Page 1: User Manual
4-Port HDMI Switch SW-H00401-0B User Manual ◄ V1.0 ► www.green-box.com.tw... - Page 2 • © 2008 by Green-Box Green-Box Technology Co. Ltd. reserves the right to make changes in the hardware, packaging, and any accompanying documentation without prior written notice. No part of this document may be reproduced or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without prior written permission of Green-Box Technology Co.
-
Page 3: Product Introduction
4-Port HDMI Switch 1. Product introduction The Databay SW-H00401 High-Definition Multimedia Interface (HDMI) Switch is a compact audio/video connector interface for transmitting uncompressed digital streams. This 4 to 1 HDMI Switch swaps HDMI signal between four different sources to one display device with an ease of pressing remote control button. This device is especially designed for advanced home theatres, conference rooms and retail stores, allowing connections from DVD player, advanced game consoles, satellite receivers, digital boxes, Blue-ray player, PCs…... -
Page 4: Product Features
4-Port HDMI Switch 2. Product Features Conform to HDMI 1.3 specifications Fully HDCP 1.1 compliant Already got HDMI Authorized Testing Centers (ATC) certificate Compatible to all HDMI equipped devices, HDCP-enable HDTV devices Four HDMI sources using one High Definition Display (eg. HDTV) Using push button or remote control to switch display device port between HDMI sources The cable length from input device to this switch box plus this switch... -
Page 5: Panel Description
4-Port HDMI Switch 4. Panel Description Power LED Channel LED Select Function IR LED (Remote Control) Power Supply (DC 5V 1A) Output Channel Source Input 5 / 8... -
Page 6: Hardware Installation
4-Port HDMI Switch 5. Hardware Installation The following guide is intended to assist users to solve install SW-H00401 HDMI Switch. Step 1 : Before installation, please make sure all of devices have been turned off. Step 2 : Connect HDMI four different sources to HDMI Switch input port, using HDMI cable Step 3 : Using one HDMI cables to display devices from the output port of the Switch... -
Page 7: Specifications
4-Port HDMI Switch 6. Specifications Model Name 4-Port HDMI Switch Model No. SW-H00401-0B HDMI source input port HDMI display device output Port HDMI source port HDMI 19-pin Type A connector (Female) Display Device Port HDMI 19-pin Type A Connector (Female) - Page 8 4-Port HDMI Switch 7. Remarks Please read this operation manual carefully before installing the system. II. Please use high quality HDMI cable for optimum results. III. To prevent potential power damage do not use 2-wire extension cords. Ensure DC outlets at PCs and displays are on the same phase and have correct and common grounding.
