- Page 1 IDD-213T User Manual (Rev. 1.5) Sinocastel Co., Ltd. September, 2014...
-
Page 2: Table Of Contents
IDD-213T User Manual Contents 1. Introduction ..................................2 2. Specifications ................................... 3 2.1 External Interface ..............................3 2.2 Status Indicator ............................... 4 2.3 Technical Parameters ............................5 3. Device Configuration ..............................7 3.1 PC Tool ..................................7 3.2 SMS Instructions ..............................7 4. -
Page 3: Introduction
IDD-213T User Manual 1. Introduction IDD-213T is a plug-and-play GPS tracker with standard OBD II interface, it monitors and records trip info including engine start/off time, real-time location, vehicle speed, various alarms and events, it supports GPRS and SMS channel. -
Page 4: Specifications
IDD-213T User Manual 2. Specifications 2.1 External Interface Product appearance as follows： OBD Connector SOS Button Interface GPS LED USB Interface Cellular LED SIM Card Slot Power/OBD LED 1. Standard OBD Connector Connect to the 16 pin on-board Diagnostic Link Connector (DLC). -
Page 5: Status Indicator
IDD-213T User Manual 2.2 Status Indicator Indicator Color Status OBD LED Solid off Fast blinking (on 0.5s, off 0.5s) - No SIM card or network searching Slow blinking (on 0.5s, off 2.5s) - Registered network Cellular LED Orange-red Solid on - Logged into the server... -
Page 6: Technical Parameters
IDD-213T User Manual 2.3 Technical Parameters Dimension 63mm (L) x 48mm (W) x 28mm (H) Mechanical Weight OBD interface: 16 pin standard OBD II Configuration interface: Mini USB Interface SOS button interface: MMCX SIM card interface: Push-Push Type Storage 2MB FLASH, can store up to 24000 GPS data... - Page 7 IDD-213T User Manual Working -30℃ ~ +70℃ Temperature Storage Environment -40℃ ~ +85℃ Temperature 5%～95%（no frog） Humidity...
-
Page 8: Device Configuration
IDD-213T User Manual 3. Device Configuration 3.1 PC Tool Download USB driver and PC Tool at http://www.sinocastel.com/en/Downloads/. Install the USB driver and PC Tool on your PC. Connect device to PC through USB configuration cable, open the OBD PC Tool, click on “Help->User manual”... - Page 9 IDD-213T User Manual Send SMS *SecretKey#position#*, device will reply *position#http://maps.google.com /?q=latitude,longitude*. e.g.: *123456#position#*http://maps.google.com/?q=22.536934,114.021425*...
-
Page 10: Installation Instruction
IDD-213T User Manual 4. Installation Instruction 4.1 SIM Card Installation 1. Remove the SIM card cover. 2. Insert the SIM card and press gently, a click will be heard upon successfully placing the SIM card in its place, please follow the insertion direction marked on the SIM card cover. -
Page 11: Obd Port
IDD-213T User Manual 4.2 OBD Port In general, the OBD port is located in the driver or passenger cabin, from the edge of dashboard on driver side to the border of 300mm. It is easy to touch by sitting in the driver's seat;... -
Page 12: Device Installation
IDD-213T User Manual 4.3 Device Installation Before installing the device, please make sure device has been configured with necessary parameters including network and other parameters. Park the car and make sure engine is off, align the OBD connector of the device with the engine diagnostic port and simply push in place, ensuring the device is secure. - Page 13 IDD-213T User Manual Some heavy duties may need 9-Pin or 6-Pin deutsch wiring harness. For vehicles do not have an OBD port, please use power cable to connect vehicle battery. Start engine, then device starts acquiring GPS info and GPRS connection. Various status can be indicated by lights and beeps.
- Page 14 IDD-213T User Manual Log into www.livetelematics.com to check real-time monitor and trip reports. Login Vehicle monitoring list Vehicle real time location Vehicle real time status...
-
Page 15: Functions
IDD-213T User Manual 5. Functions 5.1 Location Inquiry Upon receiving location inquiry message from server or via SMS, device reports GPS data immediately. 5.2 Regular GPS data reporting GPS data can be sampled by 3 means: by time interval, by distance or by heading change. -
Page 16: Cell Id Reporting
IDD-213T User Manual 5.4 Cell ID Reporting Device reports Cell ID every 30 seconds when it loses GPS signal, this function is disabled by default. 5.5 GPS Data Reporting in Sleep Mode Device reports GPS data according to configured time interval during sleep. The time interval can be 10-1440min and default setting is 60min. -
Page 17: Intelligent Power Saving
IDD-213T User Manual 5.9 Intelligent Power Saving Device wakes up from sleep on detecting motion state last for 20 seconds, and goes into sleep on detecting static state last for 3 minutes. 5.10 GPS/Cellular Timer GPS and cellular can keep working after ignition off according to configured timer, but no regular reports during this period. -
Page 18: Disclaimer
To make sure the products works well, please use the original accessories. This manual is based on the “as-is” situation. Sinocastel will not guarantee the accuracy, reliability and content of the handbook. Also Sinocastel reserves the right to... -
Page 19: Warranty
If product got quality problem within the warranty period, please bring the product together with a valid warranty card and purchase invoice to the dealer for checking. Please do not disassemble this product, this may result in damage, Sinocastel will not be responsible for those problem. -
Page 20: Statement
Without written permission from Sinocastel, it is prohibited reproduce, transmit, distribute or save part or all of the contents of this document in any form. Sinocastel reserves the rights to modify or improve these products without any prior notification. Sinocastel reserves the rights to change or cancel the content of this document without any prior notification.
