VOIspeed V-AT800 User Manual

Ip headsets
Hide thumbs
1
2
3
4
5

Advertisement

Table of Contents

DEVICE OVERVIEW
The V-AT800DP is particularly suitable for call centres and other areas where there is heavy use of the
telephone, and at the same time a requirement for PC access, as the device works as an IP adapter for
mono and binaural headsets.
Keypad description
1 LED Indicator
2 Navigation Keys
3 Mute key
4 1~9,*#
5 LCD Display
6 Software function keys
6 Menu key
7 Headset Key
Reply to call
Close call
8 Login key
9 Programmable keys
USER GUIDE VOISPEED V-AT800 IP Headsets
Flashes when a call arrives
With these you can move the cursor up and down on the menu, adjust the
volume of the headset during a converstation and adjust the volume of the ring
tone (when there is no active converstation).
Mute function for the microphone (close/ open)
Number/ symbol keys
Telephone display: show the date/time, your own extension number and, if
available, that of the calling party, the line status and the function keys.
Configurable function keys
(Fourth key on the right) To enter the adapter's configuration
When pressed at rest, it has the same function as lifting of the handset to make a
call. For an incoming call you can press the key to accept the call. If pressed
during a conversation, however, it will end the call.
Manual function for login/logout of the device (not used with VOIspeed 6). If the
user is logged out the button is turned off, otherwise it will remain turned on. A
flashing light meanwhile indicates that the LAN network is disconnected (only in
the case where the device is powered by an external power supply)
Function keys that the user can programme.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the V-AT800 and is the answer not in the manual?

Questions and answers

Related Manuals for VOIspeed V-AT800

Summary of Contents for VOIspeed V-AT800

  • Page 1 8 Login key Manual function for login/logout of the device (not used with VOIspeed 6). If the user is logged out the button is turned off, otherwise it will remain turned on. A...

  • Page 2: Connect The Headset

    LED Status Indicators Login Indicator (Connection of the device to the PBX) LED Status Description Red / Flashing LAN Disconnected SIP Not Registered SIP Registered Mute Indicator (Microphone silencer) LED Status Description Microphone off Microphone on LED Indicator LED Status Description Red / Flashing Incoming call (ring)

  • Page 3: Forward A Call

    Alternatively, you can forward a call, even in the middle of a call, via one of the 4 programmable function keys (see figure 9), provided they have been properly programmed (please refer to the V-AT800 Configuration Manual).

  • Page 4: Redial Number

    Durin the conversation press Bxfer • Dial the number of the extension you require and press Dial • REDIAL NUMBER To redial a number you have already dialed: Press Redial and select the number required from the list using the navigation keys •...

  • Page 5: Programmable Keys

    PROGRAMMABLE KEYS The adapter has 4 programmable keys. Each of these can be programmed in the following modes, supported by VOIspeed 6: Hold: puts on hold and resumes the current call • Xfer: initiates the procedure for call forwarding with supervision •...
