In the interests of user-safety (Required by safety regulations in some countries) the set should be restored to its orig-
inal condition and only parts identical to those specified should be used.
This Service Manual covers the differences from LC-46X8E/S/RU.
For other technical information, refer to the LC-42X20E/S/RU (No. S87O8LC46X20E) for Service Manual.
CHAPTER 1. OPERATION MANUAL
[1]
SPECIFICATIONS ................................. . ....... 1-1
[2]
OPERATION MANUAL .......................... . ....... 1-2
[3]
DIMENSIONS ........................................ . ....... 1-7
[1]
REMOVING OF MAJOR PARTS ........... . ....... 2-1
[1]
ADJUSTMENT PROCEDURE ............... . ....... 3-1
[1]
TROUBLESHOOTING TABLE............... . ....... 4-1
[1]
MAJOR IC INFORMATIONS.................. . ....... 5-1
Parts marked with "
" are important for maintaining the safety of the set. Be sure to replace these parts with specified ones for maintaining the
safety and performance of the set.

SERVICE MANUAL

LCD COLOUR TELEVISION
LC-46X8E/S/RU
MODELS
OUTLINE
CONTENTS
[1]
SYSTEM BLOCK DIAGRAM .........................6-1
[2]
TERMINAL BLOCK DIAGRAM .....................6-2
[3]
MAIN BLOCK DIAGRAM...............................6-3
[4]
WIRING DIAGRAM .......................................6-4
[1]
[2]
BOARD..........................................................7-5
[3]
WIRING BOARD ...........................................7-8
[4]
BOARD..........................................................7-9
CHAPTER 8. SCHEMATIC DIAGRAM
[1]
DIAGRAM......................................................8-1
[2]
SCHEMATIC DIAGRAM ................................8-2
LC-46X8E/S/RU
No. S38G2LC46X8E/
This document has been published to be used for
after sales service only.
The contents are subject to change without notice.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LC-46X8E/S/RU and is the answer not in the manual?

Questions and answers

Related Manuals for Sharp LC-46X8E/S/RU

Summary of Contents for Sharp LC-46X8E/S/RU

  • Page 1: Table Of Contents

    In the interests of user-safety (Required by safety regulations in some countries) the set should be restored to its orig- inal condition and only parts identical to those specified should be used. OUTLINE This Service Manual covers the differences from LC-46X8E/S/RU. For other technical information, refer to the LC-42X20E/S/RU (No. S87O8LC46X20E) for Service Manual. CONTENTS SAFETY PRECAUTION CHAPTER 6.

  • Page 2: Safety Precaution

    LC-46X8E/S/RU LC46X8E SAFETY PRECAUTION Service Manual IMPORTANT SERVICE SAFETY PRECAUTION Service work should be performed only by qualified service technicians who are thoroughly familiar with all safety checks and the servicing guidelines which follow: WARNING • Use an AC voltmeter having with 5000 ohm per volt, or higher, sen- sitivity or measure the AC voltage drop across the resistor.

  • Page 3: Precautions For Using Lead-Free Solder

    LC-46X8E/S/RU Precautions for using lead-free solder Employing lead-free solder • “PWBs” of this model employs lead-free solder. The LF symbol indicates lead-free solder, and is attached on the PWBs and service manuals. The alphabetical character following LF shows the type of lead-free solder.

  • Page 4: Specifications

    0°C to 40°C As a part of policy of continuous improvement, SHARP reserves the right to make design and specification changes for product improvement without prior notice. The performance specification figures indicated are nominal values of production units. There may be some deviations from these values in individual units.
  • Page 5 LC-46X8E/S/RU [2] OPERATION MANUAL Remote control unit R/G/Y/B (Colour) buttons (Standby/On) The coloured buttons are correspondingly used to select the Buttons for useful operations coloured items on the screen. (e.g. (Teletext) EPG, MHEG-5, TELETEXT) ATV: Display analogue teletext. (INPUT SOURCE) DTV: Select MHEG-5 and teletext for Select an input source.
  • Page 6 LC-46X8E/S/RU TV (Front view) Remote control sensor OPC indicator OPC sensor SLEEP indicator (Standby/On) indicator TV (Rear view) (Power) button MENU button (INPUT SOURCE) button Programme (channel) buttons ) Volume buttons AC INPUT terminal EXT1 (RGB) terminal COMMON INTERFACE slot...
  • Page 7 LC-46X8E/S/RU Preparation Attaching the stand unit Before attaching (or detaching) the stand, unplug the AC cord from the AC INPUT terminal. Before performing work spread cushioning over the base area to lay the TV on. This will prevent it from being damaged.

  • Page 8: Cautions Regarding The Remote Control Unit

    LC-46X8E/S/RU Preparation Inserting the batteries Before using the TV for the first time, insert two “AAA” size batteries (supplied). When the batteries become depleted and the remote control unit fails to operate, replace the batteries with new “AAA” size batteries.

  • Page 9: Information On The Software License For This Product

    The copyrights for the software components and various relevant documents included with this product that were developed or written by SHARP are owned by SHARP and are protected by the Copyright Act, international treaties, and other relevant laws. This product also makes use of freely distributed software and software components whose copyrights are held by third parties.

  • Page 10: Dimensions

    LC-46X8E/S/RU [3] DIMENSIONS Unit: mm 480.0 480,0 105.5 97.6 105,5 97,6 1101.0 64.0 1101,0 64,0 1023.4 1023,4 285.0 285,0 400.0 400,0 1 – 7...

  • Page 11: Chapter 2. Removing Of Major Parts

    LC-46X8E/S/RU CHAPTER 2. LC46X8E REMOVING OF MAJOR PARTS Service Manual [1] REMOVING OF MAJOR PARTS 1. Remove the 2 lock screws , 6 lock screws , 3 lock screws and the 4 lock screws . Detach the Rear Cabinet. REAR CABINET...
  • Page 12 LC-46X8E/S/RU 2. Remove all the connectors from PWBs. Wire "LB" Wire "LA" Wire "SP" Wire "SP" Wire "SP" to WH Wire "SP-L" Wire "SP" to PIN 3. Remove the 2 lock screws . and detach the Speaker L/R. Speaker R Speaker L 2 –...
  • Page 13 LC-46X8E/S/RU 4. Remove all the connectors from PWBs. #For EMC Set Wire "VD" under Wire "SP-R" (with core) Wire "KM" Wire "KM" to WH Wire "KM" to Hook SP-R WH locks Core like this. Lock side set to Panel side Wire "VD"...
  • Page 14 LC-46X8E/S/RU 5. Remove all the connectors from PWBs. R/C, LED PWB (with wire) Wire "RA" Set Wire "RA" to panel hollow Wire "RA" to WH R/C, LED PWB Front side Wire "RA" Next, Push PWB hooked 1st, Set R/C, LED PWB under LIB...
  • Page 15 LC-46X8E/S/RU 8. Remove the 2 lock screws . Detach the MINI AV Sub Ass’y. # While fix screw, forcing Mini AV PWB to M-AV KEY Mini AV Sub Ass'y 9. Remove the 3 lock screws , and 11 lock screws .
  • Page 16 LC-46X8E/S/RU 10.Remove the 14 lock screws . and detach the Panel Support Angle. PNL SUPPORT ANG 2 – 6...
  • Page 17 LC-46X8E/S/RU 11.Remove the 4 lock screws , 4 lock screws , and the 4 lock hooks . Detach the LCD Panel Module. Cushion with washer LCD MODULE 2 – 7...
  • Page 18 LC-46X8E/S/RU 12.Remove the 1 lock screw . and detach the Bottom Cover. FRONT CABINET BOTTOM COVER 2 – 8...
  • Page 19 LC-46X8E/S/RU 13.Remove the 5 lock hooks , 1 lock screw , and 6 lock hooks . and detach the KEY Unit. 14.Remove the 2 lock screws . Detach the MINI AV Unit. Top View Back View M-AV KEY COV KEY PWB...
  • Page 20 LC-46X8E/S/RU 15.Remove all the connectors from PWBs. 16.Remove the 10 lock screws . and detach the Main Shield and AV Shield. Wire "LW" Wire "LW" to WH MAIN SHIELD Wire "LW" Pull out Wire "LW" form Opening < Positioning of Wire "PD" >...
  • Page 21 LC-46X8E/S/RU 17.Remove all the connectors from PWBs. Pull same time B to B connection 18.Remove the 2 lock screws , and the 1 lock screw . Detach the Terminal Angle Bottom. TML ANG BTM SCART ANGLE #SCART Angle Stepping on terminal...
  • Page 22 LC-46X8E/S/RU 19.Remove all the connectors from PWBs. #Don't make mistake Wire "VD" and "RA" Wire "US" Wire "RA","US","KM" to WH Wire "RA" FFC "HM" Wire "KM" Core for "SP-R" Wire "VD" FFC "HM" to WH #Set at SRC Wire "KM"...

  • Page 23: Chapter 3. Adjustment Procedure

    LC-46X8E/S/RU CHAPTER 3. LC46X8E ADJUSTMENT PROCEDURE Service Manual [1] ADJUSTMENT PROCEDURE 1. Adjustment method after PWB and/or IC replacement due to repair The unit is set to the optimum at the time of shipment from the factory. If any value should become improper or any adjustment is necessary due to the part replacement, make an adjustment according to the following procedure.
  • Page 24 LC-46X8E/S/RU 2. Entering and exiting the adjustment process mode 1. Press the “POWER” key on the set of running TV set to force off the power. 2. While holding down the “VOL (-)” and “INPUT” keys on the set at once, press the “MAIN POWER” key on the set to turn on the power or plug in the AC power cord to turn on the power.

  • Page 25: Adjustment Process Mode Menu

    LC-46X8E/S/RU 5. Adjustment process mode menu The character string in brackets [ ] will appear as a page title in the adjustment process menu header. Page Line Item Description Remarks (adjustment detail, etc.) 1/33 [INFO] MAIN Version Main software version BOOT Version BOOT Version.
  • Page 26 LC-46X8E/S/RU Page Line Item Description Remarks (adjustment detail, etc.) 7/33 [HDTV] HDTV ADJ Enter HDTV video level adjustment HDTV Y GAIN HDTV Y GAIN adjustment value HDTV CB GAIN HDTV Cb adjustment value HDTV CR GAIN HDTV Cr adjustment value...
  • Page 27 LC-46X8E/S/RU Page Line Item Description Remarks (adjustment detail, etc.) 14/33 [MGXX2] MG4R W/B adjustment, gradation 4R adjustment value MG4G W/B adjustment, gradation 4G adjustment value MG4B W/B adjustment, gradation 4B adjustment value MG5R W/B adjustment, gradation 5R adjustment value MG5G...
  • Page 28 LC-46X8E/S/RU Page Line Item Description Remarks (adjustment detail, etc.) 21/33 [M OPC2] OPC LDUTY12 OPC LDUTY13 OPC LDUTY14 OPC LDUTY15 OPC LDUTY16 OPC LDUTY17 OPC LDUTY18 OPC LDUTY19 OPC LDUTY20 OPC LDUTY21 OPC LDUTY22 22/33 [M OPC3] OPC LDUTY23 OPC LDUTY24...
  • Page 29 LC-46X8E/S/RU Page Line Item Description Remarks (adjustment detail, etc.) 26/33 [M V6THE] V6 OS THERMO 1 V6 OS THERMO 2 V6 OS THERMO 3 V6 OS THERMO 4 V6 OS THERMO 5 V6 OS THERMO 6 V6 OS THERMO 7...
  • Page 30 LC-46X8E/S/RU 6. Special features 1. NORMAL STANDBY CAUSE (Page 1/33) Display of a cause (code) of the last standby. The cause of the last standby is recorded in EEPROM whenever possible. Checking this code will be useful in finding a problem when you repair the troubled set.
  • Page 31 LC-46X8E/S/RU 8. Public Mode (Hotel Mode) 1. Starting the Public Mode • There are two following ways to display the PUBLIC Mode setting screen. 1) On the process adjustment mode screen (2/33), set the “HOTEL MODE” Flag to ON. Turn off the power, and turn it on again, pressing the keys of the main unit at the same time.
  • Page 32 LC-46X8E/S/RU 4. Basic operation in the Public Mode Change or execution of the set value. Volume (+/-) or Cursor ( Movement to the selected item. Channel ( ) or Cursor ( Decision (ok) Execution (Used by the items “Execution” and “RESET”.) PUBLIC Mode R/C Ordinary operation mode: It enters the PUBLIC Mode.
  • Page 33 LC-46X8E/S/RU 6. Setting items (* Item names and selective items are expressed in English.) 1) Power ON Fixed (POWER ON FIXED) Selection “VARIABLE” or “FIXED” is selectable. (Loop is provided.) Default “VARIABLE” Function • When "FIXED" is set, “Power ON/Standby Key” of the main unit and R/C is disabled.
  • Page 34 LC-46X8E/S/RU 5) R/C Operation [RC BUTTON] Selection “RESPOND” or “NO RESPOND” is selectable. (Loop is provided.) Default RESPOND Function R/C key operation is set. When set to “NO RESPOND”, the R/C keys are disabled in the ordinary mode. The power key (Power ON/Standby Key) is also disabled.

  • Page 35: Video Signal Adjustment Procedure

    LC-46X8E/S/RU 10)Mode Fixed [INPUT MODE FIXED] Selection “VARIABLE” or “FIXED” is selectable. (Loop is provided.) Default VARIABLE Function When set to “FIXED”, it is disable to switch to other channel or input after start in the set value of “Start Mode (INPUT MODE START)”.
  • Page 36 LC-46X8E/S/RU 4. SECAM adjustment Adjustment point Adjustment Conditions Adjustment procedure Setting [Signal] • Feed the SECAM full field colour bar signal (75% colour saturation) to EXT1 SECAM SCART IN. Full Field Colour Bar signal [Terminal] EXT1 SCART IN Black 100% white...

  • Page 37: White Balance Adjustment

    LC-46X8E/S/RU 7. DVI-I adjustment (ANALOG D-sub15PIN) Adjustment point Adjustment Conditions Adjustment procedure Setting [Signal] • Feed the XGA 60Hz 100% full field colour bar signal (100% colour satura- XGA 60Hz tion) to EXT7 PC IN. 100% Full Field Colour Bar sig-...

  • Page 38: Mg1G

    LC-46X8E/S/RU 5) Repeat step 4) for points 4, 3, 2, and 1. [Adjustment reference standard value] Adjustment spec ± 0.002 Inspection spec ± 0.004 (point 1 and 2) Adjustment spec ± 0.001 Inspection spec ± 0.002 (Excluding the above-mentioned) * Adjusting procedure by use of [RS-232C] 1.

  • Page 39: Initialization To Factory Settings

    LC-46X8E/S/RU 11. Confirmation item 1. Magi-Link Inspection The thing that the Magi-Link circuit operates is confirmed. 2. HDMI-CEC Inspection The thing that the HDMI-CEC circuit operates is confirmed. 12. Initialization to factory settings CAUTION: When the factory settings have been made, all user setting data, including the channel settings, are initialized.
  • Page 40 LC-46X8E/S/RU 5. If any of the procedures fails, the following upgrade failure screen shows up. For the failing procedure, the “NG” marking turns red. NOTE: In such case, try to upgrade the software again. If it still fails, the hardware may be in trouble.

  • Page 41: Chapter 4. Troubleshooting Table Troubleshooting Table

    LC-46X8E/S/RU CHAPTER 4. LC46X8E TROUBLESHOOTING TABLE Service Manual [1] TROUBLESHOOTING TABLE Power unit operation check. Are the power cord and harness in the unit properly connected? Connect the power cord and harness properly, and turn on the power. LINE_FILTER_UNIT: Is F7000 normal? LINE_FILTER_UNIT: Isn't FL7001, L7001, R7002, CX7000-1, Z7000, etc.
  • Page 42 LC-46X8E/S/RU The sound is not emitted from the speaker though the picture has come out. No sound output in all modes. TERMINAL UNIT: Is the audio signal (L/R) output from pins (38, 39) of IC1404 Check IC1404 and its peripheral circuits.
  • Page 43 LC-46X8E/S/RU No sound (during the reception of TV (DIGITAL) broadcasting) The sound does not come out though the picture come out when DTV is received? MAIN UNIT: Is DTV_SPDIF audio signal output from pin (T2) of IC8101 (CPU/ Check the line between IC8101 and SC1101, and their peripheral DECODER) to pin (42) of connector SC1101? circuits.
  • Page 44 LC-46X8E/S/RU No sound from external input devices (2) The sound input from EXT3 doesn’t come out. MINI AV_UNIT: Is audio signal (IN3_L/R) input from pins (5, 4) of EXT3 terminal Check connection of between from J901 to P901 and the exter- (J901) to pins (3, 1) of connector (P901)? nal input device.
  • Page 45 LC-46X8E/S/RU No sound from external input devices (4) The sound input from EXT6 (analog HDMI) doesn’t come out. The sound input from EXT7 (analog RGB audio) doesn’t come out. Check whether “Analog” has selected in MENU-Option -HDMI Audio Select. MAIN UNIT:...
  • Page 46 LC-46X8E/S/RU The audio signal is not output (1) The audio signal of UHF/VHF and DTV is not output from EXT1 (SCART1). TERMINAL UNIT: Is audio signal (L/R) output from pins (3, 1) of SCART1 (SC502)? Check the connection to SCART1 and external devices.
  • Page 47 LC-46X8E/S/RU The audio signal is not output (3) The audio signal of MONITOR is not output from EXT2 (SCART2). TERMINAL UNIT: Is audio signal (L/R) sent to pins (3, 1) of SCART2 (SC503)? Check the connection to SCART2 and external devices.
  • Page 48 LC-46X8E/S/RU The audio signal is not output (5) No audio signal output from DIGITAL_AUDIO_OUTPUT terminal. TERMINAL UNIT: Is digital audio signal (OPT_OUT) output to pin (1) of optical fiber Check D501 or peripheral circuits. transmitter (D501)? (B3.3V_LINE, etc.) SPDIF_MUTE signal [pin (92) of IC9101 (CPLD)] or MUTE- This signal should be “L”.
  • Page 49 LC-46X8E/S/RU No picture on the display (1) The picture doesn't appear in all modes. MAIN UNIT: Is LVDS signal output from 1st_channel and 2nd_channel of IC3301(VIDEO PROCESSER) in each mode? TA1± (A14/B14), TB1± (A15/B15), TC1± (A16/B16), TD1± (A18/B18), TE1± (A19/B19), TCLK1± (A17/B17), TA2± (A20/B20), TB2± (C20/D19), TC2±...
  • Page 50 LC-46X8E/S/RU No picture on the display (3) The picture doesn’t come out when DTV is received. TERMINAL UNIT: Is the regulated power supplied to TUNER (5V/5VCONT) and Each power supply circuit is checked. IC7507 (B3.3V/B1.8V)? Is IF signal output from pins (20, 21) of TUNER (TU7501) to pins Check the tuner, IC7507 and their peripheral circuits.
  • Page 51 LC-46X8E/S/RU <External input EXT1, EXT2> No picture on the display (4) The CVBS video signal input from EXT1 doesn’t come out in the display. The CVBS video signal input from EXT2 doesn’t come out in the display. TERMINAL UNIT: <EXT1>...
  • Page 52 LC-46X8E/S/RU <External input EXT1, EXT2> No picture on the display (5) The R/G/B video signal input from EXT1 doesn’t come out in the display. The R/G/B video signal input from EXT2 doesn’t come out in the display. TERMINAL UNIT: <EXT1>...
  • Page 53 LC-46X8E/S/RU <External input EXT1, EXT2> No picture on the display (6) The Y/C video signal input from EXT1 doesn’t come out in the display. The Y/C video signal input from EXT2 doesn’t come out in the display. TERMINAL UNIT: <EXT1>...
  • Page 54 LC-46X8E/S/RU <When EXT3 is used for external input> No picture on the display (7) The picture video signal (CVBS) input from EXT3 doesn’t come out in the display. MINI AV UNIT: Is the CVBS signal input from pin (6) of EXT3 terminal (J901) to Check the line between J901 and P901.
  • Page 55 LC-46X8E/S/RU <When EXT3 is used for external input> No picture on the display (8) The Y/C video signal input from EXT3 doesn’t come out in the display MINI AV_UNIT: Is Y/C signal output from pins (3, 4) of J902 (Y/C TERMINAL) to Check the line between J901 and P901.
  • Page 56 LC-46X8E/S/RU <When EXT4 is used for external input> No picture on the display (9) The HDMI signal input from EXT4 doesn’t come out in the display. MINI AV_UNIT: Is the HOT_PLUG detection signal input to pin (19) of the HDMI...
  • Page 57 LC-46X8E/S/RU <When EXT5/6 is used for external input> No picture on the display (10) The HDMI signal input from EXT5/6 doesn’t come out in the display. MAIN UNIT: EXT5 EXT5 Is the HOT_PLUG detection signal input to pin (19) of the HDMI...
  • Page 58 LC-46X8E/S/RU <When EXT7 is used for external input> No picture on the display (11) The PC (ANALOG) video signal input from EXT7 (D-SUB-15pin-terminal) doesn’t come out in the display. MAIN_UNIT: Are the video signal (R, G, B) and the synchronized signal (H/V)
  • Page 59 LC-46X8E/S/RU <During external connection> No picture on the monitor (1) No picture appears on EXT1 - connected monitor during the tuner (U/V) reception. Checklist: 1) Is the Signal Type (item) in MENU-Option-Input Select equal to Signal Type of an external device? ⋅ ⋅ ⋅ Set it to “CVBS”, “Y/C” or “RGB”.
  • Page 60 LC-46X8E/S/RU <During external connection> No picture on the monitor (2) No picture appears on EXT1 - connected monitor during the tuner (DTV) reception. Checklist: 1) Is the Signal Type (item) in MENU-Option-Input Select equal to Signal Type of an external device? ⋅ ⋅ ⋅ Set it to “CVBS”, “Y/C” or “RGB”.
  • Page 61 LC-46X8E/S/RU <During external connection> No picture on the monitor (3) SCART2: No picture from EXT1 appears on EXT2-connected monitor. NOTE: Normally, if the screen during display is sent to EXT2, no picture is sent to EXT2. Checklist: 1) Is the Signal Type (item) in MENU-Option-Input Select equal to Signal Type of an external device? ⋅ ⋅ ⋅ Set it to “CVBS”, “Y/C” or “RGB”.
  • Page 62 LC-46X8E/S/RU <During external connection> No picture on the monitor (4) SCART2: No picture from EXT3 appears on EXT2- connected monitor. Checklist: 1) Is the Signal Type (item) in MENU-Option-Input Select equal to Signal Type of an external device? ⋅ ⋅ ⋅ Set it to “CVBS”, “Y/C” or “RGB”.
  • Page 63 LC-46X8E/S/RU 2) Power failure details (Power LED flashes twice and OPC LED flashes) Remarks Error type OPC LED operation (1 cycle) Description PS_ON H: On AC_DET (IC2002_16pin): Abnormal (L). Main converter 12V 12V failure is not applied. Flashes once If error is detected during operation, the power is turned on...

  • Page 64: Chapter 5. Major Ic Informations

    LC-46X8E/S/RU CHAPTER 5. LC46X8E MAJOR IC INFORMATIONS Service Manual [1] MAJOR IC INFORMATIONS 1. Detailed ICs Information 1.1. IC402 (VHiBD9305AF-1Y) 1.1.1 Block Diagram 1.1.2 Pin Connections and short description Pin No. Pin Name Pin Function — Timing Resistor external terminal.

  • Page 65: Chapter 6. Block Diagram/Wiring Diagram System Block Diagram

    LC-46X8E/S/RU 1.2. IC506 (VHiMM3151XQ-1Q) 1.2.1 Block Diagram 5 – 2...
  • Page 66 LC-46X8E/S/RU 1.2.2 Pin Connections and short description Pin No. Pin Name Pin Function Chroma signal input The terminal which detects the connection state of S-connector. Composite signal input. S2-1 The terminal which detects the aspect ratio information of S-connector. S2-2...
  • Page 67 LC-46X8E/S/RU Pin No. Pin Name Pin Function 4, 6, 10, 11, 12, 13, 17, — Unconnected pins. 19, 39, 41, 43, 48, 61, 63 1.3. IC1402 (VHiR2S15502-1Y) 1.3.1 Block Diagram 1.3.2 Pin Connections and short description Pin No. Pin Name...
  • Page 68 LC-46X8E/S/RU 1.4. IC3301 (RH-iXC010WJQZQ) 1.4.1 Block Diagram 1.4.2 Pin Connections and short description Pin No. Pin Name Pin Function Sheet Name Destination Ball Assignments for CPU Host Interface. K20, K19, K18, A_D[7:0] Multiplexed address and data bus powered by VDDH/VSS. ADAT_O-7...
  • Page 69 LC-46X8E/S/RU Pin No. Pin Name Pin Function Sheet Name Destination Y_G2 Y input 2 of component or G input 2 of PC RGB. COMP_Y_TR FROM-V-SW Y_G3 Y input 3 of component or G input 3 of PC RGB. DTM_Y open CVBS_OUT1 CVBS Output 1.
  • Page 70 LC-46X8E/S/RU Pin No. Pin Name Pin Function Sheet Name Destination Bank address select. WX_BA1 TO SDRAM Ball Assignments for Power and Ground. C14, C15, D13, VDDC — 1.2V Digital core power. D1.2V D14, D15, E13, E14, E15, G16, H5, H16, J5,...
  • Page 71 LC-46X8E/S/RU Pin No. Pin Name Pin Function Sheet Name Destination TB1M LVDS 1st Channel Differential negative data out. TB1- TO LCD CONT TC1P LVDS 1st Channel Differential positive data out. TC1+ TO LCD CONT TC1M LVDS 1st Channel Differential negative data out.
  • Page 72 LC-46X8E/S/RU 1.5. IC3501 (RH-iXC163WJQZQ) 1.5.1 Block Diagram 1.5.2 Pin Connections and short description Pin No. Pin Name Pin Function 62, 63 CK, CK The differential system clock Input. All of the inputs are sampled on the rising edge of the clock except DQ's and DM's that are sam- pled on both edges of the DQS.
  • Page 73 LC-46X8E/S/RU Pin No. Pin Name Pin Function 15, 16, 57, 17, 18, 60, A0-11 Row/Column addresses are multiplexed on the same pins. 19, 20, 21, 59, 90, 58 Row addresses : RA0 ~ RA11, Column addresses : CA0 ~ CA7.
  • Page 74 LC-46X8E/S/RU 1.6.2 Pin Connections and short description Pin No. Pin Name Pin Function VIF1 VIF differential input 1 VIF2 VIF differential input 2 Output port 1; open-collector. FMPLL FM-PLL for loop filter. DEEM De-emphasis output for capacitor. AF decoupling input for capacitor DGND —...
  • Page 75 LC-46X8E/S/RU 1.7.2 Pin Connections and short description Pin No. Pin Name Pin Function Sheet Name DAC Interface VDDZ_DAC — Digital power for DAC (+3.3V). D3.3V VSSZ_DAC — Digital ground for DAC. DAC_VS DAC vsync. open DAC_HS DAC hsync. open DAC_CLK...
  • Page 76 LC-46X8E/S/RU Pin No. Pin Name Pin Function Sheet Name TCLK1P LVDS Positive clock Output. (no connected) open TCLK1M LVDS Negative clock Output. (no connected) open TC1P LVDS Positive Output. (no connected) open TC1M LVDS Negative Output. (no connected) open LVDS_VDDO —...
  • Page 77 LC-46X8E/S/RU Pin No. Pin Name Pin Function Sheet Name AD23_FRA7 Flash address 7/PCI AD bus bit 23. FRA_7 AD16_FRA0 Flash address 0/PCI AD bus bit 16/POD host interface Card output FRA_0 enable. IRDY_PCAS PCI bus IRDY# signal/M68K CPU interface address strobe signal.
  • Page 78 LC-46X8E/S/RU Pin No. Pin Name Pin Function Sheet Name REQ1 PCI req signal. R-D3.3V REQ2 PCI req signal. R-D3.3V REQ3 PCI req signal. R-D3.3V FRAME#_SIZI PCI bus FRAME# signal/68K Transfer size bit 1. PCI_FRAM (along with Transfer size bit 0 to indicate the number byte to be transferred during a bus cycle M68K CPU bus.)
  • Page 79 LC-46X8E/S/RU Pin No. Pin Name Pin Function Sheet Name AM20 VDB_VS Video input/output: Vertical sync; VDB_VS IDE: DMAREQ, IDE bus DMA request. EJTAG: NOP POD2: POD_A_B4, the second POD host interface address bit 4. AN20 VDB_G0 Video input/output: Green channel bit 0;...
  • Page 80 LC-46X8E/S/RU Pin No. Pin Name Pin Function Sheet Name AK24 VDB_B5 Video input/output: Blue channel bit 5; VDB_B5 IDE: IDE data bus bit 15. EJTAG: PCST[3], output as EJTAG PC Trace bus, bit 3. POD2: POD2_TS2_D7, the second POD TS2 data[7].
  • Page 81 LC-46X8E/S/RU Pin No. Pin Name Pin Function Sheet Name HSDCLK 1394: clock. 8051_ALE Video 656 port: 656CLK, clock. 8051: RD, ALE, address latch enable. AM10 HSDRW 1394: Not used. 8051_RD Video 656 port: 656HS, horizontal sync. 8051: RD, read signal, low active.
  • Page 82 LC-46X8E/S/RU Pin No. Pin Name Pin Function Sheet Name AF34 MD27 Memory data bus. DDR_DQ30 AE34 DQM3 Memory data write mask enable for byte 3. DDR_DM3 AD33 DQS3 Data strobe for memory data bus MD[31:24]. DDR_DQS3 AD34 DQS3N Data strobe for memory data bus MD[31:24].
  • Page 83 LC-46X8E/S/RU Pin No. Pin Name Pin Function Sheet Name MD56 Memory data bus. DDR_DQ60 MD57 Memory data bus. DDR_DQ59 MD58 Memory data bus. DDR_DQ57 MD59 Memory data bus. DDR_DQ62 DQM7 Memory data write mask enable for byte 7. DDR_DM7 DQS7 Data strobe for memory data bus MD[63:56].
  • Page 84 LC-46X8E/S/RU Pin No. Pin Name Pin Function Sheet Name SCIO Smart card serial data, 8mA open-drain in out pad. (Not used) open SCCLK Smart card clock, 8mA open-drain output pad (7.1M to 3.5M) (Not open used) SCPRES Smart card present detect. (Not used)
  • Page 85 LC-46X8E/S/RU Pin No. Pin Name Pin Function Sheet Name Power and ground pins A26, AJ20, Y6 V5SF — 5V safe power. AA13, AA22, AB13, VDDC — Core power supply= 1.2V AB14, AB21, AB22, AD6, AE6, AF6, AG6, AH6, AJ8, AJ9, AJ10, AJ11,...
  • Page 86 LC-46X8E/S/RU 1.8. IC8301 (RH-iXC154WJQZQ) 1.8.1 Block Diagram 5 – 23...
  • Page 87 LC-46X8E/S/RU 1.8.2 Pin Connections and short description Pin No. Pin Name Pin Function 53, 52 CK, CK Clock: CK and CK are differential clock inputs. CMD, ADD inputs are sampled on the crossing of the positive edge of CK and negative edge of CK.
  • Page 88 LC-46X8E/S/RU 1.9. IC9101 (RH-iXC121WJN8Q) 1.9.1 Block Diagram 5 – 25...
  • Page 89 LC-46X8E/S/RU 1.9.2 Pin Connections and short description Pin No. Pin Name Pin Function D3.3V — Power supply (+3.3V) N_CPLD_CS0 HiDTV CS0 . . . Flash XERE HiDTV PCI_BUS OE# ROM_CE BOOT ROM CE input N_CPLD_CS1 HiDTV CS1 . . . CPLD...
  • Page 90 LC-46X8E/S/RU Pin No. Pin Name Pin Function PNL_WP VCOM Write Protect control signal CPLD_TMS CPLD_Test Mode Select FE_RST CE6353 reset CPLD_TCK CPLD_Test Clock FEPG0_COMP Sleep signal FEPG1_LOCK Signal LOCK detection FERR_UNCOR Error flag N_TS1_DEMORST TS1 demodulator reset GND_B — Ground D3.3V...
  • Page 91 LC-46X8E/S/RU Pin No. Pin Name Pin Function MUTE_HDMI HDMI_MUTE initial value Low HPLUGOUT_A HDMI Plug Out detection (H) HDMIKEY_WP EDIT_Write Protect N_CPLD2_RST CPLD2 reset PNL_POW Panel power control HDMI_SW_INT HDMI SW IC interrupt request HDELAY_DOUT HDMI Data Delay Serial_Data_OUTPUT N_MICOM_FLSW...
  • Page 92 LC-46X8E/S/RU 1.10. IC9602 (VHiMP2367DN-1Y) 1.10.1 Block Diagram 1.10.2 Pin Connections and short description Pin No. Pin Name Pin Function High-Side Gate Drive Boost Input. BS supplies the drive for the high-side N-Channel MOSFET switch. Connect a 0.01µF or greater capacitor from SW to BS to power the high side switch.
  • Page 93 LC-46X8E/S/RU LC46X8E CHAPTER 6. BLOCK DIAGRAM/WIRING DIAGRAM Service Manual [1] SYSTEM BLOCK DIAGRAM SYSTEM BLOCK DIAGRAM 6 – 1...

  • Page 94: Terminal Block Diagram

    LC-46X8E/S/RU [2] TERMINAL BLOCK DIAGRAM TERMINAL BLOCK DIAGRAM 6 – 2...

  • Page 95: Main Block Diagram

    LC-46X8E/S/RU [3] MAIN BLOCK DIAGRAM MAIN BLOCK DIAGRAM PST8424N 6 – 3...

  • Page 96: Wiring Diagram

    LC-46X8E/S/RU [4] WIRING DIAGRAM OVERALL WIRING DIAGRAM 6 – 4...

  • Page 97: Chapter 7. Printed Wiring Board

    LC-46X8E/S/RU LC46X8E CHAPTER 7. PRINTED WIRING BOARD Service Manual [1] MAIN UNIT PRINTED WIRING BOARD MAIN Unit (Side A) 7 – 1...
  • Page 98 LC-46X8E/S/RU Chip Parts Side A MAIN Unit ( R2435 SC1504 J1501 J1502 SC1502 SC1501 C2404 C2410 R2405 D2404 IC2403 C2405 R1505 C1506 R1501 R1537 D1502 D2403 FB2402 D1518 R1518 R1523 C1503 C1509 C2406 C2407 C2408 D2401 C1513 D2402 D1526 D1527...
  • Page 99 LC-46X8E/S/RU Side B MAIN Unit ( 7 – 3...
  • Page 100 LC-46X8E/S/RU Chip Parts Side B MAIN Unit ( R2417 C8391 C8390 C8394 C8392 C8384 C8383 C8378 C1504 C8377 FB8111 C1508 R1520 C8126 C8370 C8131 D1515 C8369 C8368 R1521 C8374 R8104 C8148 R9302 R9301 R8174 R8162 C8130 R1542 R1559 Q1501 IC1504...

  • Page 101: Terminal Unit Printed Wiring Board

    LC-46X8E/S/RU [2] TERMINAL UNIT PRINTED WIRING BOARD Side A TERMINAL Unit ( 7 – 5...
  • Page 102 LC-46X8E/S/RU Chip Parts Side A TERMINAL Unit ( R402 C402 C405 C430 LUG502 LUG503 R408 R409 R426 C429 R1333 C592 P401 R423 IC402 C1451 C1439 C1465 C406 LUG506 R1402 C1320 R1417 C1469 C1402 C1440 C1464 IC1406 R1405 C1427 C403 C414...
  • Page 103 LC-46X8E/S/RU Side B TERMINAL Unit ( 7 – 7...

  • Page 104: R/C, Led Unit/Key Unit Printed Wiring Board

    LC-46X8E/S/RU [3] R/C, LED UNIT/KEY UNIT PRINTED WIRING BOARD R/C, LED Unit (Side A) R/C, LED Unit (Chip Parts Side A) KEY Unit (Side A) KEY Unit (Chip Parts Side A) S155 R153 D152 S154 D101 R132 S152 C105 R151...

  • Page 105: Mini Av Unit Printed Wiring Board

    LC-46X8E/S/RU [4] MINI AV UNIT PRINTED WIRING BOARD R801 R834 Q802 D801 R907 VA801 VA802 R908 C832 R820 R906 C803 R802 C903 C827 D903 R821 D905 D904 R831 IC802 R830 R912 R911 R838 D806 Q805 R805 C805 LUG901 R818 R811...
  • Page 106 LC-46X8E/S/RU MINI AV Unit (Side B) 7 – 10...

  • Page 107: Description Of Schematic Diagram

    LC-46X8E/S/RU LC46X8E CHAPTER 8. SCHEMATIC DIAGRAM Service Manual [1] DESCRIPTION OF SCHEMATIC DIAGRAM VOLTAGE MEASUREMENT CONDITION: 1. The voltages at test points are measured on exclusive AC adaptor and the stable supply voltage of AC 230V. Signals are fed by a colour bar signal generator for servicing purpose and the above voltages are measured with a 20k ohm/V tester.
  • Page 108 LC-46X8E/S/RU [2] SCHEMATIC DIAGRAM MAIN Unit-1 8 – 2...
  • Page 109 LC-46X8E/S/RU MAIN Unit-2 8 – 3...
  • Page 110 LC-46X8E/S/RU MAIN Unit-3 8 – 4...
  • Page 111 LC-46X8E/S/RU MAIN Unit-4 8 – 5...
  • Page 112 LC-46X8E/S/RU MAIN Unit-5 8 – 6...
  • Page 113 LC-46X8E/S/RU MAIN Unit-6 8 – 7...
  • Page 114 LC-46X8E/S/RU MAIN Unit-7 8 – 8...
  • Page 115 LC-46X8E/S/RU MAIN Unit-8 8 – 9...
  • Page 116 LC-46X8E/S/RU MAIN Unit-9 8 – 10...
  • Page 117 LC-46X8E/S/RU MAIN Unit-10 8 – 11...
  • Page 118 LC-46X8E/S/RU MAIN Unit-11 8 – 12...
  • Page 119 LC-46X8E/S/RU MAIN Unit-12 8 – 13...
  • Page 120 LC-46X8E/S/RU MAIN Unit-13 8 – 14...
  • Page 121 LC-46X8E/S/RU MAIN Unit-14 8 – 15...
  • Page 122 LC-46X8E/S/RU MAIN Unit-15 8 – 16...
  • Page 123 LC-46X8E/S/RU TERMINAL Unit-1 AND SHADED COMPONENTS=SAFETY RELATED PARTS 8 – 17...
  • Page 124 LC-46X8E/S/RU TERMINAL Unit-2 8 – 18...
  • Page 125 LC-46X8E/S/RU TERMINAL Unit-3 8 – 19...
  • Page 126 LC-46X8E/S/RU TERMINAL Unit-4 8 – 20...
  • Page 127 LC-46X8E/S/RU TERMINAL Unit-5 8 – 21...
  • Page 128 LC-46X8E/S/RU R/C, LED Unit 8 – 22...
  • Page 129 LC-46X8E/S/RU KEY Unit 8 – 23...
  • Page 130 LC-46X8E/S/RU MINI AV Unit 8 – 24...

  • Page 131: Parts Guide

    LC-46X8E/S/RU PartsGuide PARTS GUIDE No. S38G2LC46X8E/ LCD COLOUR TELEVISION LC-46X8E/S/RU MODELS CONTENTS PRINTED WIRING BOARD DUNTKE264FM01 (R/C, LED Unit) ASSEMBLIES DUNTKE266FM01 (KEY Unit) LCD PANEL AND TUNER (NOTE: THE PARTS HERE SHOWN ARE CABINET PARTS SUPPLIED AS AN ASSEMBLY BUT NOT INDEPENDENTLY.)
  • Page 132 LC-46X8E/S/RU PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [1] PRINTED WIRING BOARD ASSEMBLIES MAIN Unit DUNTKE186FM03 TERMINAL Unit DUNTKE187FM03 MINI AV Unit DUNTKE188FM11 R/C, LED Unit DUNTKE264FM01 KEY Unit DUNTKE266FM01 RDENCA231WJQZ POWER Unit (Unit Replacement Item) AC Inlet Unit (Unit Replacement Item)
  • Page 133 LC-46X8E/S/RU PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [3] DUNTKE186FM03 (MAIN Unit) C1813 Capacitor 1 25V Ceramic RC-KZA114WJZZY C1816 Capacitor 4.7 10V Ceramic RC-KZA067WJZZY C2001 Capacitor 0.1 16V Ceramic VCKYCZ1CF104ZY C2002 Capacitor 1500p 50V Ceramic VCKYCZ1HB152KY C2003 Capacitor 0.1 16V Ceramic...
  • Page 134 LC-46X8E/S/RU PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [3] DUNTKE186FM03 (MAIN Unit) C3354 Capacitor 1000p 50V Ceramic VCKYCZ1HB102KY C3355 Capacitor 1000p 50V Ceramic VCKYCZ1HB102KY C3356 Capacitor 1000p 50V Ceramic VCKYCZ1HB102KY C3357 Capacitor 10 10V Ceramic RC-KZA195WJZZY C3358 Capacitor 0.1 16V Ceramic...
  • Page 135 LC-46X8E/S/RU PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [3] DUNTKE186FM03 (MAIN Unit) C4417 Capacitor 0.1 25V Ceramic VCKYCZ1EF104ZY C4420 Capacitor 68 16V Electrolytic VCAAPE1CJ686MY C8101 Capacitor 0.1 16V Ceramic VCKYCZ1CF104ZY C8102 Capacitor 0.1 16V Ceramic VCKYCZ1CF104ZY C8103 Capacitor 0.1 16V Ceramic...
  • Page 136 LC-46X8E/S/RU PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [3] DUNTKE186FM03 (MAIN Unit) C8184 Capacitor 10 10V Ceramic RC-KZA195WJZZY C8185 Capacitor 10 10V Ceramic RC-KZA195WJZZY C8186 Capacitor 0.1 16V Ceramic VCKYCZ1CF104ZY C8187 Capacitor 0.1 16V Ceramic VCKYCZ1CF104ZY C8188 Capacitor 0.1 16V Ceramic...
  • Page 137 LC-46X8E/S/RU PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [3] DUNTKE186FM03 (MAIN Unit) C8352 Capacitor 0.1 16V Ceramic VCKYCZ1CF104ZY C8353 Capacitor 0.1 16V Ceramic VCKYCZ1CF104ZY C8354 Capacitor 0.1 16V Ceramic VCKYCZ1CF104ZY C8355 Capacitor 0.1 16V Ceramic VCKYCZ1CF104ZY C8356 Capacitor 0.1 16V Ceramic...
  • Page 138 LC-46X8E/S/RU PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [3] DUNTKE186FM03 (MAIN Unit) C9617 Capacitor 10 25V Ceramic RC-KZA383WJZZY C9618 Capacitor 47 20V Electrolytic VCAAPD1DJ476MY C9619 Capacitor 10 25V Ceramic RC-KZA383WJZZY C9620 Capacitor 10 25V Ceramic RC-KZA383WJZZY C9621 Capacitor 10 10V Ceramic...
  • Page 139 LC-46X8E/S/RU PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [3] DUNTKE186FM03 (MAIN Unit) D9610 Diode DAN217UT106 VHDDAN217U+-1Y D9611 Diode 1SS355TE-17 VHD1SS355//-1Y D9612 Zener Diode UDZSNPTE-174.3B RH-EXA089WJZZY FB1101 Balun BLN-A204WJ RBLN-A204WJZZY FB1102 Balun BLN-A204WJ RBLN-A204WJZZY FB1103 RBLN-A204WJZZY Balun BLN-A204WJ FB1104 Balun BLN-A204WJ...
  • Page 140 LC-46X8E/S/RU PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [3] DUNTKE186FM03 (MAIN Unit) IC2006 IC TC74VHC32FT(EL) VHiTCVHC32T-1Y IC2008 IC TC7WH126FU(TE12L,F) VHi7WH126FU-1Y IC2009 IC TC74LCX125FT(EL,K) VHiLCX125FT-1Y IC2010 IC TC7W00FU(TE12L,F) VHiTC7W00U/-1Y IC2011 IC TC7W08FU(TE12L,F) VHiTC7W08U/-1Y IC2401 VHi7WH126FU-1Y IC TC7WH126FU(TE12L,F) IC2402 IC TC74LCX157FT(EKJ)
  • Page 141 LC-46X8E/S/RU PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [3] DUNTKE186FM03 (MAIN Unit) P1103 Plug 8Pin(FE) QPLGNA342WJZZY P2002 Plug 4Pin(KM) QPLGNA338WJZZY P2003 Plug 15Pin(RA) QPLGNA349WJZZY P2601 Connector 41Pin(LW) QCNCWA507WJQZY P2602 Plug 11Pin(LP) QPLGNA331WJZZY P2603 QPLGNA343WJZZY Plug 9Pin(LB) P9601 Plug 12Pin(PD)
  • Page 142 LC-46X8E/S/RU PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [3] DUNTKE186FM03 (MAIN Unit) R1536 Resistor 1k 1/16W Metal Oxide VRS-CZ1JF102JY R1537 Resistor 47k 1/16W Metal Composition VRK-SA1JF473JY R1538 Resistor 1k 1/16W Metal Oxide VRS-CZ1JF102JY R1540 Resistor 100k 1/16W Metal Oxide...
  • Page 143 LC-46X8E/S/RU PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [3] DUNTKE186FM03 (MAIN Unit) R2079 Resistor 10k 1/16W Metal Oxide VRS-CZ1JF103JY R2082 Resistor 10k 1/16W Metal Oxide VRS-CZ1JF103JY R2088 Resistor 39k 1/16W Metal Oxide VRS-CZ1JF393JY R2089 Resistor 10k 1/16W Metal Oxide...
  • Page 144 LC-46X8E/S/RU PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [3] DUNTKE186FM03 (MAIN Unit) R3521 Resistor 33 1/32W Metal Composition VRK-SB1FF330JY R3524 Resistor 33 1/32W Metal Composition VRK-SB1FF330JY R3525 Resistor 33 1/32W Metal Composition VRK-SB1FF330JY R3526 Resistor 33 1/32W Metal Composition...
  • Page 145 LC-46X8E/S/RU PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [3] DUNTKE186FM03 (MAIN Unit) R8130 Resistor 10k 1/32W Metal Composition VRK-SB1FF103JY R8131 Resistor 5.6k 1/16W Metal Oxide VRS-CZ1JF562JY R8132 Resistor 430 1/16W Metal Oxide VRS-CZ1JF431JY R8133 Resistor 330 1/16W Metal Oxide...
  • Page 146 LC-46X8E/S/RU PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [3] DUNTKE186FM03 (MAIN Unit) R9163 Resistor 4.7k 1/16W Metal Oxide VRS-CZ1JF472JY R9164 Resistor 33 1/16W Metal Oxide VRS-CZ1JF330JY R9181 Resistor 47k 1/16W Metal Oxide VRS-CZ1JF473JY R9185 Resistor 4.7k 1/16W Metal Oxide...
  • Page 147 LC-46X8E/S/RU PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [3] DUNTKE186FM03 (MAIN Unit) R9665 Resistor 10k 1/16W Metal Oxide VRS-CZ1JF103JY R9666 Resistor 13k 1/16W Metal Oxide VRS-CZ1JF133FY SC1101 Connector 82Pin QCNCWA673WJZZY SC1501 Sccket 23Pin(TMDS Input 3) QSOCZA072WJZZQ SC1502 Sccket 23Pin(TMDS Input 2)
  • Page 148 LC-46X8E/S/RU PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [4] DUNTKE187FM03 (TERMINAL Unit) C542 Capacitor 330p 50V Ceramic VCKYCY1HB331KY C543 Capacitor 330p 50V Ceramic VCKYCY1HB331KY C544 Capacitor 330p 50V Ceramic VCKYCY1HB331KY C545 Capacitor 470p 50V Ceramic VCKYCY1HB471KY C546 Capacitor 470p 50V Ceramic...
  • Page 149 LC-46X8E/S/RU PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [4] DUNTKE187FM03 (TERMINAL Unit) C1329 Capacitor 1 25V Ceramic RC-KZA114WJZZY C1330 Capacitor 1 25V Ceramic RC-KZA114WJZZY C1402 Capacitor 47 6.3V Electrolytic VCEASX0JN476MY C1404 Capacitor 1000p 50V Ceramic VCKYCY1HB102KY C1405 Capacitor 0.1 25V Ceramic...
  • Page 150 LC-46X8E/S/RU PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [4] DUNTKE187FM03 (TERMINAL Unit) C7522 Capacitor 10 16V Ceramic RC-KZA237WJZZY C7523 Capacitor 0.01 50V Ceramic VCKYCY1HB103KY C7524 Capacitor 0.01 50V Ceramic VCKYCY1HB103KY C7525 Capacitor 0.1 25V Ceramic VCKYCY1EF104ZY C7526 Capacitor 0.01 50V Ceramic...
  • Page 151 LC-46X8E/S/RU PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [4] DUNTKE187FM03 (TERMINAL Unit) FB406 Balun BLN-0207TA RBLN-0207TAZZY FB501 Balun BLN-0077TA RBLN-0077TAZZY FB502 Balun BLN-0077TA RBLN-0077TAZZY FB503 Balun BLN-0077TA RBLN-0077TAZZY FB504 Balun BLN-0077TA RBLN-0077TAZZY FB505 RBLN-0077TAZZY Balun BLN-0077TA FB506 Balun BLN-0077TA...
  • Page 152 LC-46X8E/S/RU PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [4] DUNTKE187FM03 (TERMINAL Unit) L7509 Coil Peaking 2.2µH VPSBN2R2JR54NY L7510 Coil Peaking 2.2µH VPSBN2R2JR54NY L7511 Coil Peaking 2.2µH VPSBN2R2JR54NY LUG501 QLUGHA009WJZZY LUG502 QLUGHA009WJZZY LUG503 QLUGHA009WJZZY LUG504 QLUGHA009WJZZY LUG505 QLUGHA009WJZZY LUG506 QLUGHA009WJZZY...
  • Page 153 LC-46X8E/S/RU PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [4] DUNTKE187FM03 (TERMINAL Unit) R540 Resistor 220 1/16W Metal Oxide VRS-TV1JD221JY R541 Resistor 220 1/16W Metal Oxide VRS-TV1JD221JY R542 Resistor 220 1/16W Metal Oxide VRS-TV1JD221JY R545 Resistor 100k 1/16W Metal Oxide...
  • Page 154 LC-46X8E/S/RU PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [4] DUNTKE187FM03 (TERMINAL Unit) R670 Resistor 100 1/16W Metal Oxide VRS-CY1JF101JY R671 Resistor 820 1/16W Metal Oxide VRS-CY1JF821JY R672 Resistor 0 1/16W Metal Oxide VRS-CY1JF000JY R1302 Resistor 1.8k 1/16W Metal Oxide...
  • Page 155 LC-46X8E/S/RU PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [4] DUNTKE187FM03 (TERMINAL Unit) R7505 Resistor 33k 1/16W Metal Oxide VRS-CY1JF333JY R7506 Resistor 68 1/16W Metal Oxide VRS-CY1JF680JY R7508 Resistor 10k 1/16W Metal Oxide VRS-CY1JF103JY R7509 Resistor 8.2k 1/16W Metal Oxide...
  • Page 156 LC-46X8E/S/RU PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [5] DUNTKE188FM01 (MINI AV Unit) D806 Diode 1PS226,115 VHD1PS226++-1Y D810 Diode MA111G VHDMA111G++-1Y D903 Zener Diode PDZ10B,115 RH-EX0265TAZZY D904 Zener Diode PDZ10B,115 RH-EX0265TAZZY D905 Zener Diode PDZ10B,115 RH-EX0265TAZZY FB802 RBLN-0210TAZZY Balun BLN-0210TA...
  • Page 157 LC-46X8E/S/RU PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [5] DUNTKE188FM01 (MINI AV Unit) VA809 Varistor EZAEG2A50AX RH-VXA187WJQZY VA810 Varistor EZAEG2A50AX RH-VXA187WJQZY [6] DUNTKE264FM01 (R/C, LED Unit) C102 Capacitor 2.2 16V Ceramic VCKYTV1CF225ZY C104 Capacitor 10 16V Electrolytic VCEASX1CN106MY C105 Capacitor 0.01 50V Ceramic...
  • Page 158 LC-46X8E/S/RU [8] CABINET PARTS...
  • Page 159 LC-46X8E/S/RU PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [8] CABINET PARTS Front Panel Ass'y CCABAB999WJ12 Front Panel Not Available LED Dec. HDECQA777WJ1A Shine Trim HDECSA033WJ1A Speaker Sheet HPNLSA178WJ1A Cushion, x4 Not Available Mask Himelon Not Available Rear Cabinet Ass'y...
  • Page 160 LC-46X8E/S/RU PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [8] CABINET PARTS Screw (TUNER) XBBS930P04000 Screw, x4 (CAB-B) XBPS740P10JS0 Screw, x2 (HDMI) XBPS830P06000 Screw with Cushion, x4 XEBS840P12000 Screw, x2 (Button/Button Cover) XEBS930P10000 XEBS940P16000 Screw, x6 (CAB-B) Screw, x4 (PNL)
  • Page 161 LC-46X8E/S/RU [9] LCD MODULE Assembly 18-1 18-2 18-3 18-4...
  • Page 162 LC-46X8E/S/RU PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [9] LCD MODULE Assembly Bezel Ass'y CANGKB414WJ01 Bezel Ass'y (PET(Black)) CANGKB414WJ02 Bezel Ass'y, x2 CANGKB415WJ01 LCD Panel Not Available P Chassis Ass'y (Top) CHLDZA988WJ01 P Chassis Ass'y (Bottom) CHLDZA989WJ01 P Chassis Ass'y (Left)
  • Page 163 LC-46X8E/S/RU [11] PACKING PARTS...
  • Page 164 LC-46X8E/S/RU PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [11] PACKING PARTS Packing Case (Top) SPAKCD994WJZZ Packing Case (Bottom) SPAKCD540WJZZ Wrapping Paper SPAKPA711WJZZ Buffer Material SPAKXB821WJZZ Buffer Material (Top C) SPAKXB822WJZZ Buffer Material (Bottom C) SPAKXB823WJZZ Polyethylene Bag SSAKAA009WJZZ Polyethylene Bag...
  • Page 165 LC-46X8E/S/RU...
  • Page 166 LC-46X8E/S/RU COPYRIGHT © 2008 BY SHARP CORPORATION ALL RIGHTS RESERVED. No Part of this publication may be reproduced, stored in a retrieval system, or transmitted in any from or by any means, electronic, mechanical, photocopying, recording, or otherwise, without prior written permission of the publisher.

Table of Contents
