- Page 1 Professional slicer CE SSG300PTB mod. Service Manual SERVICE CENTRE AUTHORISED DEALER...
- Page 2 Drawing nr. 5/5 Ref. Descrip on Code SYDNEY KEYPAD CONTR.ASS.Y 19702030 GASKET FOR ROUND CONTROL PANEL 19563034 KEYPAD HOUSING FOR SIDNEY KEYPAD 19563124 ON/OFF DECAL FOR SIDNEY KEYPAD 19420163 S/S BUTTON 19410135.08 S/S BUTTON W/LAMP 19410136.08 620A PRINTED CIRCUIT BOARD 230-110 V 19411102 620B PRINTED CIRCUIT BOARD 400 V...
- Page 3 115 V. ELECTRICAL DIAGRAM - 230V. SINGLE-PHASE - 230V. Drawing nr. 5/5 THREE-PHASE - 400V. THREE-PHASE, PUSH-BUTTON Fig. n°21 115 V. tension selection Single-phase 230 V. tension selection...
- Page 4 Three-phase 230 V. tension selection Drawing nr. 4/5 Ref. Descrip on Code CAPACITOR SL 10UF 19410307 WIRE WAY HOUSING SL 19563127 SUPPORT,TERMINAL BLOCK SL 19541741 644A POWER CORD SUKO PA 205 19410530 644B POWER CORD 3PHASE ITALIANA PA 205 19410536 648A MOTOR 230/50 SL 300 19400107...
-
Page 5: Recommended Spare Parts
Recommended Spare Parts Drawing nr. 4/5 Drawing nr. Ref. SSG300PTB Page 620A Pc board 620B On/Off touch panel Grinding stones (couple) Belt Feet (4x) Plexi hand-guard... - Page 6 Drawing nr. 1/5 Drawing nr. 3/5 Ref. Descrip on Code SHARPENER HOUSING_LNR/PLD 300-385 19511252C SHARPENER KNOB FOR LNR/PLD U 19522653 BUTTON SCREW _ SL 250-370 19335025 DEBURRING PUSH BUTTON SL 19550208 SHARPENER PINS SPRING SL 19390309 DEBURRING PIN SL 330-370 19540709 BUSHING_LNR/PLD U 19540718...
- Page 7 Drawing nr. 3/5 Drawing nr. 1/5 Ref. Descrip on Code BASE/FRAME PLD 300-330-350 19510160 FOOT BUFFER '05 LNR 350-385 19560156.05 FOOT ASSEMBLY '05 LNR 350-385 19522620.05 FOOT SUPPORT PLD 300 19540660 BLADE COVER 300 LNR 195102074 BLADE COVER KNOB 19021110 LOCK NUT 250-330 19530905 SEAL NBR_SLICER PLD 330-350...
- Page 8 Drawing nr. 2/5 Drawing nr. 2/5 Ref. Descrip on Code PLATE SL 19533200 "L" PLATE, CARRIAGE RELEASE 19533260.08 PUSH ROD - 300-385 CE 19565001 CARRIAGE SLIDE PLD 300 19500560 BUSH 22.25.30 19324106 STUD BOLT M8 LNR 19337054 HEX ROD,CARRIAGE RELEASE SL 19534036 CARRIAGE RELEASE SPRING SL 19390601...
