4CH 2.4G REMOTE CONTROL QUADCOPTER
1
INSTRUCTION MANUAL
IMPLEMENT STANDARD: GB/T26701-2011
Main characteristics
Four-axis structure is applied,which makes the quadcopter more flexible and rapid
when flying.It has the characteristics of wind-resistant and can be flied indoor or
outdoor.
Built-in 6 axis gyroscope for precise hovering in the sky.
Modular design structure is applied, more simple for assembly and convenient for
maintenance.
With 360°3D eversion function and throwing flight function .
The materials and specification mentioned in this instruction manual or the parts
inside this package is for reference only.Our company won't be responsible for any
adaption of the outer package.Nor shall we keep our customers informed in advance.
Any information updates or changes,please be subject to our website .
12
AGES 14+

Advertisement

Table of Contents
loading

Related Manuals for SYMA X12 gyroscope explorers

Summary of Contents for SYMA X12 gyroscope explorers

  • Page 1 AGES 14+ 4CH 2.4G REMOTE CONTROL QUADCOPTER INSTRUCTION MANUAL IMPLEMENT STANDARD: GB/T26701-2011 Main characteristics Four-axis structure is applied,which makes the quadcopter more flexible and rapid when flying.It has the characteristics of wind-resistant and can be flied indoor or outdoor. Built-in 6 axis gyroscope for precise hovering in the sky. Modular design structure is applied, more simple for assembly and convenient for maintenance.

  • Page 2: Important Instruction

    PREFACE Dear customers: Hello! Thank you for purchasing our flying model.Please read this instruction manual carefully in order to master the skill required quickly and operate this product more safely.In the mean time, please well keep the original of this instruction manual for future reference.

  • Page 3: Contents

    ABOUT CONTENTS Product included following contents: Quadcopter 2.4G Remote controller USB charging wire Instruction manual Screwdriver Blade(4 pieces) Remote control Installing Introduction of transmitter the battery Battery Cover Forward and backward trimmer READY TO FLY YOUR QUAD COPTER Step 2:Turn on the quadcopter button, Step 1: First of all, press and place the quadcopter on the ON/OFF power switch.

  • Page 4: Functions Mode Switch

    Step 3: Push the throttle lever to the highest position and then pull it back to the lowest position,this time there will be one clear sound sending out from the transmitter,this shows that the quad copter has entered into the pre-fly state. TIPS: When matching signal, keep the quad copter on horizontal position to fast matching and start a stable...

  • Page 5: Controlling The Quad Copter

    ILLUSTRATION ON CONTROLLING THE QUAD COPTER (MODE 1, DEFAULTED MODE WHEN STARTING) Operating direction Push the throttle up or down, the quadcopter Fine-tuning operation flies upward or downward. Push the direction lever up or down,the quadcopter flies forward or backward. Pull the direction lever left or right,the quadcopter flies to left side or right side.
  • Page 6 ILLUSTRATION ON HOW TO CONTROL THE QUAD COPTER (MODE 2) Operating direction Push the throttle up or down, the quadcopter Fine-tuning operation flies upward or downward. Push the direction lever up or down,the quadcopter flies forward or backward. Pull the direction lever left or right,the quadcopter flies to left side or right side.

  • Page 7: Flight Control

    FLIGHT CONTROL Low Speed: Press the High/Low speed switch for one time, the buzz will send out one sound. High Speed: Please press High/Low speed switch once again, the buzz will send out two sounds. 3D EVERSION AND THROWING FLIGHT INSTRUCTIONS 1.When you are familiar with the basic operation, you can play some...

  • Page 8: Battery Charging

    BATTERY CHARGING Battery charging Take out the USB charging wire, connect one end to the quad copter, then insert the USB port of the USB charging wire to the USB port of the computer (or the USB port of the power adapter) to charge the battery.During the time of charging, the red indicator of the USB will be OFF.

  • Page 9: Troubleshooting

    BATTERY REPAIR & MAINTENANCE 1. Battery should be put in the dried or ventilated place with environment temperature about 18-25 ℃. 2.In order to enhance the using life of the battery, please avoid repeat charging or excessive discharging. 3.When the battery needs to be stored for a long time, please charge the battery first.That is to say, charge the battery for about 50-60% of the volume and then well store it.
  • Page 10 X12-02 X12-03 X12-04 X12-05 Blades Motor A Motor B Circuit board X12-06 X12-07 X12-08 X12-09 Battery Soft mat Transm...
  • Page 11 Code Description Code Description Code Description Quantity Quantity Quantity Battery Soft mat Circuit board ７０ｍｍ ７０ｍｍ ７０ｍｍ ４５ｍｍ 3.7V/100mAh ２７ｍｍ The company has the right of final interpretation of this instruction manual statement. -10-...
