- Page 1 User Manual for Mobile DVR 4CH Mobile DVR USER MANUAL M705 Series Ver. 2.0...
-
Page 2: Table Of Contents
User Manual for Mobile DVR Contents System Introduction ............................4 1.1. Features .............................. 4 1.2. Appearance ............................5 Remote Control 1.3..........................6 1.4. Front panel ............................7 1.4.1. LED indicators: ........................7 1.4.2. Others ............................ 7 1.5. Back panel ............................ - Page 3 User Manual for Mobile DVR 5.2. Cables .............................. 31 5.2.1. Power Cable ......................... 31 5.2.2. GPS Antenna ........................32 5.2.3. AV input /output cable ......................32 5.2.4. Alarm input and output cable ....................33 Device Upgrade Guideline .......................... 34 6.1. M705X-RFS-*******.crc（Document system）upgrade ..............
-
Page 4: System Introduction
User Manual for Mobile DVR 1. System Introduction 1.1. Features H.264 main profile Video compression format; Support 1 to 4 channels video input. Adopt 10bit video decoder processor to ensure picture quality, and each video channel is attached with an independent video decoder to avoid disturbing from each other. -
Page 5: Appearance
User Manual for Mobile DVR Dimensions: 160(W) x200(H) x62(D) mm Weight: 2200g 1.2. Appearance Front view: Back view:... -
Page 6: Remote Control
User Manual for Mobile DVR 1.3. Remote Control Function Picture To activate the device To enter system settings. 【LOGIN】 【0－9】: Under the configuration mode, 0~9 stand for numbers; under 【0－9】 the playback mode, 1, 2, 3 and 4 are for switching between related single channel, and the number 5 is for 4 channels synchronous playback 【－】... -
Page 7: Front Panel
User Manual for Mobile DVR 1.4. Front panel 1.4.1. LED indicators: 【PWR】Power LED：LED light means system has powered on 【ALM】Alarm LED 【REC】Record LED: LED Light means device is recording 【HD】HDD, light on means load successfully. Lights off means load failure. Flicker means video recording. -
Page 8: Back Panel
User Manual for Mobile DVR 1.5. Back panel 【PWR】Power connector ● 【GPS】GPS antenna connector ● 【EXTEND I/O】Extend I/O connector ● 【RJ45】Network connector ● 【AV IN】AV inpurt connector ● 【AV OUT】AV output connector ● 【WIFI】WIFI antenna connector ● 【3G】3G antenna connector ●... -
Page 9: Technique Parameters
User Manual for Mobile DVR overwritten Video Search Search video files anytime per day, type(n/a) and target SD card. Playback Support 1 to 4 channels playback. System Playback Support forward and backword play at the speed of: x 2,x4,x8,x16. Graphical User Setup system parameters with the remote control. -
Page 10: Gui
User Manual for Mobile DVR Audio Compression G.726 5KB/s Alarm Input/Output 6 channels input;1 channel output Video Recording Recording Resolution D1/HD1/CIF, MAX:2 channels of D1 and 2 channels of CIF Record Quality 1-5 levels, 1 is the highest level and 5 is the lowest level. Record Mode Default: Auto Record. -
Page 11: System Main Interface
User Manual for Mobile DVR Attention: If the administer closed security setting, you will directly go to the main menu without login. 4.2. System Main Interface The main interface will be displayed on the screen when you login successfully, it contains 4.3. -
Page 12: System Settings
User Manual for Mobile DVR "REC TYPE": press the【Enter】 button to select All or Alarm. The default setting is All. “DISK SELECT ": press the【Enter】 button to select the SD card: The default setting is SD1. "DATE": Default is current day. Press digit keys to reset "START TIME": Press digit keys to setup the start time, default setting is 00:00. -
Page 13: Basic Settings
User Manual for Mobile DVR 4.4.1. Basic Settings BASIC SETUP BASIC SETUP Three type：Y/M/D, D/M/Y, M/D/Y DATE TYPE：Y/M/D TIMEZONE：GMT +08（00~+12 / -01~-12 ） DATE：2009/05/27 09：01：30 IDLE TIME： 30（s）（Default 30 senconds） DEVICE NO ：11111 （Default 30 senconds） COMPANY NAME：Company Name VEHICLE NO：00000 DRIVER NAME：Driver Name BUS LINE NO：Line number SAVE... - Page 14 User Manual for Mobile DVR RECORD SETUP RECORD SETUP SYSTEM：PAL/NTSC RECORD MODE： AUTO/TIMED/ ALARM/MANUAL RESOLUTION：D1/HD1/CIF BITRATE： D1（2048 /2000 /1600 /1400 AUDIO ：ON/OFF /1200 /1000 / 800 /600）HD1（1500 /1300 /1100 /900 /800 /700 /600 /500）CIF（1200 /1000 /800 /700/ 600/ 500/ 400 /300） TIME SLICE：...
- Page 15 User Manual for Mobile DVR 1. While HDD do not record, the SD card cannot have video record 2. SD card is not available 3. HDD is not available, SD card cannot record) 3) data loss: HDD error or HDD not available, SD card main stream record. Attention: HDD priority while both HDD and SD card is available.
-
Page 16: Power Management
User Manual for Mobile DVR STREAM SETUP STREAM SETUP ： ： RESOLUTION CIF/QCIF RESOLUTION CIF/QCIF ： ： QUALITY Medium/High/Low QUALITY Medium/High/Low SITS RATE: 24/32/48/56/64/80/96/112/128/160/176/200/280 SITS RATE: 24/32/48/56/64/80/96/112/128/160/176/200/280 FRAME RATE: 01/01/01/02/02/03/04/05/07/10/13/15/20 FRAME RATE: 01/01/01/02/02/03/04/05/07/10/13/15/20 SAVE "Resolution": CIF/ QCIF selectable. Image quality: Medium/ High/ Low "Bit Rate": 24/32/48/56/64/80/96/112/128/160/176/200/280 bits. -
Page 17: Alarm Settings
User Manual for Mobile DVR TIME: DVR will auto power on/off according to the preset time table. ACC: System will auto power on/off according to vehicle acc switch on/off signal. "DELAY POWER OFF": When this function is on, the DVR will continue making record for a while as per the configuration. - Page 18 User Manual for Mobile DVR ON---Enable alarm output; OFF---Disable alarm output. Press the 【ENTER】 key to select. PWL: power level output for alarm. High stands for high power level output and low refers to low power level output. Select and press “SAVE” to save all setup. MOVE SET (Motion Detection) ●...
- Page 19 User Manual for Mobile DVR GPS OVER SPEED GPS OVER SPEED THRESHOLD：60（0~999）（km/h） ： ： ENABLE ENABLE ON/OFF ON/OFF SAVE THRESHOLD：0~60km/h, input range 0-999. Key 【Del】to cancel. ENABLE: Press【ENTER】key to set-up ENABLE ON: To start alarm record and records alarm journal when GPS speed overran threshold ENABLE OFF: Never to start alarm record and records alarm journal when GPS speed overran threshold Remark: After complete setup, please press “SAVE”...
-
Page 20: Security Settings
User Manual for Mobile DVR setup. “ALARM”: G-Sensor alarm OPEN/CLOSE setup, press 【ENTER】to set it. Alarm Open: Open alarm recording and alarm files will be recorded when X/Y/Z value over than “Limit value” under record statues Alarm Close: Close alarm recording and alarm files will not be recorded when X/Y/Z value over than “Limit value”... - Page 21 User Manual for Mobile DVR the configuration is correct NETWORK SETUP NETWORK SETUP LOCAL NETWORK IP ADDRESS: 192. 168. 000. 192 NETMASK： 255. 255. 255. 000 GATE WAY: 192. 168. 000. 001 MAC：00.44.53.75.55.56 CENTER SETUP TYPE： IP/DOMAIN DOMAIN：www.123.cn SERVER IP：192 . 168 . 001 . 000 CONTROL PORT：5678 MEDIA PORT：...
- Page 22 User Manual for Mobile DVR 3G SETUP 3G SETUP 3G FN：ON / OFF TYPE： WCDMA / EVDO / TD TRIGGER NO.1： LINK MODE： NORMAL TRIGGER NO.2： /TRIGGER CALL NO.1： VOICE FN： OFF/ON CALL NO.2： CENTER NO： *99# APN： ctnet USER NAME： card PASSWORD：...
- Page 23 User Manual for Mobile DVR DDNS SETUP DDNS SETUP DDNS： ON / OFF TYPE： DYNDNS / 3322 USER NAME： PASSWORD： DOMIAN： SAVE DDNS: Close / Open, with 【Enter】 key to select. “TYPE”：DYNDNS/3322，with 【Enter】 key to select. "User Name", "Password": user name and password for setting DDNS, press 【Enter】 key to enter, then enter to the keyboard interface, move the cursor and input corresponding letter through press 【Enter】...
-
Page 24: System Info
User Manual for Mobile DVR 【Enter】key IP Address： Gateway： SUBMASK： SSID： PASSWORD： Remark: After complete setup, please press “SAVE” to save all settings and all above settings must match with router. 4.5. System Info SYSTEM INFO SYSTEM INFO FIRMWARE VER ： V000001 HARDWARE VER ：... -
Page 25: Log Management
User Manual for Mobile DVR SYSTEM INFO SYSTEM INFO FIRMWARE VER ： V000001 HARDWARE VER ： V0001 MCU VER ： V0001 CAPACITY TOTAL REMAINING TOTAL REMAINING 32000KB 2000KB 32000KB 2000KB 4.6.1. Log Management LOG MANAGE LOG MANAGE START TIME ： 2009-05-27 00:00:00 SEARCH END TIME ：... -
Page 26: Sd Card Management
User Manual for Mobile DVR 4.6.2. SD Card Management DISK MANAGE DISK MANAGE SD FORMAT FORMAT SELECT SD/HDD The data will lost against ‘FORMAT’, otherwise，please press ‘CANCEL’。 FORMAT CANCEL Disk management is used to format the SD cards. "SD SELECT": to select SD1 or HDD by pressing the ‘enter’ key. "CANCEL": Cancel disk management operations, and return back to the management tool interface. -
Page 27: Default Settings
User Manual for Mobile DVR Message Format HDD ？ "Yes": press the【ENTER】key to start formatting. "No": Cancel formatting and return back to the disk management interface. 4.6.3. Default Settings Message Default all settings? RESTORE TO FACTORY DEFAULTS "Yes": Press the【ENTER】key to recover all parameters to the original default settings. "No": Cancel this operation and return back to the management tool interface. -
Page 28: System Upgrade
User Manual for Mobile DVR CONFIG MANAGE CONFIG MANAGE IMPORT CONFIG FILE: IMPORT CONFIG FILE: SD/HDD SD/HDD IMPORT CFG EXPORT CURRENT CONFIG FILE: EXPORT CURRENT CONFIG FILE: SD/HDD SD/HDD EXPORT CFG Import Configuration: Import the “DVR.CFG” file into device from the SD card or HDD Export Configuration: Export the “DVR.CFG”... - Page 29 User Manual for Mobile DVR 4.6.6. OSD Setup OSD SETUP OSD SETUP REAL TIME DISPLAY REAL TIME DISPLAY TIME: YES TIME: YES RECORD OVERLAY DISPLAY RECORD OVERLAY DISPLAY RECORD TIME: YES RECORD TIME: YES VEHICLE NO: YES VEHICLE NO: YES GPS: YES GPS: YES SAVE...
-
Page 30: Installation Guideline
User Manual for Mobile DVR SERIAL MANAGE SERIAL MANAGE CHOICES CHOICES SERIAL 1 SERIAL 1 PTZ / LED SCREEN PTZ / LED SCREEN SERIAL 2 PTZ / LED SCREEN SERIAL 2 PTZ / LED SCREEN SAVE 5. Installation guideline 5.1. M705A and M 705 B Pictures 5.1.1. -
Page 31: M705B
User Manual for Mobile DVR 5.1.2. M705B GPS connector 3G Antenna connector M705A device 3G Module WIFI Antenna connector picture (without removable hard disk SIM card slot SD card slot 5.2. Cables 5.2.1. Power Cable It is power cable picture. The red and black cable should be connect to the power level in vehicle. Pay attention to the color. -
Page 32: Gps Antenna
User Manual for Mobile DVR diameter of anode and cathode cables must over thanΦ1.5 Cable color Name Explanation Black BAT- It is ground cable BAT+ It is power cable Yellow It is ACC cable 5.2.2. GPS Antenna 5.2.3. AV input /output cable It is picture for AV input/output cable... -
Page 33: Alarm Input And Output Cable
User Manual for Mobile DVR Connector Name Explanation Video input VIN1~VIN4 4 video input with BNC connector AV output VOUT 1 video output with BNC connector Audio input AIN1~AIN4 4 audio input with BNC connector Power output 12 V power output with DC connector 5.2.4. -
Page 34: Device Upgrade Guideline
User Manual for Mobile DVR 6. Device Upgrade Guideline 6.1. M705X-RFS-*******.crc（Document system）upgrade 1. Copy the files to SD card or at Hard disk and please be sure that make the file copied completely 2. Insert SD card or Hard disk when device in disconnect electricity statues 3. -
Page 35: M705X-App-*******.Crc（Application Program）Upgrade
User Manual for Mobile DVR 6.2. M705X-APP-*******.crc（Application program）upgrade Upgrade same as 6.1 6.3. MCU upgrade 1. Make the upgraded file to be copied to SD card or at hard disk, then change the file name as Boot_flash.bin. please be sure that make the file copied completely 2. -
Page 36: User Guideline
User Manual for Mobile DVR 7. 3G User Guideline 7.1. Working System Representation External Module G Sensor,GPS WCDMA 3G/EVDO HSPA Wireless network PC Management software Remote Control Remote monitor center 7.2. Parameter Settings 7.2.1. Network Setting NETWORK SETUP NETWORK SETUP LOCAL NETWORK IP ADDRESS: 192. - Page 37 User Manual for Mobile DVR 1） Server IP must be globe IP 2） Default Port is 5678. 3） If the computer which running Fclient in local area network, Port map must be setting in router (Please make a reference in picture 2) 4）...
-
Page 38: Wireless Setting
User Manual for Mobile DVR 7.2.2. Wireless setting There are 3 types: WCDMA, EVDO and TD. When user set it, please make sure the type you select must be match with the type of 3G modules (Please make a reference in picture 3) 3G SETUP 3G SETUP 3G FN ：... -
Page 39: F.a.q
User Manual for Mobile DVR Remote ID Picture 5 F.A.Q Problem 1: The power indicator not bright after power on. The following reasons will cause the power indicator not works: 1) Electric voltage isn’t within the range of 8-36 V; 2) The fuse in power cable was burned;... - Page 40 User Manual for Mobile DVR 3) Indicator is damaged; 4) The system cannot be operated in normal. Problem 4: SD card indicator not works or keep flicker The SD card indicator has 3 medium statuses: OFF, ON and Flicker; respectively meaning as follows: OFF: This SD card didn't be inserted or can not be identified by the equipments;...
- Page 41 User Manual for Mobile DVR 1) Audio function setup in “OFF” mode in system 2) Use wrong input cables Audio input including two types. One is LINE IN and the other one is MIC IN. It will be showed on Record setup interface in system.
- Page 42 User Manual for Mobile DVR 3) The GPS module damages; Problem 13: G-Sensor data abnormal. The reason as below: 1) The G-Sensor damage; 2) User did not check the X/Y/Z data in system Problem 14: Can’t playback files on PC successfully. Possible reason is as follows: 1) Have never chosen a record file or document path;...
