SAFETY PRECAUTIONS

Before using HDMI-Cloner Box, please ensure that you read and understand the
safety precautions below.
Do not attempt to open the case of HDMI-Cloner Box or modify it in any way, as
this will void the warranty.
Keep HDMI-Cloner Box away from water and other liquids, as this may
cause the unit to malfunction.
HDMI-Cloner Box may become warm during use. This does not indicate
malfunction.
Do not place heavy objects on HDMI-Cloner Box, as this may cause the unit to
overheat and malfunction.
If the exterior of HDMI-Cloner Box requires cleaning, wipe it with a soft
dry cloth.
Do not dispose of the unit via conventional domestic waste.
14
1
2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HDMI Cloner Box and is the answer not in the manual?

Questions and answers

Summary of Contents for Cloner Alliance HDMI Cloner Box

  • Page 1: Safety Precautions

    SAFETY PRECAUTIONS Before using HDMI-Cloner Box, please ensure that you read and understand the safety precautions below. Do not attempt to open the case of HDMI-Cloner Box or modify it in any way, as this will void the warranty. Keep HDMI-Cloner Box away from water and other liquids, as this may cause the unit to malfunction.
  • Page 2: Product Diagram

    PRODUCT DIAGRAM PRODUCT DIAGRAM Power ON/OFF DC input 5V/2A HDMI In* HDMI Out* USB 2.0 port (compatible with USB 3.0) REC/STOP and 720p/1080p button MIC input *Not all games are 1080p...
  • Page 3: Connection Guides

    CONNECTION GUIDES CONNECTION GUIDES PlayStation 3 and PlayStation 4 Make sure the PS3/PS4 video/audio output settings are set up correctly before you begin. Connect the other end of the HDMI cable into HDMI-Cloner Box. Connect HDMI-Cloner Box to TV via HDMI cable.
  • Page 4 CONNECTION GUIDES CONNECTION GUIDES Xbox 360 and Xbox One Connect HDMI-Cloner Box from HDMI out to TV via an HDMI cable. Connect Xbox 360/Xbox One to HDMI in on HDMI-Cloner Box via an HDMI cable. 3. Make sure gameplay is visible on TV screen. XBOX 4.
  • Page 5 CONNECTION GUIDES CONNECTION GUIDES Connect all devices by HDMI cables. Nintendo Wii Make sure gameplay is visible on TV screen. Connect HDD or USB stick to USB port on HDMI-Cloner Box. HDMI HDMI HDMI-Cloner Box...
  • Page 7 CONNECTION GUIDES CONNECTION GUIDES Y our HDMI-Cloner Box can capture any video from any video source/device Set-top box/DVD/Blu-ray player/PC HD video output devices all you need is the right ports/connections! Connect HDMI-Cloner Box to TV via HDMI cable. Connect set-top box, DVD/Blu-ray player, PC or any other device to HDMI-Cloner Box.
  • Page 8 The HDMI-Cloner Box LED lights will illuminate different colours/ways to indicate functions. RECORDING/CAPTURE LED Status Chart How to: LED red POWER ON LED green 1080p/1080i Switch On Power. The button LED will illuminate Blue or Green. LED blue 720p/others Connect a USB storage device to the HDMI-Cloner Box USB port. LED flashing Recording/buffering Prior to gameplay, press...
  • Page 9: Saving Files

    HDMI-Cloner Box SAVING FILES File saving Supported resolutions HDMI-Cloner Box will record a new file when the previous file reaches a capacity Input/output 1920 x 1080 (50p), 1920 x 1080 (60p) of 2GB. 1920 x 1080 (24p), 1920 x 1080 (25p), 1920 x 1080 (30p) When HDD or USB storage is full, HDMI-Cloner Box stops recording and the REC LED 1920 x 1080 (50i), 1920 x 1080 (60i), 1280 x 1024 (60p)
  • Page 10: Product Specifications

    PRODUCT SPECIFICATIONS Microphone Function Capture format MP4 (H.264) For best quality voice recording, please use good quality microphone. Video format (input) NTSC, PAL, PAL-60 To control voice recording, please adjust the volume of HDMI input source. Supported recording format FAT, FAT32, NTFS Input signals HDMI Output signals...
