Manzano Laser Works Junkers Ju 88 Assembly Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Specifications
Wingspan: 49.75 inches
Area: 339 square inches
Length: 36.12 inches
Power: 2x BP21 Brushless
2x Speed-400
Copyright 2007 Thomas A. Jacoby and WarbirdKits.com
Junkers Ju 88
Junkers Ju 88
Junkers Ju 88
Junkers Ju 88
Manual Version 1.2 – 13 March 2008

Advertisement

loading
Need help?

Need help?

Do you have a question about the Junkers Ju 88 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Manzano Laser Works Junkers Ju 88

Summary of Contents for Manzano Laser Works Junkers Ju 88

  • Page 1 Junkers Ju 88 Junkers Ju 88 Junkers Ju 88 Junkers Ju 88 Manual Version 1.2 – 13 March 2008 Specifications Wingspan: 49.75 inches Area: 339 square inches Length: 36.12 inches Power: 2x BP21 Brushless 2x Speed-400 Copyright 2007 Thomas A. Jacoby and WarbirdKits.com...
  • Page 2 Assembly Manual for Junkers Ju 88 NOTE: We recommend that you read this entire Materials manual before beginning construction. This kit contains the following materials: Construction This construction manual Plan sheet Wings Decal sheet Assemble the wing skins. The easy way to do this is Laser-cut wood pack tape them together on the “good”...
  • Page 3 Assembly Manual for Junkers Ju 88 thru W11) attached to the sheet for now. Also remove spars W12 thru W14 from the sheets. Trial-fit the wing ribs to the spars. Place the assembled ribs and spars on the skin and align with the etched lines. Glue the ribs to the bottom skin.
  • Page 4 Assembly Manual for Junkers Ju 88 Nacelles Tape the nacelle plans to your building board and cover with wax paper. NOTE that the nacelle plans show the nacelles from the bottom looking up! Also NOTE that the nacelle parts are lettered with an “R” or an “L” to designate their use on either the right or left nacelle.
  • Page 5 Assembly Manual for Junkers Ju 88 Glue 1/8” square balsa stringers in place between N1 Glue the upper portions of N1, N2 and N3 to the and N6. nacelle bottom. Add a 1/8 square balsa stringer between N1 and N3.
  • Page 6 Assembly Manual for Junkers Ju 88 Place a magnet over each of the two magnets Cowlings in the firewall. Put one or two drops of epoxy in the magnet holes on the cowl mount. Place the cowl mount over the magnets so that the magnets are in the magnet holes.
  • Page 7 Assembly Manual for Junkers Ju 88 NOTE: Formers F3, F3A, F4, F5, F5A, F6 and F6a must be Fuselage perpendicular to the fuselage! Begin with the right side. Carefully align FRS1 and Trial fit former F3. Bevel the upper edge of F3 to match FRS2, and pin them to your building board –...
  • Page 8 Assembly Manual for Junkers Ju 88 Using 3/32 balsa, plank the fuselage top and bottom Glue the lower fuselage cutout to the wing. Cut out a from F3 to the tail. The grain of the planking should be hole for access to the mounting bolt.
  • Page 9 Assembly Manual for Junkers Ju 88 Glue the horizontal stabilizer into the slot in the thoroughly cover the ink; this will prevent smears and fuselage. stains during everyday handling. Glue a piece of scrap 3/16 balsa filler into the fuselage Make sure the surface where the decal is to be applied slot behind the horizontal stabilizer.
  • Page 10 Assembly Manual for Junkers Ju 88 Parts Layout 1/16” Balsa Copyright 2007 Thomas A. Jacoby and WarbirdKits.com...
  • Page 11 Assembly Manual for Junkers Ju 88 Copyright 2007 Thomas A. Jacoby and WarbirdKits.com...
  • Page 12 Assembly Manual for Junkers Ju 88 3/32” Balsa Copyright 2007 Thomas A. Jacoby and WarbirdKits.com...
  • Page 13 Assembly Manual for Junkers Ju 88 Copyright 2007 Thomas A. Jacoby and WarbirdKits.com...
  • Page 14 Assembly Manual for Junkers Ju 88 1/8” Balsa Copyright 2007 Thomas A. Jacoby and WarbirdKits.com...
  • Page 15 Assembly Manual for Junkers Ju 88 Battery Tray 3/16” Balsa Copyright 2007 Thomas A. Jacoby and WarbirdKits.com...
  • Page 16 Assembly Manual for Junkers Ju 88 1/4” Balsa Gondola Parts Copyright 2007 Thomas A. Jacoby and WarbirdKits.com...
  • Page 17 Assembly Manual for Junkers Ju 88 1/16” Plywood Optional Firewalls Servo Hatches Spinner Backplates Copyright 2007 Thomas A. Jacoby and WarbirdKits.com...
