Summary of Contents for Dynam SR Trainer
- Page 3 RTF INCLUDING RTF including: fuselage wing elevator landing gear Landing pole plastic parts set push rod glue decal balance charger LI-Po battery (11.1V 2200mAh 20C) transmitter Adaptor Propeller...
- Page 4 As shown, coated adhesive foam As shown, horizontal tail position in the rubber in the horizontal tail Office. corresponding bonding fuselage. As shown, the elevator rod penetration As shown, the rudder rod penetration quick connector, tighten with a quick connector, tighten with a screwdriver.
- Page 5 The front wheel steering rod into quick As shown,Tear up the surface layer connector fastened with a screwdriver. of the double-sided adhesive. this time steering the Huizhong state. Indicate: As shown,Install hood in the fuselage. As shown in the installation of 9060 Clover paddle Phillips screwdriver fastening fairing.
- Page 6 Bubble gum on the left and right As shown, Left and right wing bonding. wing James. As shown,Installation of plastic parts As shown,Landing gear screws around in the position of the wing mark. with PA2.5X6. As shown,The aileron cable with As shown,Installation of wing and Y-cable fuselage, tighten with a screwdriver.
- Page 7 STICK OPERATION MODE 1 MODE 2 MOVEMENT THROTTLE RUDDER control plane airplane action movement ELEVATOR control plane movement airplane action AILERONS airplane action Aileron movement airplane action...
- Page 10 After flight, the battery cool down to ambient temperature before charging. Wire lead shorts can cause fire! If you accidentally short the wires, the battery must be placed in a safe area for observation for approximately 15 minutes. observation...
- Page 12 Once you have connected the charger to a power source,The red LED will turn on. Connect the Li-Po battery pack to the charger.When the park is full charged.The green LED will turn on.
-
Page 13: Parts List
Parts List SRTR-01 Fuselage SRTR-02 wing SRTR-03 Canopy SRTR-04 Elevator SRTR-05 canopy 1 SRTR-06 Propeller DYM-0010 Brushless Motor SRTR-07 Plastic Part set SRTR-08 Landing gear SRTR-9 Landing Wheel SRTR-10 Fairing SRTR-11 push rod DY-3001 quick-controller DY-1007 9g Servo DYA-000X Adaptor DYE-1002 Balance Charger DY-6006 DYT-2002...
