Summary of Contents for Weldex WDR-4011-1TB
- Page 2 WARNING TO REDUCE FIRE OR SHOCK HAZARD, DO NOT EXPOSE THE UNIT TO RAIN OR MOISTURE. The installation should be made by a qualified service person and conformed to all local codes. * This is a brief manual for quick and convenient reference. Please refer to the User Manual contained in CD for details.
-
Page 3: Table Of Contents
Contents 1. Getting Started ……………………………..…………………………. 4 1.1 Checking Supplied Items ………………………………………………………. 4 1.2 User Login ……………………………………………………………………….. 4 1.3 Date/Time Setting and HDD Format ………………………………………….. 5 1.4 Quick Setup ……………………………………………………………………… 5 2. System Operation ………………………………….…………………… 6 2.1 Using Tool Bar …………………………………………………………………… 6 2.2 Using Pop-Up Menu ……………………………………………………………. -
Page 4: Getting Started
1. Getting Started 1.1 Checking Supplied Items Make sure that you have following items supplied with your DVR. If any of these items is missing or damaged, notify your vendor immediately. Quick Manual 1 Piece CD (User Manual & Software) 1 Piece 12V D/C Adaptor &... -
Page 5: Date/Time Setting And Hdd Format
1.3 Date/Time Setting and HDD Format 1) Go to the menu of [TOOL > System > System Info > Date/Tome] and make a proper time/date setting based on your time zone. 2) User has to format new HDD before use. Go to the menu of [TOOL > System > HDD] and select the HDD to format. -
Page 6: System Operation
2. System Operation 2.1 Using Tool Bar Move the mouse cursor to the low part of the screen to open the hidden Tool Bar and click [TOOL] icon. Then, system setting menu such as MENU, SEARCH, BACKUP, USER and SHUTDOWN shows up. Icon on Tool Bar Instant Recording Go to PTZ Mode... -
Page 7: Display Mode
2.3 Display Mode The images can be User can select display mode by using tool bar or pop-up menu. seen on real-time speed by 1, 4, 9, 16 split screen and PIP screen. Icon on Each Channel Screen Icon on Main Screen Continuous Recording No HDD or HDD Failure Motion Recording... -
Page 8: Search And Playback Mode
2.5 Search and Playback Mode User can click the Playback icon on the Tool Bar to playback the latest video clip and search the recorded image by selecting the date & time on calendar. 2.6 Quick Backup Mode User can easily archive video image under playback mode. 1) Press [ENTER] button on the front panel to set “start”... -
Page 9: System Setting
3. System Setting The structure of system setting consists of 6 categories as below. Main Classification Sub Classification SYSTEM INFO USER SYSTEM EXPORT/IMPORT FACTORY DEFAULT CAMERA AUDIO SENSOR DEVICE MOTION ALARM EXTRA ALARM CAMERA RECORD SCHEDULE NETWORK DDNS NETWORK NOTIFICATION BACKUP MANUAL BACKUP QUICK SETUP... -
Page 10: Web Operation By M/S I/E
4. Web Operation by M/S I/E The system is equipped with built-in web server, thus, user can be connected to the system by ordinary web-browser for live monitoring, playback or remote configuration. [Setting in IE Web browser] 1) Input IP address or mac address. (ex, http://00231c381f2d.cctv-link.net.) 2) After downloading Active-X file, login page will show up. -
Page 11: Remote Software
5. Remote Software 5.1 RMS (RemoteManager Software) RMS is the basic remote management software, offering Live Monitoring, VOD Playback with Intelli-Search Bar, Live & VOD Backup and Built-In Backup Player. • 16 Ch Real-Time Monitoring • Remote VOD Playback • Remote Backup (Live & VOD) •... -
Page 12: Mobile Viewer (Wap Connection)
6. Mobile Viewer (WAP Connection) WAP (Wireless Application Protocol) is a system which allows devices such as mobile phones to connect to the Internet. If user wants to connect to the DVR especially under narrow-bandwidth network situation by sing 2G cellular phone, it is recommended to use WAP connection. -
Page 13: Mms (Mobile Viewer By Smart Phone)
7. MMS (Mobile Viewer by Smart Phone) MMS is the mobile viewer software that allows user to view video image from the DVR on the mobile phones. By installing the corresponding MMS software on the mobile phone, user can view live video image through WAP, Wi-Fi or Dial-up Network. 7.1 iPhone MMS software for iPhone is registered at “App Store in USA”, hence you have to get your Apple account registered at same App Store in USA for software download. -
Page 14: Black Berry
7.3 Black Berry 1) Execute MobileViewer after installation on your phone. 2) Select the target site and channel # by using track ball, and then click [LIVE] button. 7.4 Windows Mobile O/S Phone 1) Execute MobileViewer software after installation on your phone. 2) Select the target site from DVR LIST and click [CONNECT] button to get live image. - Page 15 MEMO...
