- Page 1 User Manual for Mobile DVR 4CH MINI Mobile DVR USER MANUAL Ver. 1.1...
-
Page 2: Table Of Contents
User Manual for Mobile DVR Contents System Introduction ............................4 1.1. Features .............................. 4 1.2. Appearance ...................... 错误！未定义书签。 1.3. Remote Control ..........................5 1.4. Front panel ............................7 1.4.1. LED indicators: ........................7 1.4.2. SD card: ..........................7 1.5. Back panel ............................ - Page 3 User Manual for Mobile DVR Syestem Upgrade User Guideline ........................ 33 6.1. MU-MINI-RFS.crc（Record File System）Upgrade ..............33 6.2. MU-MINI-APP.crc（Application Program）Upgrade ..............33 6.3. MCU Upgrade ..........................33 6.4. Upgrade Check out............................ 33 3G User Guideline ............................34 7.1. Working principle representation .....................
-
Page 4: System Introduction
User Manual for Mobile DVR 1. System Introduction 1.1. Features H.264 main profile Video compression format; Support 1 to 4 channels video input. Adopt 10bit video decoder processor to ensure picture quality, and each video channel is attached with an independent video decoder to avoid disturbing from each other. -
Page 5: Appearance
User Manual for Mobile DVR 1.1.1. 1.2. Appearance Front view: Back view:... -
Page 6: Remote Control
User Manual for Mobile DVR 1.3 Remote Control... -
Page 7: Front Panel
User Manual for Mobile DVR 1.4 Front panel The front panel for the device which supports two SD card: The front panel for the device which supports one SD card: 1.4.1 LED indicators: 【PWR】Power indicator. 【ERR】Error indicator: LED on－No SD cards ... -
Page 8: Back Panel
User Manual for Mobile DVR 1.5 Back panel 【PWR】Power Supply connector 【GPS】GPS antenna connector 【WIRELESS】WIRELESS antenna connector 【USB】USB1.1 port 【ETHERNET】LAN port. 【ALARM IN/OUT】Alarm input and output connector 【VI/VO AI/AO】Audio and video input and output connector Remark: GPS and wireless transmission functions are available with M603B. -
Page 9: Specifications
User Manual for Mobile DVR Specifications Function Item Description Channel 1-4 channels Support CIF、 HD1、 D1 resolution, compatible with 2CH of D1 & 2CH of CIF. fps: Resolution 1 to 25f/s/ch adjustable (PAL) or 30f/s/ch (NTSC) . Video Quality 1-4 levels, 1 is the highest level and 4 is the lowest level. Overlays information such as date time and vehicle ID Recording Support two SD card recycle recording. -
Page 10: Technique Parameters
User Manual for Mobile DVR Technique Parameters Item Description Processor Hisilicon Hi3511 Operating system Linux(2.6) Signal format PAL/NTSC System Two level password protections for administrators and Security users Input 4 CVBS, 1.0Vp-p, 75Ω Output 1 CVBS, 1.0Vp-p, 75Ω Video Play channels 1 channel or 4 channels synchronous play PAL: 25Frame/s ,CCIR625 line,50 field Recording speed... -
Page 11: Gui
User Manual for Mobile DVR Support two (SDHC) SD card, the max capacity is 32G for Storage capacity each. File system: FAT32 input 4Ch input Alarm output 2Ch output RS-232 Communication Interface RJ45 10M/100M Ethernet Embedded GPS module Optional PC Viewer PC playback software Firmware upgrade Upgrade with SD card... -
Page 12: System Main Interface
User Manual for Mobile DVR Factory Default User Password: 111111 4.5 System Main Interface The main interface will be displayed on the screen when you login successfully, it contains 4.6 Video Records Playback Select ‘Playback’ icon with left/right/up or down key and press ‘enter’ key to get below interface REC SEARCH REC SEARCH REC TYPE：ALL/ALARM... -
Page 13: System Settings
User Manual for Mobile DVR "REC TYPE": press the【Enter】 button to select All or Alarm. The default setting is All. “DISK SELECT ": press the【Enter】 button to select the SD card: The default setting is SD1. "DATE": Default is current day. Press digit keys to reset "START TIME": Press digit keys to setup the start time, default setting is 00:00. -
Page 14: Basic Settings
User Manual for Mobile DVR 4.7.2 Basic Settings BASIC SETUP BASIC SETUP Three type：Y/M/D, D/M/Y, M/D/Y DATE TYPE：Y/M/D TIMEZONE：GMT +08（00~+12 / -01~-12 ） DATE：2009-05-27 09：01：30 IDLE TIME： 30（s）（Default 30 senconds） DEVICE NO ：11111 (Default 30 senconds） COMPANY NAME：Company Name VEHICLE NO：00000 DRIVER NAME：Driver Name BUS LINE NO：Line number SAVE... -
Page 15: Recording Settings
User Manual for Mobile DVR 4.7.3 Recording Settings RECORD SETUP RECORD SETUP SYSTEM： PAL/NTSC RECORD MODE ： AUTO/TIMED/ALARM/MANUAL RESOLUTION： D1/HD1/CIF BITRATE ：（D1） 2048 /2000 /1600 /1400 /1200 /1000 / 800 /600 （HD1） 1500 /1300 /1100 /900 /800 /700 /600 /500 AUDIO ：... -
Page 16: Sub-Stream Settings
User Manual for Mobile DVR RECORD TIME LIST RECORD TIME LIST DATE TIME 1 TIME 2 EVERYDAY 00:00-00:00 00:00-00:00 MONDAY 00:00-00:00 00:00-00:00 TUESDAY 00:00-00:00 00:00-00:00 WEDNESDAY 00:00-00:00 00:00-00:00 THURSDAY 00:00-00:00 00:00-00:00 FRIDAY 00:00-00:00 00:00-00:00 SATURDAY 00:00-00:00 00:00-00:00 SUNDAY 00:00-00:00 00:00-00:00 SAVE Note: System will auto start recording within the period in “Timed”... -
Page 17: Power Management
User Manual for Mobile DVR Default is 10f, press【ENTER】 key to enter. Click ’SAVE’ to save the configuration. 4.7.5 Power Management POWER SETUP POWER SETUP POWER MODE： TIME /ACC DELAY POWER OFF： ON/OFF DELAY TIME： 5（MIN） POWER ON TIME： HH:MM:SS POWER OFF TIME：... -
Page 18: Alarm Settings
User Manual for Mobile DVR 4.7.6 Alarm Settings ALARM SETUP ALARM SETUP ENABLE RECORD INPUT HIGH ALARM HIGH LEFT RIGHT BRAKE OUTPUT ENABLE OUTPUT1 HIGH OUTPUT2 SAVE MOVE DETECT SPEED G-SENSOR Alarm input Support 4ch alarm input. "ENABLE": switch on/off. ON---Enable alarm input;... -
Page 19: Motion Detection
User Manual for Mobile DVR MOTION DETECTION CHANNEL LEVEL ENABLE AREA CHANNEL LEVEL ENABLE AREA CHI/CH2/CH3/CH4 HIGH/MID/LOW OFF/ON CHI/CH2/CH3/CH4 HIGH/MID/LOW OFF/ON SETUP SETUP SAVE SPEED OVER SPEED OVER SPEED THRESHOLD：0（0~60）（km/h） ENABLE ： ON/OFF ENABLE ： ON/OFF SAVE G-SENSOR（This functions is available with M603B）... -
Page 20: Security Settings
User Manual for Mobile DVR SENSOR SENSOR REAL LIMIT VALUES X= -0.00 Y= -0.00 Z= -0.00 ADJUST THRESHOLD VALUES ALARM: CLOSE/OPEN X: 2.00g Y: 2.00g Z: 2.00g SAVE “LIMIT”: Limit value for X/Y/Z, Minimum value is 0.00g and Maximum value is 9.99g, press digit keys to setup. -
Page 21: Network Settings
User Manual for Mobile DVR Password setting: "PASSWORD": ON---Enable password; OFF---Disable password, press the【ENTER】 key to select. Select and press “SAVE” to save the configuration. 4.7.8 Network Settings: Network parameters should be set on the device. The system will detect devices without any further setting if the configuration is correct NETWORK SETUP NETWORK SETUP... - Page 22 User Manual for Mobile DVR 3G SETUP 3G SETUP 3G： ON / OFF TYPE： WCDMA / EVDO / TD APN： 3gnet CENTER NO： *99# USER NAME： card PASSWORD： card SAVE “WIRLESS”: ON—enable wireless; OFF—Disable wireless, press the【ENTER】 key to select. “TYPE”: WCDMA—WCDMA module;...
-
Page 23: Ddns Setup
User Manual for Mobile DVR DDNS SETUP DDNS SETUP DDNS： ON / OFF TYPE： DYNDNS / 3322 USER NAME： PASSWORD： DOMIAN： SAVE DDNS: Close / Open, with 【Enter】 key to select. "User Name", "Password": user name and password for setting DDNS, press 【Enter】 key to enter, then go to the keyboard interface, move the cursor and input corresponding letter through press 【Enter】... -
Page 24: System Info
User Manual for Mobile DVR 4.8 System Info SYSTEM INFO SYSTEM INFO FIRMWARE VER：Mini001.00 HARDWARE VER：V0001 MCU VER：V0001 SD CAPACITY SD NO. TOTAL REMAINING SD NO. TOTAL REMAINING 3.6842GB 407.6875MB 3.6842GB 407.6875MB "FIRMWARE VER": Software version number. "HARDWARE VER": Hardware version number. "MCU VER": Single-chip version number. -
Page 25: Log Management
User Manual for Mobile DVR MANAGE TOOL MANAGE TOOL DISK MANAGE LOG MANAGE DEFAULT SET CFG MANAGE PTZ MANAGE OSD SET 4.9.2 Log Management LOG MANAGE LOG MANAGE START TIME：2009-05-27 00:00:00 SEARCH END TIME：2009-05-27 23:59:59 DATE TIME EVENT NAME 09/05/27 15：30：25 alarm in 09/05/27... -
Page 26: Sd Card Management
User Manual for Mobile DVR 4.9.3 SD Card Management DISK MANAGE DISK MANAGE SD FORMAT SD SELECT：SD1/SD2 FORMAT CANCEL ’ ’ The data will lost against FORMAT , otherwise ’ ’ 。 please press CANCEL Disk management is used to format the SD cards. "SD SELECT": to select SD1 or SD2 by pressing the ‘enter’... -
Page 27: Default Settings
User Manual for Mobile DVR 4.9.4 Default Settings Warning: Default all settings? "Yes": Press the【ENTER】key to recover all parameters to the original default settings. "No": Cancel this operation and return back to the management tool interface. 4.9.5 Config Management Import and export config file CONFIG MANAGE CONFIG MANAGE IMPORT CONFIG FILE:... -
Page 28: Device Installation
User Manual for Mobile DVR 4.9.6 PZT Management PTZ MANAGE PTZ MANAGE CHANNEL ADDRESS BAUDRATE CHANNEL ADDRESS BAUDRATE （ （ 0 ~ 255 0 ~ 255 ） ） 4800/9600/19200/38400/57600/115200 4800/9600/19200/38400/57600/115200 （ 0 ~ 255 ） 4800/9600/19200/38400/57600/115200 （ 0 ~ 255 ）... -
Page 29: Audio/Video Input And Output Cable
User Manual for Mobile DVR Notes: 1: Please make sure the battery voltage range within 12-24V, otherwise device will break down when voltage more than 24V 2: Please check out the three cables and make sure isolative between them after complete connection 3: Make sure connect the Black and Red cables with battery directly and never choose ground strap connection way as GND, otherwise device cannot work normally 4: The yellow cable must be connected to the ignition;... -
Page 30: Alarm Input And Output Cable
User Manual for Mobile DVR Connector Name Instruction Video Input VIN1~VIN4 4 VIN BNC connector Video Output VOUT 1 VOUT BNC connector Audio Input AIN1~AIN2 2 AIN BNC connector Audio Output AOUT1~AOUT2 2 AOUT PCA connector MIC Input MIC IN 1 MIC IN RCA connector 5.1.3 Alarm Input and Output Cable... -
Page 31: Main Board Outside View
User Manual for Mobile DVR 5.2. Main Board Outside View 5.2.1.DVRwithout 3G and GPS PCB Alarm IN/OUT cable connector Power cable connector... -
Page 32: Dvr With 3G And Gps Pcb
User Manual for Mobile DVR VI/VO AI/AO cable connector SD card holder 5.2.2. DVR with 3G and GPS PCB 3G antenna connector GPS antenna connector SIM card holder 3G module... -
Page 33: Syestem Upgrade User Guideline
User Manual for Mobile DVR Syestem Upgrade User Guideline 6.4 MU-MINI-RFS.crc（Record File System）Upgrade 1. Cope files into SD card. Make sure files were copied totally 2. Insert SD card into device before power on 3. Power on the device and all indicator except SD1 and SD2 will be light. 4. -
Page 34: User Guideline
User Manual for Mobile DVR 3G User Guideline 7.4 Working principle representation External Module G Sensor,GPS WCDMA 3G/EVDO HSPA Wireless network PC Management software Remote Control Remote monitor center 7.5 Installation Guideline 3G antenna connector SIM card holder 3G Module... -
Page 35: Parameter Settings
User Manual for Mobile DVR 7.6 Parameter Settings 7.6.2 Network Setting NETWORK SETUP NETWORK SETUP LOCAL SETUP IP ADDRESS: 192. 168. 000. 192 NETMASK：255. 255. 255. 000 GATEWAY: 192. 168. 000. 001 MAC：00：44：53：75：55：56 CENTER SET TYPE：IP/DOMAIN DOMAIN：www.123.cn SERVER IP：192 . 168 . 001 . 000 CONTROL PORT：5678 MEDIA PORT：... -
Page 36: Wireless Setting
User Manual for Mobile DVR Picture 3 7.6.3 Wireless setting There are 3 types: WCDMA, EVDO and TD. When user set it, please make sure the type you select must be match with the type of 3G modules (Please make a reference in picture 3) 3G SETUP 3G SETUP 3G：... -
Page 37: Pc Software Setting
User Manual for Mobile DVR (Please make a reference in picture 4) 7.7 PC software setting Make Fclient software running first. When device dial-up successfully, it will connect with sever setted by user automatically. Green color means connecting success (Please make a reference in picture 5) Remote ID Picture 5... -
Page 38: General Problems
User Manual for Mobile DVR and the other possibility is antenna not connect well. 3) Q: Why 3G can not transmit data? A: Probably of the reason is as follows: 1) Didn’t connect 3G antenna 2) Didn’t insert SIM card; 3) Wireless and network setup in a wrong way 4) The PC setup not matches with 3G. - Page 39 User Manual for Mobile DVR 1) Electric voltage isn’t within the range of 8-36 V; 2) The fuse in power cable was burned; 3) ACC setting failure or ignition connects in a wrong way Problem 2: ERR indicator keep on light. The following errors will cause the ERR indicator keep on light.
- Page 40 User Manual for Mobile DVR 3) If the camera takes an electricity power from the equipments directly, may be the equipment’s electric voltage isn't enough to make camera work as usual; 4) The cable that links this channel has problem Problem 6: Record files have no audio Probably of the reason is as follows: 1) Audio function setup in “OFF”...
- Page 41 User Manual for Mobile DVR 2) System setting in a wrong way Remarks: More information and user guidelines please find on page fifteenth in user manual Problem 10: GPS signal lost GPS has no signal, probably of the reason is as follows: 1) Didn’t connect GPS antenna;...
