INSTRUCTION MANUAL
Cooktop
KI901
Klugmann Hausgeraete GmbH.
Gropiusstraße 7,
48163 Münster, Deutschland
+
49
2501
594060
-
408
service@klugmann-hausgeraete.de
www.klugmann-hausgeraete.de

Advertisement

loading
Need help?

Need help?

Do you have a question about the KI901 and is the answer not in the manual?

Questions and answers

Summary of Contents for Klugmann KI901

  • Page 1 INSTRUCTION MANUAL Cooktop KI901 Klugmann Hausgeraete GmbH. Gropiusstraße 7, 48163 Münster, Deutschland 2501 594060 service@klugmann-hausgeraete.de www.klugmann-hausgeraete.de...
  • Page 2 Dear Customer; Please keep this manual within your reach for future reference. First of all, thank you for buying our product. Please read all the instructions and warnings in this manual carefully. The manual includes important information about safe installation, use, and maintenance of your product, as well as necessary warnings for optimum use of your appliance.
  • Page 3: Safety Information And Warnings

    SAFETY INFORMATION AND WARNINGS A)The appliance is set to 220-240 Volt. B)The appliance's plug is earthed, thus it must be connected to a earthed outlet. C)Avoid routing the appliance's power cord through hot areas. D)Place cookware on the hob gently; do not throw or slam them. E)Choose cooking zones proportionally based on size of the cookware you will use.
  • Page 5 MODEL - 2 V 8001...
  • Page 6 MODEL - 3 V 9001...
  • Page 7: Troubleshooting

    SAFETY INFORMATION AND TROUBLESHOOTING Never use your vitroceramic hob near a gas range or similar heater. Never place inflammable or combustible materials under the counter top where your hob is installed. Do not turn on your hob without placing any cookware on it.
  • Page 8 If the surface of the appliance is broken or cracked, disconnect immediately the appliance from the power supply to prevent an electrical shock. Do not wash or immerse your hob. Do not turn on your hob with an empty cookware on it. Do not touch the surface of your hob right after cooking as it may still be hot.
  • Page 9 HOB ENERGY EFFICIENCY -Use smooth bottomed cookware on the hob. These will ensure maximum use of heat energy. -It is recommended not to use convex bottomed cookware. -Please use cookware of suitable sizes. Try not to use cookware with diameters smaller than that of the cooking zone.
  • Page 10 INSTALLATION OF HOBS Note: Any paddle box, aspirator or furniture to be placed over the hob must be at minimum 650 mm distance. 3.Affix your hob to your kitchen top using glue on all four sides of the appliance. Once you place the hob, you can adjust its suitable position and level. Warnings 1.The hob must be installed by an authorized service.
  • Page 11 INSTALLATION OF HOBS The power connection of your hob must be established according to appropriate standards. Types of connection to main power inlet Authorized service must make sure that the connections of your hob are established according to standards and rules. * Grounding cable must be minimum 2 cm longer than the other cable.
  • Page 12 INSTALLATION OF HOBS 1. Choosing installation equipment Make an aperture on the worktop according to the given dimensional values of your product. For ease of use and installation, leave 50 mm area around the aperture empty. V 9001 V 6004 V8001...
  • Page 13 2 ) Please make sure that air inlet and outlet points of your hob are not blocked. Make sure that your hob is installed in a manner that it can operate properly.
  • Page 14: Cleaning And Maintenance

    USE OF HOBS Place your cookware on the cooking zone. When you turn on your hob, all the signs on it will light for a second. Then the hob will automatically switch to standby mode, and the lights will go off. Once the “ON/OFF"...
  • Page 15: Technical Specifications

    TECHNICAL SPECIFICATIONS V 6004 V 8001 V9001 MODEL SAFETY LOCK BOOSTER FEATURE ELECTRICAL DUAL ZONE CENTER ZONE SMALL ZONE CONTROL PANEL TOUCH OPERATED TOUCH OPERATED TOUCH OPERATED DIGITAL DISPLAY BLACK BLACK BLACK COLOR COOKING TIME SETTING RESIDUAL HEAT INDICATORS PRODUCT 590X520 785X520 860X510...
