Page 1: User Manual
8/16-Port PS/2 KVM Switch KV-P00801 KV-P01601 User Manual ◄ V1.0 ► www.green-box.com.tw... - Page 2 8/16-Port PS/2 KVM Switch Certifications This equipment has been tested and found to comply with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference (2) This device must accept any interference received, including interference that may cause undesired operation.
-
Page 3: Table Of Contents
8/16-Port PS/2 KVM Switch Contents 1. Product introduction ............4 2. Product Feature ..............5 3. Specifications..............6 4. Hardware Installation ............8 5. Operation & Usage ............11 5.1 Set Password ...............11 5.2 Activate OSD..............11 5.3 OSD Main Screen Headings ..........12 5.4 OSD Status Indication ...........13 5.5 Edit Computer Name .............13 5.6 Set Password ...............14 5.7 Scan Setting ..............16... -
Page 4: Product Introduction
8/16-Port PS/2 KVM Switch 1. Product introduction This PS/2 KVM (Keyboard, Video and Mouse) Switch allows multiple computers (PCs or servers) controlled by one set of keyboard, monitor and mouse. It ensures easy switch by front panel button, Hot-keys or the friendly On Screen Display (OSD) menu with connection up to 128 computers (by chaining 16-port PS/2 KVMs). -
Page 5: Product Feature
8/16-Port PS/2 KVM Switch 2. Product Feature Software free, easy installation, fully plug-and-play design. Compatible with typical PS/2 computers, monitors and keyboards. Supports IntelliMouse, IntelliMouse Explorer, and Logitech Net Mouse… etc. Compatible using DOS, Win3.x, Win95/98/98SE/2000/ME/XP/Vista, WinNT, Netware, HP Unix, Linux…etc. If keyboard or mouse is using USB interface, please implement USB to PS/2 converter. -
Page 6: Specifications
8/16-Port PS/2 KVM Switch 3. Specifications Model No. 8PORT KVM 16PORT KVM Computer port Console Port Firmware Upgrade Port Daisy Chain Port Computer Port Connector HDDB 15-pin (All Female Type) Console Port Connector PS/2 Keyboard mini Din 6-pin (All Female Type) PS/2 Mouse Mini Din 6-pin Monitor VGA HDDB 15-pin Firmware Upgrade Port... - Page 7 8/16-Port PS/2 KVM Switch Firmware Upgrade Port RS-232 Monitor resolution 1920X1440 /60Hz DDC version DDC2 Daisy Chain MAX Level 8 levels maximum Maximum connected computers Housing Metal 19” Metal 19” 1RU (Rack Mount 1RU (Rack Mount Unit) Unit) Power adaptor Dual Power Input) DC 5V/1A *1 DC5V/1A* 1 (Redundancy)
-
Page 8: Hardware Installation
8/16-Port PS/2 KVM Switch 4. Hardware Installation Prior to installation please switch off all computer and peripherals. Following guide is using 8-port PS/2 KVM as example. Please note 16-port PS/2 KVM has similar hardware installation. Step 1 Please open the package carefully and take out all required accessories to prepare fluent installation. - Page 9 8/16-Port PS/2 KVM Switch Step 4 Please connect PS/2 Mini Din 6-pins purple connector on keyboard to console port on PS/2 KVM as illustrated below: Step 5 Please connect PS/2 Mini Din 6-pins green connector on mouse to console port on PS/2 KVM as illustrated below: Step 6 Please use KVM cable to connect computer and PS/2 KVM.
- Page 10 8/16-Port PS/2 KVM Switch Step 8 Daisy Chain (optional) If daisy chaining is needed please use the daisy chain cable included with package. ★ NOTE: Please do not use other type of cable for daisy chaining PS/2 KVMs. 10 / 26...
-
Page 11: Operation & Usage
8/16-Port PS/2 KVM Switch 5. Operation & Usage 5.1 Set Password At factory default the PS/2 KVM will not ask for password unless it is set by user. You may press “Scroll Lock” twice followed by “F2” to bring up password setting menu. -
Page 12: Osd Main Screen Headings
8/16-Port PS/2 KVM Switch 5.3 OSD Main Screen Headings indicates the computer is powered on at selected port indicates the computer attached at this port has password protected. All ports at factory default do not have password assigned, therefore no icon present USER1~8 Port name of corresponding port number. -
Page 13: Osd Status Indication
8/16-Port PS/2 KVM Switch 5.4 OSD Status Indication Use right hand side of OSD commands for adjust settings Function keys: F1, F2, F3, F4, F5, ESC and left arrow key First row on right hand window – “1 1 Bank1” : indicates currently PS/2 KVM active at Bank 1, computer port 1. -
Page 14: Set Password
8/16-Port PS/2 KVM Switch 5.6 Set Password F2- Password setting (SECURITY) Press F2 at OSD main menu to activate password setting ( SECURITY). Password setting menu for “PORT USER” pops up as illustrated below <fig.3>. In this screen you may use the secondary OSD function keys: F1(SUPERUSER), ESC(QUIT), ENTER(Complete). - Page 15 8/16-Port PS/2 KVM Switch Set Super User Password <fig.5> PC port without Password illustrated below <fig.6>: <fig.6> At factory default, no password is set for PS/2 KVM Switch as illustrated above. Selected PC port is powered on with indication. To setup password please open OSD, select SECURITY. Please refer to <fig.3> and <fig.4>...
-
Page 16: Scan Setting
8/16-Port PS/2 KVM Switch 5.7 Scan Setting F3- SELECT SCAN PORT Press F3 at OSD main menu to select Auto Scan active port. If a port is selected for Auto Scan, a icon appears, press F3 again, the icon will disappear. -
Page 17: Hot-Key Setting
8/16-Port PS/2 KVM Switch 5.8 Hot-Key Setting F5- HOT-KEY At OSD main menu, please press F5 to enter HOT-KEY setting menu <fig.10>. In the HOT KEY setting menu, secondary selection keys are F1, F2, F3, ENTER. Press F1 to select Scroll Lock as Hot-key Press F2 to select Num Lock as Hot-key Press F3 to select Caps Lock as Hot-key Press ENTER to save setting and exit the Hot-key setting menu... -
Page 18: Osd Rate / Scan Rate Setting
8/16-Port PS/2 KVM Switch 5.9 OSD Rate / Scan Rate Setting To set scan rate please press button to enter Scan Rate/OSD Rate setting menu as illustrated below <fig.11>. The secondary menu functions are F1 and ENTER button SCAN RATE SETTING Please note that scan rate is set 10 seconds at factory default. - Page 19 8/16-Port PS/2 KVM Switch OSD time setting menu <fig.12> 19 / 26...
-
Page 20: Upgrade Firmware
8/16-Port PS/2 KVM Switch 6. Upgrade firmware This PS/2 KVM Switch has built-in ability to upgrade firmware. Whenever upgrading is desirable, the device can be easily upgraded without purchasing new hardware to suit the new environment. A CD ROM software package is included with the package. Please execute BSETUP.EXE to obtain the new firmware file. - Page 21 8/16-Port PS/2 KVM Switch <fig.14> <fig.15> 21 / 26...
- Page 22 8/16-Port PS/2 KVM Switch 6.3 Please run FW upgrade program as illustrate below<fig.16> <fig.16> 6.4 Download new upgrade file as illustrate below<fig.17> <fig.17> 22 / 26...
- Page 23 8/16-Port PS/2 KVM Switch 6.5 KVM not found as illustrate below<fig.18> <fig.18> 6.6 If RS-232 Port Fail as illustrate below <fig.19> <fig.19> 23 / 26...
- Page 24 8/16-Port PS/2 KVM Switch 6.7 The models chosen are not accorded with upgrade file as illustrate below <fig.20> <fig.20> 6.8 Firmware upgrade successful as illustrate below <fig.21> <fig.21> 24 / 26...
-
Page 25: Troubleshooting
8/16-Port PS/2 KVM Switch 7. Troubleshooting The following guide is intended to assist users to solve possible issues from operating or installing PS/2 KVM. i. After hardware installation, please affix label to all cable to assist in future maintenance. ii. The maximum KVM cable distance is approximately 100 inches when high quality cable is used. -
Page 26: Notice
8/16-Port PS/2 KVM Switch 9. Notice 1. All other company or product names mentioned herein are trademarks or registered trademarks of their respective companies. 2. Specifications are subject to change without notice. 3. Please read user manual carefully before operating the device 4.
