INSTRUCTION MANUAL
Cooktop
KT905TCBGL
KT905.2X
Klugmann Hausgeraete GmbH.
Gropiusstraße 7,
48163 Münster, Deutschland
+49 (0)2501 - 963 5732
+49 (0)2501 - 963 1834
service@klugmann-hausgeraete.de
www.klugmann-hausgeraete.de
|
KT905.1X
KT604TCBGL
|
|
KT905BGL
|
KT604BGL
KT604X
|
KT905BGLX
|
KT604BGLX
|
KT604.1X
|
|
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Klugmann KT905TCBGL
Summary of Contents for Klugmann KT905TCBGL
- Page 1 INSTRUCTION MANUAL Cooktop KT905TCBGL KT905.1X KT905BGL KT905BGLX KT905.2X KT604TCBGL KT604BGL KT604BGLX KT604X KT604.1X Klugmann Hausgeraete GmbH. Gropiusstraße 7, 48163 Münster, Deutschland +49 (0)2501 - 963 5732 +49 (0)2501 - 963 1834 service@klugmann-hausgeraete.de www.klugmann-hausgeraete.de...
-
Page 2: Table Of Contents
Thank you for choosing our appliance. Before using the appliance, please read the warnings and instructions in this manual. This will make it easier to operate and also prolong its service life. Keep this booklet for further reference. INDEX Safety Information..............2 Models....................3 Gas Connection................4 Insruction For Use................5... -
Page 3: Safety Information
appliance. -
Page 4: Models
Models 30 cm. Glass 60 cm. Inox - Glass 60 cm. Inox 60 cm. Glass 90 cm. Inox 90 cm. Glass Rapid Burner Semi-rapid Burner Auxiliary Burner P4) Ø180 Hot Plate (Rapid) P5) Ø145 Hot Plate (Rapid) Wok Rapid Burner... -
Page 5: Gas Connection
Gas Connetion Before montage , make sure the system of local gas supply compatible with applience. In order to do this, you can profit from the label of applience and board on the operating manual.Bearing in mind asset norms , gas connection must be made by specialized clerk. -
Page 6: Insruction For Use
Instruction For Use Gas Crowns Turn the chosen control knob to ignition the gas as it exist through the flame spread crown. Modifying symbols of models are written on appliance or control panel. Circle : tap closed; large flame : maximum gas delivery; small flame : minimum gas delivery. -
Page 7: Cleaning And Maintaining
Cleaning and Maintaining This appliance cannot be cleaned with steam or with a steam cleaning machine. The Hob Top Regularly wipe over the hob top using a soft cloth well wrung out in warm water to which a little wasing up liquid has been added. Avoid the use of the following: - household detergent and bleaches;... - Page 8 f) You should not using acid ,thinner, gasolin and this kind of substances for cleanening. g) While you are cleaning your device , do not use dusty cleaning material to clean the logo and marks on the controllig panel. h) For the cleaning of glass should you use acceptable cleaning agent. i) Do not use overwhelming cleaning agent, stain remover, plotter detergent, scourer, wash cloth.
-
Page 9: Installation
Installation Figures below are the procedures to be followed for the install; 30 cm. Glass 60 cm. Inox –Glass 90 cm. Inox –Glass Prepare the cut-out in the worktop as per the measurements shown in Figures Please call authorized service centre after making worktop cut-out to start guarantee period and prim the hob. - Page 10 • Hob should be placed centre assembly hole carefully. • Assemly metal sheet can be used to �ix the hob. After -Sales Service: In order to learn that nearest Klugmann application agent, you can call upon application agent's list. If your list is older than 1-2 year, call...
-
Page 11: Installation Instructions
Installation Instructions Assembly line room and discharge of combustion fumes. Make sure that adequate air flow as current prescribed by standards. The oxygen necessary for combustion is 2 m for 1kW energy (gas). Installation Area; Keep the room well-ventilated for sufficient combustion. Air current, the size of the Ventilation opening has to be 100 cm2 working section for exterior wall to provide air current. -
Page 12: Installation Instructions
Installation Instructions Electrical connection • Make sure value of voltage and power cable is coherent with the label, before making electrical connection. • If appliance will be connected directly to the mains, appropriate switch which has 3mm contact distance, up to standards and appliance load, must be used. -
Page 13: Using The Hob Corretly
Using The Hob Correctly To ensure maximum burner efficiency, it is strongly recommended that you use only pots and pans with a flat bottom fitting the size of the burner used so that flame will not spread beyond the bottom of the vessel. -
Page 14: Important Safety Information
Important Safety Information You MUST read these warnings carefully before installing or using the hob. Installation This appliance must be installed and serviced by a competent person as stated in the Gas Safety (Installation and Use) Regulations Current Editions and the IEE Wiring Regulations. For appliances installed in the Republic of Ireland please refer to NSAIDomestic Gas Installations I.S.813 Current Editions and the ETCI Rules for Electrical Installations. -
Page 15: Child Safety
Child Safety This hob is designed to be operated by adults. Do not allow children to play near or with the hob. This appliance is not intended for use by children or other persons whose physical, sensory or mental capabilities or lack of experience and knowledge prevents them from using the appliance safely without supervision or instruction by a responsible person to ensure that they can use the appliance safely.
