AGA "CHILLBUSTER MAGNUM"
Assembly, Installation, and Operation Instructions for Rasmussen
Chillbuster Magnum (M-1, M-2) Manual, Switch, or Remote Control,
Natural or Propane Gas Log Room Heater Models:
18" or 24" SINGLE BURNER Manual Control (CM)(18, 24)-M1A-M-(N,P)
18" or 24" SINGLE BURNER Switch Control (CM)(18, 24)-M1A-S-(N,P)
18" or 24" SINGLE BURNER Remote Control (CM)(18, 24)-M1A-R-(N,P)
30" SINGLE BURNER Manual Control (CM)(30)-M1B-M-(N,P)
30" SINGLE BURNER Switch Control (CM)(30)-M1B-S-(N,P)
30" SINGLE BURNER Remote Control (CM)(30)-M1B-R-(N,P)
18" DUAL BURNER Manual Control (CM)(18 )-M2A-M-(N,P)
18" DUAL BURNER Switch Control (CM)(18 )-M2A-S-(N,P)
18" DUAL BURNER Remote Control (CM)(18 )-M2A-R-(N,P)
24" or 30" DUAL BURNER Manual Control (CM)(24, 30)-M2B-M-(N,P)
24" or 30" DUAL BURNER Switch Control (CM)(24, 30)-M2B-S-(N,P)
THESE GAS LOG HEATERS ARE CERTIFIED TO THE FOLLOWING STANDARDS:
UNVENTED ROOM HEATER ANSI Z21.11.2a 2001
VENTED DECORATIVE APPLIANCE ANSI Z21.60b 2001 * CGA 2.26b-2001
Read these Instructions carefully and retain them for future use.
WARNING: Improper installation, adjustment, alteration, service or maintenance can
cause property damage, personal injury or loss of life. Read these instructions thoroughly
before installation. For assistance or additional information, consult your gas log dealer,
Design certified for installation only in a solid-fuel burning masonry or UL 127 factory-built fireplace or
in a listed ventless firebox enclosure. DO NOT install this appliance in a factory-built fireplace that
includes instructions stating it has not been tested or should not be used with unvented gas logs.
Do not use this CHILLBUSTER as a Vent Free Heater in sleeping quarters, bathrooms or
WARNING: If the information in this manual is not followed exactly, a fire or explosion
may result causing property damage, personal injury or loss of life
This appliance may be installed in an after
market,
permanently
manufactured (mobile) home, where not
prohibited by local codes.
This appliance is for use with the type of
gas indicated on the rating plate. This
appliance is not convertible for use with
other gases.
FOR YOUR SAFETY: Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other appliance.
Installation and service must be performed by a qualified installer, service
This is an unvented gas-fired heater. It uses air (oxygen) from the room in which it is
installed. Provisions for adequate combustion and ventilation air must be provided.
Refer to Section "PROVISIONS FOR ADEQUATE COMBUSTION AND VENTILATION
AIR" (pages 4 and 5.)
E-Mail: gaslogs@riwinc.com Web http://www.riwinc.com
qualified installer, service agency or gas supplier.
recreational vehicles.
located,
agency or the gas supplier.
.
12028 E. Philadelphia St. Whittier , CA 90601 U.S.A.
(562) 696-8718
WHAT TO DO IF YOU SMELL GAS
Do not try to light any appliance.
Do not touch any electrical switch; do
not use any phone in your building.
Immediately call your gas supplier from
a neighbors phone. Follow the gas
supplier's instructions.
If you cannot reach your gas supplier,
call the fire department.
1
FAX (562) 698-3510
.
FORM M-CB 3-03
.
.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Chillbuster Magnum Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Rasmussen Chillbuster Magnum Series

  • Page 1 (562) 696-8718 FAX (562) 698-3510 E-Mail: gaslogs@riwinc.com Web http://www.riwinc.com Assembly, Installation, and Operation Instructions for Rasmussen Chillbuster Magnum (M-1, M-2) Manual, Switch, or Remote Control, Natural or Propane Gas Log Room Heater Models: 18" or 24" SINGLE BURNER Manual Control (CM)(18, 24)-M1A-M-(N,P) 18"...
  • Page 2 ALL APPLICATIONS (Installation) ALL APPLICATIONS-IMPORTANT NOTICE • Children and adults should be alerted to the hazard of high surface temperature and should stay away to avoid burns or clothing ignition. • Young children should be carefully supervised when they are in the same room with the appliance. •...
  • Page 3 ALL APPLICATIONS (Installation) Fireplace/Firebox Sizing (VENTED and VENT-FREE): 1. The minimum size (in inches) of the fireplace in which this CHILLBUSTER is to be installed must be as follows: S E T MODEL FRONT SIZE NUMBER WIDTH HEIGHT D E P T H (CM)(18)-M1A-(M, S, R)-(N,P) 33,000 BTU/HR (CM)(24)-M1A-(M, S, R)-(N,P) 33,000 BTU/HR (CM)(30)-M1B-(M, S, R)-(N,P) 33,000 BTU/HR...
  • Page 4 VENT-FREE APPLICATIONS (Additional Requirements) 1. Do not use this CHILLBUSTER as a Vent Free Heater in sleeping quarters, bathrooms or recreational vehicles. 2. When operated as a VENT FREE heater, the minimum clearances from the fireplace opening to combustible materials must be maintained as outlined in section "CLEARANCES TO COMBUSTIBLES" (page 6). 3.
  • Page 5 VENT-FREE APPLICATIONS (Additional Requirements) COMBUSTION AIR CALCULATIONS WORKSHEET H=Vol. (ft 3 ) 1 . Room Width Length Height 1 a . 1 b . 1 c . 1 d . 2 . Total Volume (ft 3 )sum of Volume (ft 3 ) of all rooms (sum lines 1a.
  • Page 6 VENT FREE OPERATION Fireplace Hoods (VENT-FREE) A fireplace hood deflects heat away from the fireplace face and mantel, reducing the potential for heat related warping or discoloration. The use of a fireplace hood is highly recommended. Fireplace Hoods are offered by many leading fireplace manufacturers.
  • Page 7: Log Placement

    ALL APPLICATIONS (VENTED and VENT FREE OPERATION) Ember Material Preparation And Placement (Models C2A and C2B): 1. Prepare the ember material by Figure 5 Ember pulling apart into loose pieces (not Material tight clumps) the size of a dime. S e e Figure 5.
  • Page 8: Lighting And Operation

    Port 5. Slowly turn knob to “ON ”. The rear burner will light from the pilot. The Manufactured by: Rasmussen front burner will light from the carry-over tube. Whittier, CA USA If appliance fails to light or if pilot goes out, repeat steps 1 through 5 .
  • Page 9 ALL APPLICATIONS (VENTED and VENT FREE OPERATION) M1A-S/R, M1B-S/R, M2A-S/R, M2B-S/R (SWITCH or REMOTE CONTROL Cont.) Ultrasonic Remote Control (Manual or Remote ON-OFF) Manual: Switch from OFF to SWITCH ON; SWITCH ON to OFF Before you start: Both the transmitter and receiver require 9 volt batteries Remote: Switch to to operate in remote control.
  • Page 10 Additionally, firebox walls and damper must also be thoroughly cleaned of all burn residue and soot using a damp cloth, sponge or brush. • Do not operate this set with any logs other than the RASMUSSEN CHILLBUSTER Refractory Logs specifically designed and approved for use with this Burner System.
  • Page 11 PARTS LIST: M1A-M, M1A-S/2, M1B-M, M1B-S/R, M2A-M, M2A-S/R, M2B-M, M2B-S/R 5 0 . 5 1 . 5 3 . 5 2 . 5 4 . 1 2 . 4 2 . 4 0 . 3 0 . 1 1 . 4 3 .
  • Page 12 Gas Log Set and accessories against defects in above. materials and workmanship, and suitable for a particular (2) RASMUSSEN shall not be liable for any loss, purpose, for a period of: damage, incidental or consequential damages of any kind, whether based upon warranty, contract, or...
  • Page 13 CPW-CB-2-96...
  • Page 14 CHANGES (next) page 1: standard update z21.11.2a 2001 DUE 4-03; standard update z21.11.2b 2002 DUE 12-03 Title change: Customer Responsibilities And Annual Maintenance page 10 next z21.11 update due 3-03...
