M3 SM10 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

User Manual

Version 1.1 © 2015
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SM10 and is the answer not in the manual?

Questions and answers

Related Manuals for M3 SM10

Summary of Contents for M3 SM10

  • Page 1: User Manual

    User Manual Version 1.1 © 2015...
  • Page 2 Thank you for purchasing the M3 SM10. This device provides high performance data collection and mobile communications that meet industrial standards. This user manual enables users to know the characteristics of the M3 SM10 series and how to use it. Caution ...
  • Page 3 you want to receive information on the latest OS, please contact your local distributor.  This manual may include technical or editing errors.

  • Page 4: Instructional Icons

     M3 Mobile and M3 logos are registered trademarks of M3 Mobile.  M3 SM10 is a registered trademark of M3 Mobile Co., Ltd. Instructional Icons Before using this manual, please carefully read and understand the following icons: Warning – Situations that may cause injury to yourself or others Caution –...
  • Page 5 Safety Rules  Do not use the device while driving.  Traffic accidents may occur.  Observe the rules on device use while driving.  Do not touch the power plug with wet hands.  You may be electrocuted.  Be careful when using the battery.
  • Page 6  Loud sounds while walking or driving distract your attention and may cause traffic accidents.
  • Page 7 Revision Release date of version 1.0: April 2015  Initial distribution...

  • Page 8: Table Of Contents

    Table of Contents Getting Started ......................10 Package Contents ......................10 1.1.1 Device and Accessories ....................10 Battery ..........................11 1.2.1 How to Use ........................11 1.2.2 Charging the Battery ......................12 Turning the Device On/Off ....................15 1.3.1 Turning the Device On ...................... 15 1.3.2 Turning the Device Off ......................
  • Page 9 Device Reset ........................25 2.5.1 Soft Reset (1) ........................25 2.5.2 Soft Reset (2) ........................26 2.5.3 Factory Reset ........................26 Connecting with PC ......................26 2.6.1 How to Connect ........................ 26 Using the Application Screen ..................28 Phone Function......................... 28 3.1.1 Basics ..........................

  • Page 10: Getting Started

    Getting Started Package Contents 1.1.1 Device and Accessories The M3 SM10 package includes the following items: <M3 SM10> <Battery> <Micro-USB Cable> <Adaptor> <Quick Manual> If one or more items above are damaged or are not included in the package, contact the store where you purchased the device.

  • Page 11: Battery

    Insert the battery from the bottom in the right direction.  After inserting the battery, slide the Slide button to the left to fix the locking device. M3 SM10 uses 3.8 V, 4,100 mAh Li-ion (standard battery) or 3.8 V, 6,150 mAh Li-ion (extended battery). ...

  • Page 12: Charging The Battery

    Before the battery is removed, save the data being used. M3 SM10 can be used for up to 10 hours after the battery is fully charged. (The maximum time of using the device depends on the usage environment of a user.)
  • Page 13 Charging the Battery  Use a portable adaptor to connect with the micro-USB port to supply external power.  Alternatively, you may connect the device to a cradle that you can additionally purchase to charge the battery.
  • Page 14 AC adaptor can be used in 100–240 V, 2A. If a voltage beyond the range is supplied, the device may be seriously damaged. Use only an M3 Mobile-approved adaptor. If not, the device may malfunction or be damaged during or after its charging, or the battery performance may degrade.

  • Page 15: Turning The Device On/Off

    1.3 Turning the Device On/Off 1.3.1 Turning the Device On Press and hold the Power button until the device vibrates. This will turn the device on and the initial screen will be displayed. If the battery is completely discharged or charge is too low, problems may occur when the device is turned on.

  • Page 16: Turning The Device Off

    1.3.3 Standby Mode If the device is not used for a long time, M3 SM10 automatically shifts to standby mode to decrease battery consumption. To manually set the device in standby mode, lightly press the Power button.

  • Page 17: Memory Card

    Memory Card 1.4.1 Inserting an External Memory Card The Micro-SD card is used as an external memory of M3 SM10. After removing the battery, insert the SD memory card into the Micro-SD card slot.

  • Page 18: Checking Data

    To insert the Micro-SD card, remove the battery cover on the rear of the device and pull out the battery.  Android 4.3 (Jelly Bean), the OS used in M3 SM10, can support up to 32 GB for external memory. 1.4.2 Checking Data ...

  • Page 19: Sam Card

    For more information on how to use the phone, please see the phone section.  When using two SIM cards, Slot 1 supports 3G/2G and Slot 2 supports GSM only.  When using only one SIM card, Slot 1 supports 3G/2G and Slot 2 supports 2G only.

  • Page 20: Basic Use

    Basic Use 2.1 Features Device Layout...

  • Page 21: Key

    2.2 Key 2.2.1 Button Button Description Scanner Operate the scanner while executing the scanner program. Volume High Increase the volume. Volume Low Decrease the volume. Camera Take pictures while executing the camera program. Back Return to the previous stage. Home Go to the Home screen.

  • Page 22: Status Bar

     Status Bar Notification Bar  Home Screen  Dock Bar 2.3.1 Status Bar The Status Bar displays the status of the device.

  • Page 23: Notification Bar

    2.3.2 Notification Bar The Notification Bar displays device notifications.

  • Page 24: Home Screen

    2.3.3 Home Screen In the Home Screen, there are shortcut icons of the main programs. A shortcut icon can be added or deleted. 2.3.4 Dock Bar Shortcut icons can be placed on the lower section to rapidly execute frequently used programs. In the Dock Bar, up to four shortcut icons may be added or deleted.

  • Page 25: Data Input

    2.4 Data Input 2.4.1 Virtual Keyboard If focus is located in the input screen, the virtual keyboard will be automatically displayed. 2.5 Device Reset 2.5.1 Soft Reset (1) Press and hold the Power button to display the power management menu. Select the “Power Off and Restart”...

  • Page 26: Soft Reset (2)

    2.5.2 Soft Reset (2) If the device stops its operation for a long time, press the Volume Down button + the Back button + the Camera button to perform soft reset. The program being executed will end, and the data or file being used will also be deleted. However, the stored data or file will not be affected by the soft reset.
  • Page 27  Media Device (MTP) – Media file can be sent.  Camera (PTP) – With the camera software, a photo can be sent.  SD Card – A file in the SD card of the device can be sent.  Charging –...

  • Page 28: Using The Application Screen

    Using the Application Screen Phone Function M3 SM10 supports the 2G (GSM, CDMA) and 3G (UMTS, HSPA+) networks. 3.1.1 Basics Press the icon to use the Phone menu. Press the ) icon to see the call history. Press the ) icon to see the contacts.

  • Page 29: Wi-Fi

    Wi-Fi 3.2.1 Setting the Wi-Fi Feature Activating the Wi-Fi feature  and set the Wi-Fi menu to ON/OFF to activate or deactivate the Wi-Fi feature. Connecting to a Wi-Fi network To connect to an AP, perform the following procedure: Select the “Wi-Fi” menu of the icon.

  • Page 30: Scanner

    In the list, select an AP name to access it. If necessary, enter the password to complete the access. 3.3 Scanner M3 SM10 provides the 1D or 2D scanner as an option. For detailed information on available options, please contact the local distributor or refer to our Web site. (Home page: http://www.m3mobile.net). 3.3.1 How to Use Scanner M3 Mobile provides the program needed to use a scanner by default.

  • Page 31: Using The Scanner

    In case of a 2D scanner, it cannot be simultaneously used with a camera. 3.3.2 Using the Scanner Place the device toward to the barcode desired, and press the Scan button. The laser beam of the scanner should completely cover the bar code as shown in the following.

  • Page 32: Bluetooth

    2. If the device is used for purposes other than that described in this manual, a user may be exposed to harmful electromagnetic waves. 3.4 Bluetooth 3.4.1 Setting the Bluetooth Feature A Bluetooth device frequently used can be registered or the M3 SM10 can be searched in another device. Activating the Bluetooth feature ...

  • Page 33: Connecting Bluetooth

     Bluetooth. To activate the Bluetooth feature, select the To connect using Bluetooth, tap Bluetooth tab of the icon. Connect M3 SM10 with a Bluetooth device to share information via wireless connection.  Bluetooth  SEARCH FOR DEVICES to search a device to connect. 1. Tap...
  • Page 34 2. Select a Bluetooth device. 3. If the “Bluetooth pairing request” screen is displayed, enter the PIN code of a Bluetooth device to complete access to the device.

  • Page 35: Nfc

    Guide on the distance between the device and user The device is tested in general conditions wherein the back part of the device is 1.5 cm apart from a user. To meet the radiation safety and protection standards of the Ministry of Science, ICT and Future Planning, the back part of the device and the antenna should be 1.5 cm or more from a user regardless of the antenna use.
  • Page 36 Insert the NFC USIM into USIM SLOT1 (front of Dual SIM Slot).   More…  NFC to activate or deactivate the NFC feature.

  • Page 37: Connecting The Nfc Feature

    When transferring data between devices, they do not need to be closer. It is recommended to keep the distance between devices within 10 m. Connecting to the NFC Chip / Tag Card Hold the M3 SM10 as shown below. Do not cover the antenna area of the battery cover with...
  • Page 38 Place the M3 SM10 near the NFC chip or tag card until the data transfer is completed. (Generally, data is displayed in the application.) Connecting to a Bluetooth Device with the NFC Feature Hold M3 SM10 as shown below. Do not cover the antenna area of the battery cover with hands.

  • Page 39: Advanced Use

    The OS of M3 SM10 can be updated through two methods: Use the Micro SD card. Connect the device through USB cable. For detailed information on OS update, please refer to the “OS” item of the M3 FAQ (FAQ download).

  • Page 40: Key Setting Conversion

    4.2 Key Setting Conversion The M3 SM10 allows a user to change and modify the key settings for user convenience. Keys can be set as follows: SM10 KEYTOOL application  [SM10 KEYTOOL]...
  • Page 41 The setting of the device’s physical buttons, except for the Power button, can be changed.

  • Page 42: Others

    5. Others 5.1 Device Specifications Physical Features Wireless LAN IEEE 802.11 a/b/g /n WEP, WPA, WPA2, TKIP, AES, EAP- 76.4 x 154.8 x 19.7 mm Size FAST, EAP-TLS, EAP-TTLS, PEAP- (W x H x D) Security GTC, PEAP- TLS, PEAP-MSCHAPv2, mm/inch 3.00 x 6.09 x 0.77 inch LEAP, CCXv4...

  • Page 43: Service

    5.2 Service If you have any questions or complaints with using our product, please contact the M3 Service Center or visit our Web site (http://itc.m3mobile.net). We do our best to immediately respond to your inquiry. The M3 FAQ document may help resolve general problems.
