Makita HP2040 Instruction Manual

20 mm (3/4”)
Hide thumbs

Advertisement

Hammer Drill
20 mm (3/4")
MODEL HP2040
20 mm (3/4")
MODEL HP2041
I N S T R U C T I O N
WARNING:
For your personal safety, READ and UNDERSTAND before using.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
DOUBLE
INSULATION
M A N U A L
002401

Advertisement

loading

  Related Manuals for Makita HP2040

  Summary of Contents for Makita HP2040

  • Page 1 Hammer Drill 20 mm (3/4”) MODEL HP2040 20 mm (3/4”) MODEL HP2041 I N S T R U C T I O N WARNING: For your personal safety, READ and UNDERSTAND before using. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE. DOUBLE...
  • Page 2: Specifications

    (one blade is wider than the other.) This plug will fit in a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If it HP2040/HP2041 High 13 mm (1/2”) 40 mm (1-9/16”) 0 - 950/min.
  • Page 3 still does not fit, contact a qualified elec- trician to install a polarized outlet. Do not change the plug in any way. Double insula- tion eliminates the need for the three wire grounded power cord and grounded power supply system. 5.
  • Page 4: Specific Safety Rules

    Not More Than SPECIFIC SAFETY RULES DO NOT let comfort or familiarity with product (gained from repeated use) replace strict adherence to hammer drill safety rules. If you use this tool unsafely or incorrectly, you can suffer serious personal injury.
  • Page 5 5. Do not leave the tool running. Operate the tool only when hand-held. 6. Do not touch the bit or the workpiece immediately after operation; they may be extremely hot and could burn your skin. SAVE THESE INSTRUCTIONS WARNING: MISUSE or failure to follow the safety rules stated in this instruction manual may cause serious personal injury.
  • Page 6: Functional Description

    FUNCTIONAL DESCRIPTION 002408 1. Switch trigger 2. Lock button 002448 1. Reversing switch lever CAUTION: • Always be sure that the tool is switched off and unplugged before adjusting or checking function on the tool. Switch action CAUTION: • Before plugging in the tool, always check to see that the switch trigger actuates properly and returns to the “OFF”...
  • Page 7: Speed Change

    002418 1. Speed change knob 002425 1. Action mode changing button Speed change Two speed ranges can be preselected with the speed change lever. To change the speed, turn the speed change lever to the position 1 for low speed or the position 2 for high speed. If the speed change lever does not turn easily, turn the chuck slightly in either direction and turn the lever again.
  • Page 8 To remove the bit, hold the ring and turn the sleeve counter- clockwise. For Model HP2040 To install the bit, place it in the chuck as far as it will go. Tighten the chuck by hand. Place the chuck key in each of the three holes and tighten clockwise.
  • Page 9: Depth Gauge

    002443 1. Depth gauge OPERATION Depth gauge The depth gauge is convenient for drilling holes of uniform depth. Loosen the side grip and insert the depth gauge into the hole in the side grip. Adjust the depth gauge to the desired depth and tighten the side grip.
  • Page 10 002449 1. Blow-out bulb Blow-out bulb (optional accessory) After drilling the hole, use the blow-out bulb to clean the dust out of the hole. Drilling operation CAUTION: • Pressing excessively on the tool will not speed up the drilling. In fact, this excessive pressure will only serve to damage the tip of your bit, decrease the tool performance and shorten the service life of the tool.
  • Page 11: Maintenance

    CAUTION: • These accessories or attachments are recommended for use with your Makita tool specified in this manual. The use of any other accessories or attachments might present a risk of injury to persons. Only use accessory or attachment for its stated purpose.
  • Page 12 Memo...
  • Page 13 Makita Canada Inc. 1950 Forbes Street, Whitby, Ontario L1N 7B7 Fold Stamp Timbre...
  • Page 14 Street Address City AGE: Under 19 Occupation: Dealer's Name & Address: Paste Paste Paste 3. How did you first learn of Makita Power Tools? Magazine/Newspaper From dealer Store display 4. Most favored points are? Design Features Size Price Model No.
  • Page 15 When you need service... • Explain the problem in a letter • Enclose the letter with the tool • Package carefully and send prepaid to the nearest Makita factory or authorized service centre (905) 571 - 2200 1-800-263-3734 (604) 272 - 3104 1-800-663-0909...
  • Page 16: Warranty Policy

    WARRANTY. “The Makita Warranty is the only and the entire written warranty given by Makita for the Makita tools. No dealer or his agent or employee is authorized to extend or enlarge upon this warranty by any verbal or written statement or advertisement.”...
