Page 1: User Manual
2x1 VGA Audio Switch SW-VA0201 User Manual ◄ V1.0 ► www.green-box.com.tw www.data-av.com... -
Page 2: Package Content
2x1 VGA Audio Switch 1. Package Content SW-VA0201 VGA Audio Switch: 2x1 VGA Audio Switch x 1 Control Button Cable x 1 Rack Mounting Kit x 1 User Manual x 1 Optional Accessories (Sold Separately) DC 5V Power Adapter VGA Cable Audio Cable 2. -
Page 3: Product Descriptions
2x1 VGA Audio Switch 4. Product Descriptions Front and Rear Panel Audio Input I Video Input I Video Input II Audio Input II CTRL- Control Button Cable Port Video Output Audio Output Power Adaptor Rack Mounting kit with Magnet Control Button Cable Rack Mounting Kit 3 / 8... - Page 4 2x1 VGA Audio Switch 5. Installation STEP 1 Set the power off to all connecting devices (eg. PC, monitor, speaker) STEP 2 Connect VGA (HDDB-1S) cable from your video source (eg. PC) to 2x1 VGA Audio Switch "Video Input Port" STEP 3 Repeat STEP 2 for your second video source STEP 4...
- Page 5 2x1 VGA Audio Switch STEP 6 Connect VGA (HDDB-15) cable from VGA monitor to 2x1 VGA Audio Switch "Video Output Port" STEP 7 Connect audio cable from speaker or earphone to 2x1 VGA Audio Switch "Audio Output Port" STEP 8 Connect Control Cable (included) to "Control Port"...
-
Page 6: Specifications
2x1 VGA Audio Switch 6. Specifications Model No. 2x1 VGA Audio Switch Model Name SW-VA0201 Input VGA Female x 2 / Audio Female x 2 Output VGA Female x 1 / Audio Female x 1 Resolution 1920x1200* Audio Stereo Automatic detection switch... - Page 7 2x1 VGA Audio Switch 7. Remarks Please read this operation manual carefully before installing the system. II. Please use correct power adapter and use high quality cable for optimum broadcasting. III. To prevent potential power damage do not use 2-wire extension cords. Ensure DC outlets at PCs and displays are on the same phase and have correct and common grounding.
- Page 8 RoHS. © 2009 by Green-Box Green-Box Technology Co. Ltd. reserves the right to make changes in the hardware, packaging, and any accompanying documentation without prior written notice. No part of this document may be reproduced or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without prior written permission of Green-Box Technology Co.
