Page 2: Product Specification
PRODUCT SPECIFICATION Component Specifications Motor 120 V Ac 60 Hz 12 Amp No-load Speed Cutting Path 20 in. (508 mm) Height Adjustment 1-3/4–3-3/4 in. (45 mm-95 mm) Wheels Size 7 in. (Front)/ 8 in. (Rear) Unit Weight 26 Kg SYMBOL SYMBOL NAME SYMBOL... -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS WARNING: Read all instructions when using electric gardening appliances. Basic safety precautions should always be followed to reduce the risk of fire,electric shock, and personal injury. FOR ALL LAWN MOWERS a) Avoid Dangerous Environment Don’t use appliances in damp or wet locations. b) Don’t Use In Rain. -
Page 4: Slope Operation
SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS FOR WALK-BEHIND MOWERS I. GENERAL OPERATION 1. Read, understand, and follow all instructions on the machine and in the manual (s) before starting. 2. Do not put hands or feet near or under the machine. Keep clear of the discharge opening at all times. 3. - Page 5 SAFETY INSTRUCTIONS III. CHILDREN Tragic accidents can occur if the operator is not alert to the presence of children. Children are often attracted to the machine and the mowing activity. Never assume that children will remain where you last saw them. 1.
- Page 6 SAFETY INSTRUCTIONS • Always wear safety glasses with side shields. Every day glasses have only impact resistant lenses. They are NOT safety glasses. Following this rule will reduce the risk of eye injury. Use face mask if operation is dusty. •...
-
Page 7: Guidelines For Using Extension Cords
SAFETY INSTRUCTIONS Double insulated lawn mower This mower is "DOUBLE INSULATED" 1. Replacement Parts: When servicing use only identical replacement parts. 2. Polarized Appliance Connections: To reduce the risk of electric shock, this appliance has a polarized plug (one blade is wider than the other) and will require the use of a polarized extension cord. The appliance plug will fit into a polarized extension cord only one way. -
Page 8: Know Your Product
KNOW YOUR PRODUCT Read this owner's manual and safety rules carefully before operating the mower. Compare the illustration below to the mower in order to become familiar yourself with the location of the various controls and adjustments. Save this manual for future reference. Power button Handle grip Upper handle... -
Page 9: Assembling Your Lawn Mower
ASSEMBLING YOUR LAWN MOWER Parts List Note: ASSEMBLING THE HANDLE... - Page 10 ASSEMBLING YOUR LAWN MOWER INSTALLING THE GRASS CATCHER BAG (see Fig.4) 1. UNPLUG THE POWER CORD, AND WAIT FOR BLADE TO COME TO A COMPLETE STOP. 2. Lift the chute cover (1). 3. While holding up the cover (1), place the grass catcher bag hanger hooks (2) into the opening on the chute cover (1) to allow the hanger hooks to attach to the rod (3) which secures the chute cover.
- Page 11 ASSEMBLING YOUR LAWN MOWER INSTALL THE SIDE DISCHARGE CHUTE (see Fig.5) This mower has 3different functions -mulch, sidedischarge, andrearbag. If youwish todischarge the clippings rather thanmulch, perform these steps. 1. UNPLUG THE POWER CORD, AND WAIT FOR BLADE TO COME TO A COMPLETE STOP. 2.
- Page 12 ASSEMBLING YOUR LAWN MOWER INSTALLATION OR REMOVAL OF THE MULCH PLUG (see Fig.6) 1. UNPLUG THE POWER CORD, AND WAIT FOR BLADE TO COME TO A COMPLETE STOP. 2. To remove the mulch plug lift the chute cover (1) and pull out on the handle. 3.
- Page 13 ASSEMBLING YOUR LAWN MOWER ADJUST THE UPPER HANDLE HEIGHT (see Fig.7) 1. Loosen the upper handle knob. 2. Adjust the handle to the most comfortable of the 3 positions. 3. Tighten the upper handle knob as tight as you can. Fig.7...
-
Page 15: Operating Your Mower
OPERATING YOUR MOWER ADJUST THE CUTTING HEIGHT ( see Fig.10) 1. Simply depress the lever (1) towards the wheel and move to desired position. This sets all wheels to the same position. 2. To raise the height, pull the height adjustment lever from the current stop position towards the back of the mower. -
Page 16: Mowing Tips
OPERATING YOUR MOWER WARNING: Do not mow a slope that has an angle of greater than 15° (a rise of approximately2-1/2 ft. [ 75 m]every 10 ft. [3m]).Mow a cross the face of a slope, and never up and down. MOWING TIPS NOTE: A sharp blade will greatly enhance the performance of the mower, especially when cutting high grass. - Page 17 OPERATING YOUR MOWER Fig.11 Fig.12 Loosen Tighten NOTE: Be sure to replace the parts in the exact order in which they were removed. When installing the cutting blade, verify that it is installed with the curved ends pointing toward the mower deck. CLEAN THE MOWER WARNING: To reduce the risk of electric shock, do not expose the mower to water.
- Page 18 SERVICE 1. When servicing the mower, use only replacement parts that are available from the manufacturer. In order to obtain replacement parts, call the toll-free helpline. The use of parts that do not meet the original equipment specifications may lead to improper performance, and may compromise safety. 2.
- Page 19 PARTS...
-
Page 20: Parts List
PARTS LIST APA Part No. Part No. Description 8220502 Hexagon Lock Nut M8 PM207AC-01-QQ-1 8240112 Wash PM207AC-02-QQ-2 8412501 Hang Hook PM207AC-03-QQ-3 8220401 Cap Screw M5 14 PM207AC-04-QQ-4 Height Adjustment Shaft PM207AC-05-QQ-5 8321301 8419001 Height Adjustment Handle PM207AC-06-QQ-6 8221101 Cap Screw M4 PM207AC-07-QQ-7 Rear Shield 8430201... - Page 21 PARTS LIST APA Part No. Part No. Description 8323001 Fan Sleeve PM207AC-43-QQ-43 8230201 Hexagon Lock Nut M6 PM207AC-44-QQ-44 8410701 7-inch Wheel Components PM207AC-45-QQ-45 8321002 Front Axle Sleeve PM207AC-46-QQ-46 8410401 PM207AC-47-QQ-47 Front Wheel Upper Board 8410301 Front Wheel Lower Board PM207AC-48-QQ-48 8410201 Front Cover PM207AC-49-QQ-49...
- Page 22 Steele® warrants to the original purchaser who uses the product in a consumer application (personal, residential or household usage) that all products covered under this warranty are free from defects in material and workmanship for two years from the date of purchase. All products covered by this limited warranty which are used in commercial applications (i.e.
- Page 23 Merchandise sold by Steele® which has been manufactured by and identified as the product of another company, such as gasoline engines. The product manufacturer’s warranty, if any, will apply. ANY INCIDENTAL, INDIRECT OR CONSEQUENTIAL LOSS, DAMAGE, OR EXPENSE THAT MAY RESULT FROM ANY DEFECTS, FAILURE OR MALFUNCTION OF THE PRODUCT IS NOT COVERED BY THIS WARRANTY.
