of monitoring several different voltages under any level of load with a digital multi-meter so you can see exactly what voltages your board is pushing, mainly used for extreme overclocking. -
Page 27: 6Pin Pcie
EVGA Z170 STINGER (111-SS-E172) 6pin PCIE The 6pin PCIE connector present on the motherboard is there to provide additional power to the PCIE slots rather than pulling it all from the 24 pin main power. It is advised when using SLI especially with higher power draw cards, 3 and 4 way SLI it is strongly recommended to use this, regardless of GPU. -
Page 28: Pci-E And M.2 Slots
EVGA Z170 STINGER (111-SS-E172) PCI-E & M.2 Slots All of the boards in this series have at least 1 PCI-E x16 slot available, which is typically used for a video card, however if you use a CPU with onboard video you can leave it empty or place a different type of card into the slot. -
Page 29: Onboard Buttons
EVGA Z170 STINGER (111-SS-E172) Onboard Buttons These onboard buttons include RESET, POWER and Clear CMOS. These functions allow you to easily reset the system, turn on/off the system, or clear the CMOS. Clear CMOS Button The motherboard uses the CMOS RAM to store all the set parameters. -
Page 30: Post Debug Led And Led Status Indicators
EVGA Z170 STINGER (111-SS-E172) Post Debug LED and LED Status Indicators Post Port Debug LED Provides two-digit diagnostic POST codes which shows system boot status and can also show why the system may be failing to boot. It is very useful during troubleshooting situations. -
Page 31: Installing Drivers And Software
64 bit versions of Windows 10 and 8, also 64 & 32 bit versions of Windows 7. The kit comes with a CD that contains utilities, drivers, and additional software. The CD that has been shipped with the EVGA Z170 Motherboard contains the following software and drivers:... -
Page 32: Post Codes
EVGA Z170 STINGER (111-SS-E172) POST Codes This section provides the AMI POST Codes for the EVGA Z170 Dark Motherboard during system boot The POST Codes are displayed on the Debug LED readout located directly onboard the motherboard. Debug LED with CPU... - Page 33 EVGA Z170 STINGER (111-SS-E172) information Memory initialization. Configuring memory Memory initialization (other). Reserved for ASL (see ASL Status Codes section below) Memory Installed CPU post-memory initialization is started CPU post-memory initialization. Cache initialization CPU post-memory initialization. Application Processor(s) (AP) initialization CPU post-memory initialization.
- Page 34 EVGA Z170 STINGER (111-SS-E172) Recovery firmware image is found Recovery firmware image is loaded F5-F7 Reserved for future AMI progress codes Recovery PPI is not available Recovery capsule is not found Invalid recovery capsule FB–FF Reserved for future AMI error codes...
- Page 35 EVGA Z170 STINGER (111-SS-E172) SCSI Reset SCSI Detect SCSI Enable Setup Verifying Password Start of Setup Reserved for ASL (see ASL Status Codes section below) Setup Input Wait Reserved for ASL (see ASL Status Codes section below) Ready To Boot event...
-
Page 36: Evga Glossary Of Terms
DIMM - Dual In-line Memory Module DMI – Direct Memory Interface DRAM - Dynamic random access memory DVI – Digital Video Interface ELEET/ELEET X – EVGA motherboard monitoring and tuning software GHz – Gigahertz GPU – Graphics Processing Unit HDD - Hard Disk Drive HDMI - High-Definition Multimedia Interface HDR –... - Page 37 EVGA Z170 STINGER (111-SS-E172) IRQ - Interrupt Request JBOD - Just a Bunch of Disks JEDEC - Joint Electron Device Engineering Council LAN - Local Area Network LCD - Liquid Crystal Display LGA – Land Grid Array LN2 – Liquid Nitrogen Cooling...
- Page 38 EVGA Z170 STINGER (111-SS-E172) SATA - Serial Advanced Technology Attachment SAS – Serial Attached SCSI SB - Southbridge SCSI - Small Computer System Interface SFR – Split Frame Rendering SLI - Scalable Link Interface SPD - Serial Presence Detect S/PDIF - Sony/Philips Digital Interconnect Format SPP - System Platform Processors SSD –...
-
Page 39: Compliance Information
Original Purchaser. Upon termination, for any reason, all copies of Software and materials must be immediately returned to EVGA and the Original Purchaser shall be liable to EVGA.com CORP for any and all damages suffered as a result of the violation or default.
