Recoda M602 User Manual

Sd card mini mobile dvr
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
M602 SD card MINI Mobile DVR
User manual
Ver. 1.2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M602 and is the answer not in the manual?

Questions and answers

Related Manuals for Recoda M602

Summary of Contents for Recoda M602

  • Page 1 M602 SD card MINI Mobile DVR User manual Ver. 1.2...
  • Page 2 Note: ·Put Mobile DVR on horizontal plane; ·Select appropriate installation position to provide good ventilation and prevent overheating of the device. ·Do not put liquid stuff onto it ·Install the device in suitable humidity and temperature environment. Statement: · We strive to ensure the exactness and integrality of the manual in the process of preparation, but still error or omission is inevitable.

  • Page 3: Table Of Contents

    Mini SD card mobile DVR M602 user manual CONTENT 1.1.P RODUCT INTRODUCTION ......................4 1.2 T ECHNICAL ARAMETER ........................4 2.THE PRODUCT STRUCTURE INTRODUCTION ................6 2.1 P RODUCT ONNECTION NSTRUCTION ................6 2.2 F RONT ANEL NSTRUCTION ....................7 2.4 R EMOTE CONTROL DESCRIPTION ....................10...

  • Page 4: Product Introduction

    Mini SD card mobile DVR M602 user manual 1.1.Product introduction This device is specially designed for the mobile DVR. It adopts embedded processor and embedded operating system, combines the latest technologies in the IT filed like audio and video compression/decompression technology. Its structure adopts special anti-vibration technology.
  • Page 5 Mini SD card mobile DVR M602 user manual Item Description The main processor Hi3512 operating system Embedded Linux operating system System resource 4 channel full real-time video at the same time Built-in 3G wireless module optional. Such as EVDO, 3G optional HSPA, HSDPA, WCDMA…GPRS, EDGE, …...

  • Page 6: The Product Structure Introduction

    Mini SD card mobile DVR M602 user manual 2.The product structure introduction 2.1 Product Connection Port Instruction LED7 LED6 LED5 LED4 LED3 LED2 LED1...

  • Page 7: Front Panel Port Instruction

    Mini SD card mobile DVR M602 user manual Connection Port Definition Code Number Function Discription 4: Ignition singal Power input port 1: GND 2: GND 3: 5-32V input USB1.1 port 1: +5V power supply 2: USB_D- 3: USB_D+ 4: GND...
  • Page 8 Mini SD card mobile DVR M602 user manual ⑥ ⑦ ① ② ③ ④ ⑤ ① Status LED ② IR ③ SD Card ④ USB ⑤ Video Out ⑥ SD Card Lock ⑦ SIM Card 2.2.1： Status LED Indicator definition instruction: Power: the power led will turn red when the power is connected;...
  • Page 9 Mini SD card mobile DVR M602 user manual 2.3 Back Panel Port Instruction 2.3.1 : Power Supply Interface 2.3.2:Debug Serial RS232_RXD RS232_TXD 2.3.3: I/O Signal Interface Unit 2.3.4:Video- Audio Input And Output Interface...

  • Page 10: Remote Control Description

    Mini SD card mobile DVR M602 user manual Video-Audio output Video-Audio Video-Audio Video-Audio Video-Audio input input input input 2.4 Remote control description 1. Power key: used to close the system, press and hold 5 seconds 2. FN key: In the video file list, select the specified file and used to backup used to switch the soft keyboard input.

  • Page 11: System Operating Instruction

    Mini SD card mobile DVR M602 user manual Bring up the main menu exit the soft keyboard clear out all the regional settings 4. MULTI key: Set up to 4 pictures. 5. SHIFT key: playback, used to show / hide the control bar 6.

  • Page 12: Menu Component Instruction

    Mini SD card mobile DVR M602 user manual 3.3.2 Menu Component Instruction Menu component units mainly include: (1) Check box: “√” means valid, blank means shield. There are two operating modes: 1. use the 【OK】 button or the 【↑】 , 【↓】 button on the remote control; 2. click the left mouse button to operate.

  • Page 13: Channel Preview

    Mini SD card mobile DVR M602 user manual 3.5 Channel Preview Single-channel Preview: single-click the left mouse button, you can single-picture preview; press number 1-4 on the remote control, you can single preview the corresponding channel. Four-channel preview: press the 【Multi】 key on the remote control or single-click the left mouse button, it can return to four-picture preview status.
  • Page 14 Mini SD card mobile DVR M602 user manual shown after selection) in order to backup files.  Prev: jump to the previous page  Next: jump to the next page  Goto: go to the specific page  Backup: you can use the 【FN】 key on the remote control or the number “0” or the right mouse button to make a backup mark, backup the selected recording file in the current list box to the corresponding device (USB disk).

  • Page 15: Manual Recording

    Mini SD card mobile DVR M602 user manual 3.7 Manual Recording Enter manual record interface Press 【Record/ 】 on the remote control or click “Manual Record” by mouse can enter the ● manual record interface directly. Manual record interface instruction The manual record operation interface is consists of the following components: channel, status, start/stop icon mark, Start All, Stop All and Exit.

  • Page 16: Tools

    Mini SD card mobile DVR M602 user manual 3.8.1 Tools Including HDD (HDD management), User (user management), Default (restore to default), Clear (clear alarm), Update (software update), Time (date and time), Export(import and export configuration) and Info (system information). 3.8.1.1 HDD Management Check the current status, capacity and the remaining space of the specified HDD and if the HDD was formatted.

  • Page 17: User Management

    Mini SD card mobile DVR M602 user manual 3.8.1.2 User Management Add user, delete user and modify user. (Other users except the Admin user don’t have the authority to set the authorities of the other users)  Add User Enter “User” operation interface.
  • Page 18 Mini SD card mobile DVR M602 user manual selection box, click the “Delete” button to delete the specified user. 3.8.1.3 Restore to Default Restore the system configuration parameter to factory configuration, the system will auto restart when the restore is complete.
  • Page 19 Mini SD card mobile DVR M602 user manual system will auto restart. 3.8.1.6 Date and Time Enter the time page of the system, you can modify the time of the system and the time format. Note: the time can be modified when recording is stopped.
  • Page 20 Mini SD card mobile DVR M602 user manual 3.8.1.8 Import and Export Used to export the system configuration to the USB disk, or import the system configuration from the USB disk, in order to facilitate configuring multiple devices in batch.
  • Page 21 Mini SD card mobile DVR M602 user manual 3.8.2.1 System Parameter Overwrite: Select “Yes”, when the HDD or SD card is full of recording, the system will overwrite the earliest video information to achieve the purpose of cycle recording. Select “No”, when the HDD or SD card is full of recording, the system will not record any more;...
  • Page 22 Mini SD card mobile DVR M602 user manual starting but not login, the device will display four-picture, after 20S, it will display the screen set up in “Preview”. ACC Delay: Used to set when to shutdown the system after setting ACC staling. The value between [0--255] can be set (unit is minute).
  • Page 23 Mini SD card mobile DVR M602 user manual 3.8.2.3 Image Setting Channel: Select the number of the target channel number to be set up. Name: Used to modify the name of the channel (cannot be copied). It supports numbers, uppercase and lowercase letters, Chinese and common used marks, up to 12 characters at the most.
  • Page 24 Mini SD card mobile DVR M602 user manual 3.8.2.4 Alarm Input Input: Select the number of the target channel number to be set up. Type: According to actual conditions, set if the alarm input is valid when choose High Volt orlow Volt.
  • Page 25 Mini SD card mobile DVR M602 user manual up within each time period. The status of each time period will display at the bottom as well as the overall plan from 0 to 24 hours. CopyTo: Used to copy the parameters of this channel to other channel so as to configure quickly.
  • Page 26 Mini SD card mobile DVR M602 user manual Delay: When the motion detection is ended, how long will the related processing (such as recording, buzzer, alarm output) delay. Rec. CH: Setup which channels to be triggered to record. To record, you have to set the time periods in the schedule interface.

  • Page 27: Ptz Control

    Mini SD card mobile DVR M602 user manual retention time. Thus, the settings of the cruise path include the parameter settings of the cruise point, preset point, retention time and cruise time etc, then enter “set” to set the cruise path and cruise path number. At present, one device supports the setting of 16 cruise path numbers.

  • Page 28: Shutdown System

    Mini SD card mobile DVR M602 user manual time. Type: Select the log type, including all, alarm, expection, local operation and remote operation. Start/End: Set the start and end time of searching log. Prev: Used to go to the preview page.

  • Page 29: Bus Information

    Mini SD card mobile DVR M602 user manual 3.8.7 Bus Information DeviceID: Used to set the ID number of every device. DeviceName: Used to set the device name which is the same as the device name set up in “Info”.

  • Page 30: Lient Software User Manual

    Mini SD Mobile DVR User Manual 4Client Software User Manual...
  • Page 31 Mini SD card mobile DVR M602 user manual  Instruction of Client software Main Functions (1) The “RecordFile” interface realizes the search and playback functions of the recording file in the storage medium: search and playback the recording file in the storage medium (HDD or SD card) by channel number, start and end time, recording type and car number.
  • Page 32 Mini SD card mobile DVR M602 user manual 1.1 Playback by file After set up the channel number, start and end time, recording type (event) and car number, click “Search” button, all the recording files which meet the conditions will display in the list box.
  • Page 33 Mini SD card mobile DVR M602 user manual 1.3 Backup File Select the recording file which you want to backup from the list box, then click “BackupFile” button, select the storage path to backup. When the backup is complete, there will be a succeed prompting. The backup file can be with ifv and avi format.
  • Page 34 Mini SD card mobile DVR M602 user manual 2.1 Stop: Click “Stop” button to stop the file play. 2.2 Pause, Frame Forward: “Pause” button controls pause or play recording file; frame forward: each click will play one frame forward. 2.3 Playback Speed: It can play in normal speed (1 time), fast forward (2 times, 4 times, 8 times, 16 times), slow forward (1/2, 1/4, 8, 1/16).
  • Page 35 Mini SD card mobile DVR M602 user manual Note: when the interval between the start time and the end time is relatively big, but the time interval of the video which needs to be cut is relatively small, two cut points will overlap together which will not affect the cut function.
  • Page 36 Mini SD card mobile DVR M602 user manual 3.1 Browse: Used to setting the path of the log file (log.bin), click “Search Log” to view the log file. Without setting the path, it will default to search the current log information in the storage medium.
  • Page 37 Mini SD card mobile DVR M602 user manual 4.1 Browse: Used to set the file which save the recording files in local. 4.2 Search: Select the car number and the start time and end time which you want to search, click “Search” button, all the recording files of a vehicle within a time period will display in the list box.

  • Page 38: Frequently Asked Question

    Mini SD card mobile DVR M602 user manual 5 Frequently Asked Question 1. How to operate the motion detection recording? A: There are mainly two steps for setting the motion detection recording:  Set the sensitivity, area and the recording channel to be triggered of the corresponding channel in the “MTD”...
  • Page 39 Mini SD card mobile DVR M602 user manual...
