Summary of Contents for Klugmann KT905X
- Page 1 INSTRUCTION MANUAL Cooktop KT905X Klugmann Hausgeraete GmbH. Gropiusstraße 7, 48163 Münster, Deutschland +49 (0)2501 - 963 5732 +49 (0)2501 - 963 1834 service@klugmann-hausgeraete.de www.klugmann-hausgeraete.de...
-
Page 2: Igniting The Burners
Introduction We thank you for choosing a product. Before starting to use the appliance, we recommend you to carefully read the warnings and recommendations given in the user manual. Thus, you can use and protect your appliance efficiently for a longer period of time. Please keep this user manual for future reference. - Page 3 •If a fluid containing sugar overflows onto the hob, wipe this immediately with a suitable sponge.•Wipe the hob carefully with a paper towel or a damp cloth by using a few drops of detergent which is manufactured particularly for glass-ceramic. •In the event that sugar, plastic or aluminum folio falls down or are placed onto the hob accidentally, unplug the hob from the wall outlet.
-
Page 4: Safety Warnings
Safety warnings Consult qualified persons in the following situations: - installation (see the installation section); - in case you are not sure about the method of operation. In the following situations, consult technical support center approved by the manufacturer: -After you open the package, if you suspect that the appliance has missing parts; -if the power cable is changed or damaged;... - Page 5 Installation Fig.l Installation / Fig.2...
- Page 7 Controls zone P1) Rapid Burner P3) Auxiliary Burner P5) Ø145 Hot Plate P2) Semi-Rapid Burner P4) Ø180 Hot Plate P6) Triple Burner Wok...
- Page 8 Gas connection Connect the appliance with the gas pipe as per the laws in force and only after you properly complete the adjustments intended and required for such a gas-operated appliance. Otherwise, perform the actions given in the paragraph of “replacing the injectors”. To operate the appliance with liquid gas, use pressure regulators in accordance with the laws in force.
- Page 9 e) 2 electrical appliances should not be connected to the same wall BLUE outlet at the same time; f) if the power cable will be replaced, H05VV-F type 3xl,5mm cable YELLOW - GREEN should be used; BROWN g) it is essential that the support poles of the empty terminals be distinguished (Brown=Phase Blue=Neutral Yellow/Green=Earth).
-
Page 10: Installation
Important - Do not place unbalanced or deformed pots onto the burners since they may overturn or overflow. - If the appliance is equipped with a cover, make sure that the appliance cools down before closing the cover. - Close the supply valve when the hob is not in use. - Before the installation process, check the gas distribution conditions and whether these match with those given on rating plate of the appliance. -
Page 11: Using The Hot Plate
Using the hot plate Never cook the food itself directly on the hot plate without using pots or containers. Hot plate has 3 positions: symbol means closed and each of the 1-2-3 positions means different power levels. Total power of the hot plate is 1500 watt. The 1 level is 350w and used for heating, the 2 level is 1100w and used for cooking and the 3... - Page 12 Technical Specifications II 2H3+ category appliance Gas type Burner Marking the injectors Nominal thermal Reduced thermal capacity (kW) capacity (kW) Liquified Auxiliary 50 65 85 115 0.09 (kw) Hs 0,091 m3/h gas (LPG) semi-quick 1.65 (kw) Hs 0.166 m3/h G30-G3130/37 quick 2.85 (kw) Hs 0.264m3/h...
