DOEPFER Drehbank User Manual

Midi controller box

Advertisement

Quick Links

DOEPFER
MIDI Controller Box
Drehbank
User's Guide (short version)
A more detailed manual and info material you will find on the
enclosed CD

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Drehbank and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for DOEPFER Drehbank

  • Page 1 DOEPFER MIDI Controller Box Drehbank User's Guide (short version) A more detailed manual and info material you will find on the enclosed CD...
  • Page 2: Table Of Contents

    Contents of this short manual Contents of this short manual....................2 Connections .......................... 3 Hardware unit: Drehbank ....................3 Power input/ Power supply (1) ................... 3 Midi-Out-Buchse (2)......................3 Midi-In-Buchse (3) ......................4 Control-LED's (4) ....................... 4 Operation indicators ....................... 4 Bank indicators.......................
  • Page 3: Connections

    Connections Hardware unit: Drehbank Front panel • 64 control knobs • 64 labelling pads (for the user to label the function of each control knob). • 3 switches (on the left side of the unit; black): (one) to create a „Snapshot“ (the top switch) (two) to switch from one bank to the other (the lower 2 switches) (5) •...
  • Page 4: Midi-In-Buchse (3)

    Drehbank normally works in Midi Merge mode. Important: If there is a lot of data coming into the Midi In port it is possible that the Drehbank will have problems with merging, as the internal memory has a limited capacity.
  • Page 5: Snapshot Mode

    The L.E.D. above that switch will not light up, but the other 2 L.E.D.s will light up. This inverted indication system also goes for the recalling of the other presets. This means that the Drehbank at that moment loads the ROM preset and will wait until you release the switch.
  • Page 6: External Control Inputs (6)

    L.E.D. This flash is important, because if you trigger a Snapshot accidentally ( or at the wrong time) you could overload the Midi connection. Once the Snapshot has been sent the Drehbank returns to bank indicator mode. Important If you change your mind and don‘t want to send a Snapshot (or if you go into the...
  • Page 7: Windows Pc Editor Programm

    This default path you can change if you want. Windows PC Editor Programm Once you‘ve installed the application you’ll find a file titled Drehbank.EXE in the directory you have chosen. You can also create a link on the desktop for quicker access to the editor application. To start the program simply doubleclick on the Drehbank.EXE file.
  • Page 8 Doepfer Musikelektronik © 2001 by Doepfer Musikelektronik Drehbank Page 8 Short Manual...
