INSTALLATION AND SERVICE INSTRUCTIONS
Keep this booklet for future reference.
The dryer must be fitted by a competent person. In the U.K. Registered Installers undertake to
work to safe and satisfactory standards.
The dryer must be installed in accordance with the Gas Safety (Installation and Use)
Regulations 1998.
Guidance may be obtained from the relevant parts of B.S. 7624: B.S. 5440 parts 1 and 2, B.S.
6891: current editions, I.E.E. Wiring Regulations, and relevant Building Regulations.
Failure to install the appliance correctly could invalidate the warranty liability claims and could
lead to prosecution.
FOR USE IN GREAT BRITAIN AND EIRE WITH NATURAL GAS
ONLY: I
, GAS SUPPLY PRESSURE : 20 mbar.
H
2
THE INSTALLER MUST LEAVE THIS BOOKLET WITH THE
CUSTOMER
Advertisement
Related Manuals for Urban choice UC LOGIC 83AW
Summary of Contents for Urban choice UC LOGIC 83AW
- Page 1 INSTALLATION AND SERVICE INSTRUCTIONS Keep this booklet for future reference. The dryer must be fitted by a competent person. In the U.K. Registered Installers undertake to work to safe and satisfactory standards. The dryer must be installed in accordance with the Gas Safety (Installation and Use) Regulations 1998.
-
Page 2: Table Of Contents
Contents Page Technical Data ..... . 3 Installation ......4 Service instructions . -
Page 3: Technical Data
TECHNICAL DATA CONTROL Type:Pactrol full sequence flame control, P16AGTD(CE) GENERAL 414601. Ignition electrode gap to burner 3 to 4mm Flame failure electrode (4213 078 52641).Height from heater Front loading resistance sensing tumble dryer with gas base to centre of electrode 27.0±0.5mm. heating.Reverse actiondrum tumble.Electroniccontrol. -
Page 4: Installation
INSTALLATION 5 POSITION OF DRYER AND CONNECTIONS 1INSTALLATION The dryer is designed for installation using a flexible gas connection with tubing in accordance with B.S.669. Ensure that the supply gas sizing is adequate. When installing, position the appliance so that the plug is accessible. - Page 5 9 STACKING 6. OPERATIONAL CHECK Instructions for stacking, if required, are supplied 6.1 Remove the pressure test point screw from the gas with the stacking kit. tee connection at the back of the dryer and connect a gas pressure gauge. PROGRAMME 6.2 Check that the dryer timer is in the 'off' position, and The electronic control measures dryness by the electrical...
-
Page 6: Service Instructions
SERVICE INSTRUCTIONS RECOMMENDATIONS FOR DISMANTLING Note:Re-assembly should be done in reverse sequence to these instructions. Terminal Block (28),Control Unit (10),Timer (211), Heat Switch (235),Neon (213),Micro-Switch Assembly (248),Control Panel (353). Withdraw 3 screws from the back flange of the Table Top Assy.(386) and lift and move it rearwards for removal. - Page 7 Withdraw the 3-screws and shakeproof washers (13) Withdraw the 8-screws securing the Back Panel (24) to securing the Flame Tube Assy.(34) to the Cabinet Base. the Cabinet (196).Disengage the T-piece Grommet from Note:On re-assembly the shakeproof washers must be the slot in the Back Panel and lift off. replaced to ensure a good earth connection.
-
Page 8: Fault Finding
Chart 1 - Motor does not run. FAULT FINDING In the event of an electrical fault carry out the preliminary electrical system checks i.e.earth continuity, polarity, and insulation resistance. Use each chart to locate the fault causing the dryer to operate incorrectly as follows: Chart No. - Page 9 Chart 2. Motor runs but full sequence control does not produce With machine ON (30 min) is START ignition spark voltage between output HE on controller and TB-N 230v? Exchange sensing controller, Does gas control spark? Does control spark with high heat selected? Does control spark with low heat selected?
- Page 10 Chart 3. Motor runs Remove plinth 199. Can gas be Start Full Sequence Control lit manually? produces ignition sparks, but gas does not ignite Check spark gap continuity of H.T. lead and electrode not cracked. Does burner light? Whilst control is sparking is voltage at terminal 4 of control unit 230V? Exchange control unit.
- Page 11 Chart 4. Motor runs, gas ignites but stays on for only short period. Before proceeding, ensure polarity of 13 Amp supply socket and earthing is correct Is weight of load suitable? Start Is filter clean? Is vent hose or terminal unobstructed? Is vent terminal unaffected by wind conditions that may...
-
Page 12: Wiring Diagram
/ECO 83A... -
Page 13: Exploded Views
URBAN CHOICE ECO 83A EXPLODED VIEW 1 363a 203a... - Page 14 URBAN CHOICE ECO 83A_ Exploded View 2...
- Page 15 URBAN CHOICE ECO 83A_ EXPLODED VIEW 3...
- Page 16 URBAN CHOICE ECO 83A Exploded View 4 101a...
- Page 17 URBAN CHOICE ECO 83A Exploded View 5...
-
Page 18: Parts List
URBAN CHOICE 83A_ PARTS LIST Item Description Part Number Expl. View Control Unit 4213 092 25451 Control Unit Bracket Assembly 4213 070 08623 Screw M4 x 10 8213 130 37161 2&3 Rear Seal Assembly 4213 092 08511 External Feed Pipe (Bundy Tube Assy 3) - Page 19 URBAN CHOICE 83A_ PARTS LIST Timer Knob Assembly 4213 092 45741 Control Panel Assembly 4213 092 52001 Locator Peg 4213 077 61281 6G*3/8 DP/PWABE/NIBS/TSZPC 8213 130 38051 Hinge Assembly 4213 092 25361 Window 4213 077 4409_ Door Frame 4213 077 92132...
- Page 20 URBAN CHOICE 83A_ PARTS LIST Ring Spring 4213 075 70931 Sensing Strip 4213 075 13152 Sensing Strip Clip 4213 077 41176 Ring Spring Plug 4213 074 81353 M4 Toothed Lockwasher 2522 616 15007 W’ Button (access cover) 4213 078 26311...
