qpcom qp-3014 User Manual

With 4 ports lan and 1 wan
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User's Manual
QP-3014
Broadband Router
with 4 Ports LAN and 1 WAN
www.qpcom.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the qp-3014 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for qpcom qp-3014

Summary of Contents for qpcom qp-3014

  • Page 1 User’s Manual QP-3014 Broadband Router with 4 Ports LAN and 1 WAN www.qpcom.com...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1. Software Installation and Configuration................1 1.1 Configuring the IP Sharing....................1 1.2 Connecting to the IP Sharing................... 1 1.3 Getting IP Automatically....................1 1.4 Setting IP Address Manually................... 2 1.5 Installing the Utilities of IP Sharing ................2 1.5.1 Step-by-Step Installation: ..................

  • Page 3: Software Installation And Configuration

    1. Software Installation and Configuration 1.1 Configuring the IP Sharing The IP sharing can be configured to meet various usage conditions. Some of the factory default settings may suit your usage; however, the other settings may need changing. Before using the IP sharing, you may check the basic settings to guarantee that it will work in your environment.

  • Page 4: Setting Ip Address Manually

    1.4 Setting IP Address Manually If you want to set your IP address manually, you should know the following default settings of the IP Sharing: IP Address: 192.68.1.1 (Default) Subnet Mask: 255.255.255.0 If you set your computer’s IP address manually, the address must be on the same segment.
  • Page 5 (2) Click “Next”. (3) After reading and accepting the License Agreement, Click “Next. (4) Input a user name and organization as information and click “Next”.

  • Page 6: Installing Winpcap

    (5) A default destination folder and user information appear. Click “Install”. (6) The IP SHARING software installation is finished. Click “Finish”. (After installation, a shortcut of ”IP Sharing” will appear on desktop.) 1.5.1.2 Installing WinPcap (1) After installation of the software, a WinPcap 3.1 beta3 InstallShield wizard appears immediately.
  • Page 7 (2) After reading and accepting the License Agreement, Click “Next. (3) Read Readme information and Click “Next. (4) After installation, reboot your PC. (Recommnded)

  • Page 8: Configuring The Ip Sharing

    Note: You must connect the WAN port of the IP Sharing to your ADSL or Cable modem using a network cable. When your PC is rebooted, the power of IP sharing must be turned ON in ready state. 1.5.1.3 Configuring the IP Sharing Executing IP SHARING Setup If there is any firewall function enabled in your PC, please disable the function before executing IP SHARING Setup.

  • Page 9: Administration Interface

    1. Select a network interface card (NIC). 2. Input the IP Sharing’s address (192.168.1.1). (If your computer’s IP address is the on the same subnet as the IP Sharing (192.168.1.x), you will not connect to Internet.) The IP address can be any number from 2 to 254 that is not used by any device.
  • Page 10 Setting Your Own Password You are given a default password. However, in consideration of safety, it is recommended that you set your own password. If you forget the password, click “Reset” on the interface to recover to the default settings.

  • Page 11: Description Of Administration Interface

    2. Description of Administration Interface Factory Default Settings Addresses of LAN and WAN Ports The parameters of LAN are factory defaults. The defaults are as follows: LAN Port IP Address: 192.168.1.1 Subnet Mask: 255.255.255.0 DHCP Server Function: enabled IP Address Configured to PC: any of the addresses extended from 192.168.1.2 to 192.168.1.254 (total 253 addresses) WAN Port If you enable the DHCP Client function, ISP (Internet Service Provider) may...
  • Page 12 Static Mode (Addresses Given by ISP) Name IP Address Global Address Give Ex. 203.66.81.201 by ISP Subnet Mask Addres Ex. 255.255.255.0 Gateway Address Ex. 203.66.81.254 DNS Address Ex. 203.66.81.251 After successfully logging in, you will enter a main menu soon. There are two major setup items on the main menu, “Quick Setup”...

  • Page 13: Quick Setup

    2.1 Quick Setup This item provides a user-friendly setup procedure and users follow only several steps to complete the work. Three setup items are provided on Quick Setup, shown as follows. 2.1.1 Dynamic IP Setup ISP gives a dynamic IP to access Internet. You can use this mode to get a dynamic IP address the DHCP from ISP.

  • Page 14: Static Ip Configuration

    The option is enabled as default. Start IP: You can set up the DHCP server in the blank of LAN configuration, a first address configured in the list. End IP: You can set up the DHCP server in the blank of LAN configuration, a last address configured in the list.

  • Page 15: Lan Configuration

    DNS IP: (given by your ISP) Flow Control: to control packet flow for smooth network traffic WAN Packet Tag-aware: to allow the packets sent from WAN to be attached with Tag- VID (Virtual IDentifier) If you enable this option, the packets sent from WAN will have Tag-VID;...

  • Page 16: Pppoe Configuration

    Start IP: You can set up the DHCP server in the blank of LAN configuration, a first address configured in the list. End IP: You can set up the DHCP server in the blank of LAN configuration, a last address configured in the list. Broadcast Storm: When a large number of broadcast packets are sent, network traffic jam will occur so as affect the bandwidth.

  • Page 17: Lan Configuration

    Password: (given by ISP) The Characters you input in length cannot be more than 20 characters. Confirm: input the password again for confirmation. MTU: input data for a proper MTU (1492 is a default/maximum.) Reducing the packet length helps you to enter a specific website or speed up packet transmission. However, if you input wrong data, you may not enter some websites.
  • Page 18 address. If you enable the option, DHCP will automatically distribute any IP address to your PC. (The IP Sharing is provided with a DHCP server for the LAN PC to get IP automatically, and thus each PC is not required to record and set its IP address.) (The option is enabled as default.) Start IP: You can set up the DHCP server in the blank of LAN configuration, a first address configured in the list.

  • Page 19: Advanced Setup

    2.2 Advanced Setup A further setup items are provided, such as Fire Wall, Virtual Server, Port Forwarding and the like. System Status If you want to know the network connection status, you can click “Advanced Setup” or “Status” at the left side of the interface. 2.2.1 LAN: (See “Quick Setup”) 2.2.2 WAN Configuration...

  • Page 20: Dhcp Configuration

    2.2.2.1 DHCP Configuration WAN MAC Address: a MAC Address of WAN Broadcast Storm: When a large number of broadcast packets are sent, network traffic jam will occur so as affect the bandwidth. If you enable this function, the broadcast packet flow can be controlled for smooth network traffic. Flow Control: to control packet flow for smooth network traffic WAN Packet Tag-aware: to allow the packets sent from WAN to be attached with Tag- VID (Virtual IDentifier).

  • Page 21: Pppoe Configuration

    DNS IP: (given by your ISP) Flow Control: to control packet flow for smooth network traffic WAN Packet Tag-aware: to allow the packets sent from WAN to be attached with Tag- VID (Virtual IDentifier) If you enable this option, the packets sent from WAN will have Tag-VID;...

  • Page 22: Firewall Configuration

    Confirm: input the password again for confirmation. MTU: input data for a proper MTU (1492 is a default/maximum.) Reducing the packet length helps you to enter a specific website or speed up packet transmission. However, if you input wrong data, you may not enter some websites. Disconnect: to allow you to set an automatic disconnection time after the network leaves unused.

  • Page 23: Nat Configuration

    Other Setting Enable Filtering Ping Packet: When this function is enabled, ping packets can be filtered. Enable Forwarding Multicast: When this function is enabled, packets can be sent from WAN. Drop MAC: When this function is enabled, specific MAC address packets can be dropped.

  • Page 24: Password

    Port: to allow you to input a communication port number. If a destination communication port for packets received is exactly the connection port, the received packets will be re-sent to an IP address specified in LAN IP. Protocol: Communication protocol types are shown in the blank. Refresh: recover to all the defaults.

  • Page 25: Reset

    2.2.6 Reset You can use “Reset” in “Advanced Setup” to recover to the factory default settings. When you click this item, you will see a prompt menu and you can determine the reset or not on this prompt menu. 2.2.7 Exit If you want to exit from this administration interface, click the leftward “Exit”...

  • Page 26: Language

    2.2.8 Language This tool provides 3 language interfaces, English, Traditional Chinese, and Simplified Chinese. You can select a language you want.
