INSTALLATION AND SERVICE INSTRUCTIONS
Keep this booklet for future reference.
The dryer must be fitted by a competent person. In the U.K. Registered Installers undertake to
work to safe and satisfactory standards.
The dryer must be installed in accordance with the Gas Safety (Installation and Use)
Regulations 1998.
Guidance may be obtained from the relevant parts of B.S. 7624: B.S. 5440 parts 1 and 2, B.S.
6891: current editions, I.E.E. Wiring Regulations, and relevant Building Regulations.
Failure to install the appliance correctly could invalidate the warranty liability claims and could
lead to prosecution.
FOR USE IN GREAT BRITAIN AND EIRE WITH NATURAL GAS
ONLY: I
, GAS SUPPLY PRESSURE : 20 mbar.
H
2
THE INSTALLER MUST LEAVE THIS BOOKLET WITH THE
CUSTOMER
Advertisement
Related Manuals for Urban choice ecp 43A
Summary of Contents for Urban choice ecp 43A
- Page 1 INSTALLATION AND SERVICE INSTRUCTIONS Keep this booklet for future reference. The dryer must be fitted by a competent person. In the U.K. Registered Installers undertake to work to safe and satisfactory standards. The dryer must be installed in accordance with the Gas Safety (Installation and Use) Regulations 1998.
-
Page 2: Table Of Contents
Contents Page Technical Data ..... . 3 Installation ......4 Service instructions . -
Page 3: Technical Data
TECHNICAL DATA CONTROL Type:Pactrol full sequence flame control, P16AGTD(CE) GENERAL 414601. Ignition electrode gap to burner 3 to 4mm Flame failure electrode (4213 078 52641).Height from heater Front loading tumble dryer with gas heating. Reverse base to centre of electrode 27.0±0.5mm. action drum tumble.Time control. -
Page 4: Installation
INSTALLATION 5 POSITION OF DRYER AND CONNECTIONS 1INSTALLATION The dryer is designed for installation using a flexible gas connection with tubing in accordance with B.S.669. Ensure that the supply gas sizing is adequate. When installing, position the appliance so that the plug is accessible. - Page 5 9 STACKING 6. OPERATIONAL CHECK Instructions for stacking, if required, are supplied 6.1 Remove the pressure test point screw from the gas with the stacking kit. tee connection at the back of the dryer and connect a gas pressure gauge. PROGRAMME 6.2 Check that the dryer timer is in the 'off' position, and that the heat switch is set to 'high'.
-
Page 6: Service Instructions
SERVICE INSTRUCTIONS RECOMMENDATIONS FOR DISMANTLING Note:Re-assembly should be done in reverse sequence to these instructions. Terminal Block (28),Control Unit (10),Timer (211), Heat Switch (235),Neon (213),Micro-Switch Assembly (248),Control Panel (353). Withdraw 3 screws from the back flange of the Table Top Assy.(386) and lift and move it rearwards for removal. - Page 7 Withdraw the 3-screws and shakeproof washers (13) Withdraw the 8-screws securing the Back Panel (24) to securing the Flame Tube Assy.(34) to the Cabinet Base. the Cabinet (196).Disengage the T-piece Grommet from Note:On re-assembly the shakeproof washers must be the slot in the Back Panel and lift off. replaced to ensure a good earth connection.
-
Page 8: Fault Finding
FAULT FINDING In the event of an electrical fault carry out the preliminary electrical system checks i.e. earth continuity, polarity, and resistance to earth. Use each chart to locate the fault causing the dryer to operate incorrectly as follows: Chart No: 1 Motor does not run. - Page 9 Chart 2. Motor runs but full sequence control does not produce ignition spark With timer ON (30 min) is voltage between output C2 on timer and START TB-N 230v?? Exchange timer. Does control spark? Does control spark with high heat selected? Does control spark with low heat selected?
- Page 10 Chart 3. Motor runs Full Sequence Control produces ignition sparks, but gas does not ignite. Start Remove plinth 199. Can gas be lit manually? Check spark gap continuity of Whilst control is sparking is H.T. lead and electrode not voltage at terminal 4 of control cracked.
- Page 11 Chart 4. Motor runs, gas ignites but stays on for only short period Before proceeding, ensure polarity of 13Amp supply socket and earthing is correct Is weight of load suitable? Is Start filter clean? Is vent hose or terminal unobstructed? Is vent terminal unaffected by wind conditions that may cause back pressure?
-
Page 12: Wiring Diagram
URBAN CHOICE ECO 43A_... -
Page 13: Exploded Views
URBAN CHOICE ECO 43A EXPLODED VIEW 1 249a 249b 363a 203a... - Page 14 URBAN CHOICE ECO 43A EXPLODED VIEW 2 REAR ASSEMBLY VIEWED FROM FRONT...
- Page 15 URBAN CHOICE ECO 43A_ EXPLODED VIEW 3 INTERNALS VIEWED FROM REAR...
- Page 16 URBAN CHOICE ECO 43A_ EXPLODED VIEW 4 INTERNALS VIEWED FROM REAR 101a...
-
Page 17: Exploded View
URBAN CHOICE ECO43A_ Exploded View 5... -
Page 18: Parts List
ECO43A_ PARTS LIST Item Description Part Number Expl. View Control Unit 4213 092 25451 Control Unit Bracket Assembly 4213 070 08623 Screw M4 x 10 8213 130 37161 2,3&5 Rear Seal Assembly 4213 092 08511 External Feed Pipe (Bundy Tube Assy 3) 4213 089 0788_ Gas Inlet Connector 4213 078 49504... - Page 19 ECO43A_ PARTS LIST Exhaust Thermostat 60 Deg C 4213 078 53001 Inlet Thermostat 130 Deg C 4213 092 24161 Electronic Start Assembly 4213 092 46461 Micro Switch Assembly 4213 092 05251 1 & 3 249a Gas Control Relay assembly 4213 092 51871 249b Gas Control Relay assembly 4213 092 51871...
- Page 20 ECO43A_ PARTS LIST Cable Clamp 2 4213 077 47303 Washer M5 Form A 2522 604 60002 M5 Form A Washer 2522 604 60002 Screw 6 x 1/2 2522 165 20004 M4 Hex Nut 2522 402 50001 2 & 5 Screw No 10-24 UNC x 3/8” 8213 130 31051 Motor Retaining Clips 4213 078 4536_...
