GENERAL INSTALLATION INSTRUCTIONS
ASSEMBLY, INSTALLATION, AND OPERATION INSTRUCTIONS FOR RASMUSSEN
CXF for use with Natural Gas; CXFA for use with Propane (LP) Gas
IMPORTANT
WARNING:
Improper installation,
alteration, service or maintenance can cause
injury or property damage. Read these
instructions thoroughly before installation.
For assistance or additional information, consult
your gas log dealer, qualified installer, service
agency or gas supplier.
FOR YOUR SAFETY
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
THIS GAS LOG SET MUST BE INSTALLED IN A FULLY VENTED SOLID-FUEL BURNING
FIREPLACE WITH A WORKING FLUE CONSTRUCTED OF NON COMBUSTIBLE MATERIAL.
The minimum permanent free opening of the fireplace chimney or chimney damper must be at least the minimum
Chimney Area shown below, based on a minimum chimney height of at least 8 feet. The area of the flue must not be less
than 1/10 the area of the fireplace opening. The flue must exhaust all products of combustion.
The chimney damper must be fixed in a manner to maintain permanent free opening as outlined above at all times. To
accomplish this, install the damper clamp (provided) on the edge of the damper blade to prevent its closing, drill a hole or
holes in the damper, or remove damper completely.
The minimum size of the fireplace in which the log set is to be installed must be as follows:
Model/Set Size
HEIGHT
CXF12 - 12 INCH
CXF15 - 15 INCH
CXF18 - 18 INCH
CXF21 - 21 INCH
CXF24 - 24 INCH
CXF30 - 30 INCH
CXF36 - 36 INCH
Glass doors must be wide open when burner is lighted
to allow air for safe combustion, venting and cooling of valves.
Custom Embers Pan Burner
VENTED CUSTOM EMBERS PAN BURNER MODELS:
IMPORTANT INFORMATION
MINIMUM FIREPLACE SIZE IN INCHES
DEPTH
REAR WIDTH
16
12
16
12
16
14
16
14
16
14
16
14
18
16
12028 E. Philadelphia St. Whittier , CA 90601 U.S.A.
(562) 696-8718
gaslogs@rasmussen.biz
READ THESE INSTRUCTIONS CAREFULLY BEFORE
STARTING INSTALLATION OF LOG SET.
FOR YOUR SAFETY
WHAT TO DO IF YOU SMELL GAS
•
Do not try to light any appliance.
•
Do not touch any electrical switch; do not use
any phone in your building.
•
Immediately call your gas supplier from a
neighbors phone. Follow the gas suppliers
instructions.
•
If you cannot reach your gas supplier, call the
fire department.
FRONT WIDTH
12
15
18
.
21
24
30
36
FAX (562) 698-3510
www.rasmussen.biz
GAS PIPING
16
½" i.d.
20
½" i.d.
24
½" i.d.
27
½" i.d.
32
½" i.d
38
½" i.d
44
½" i.d
CXF-705
CHIMNEY AREA
6 INCH DIAMETER
7 INCH DIAMETER
7 INCH DIAMETER
8 INCH DIAMETER
8 INCH DIAMETER
9 INCH DIAMETER
10 INCH DIAMETER
.
Advertisement
Table of Contents
Related Manuals for Rasmussen CXF12
Summary of Contents for Rasmussen CXF12
-
Page 1: General Installation Instructions
FAX (562) 698-3510 gaslogs@rasmussen.biz www.rasmussen.biz GENERAL INSTALLATION INSTRUCTIONS ASSEMBLY, INSTALLATION, AND OPERATION INSTRUCTIONS FOR RASMUSSEN VENTED CUSTOM EMBERS PAN BURNER MODELS: CXF for use with Natural Gas; CXFA for use with Propane (LP) Gas READ THESE INSTRUCTIONS CAREFULLY BEFORE IMPORTANT STARTING INSTALLATION OF LOG SET. - Page 2 THIS BURNER IS FOR USE IN FULLY FUNCTIONING WOOD BURNING FIREPLACE WITH THE DAMPER WIDE OPEN. THE FLUE MUST VENT ALL PRODUCTS OF COMBUSTION. IMPORTANT INFORMATION (continued) A fireplace screen must be in place when the log set is in The gas log set and its individual shutoff valve must be operation and, unless other provisions for combustion air disconnected from the gas supply piping system during...
- Page 3 WARNING! CHECK FOR PROPER VENTING A properly sized, unobstructed chimney will normally vent all fumes and products of combustion. Any odor, smoke or soot detected inside the room is an indication that the flue is not properly removing the combustion products. SHUT OFF THE BURNER IMMEDIATELY! THE CAUSE OF THE VENTING PROBLEM MUST BE DISCOVERED AND CORRECTED BEFORE CONTINUED USE OF THE GAS LOG SET.
- Page 4 Standard Match Lighted • (For use only with Natural Gas Models CXF) WARNING: A SAFETY PILOT CONTROL Figure 2 MUST BE INSTALLED ON ALL UNITS DESIGNED OR CONVERTED TO BURN PROPANE/LP GAS Apply pipe compound to threaded end of 3/8" FLARED BRASS ELBOW (A).
- Page 5 WARNING: DO NOT FLAME TEST FOR LEAKS. STEP FOUR: White Sand, Black Volcanic Ash and Ember Magic Placement. Completely fill BURNER PAN, including underneath BAFFLE PLATE, with appropriate PAN MEDIUM. The WHITE SAND is for use with Natural Gas, the BLACK VOLCANIC ASH is for use with Propane/LP Gas.
-
Page 6: Parts List
THIS BURNER IS FOR USE FOR USE IN A FULLY FUNCTIONING WOOD BURNING FIREPLACE WITH THE DAMPER WIDE OPEN. THE FLUE MUST VENT ALL PRODUCTS OF COMBUSTION. Your Gas Log Set is designed to burn with a natural smoky yellow flame that produces carbon soot. Like a wood fire, burning a gas log set with the flue undersized, blocked or closed will cause fumes, smoke and soot to enter into the living space, which may be harmful to health and property. - Page 7 Whittier California, U.S.A., warrants this Gas Log Set and accessories against defects in materials and workmanship, and (2) RASMUSSEN shall not be liable for any loss, damage, suitable for a particular purpose, for a period of: incidental or consequential damages of any kind, whether based...
