OPERATOR'S MANUAL
™
Tower
Charcoal Grill
SCC0140/SCC0140SB
FOR OUTDOOR USE ONLY
DANGER:
You WILL be KILLED or SERIOUSLY HURT if you do not
follow the instructions in this operator's manual.
NOTE TO INSTALLER/ASSEMBLER: Give this Operator's Manual to the consumer so the consumer may retain it for future
reference.
SAVE THIS MANUAL FOR FUTURE REFERENCE
Visit the ST K website at: www.stokgrills.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Tower SCC0140 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for STOK Tower SCC0140

Summary of Contents for STOK Tower SCC0140

  • Page 1 OPERATOR’S MANUAL ™ Tower Charcoal Grill SCC0140/SCC0140SB FOR OUTDOOR USE ONLY Visit the ST K website at: www.stokgrills.com DANGER: You WILL be KILLED or SERIOUSLY HURT if you do not follow the instructions in this operator’s manual. NOTE TO INSTALLER/ASSEMBLER: Give this Operator’s Manual to the consumer so the consumer may retain it for future reference.
  • Page 2 TABLE OF CONTENTS „ Introduction ..................................2 „ General Safety Rules ................................ 3 „ Specific Safety Rules ................................ 4 „ Symbols .................................... 5 „ Features ..................................6-7 „ Tools Needed ................................... 7 „ Loose Parts ..................................8 „ Assembly ..................................9-12 „ Operation ...................................13-16 „...

  • Page 3: General Safety Rules

    GENERAL SAFETY RULES „ Position grills well away from house siding, deck railings WARNING: and out from under eaves. Grills should be at least 10 feet away from these combustible structures. Read and understand all instructions. Failure to follow „ The grill shall not be used under overhead combustible all instructions listed below, may result in electric shock, construction.

  • Page 4: Specific Safety Rules

    SPECIFIC SAFETY RULES „ Do not add charcoal starter fluid or charcoal impregnated „ Dispose of hot coals properly. Douse them with plenty of with charcoal lighter fluid to hot or warm charcoal. water and stir to ensure that the fire is out. Never place coals in plastic, paper or wooden containers.

  • Page 5: Symbols

    SYMBOLS The following signal words and meanings are intended to explain the levels of risk associated with this product. SYMBOL SIGNAL MEANING Indicates an imminently hazardous situation, which, if not avoided, will result DANGER: in death or serious injury. Indicates a potentially hazardous situation, which, if not avoided, could result WARNING: in death or serious injury.

  • Page 6: Features

    FEATURES PRODUCT SPECIFICATIONS Primary grilling surface ............................363 sq. in. Grilling surface height ..............................34.6 in. Fuel source ............................Charcoal (not included) GRATE HOOD HANGER INSERT VENT HOOD TEMPERATURE GAUGE VENT CANISTER FRONT VIEW INSERT REMOVAL TOOL PIZZA STONE REAR VIEW Fig.

  • Page 7: Features

    FEATURES KNOW YOUR GRILL INSERT REMOVAL TOOL - Allows you to easily place and See Figure 2. remove the cast-iron center insert and charcoal basket from the grill. The safe use of this grill requires an understanding of the PIZZA STONE - Make brick oven-quality pizza using the grill information on the grill and in this operator’s manual.

  • Page 8: Loose Parts

    LOOSE PARTS Fig. 4 Description Qty. Description Qty. A - Firebox ............... 1 HARDWARE BLISTER PACK B - Support ..............3 AA - Nyloc nut (M6) ............2 C - Insert removal tool ............. 1 BB - Spacer ..............2 D - Pizza stone ..............

  • Page 9: Assembly

    ASSEMBLY UNPACKING This product requires assembly. SUPPORT(S) „ Carefully lift grill and components from the carton and place the grill on a level work surface. WARNING: Do not use this product if any parts on the Loose Parts List are already assembled to your product when you unpack WASHER it.
  • Page 10 ASSEMBLY „ Place the side panel labeled “L” around the rear support. STEP 2: ASSEMBLING PANELS TO THE The screw holes in the left side panel should align with SUPPORTS the screw holes on the outside of the support. See Figures 6 - 7. „...
  • Page 11 ASSEMBLY „ Insert two (2) bolts (LL) through the two rounded tabs and STEP 3: ASSEMBLING THE LEGS AND BASE one (1) bolt (LL) through the front support and base. TO THE STAND „ Slide a washer (II), lock washer (JJ), and nut (KK) over See Figures 8 - 9.

  • Page 12: Assembly

    ASSEMBLY STEP 4: ASSEMBLING THE WHEELS TO THE LEGS See Figure 10. WASHER Remove the following hardware from the blister pack: WHEEL AXLE EE - 2 Cotter Pins FF - 2 Flat washers -10 mm GG - 2 Axles „ Insert an axle (GG) through each wheel. Slide a washer (FF) over each axle.
  • Page 13 ASSEMBLY STEP 7: INSTALLING THE GRATES STEP 8: INSTALLING THE ASH CANISTER See Figure 13. See Figure 14. „ Place the charcoal grate into the firebox. „ Set the paper basket into the ash canister. „ Place the main grate into the firebox. „...

  • Page 14: Operation

    OPERATION „ Before you start grilling, organize the food by cooking WARNING: technique, required cooking time, and grilling area required. Do not allow familiarity with grill to make you care- „ Sauces containing sugars and fats can cause flare-ups less. Remember that a careless fraction of a second is and burn your food.
  • Page 15 OPERATION WARNING: The charcoal basket and grate insert will remain hot for some time after they are removed from the grate. Set a hot charcoal basket or grate insert on a non-flammable surface. Do not place it on plastic or wood. Make sure not to put the hot accessories where people or pets will come in contact with it.

  • Page 16: Operation

    OPERATION LIGHTING THE CHARCOAL See Figures 17 - 19. GRATE INSERT Your grill has a convenient charcoal starting system. Using this system helps the briquettes heat faster and more evenly than if they were spread out across the grate. BEFORE FIRST USE The first time you use your newly purchased grill, it is recommended that you remove the hood and light some charcoal, following the instructions below.
  • Page 17 OPERATION WARNING: Never use an accessory if the porcelain coating is damaged or chipped. Use with a damaged coating could result in serious personal injury if ingested. PIZZA STONE USING THE GRILL AND ACCESSORIES GRATE See Figure 20. INSERT INSERT TOOL There are two basic methods of cooking with charcoal.

  • Page 18: Maintenance

    MAINTENANCE WARNING: When servicing, use only identical replacement parts. Use of any other parts may create a hazard or cause product damage. GENERAL MAINTENANCE Do not mistake brown and black build up of grease and smoke for paint. The inside of the hood is not painted and should never be painted.

  • Page 19: Warranty

    WARRANTY ST / ™ CHARCOAL GRILL LIMITED WARRANTY ™ Thank you for purchasing a ST K brand grill. Below is our limited charcoal grill product warranty. Before submitting a warranty claim, we suggest you read the Operator’s Manual that came with your grill. You may discover an easy and simple solution to your problem.
  • Page 20 OPERATOR’S MANUAL ™ Tower Charcoal Grill SCC0140/SCC0140SB Customer Service Information: For parts or service, please call 1-800-847-5993 or visit us online at www.stokgrills.com. The model number and serial number of this grill is found on a label located on the leg stand. Please record the serial number in the space provided below.
